2016 Suzuki Bandit 1250S ABS

Back to the 2016 Suzuki Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2016 Suzuki Bandit 1250S ABS
2016 Suzuki Bandit 1250S ABS

2016 Suzuki Bandit 1250S ABS
2016 Suzuki Bandit 1250S ABS

2016 Suzuki Bandit 1250S ABS
2016 Suzuki Bandit 1250S ABS

2016 Suzuki Bandit 1250S ABS
2016 Suzuki Bandit 1250S ABS



2016 Suzuki Bandit 1250S ABS Review

2016 Suzuki Bandit 1250S ABS on www.Totalmotorcycle.com

Designed to be The Top Performer in its class…

You can’t break the laws of physics, but the 2016 Suzuki Bandit 1250S ABS shows that you sure can bend them. Its Suzuki fuel-injected four-cylinder engine offers thrilling acceleration in every gear, with a rush of high-rpm performance. For crisp, precise handling on twisty roads, it has balanced suspension systems front and rear. It also features a technically advanced Antilock Braking System (ABS)* that monitors wheel speed, and matches stopping power to available traction.

*Depending on road surface conditions, such as wet, loose, or uneven roads, braking distance for an ABS-equipped vehicle may be longer than for a vehicle not equipped with ABS. ABS cannot prevent wheel skidding caused by braking while cornering. Please ride carefully and do not overly rely on ABS.

The Suzuki Bandit has won the respect and admiration of riders around the globe with its unmatched quality, wide power spread, and exceptional balance of performance, technology, and style. The new Bandit 1250S ABS refines its styling with a sculpted half-fairing that wraps around the radiator sides and is vented just below the headlight. In addition to sharpening the Bandit’s looks, the fairing improves aerodynamics providing riders with great wind protection and riding comfort.

Think of the Suzuki GSX1250F as a kinetically charged invitation to enjoy the ride of your life. It has a fuel-injected powerplant with loads of torque and a wide powerband, which gives it awesome acceleration in every gear matched by heart-pounding top-end performance. It features advanced suspension front and rear, giving you the advantage when the road turns twisty.

With its fully faired design, the GSX1250F rewards you with a smooth and comfortable highway ride mile after mile after mile. It also has Suzuki’s Digital Antilock Brake System (ABS) for optimum braking performance. The GSX1250F – with exciting performance and truly versatile capabilities, it’s an all-around sportbike at an exceptional value.

*The ABS is a supplemental device for brake operation, not a device for shortening stopping distance. Always remember to reduce speed sufficiently before approaching curves.





2016 Suzuki Bandit 1250S ABS www.Totalmotorcycle.com Key Features

Extra smooth Acceleration, Broad Power:
Powering the Bandit is a 1255cc liquid-cooled, fuel-injected, DOHC engine delivering extra smooth acceleration and a wide spread of power for relaxed motorway cruising. With a full 1255cc of torque producing displacement, the power plant is tailored to wide ranging sporty enjoyment, generating peak torque from relatively low in the rev range.

Suspension:
The Bandit 1250S ABS has a single rear shock that works with a progressive, rising rate link system designed to respond smoothly to road irregularities. Rear shock rebound damping and spring preload are adjustable.

Wind protection:
Wrapping around the radiator sides and vented just below the headlight, the sculpted half-fairing design is the result of repeated wind tunnel testing. This design achieves better aerodynamics and wind protection giving both the rider and passenger great riding comfort.

Anti-lock brake system (ABS):
The Bandit 1250S ABS is equipped with digital ABS and monitors wheel speed, matching stopping power to available traction. It comes with fully floating 310mm-diameter dual front brake discs with 4 piston calipers and a 240mm diameter rear disc brake with a single piston caliper.

Instrument panel:
The analogue tachometer on the left incorporates FI and ABS indicators. The LCD panel on the right displays a digital speedometer and odometer, dual trip meters, clock, and a fuel gauge.

Standard equipment:
The height of the comfortably contoured seat can be adjusted up or down by 20mm. The grab bar is fitted as standard and incorporates hooks on either side of its base that are convenient on long tours. Also standard is the convenient centre stand.








2016 Suzuki Bandit 1250S ABS www.Totalmotorcycle.com Features and Benefits

ENGINE FEATURES
Powering the Bandit S is a 1,255cc liquid-cooled, fuel-injected, DOHC, four-cylinder engine delivering a wide spread of power for relaxed cruising or sport riding.

Engineered for smooth operation, the engine has an effective secondary balancer shaft.

Power is transmitted through a 6-speed transmission using gear ratios chosen for impressive accelerations as well as smooth highway use. Clutch operation is low effort and smooth, with low maintenance, thanks to a hydraulic clutch actuation system.

The state-of-the-art Suzuki Dual Throttle Valve (SDTV) digital closed-loop EFI system also delivers improved mileage and reduced emissions.

The 4-into-2-into-1 exhaust system is built of steel and stainless steel and is equipped with a catalyzer and HO2 sensor. The large silencer controls sounds while permitting excellent flow to maximize torque and overall engine power.

To shed heat from the high torque, large displacement engine, a high capacity radiator is employed. Cooling air is directed to the radiator via the front fender and directed away by the outer fairing shroud.

Additional engine cooling comes from a liquid-cooled oil cooler, similar to the type used on the GSX-R750.



CHASSIS FEATURES
The refined half-fairing wraps around the radiator sides and is vented just below the headlight. In addition to sharpening the Bandit’s looks, the fairing improves aerodynamics providing riders with great wind protection and riding comfort.

Hollow, three-spoke cast wheels feature 1270/70ZR17 and 180/55ZR17 radial tires.

The strong, double-cradle steel frame supports a stout set of SHOWA 43mm forks with adjustable spring preload.

The single rear shock that works with a progressive, rising rate link system designed to respond smoothly to road irregularities. Rear shock rebound damping and spring preload are adjustable.

Stopping power is provide by fully floating 310mm-diameter dual front brake discs with 4 piston calipers and a 240mm diameter rear disc brake with a single piston caliper.

The standard digital ABS monitors wheel speed, matching stopping power to available traction*.

* Depending on road surface conditions, such as wet, loose, or uneven roads, braking distance for an ABS-equipped vehicle may be longer than for a vehicle not equipped with ABS. ABS cannot prevent wheel skidding caused by braking while cornering. Please ride carefully and do not overly rely on ABS.

The analog tachometer on the left side of the instrument panel incorporates FI and ABS indicators.

The LCD panel on the right side displays a digital speedometer and odometer, dual trip meters, clock, and a fuel gauge.

The height of the comfortably contoured seat can be adjusted up or down by 20mm (0.78 in.).

The passenger grab bar incorporates cargo cord posts.



ADDITIONAL FEATURES
A convenient center stand is standard.

A variety of Genuine Suzuki Accessories for Bandit owners are available including a large selection of Suzuki logo apparel.

12-month limited warranty










2016 Suzuki Bandit 1250S ABS – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9899 USD

ENGINE
Engine Inline, transverse mount 4-cylinder, 4-stroke, DOHC
Bore Stroke 79.0 mm (3.110 in) x 64.0 mm (2.520 in)
Cooling medium Liquid cooled main radiator, water-cooled oil cooler
Starter Electric
Compression Ratio 10.5 : 1
Fuel System Fuel injection
Ignition Electronic ignition (Transistorized)
Lubrication Wet sump
CHASSIS
Brakes Front 310 mm floating dual discs
Brakes Rear 240mm single disc
Color Candy Daring Red, Glass Sparkle Black
Curb Weight 254 kg (560 lbs)
Final Drive RK GB50GSVZ3, 118 links
Fuel Tank Capacity 19 L (5.0 US gal) includes reserve
Ground Clearance 135 mm ( 5.3 in)
Overall Length 2130 mm (83.9in)
Overall Width 790 mm (31.1 in)
Seat Height 805mm (31.7 in. ) LOW setting, 825 mm (32.5 in.) HIGH setting
Suspension Front Telescopic, coil spring, oil damped (SHOWA)
Suspension Rear Single shock, coil over oil damper, link-style (SHOWA)
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 180/55ZR17M/C (73W), tubeless
Transmission 6-speed Close ratio, constant mesh, return shift type
Wheelbase 1485 mm (58.5 in)
WARRANTY
Warranty 12 month unlimited mileage limited warranty.









2016 Suzuki Bandit 1250S ABS – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $11399 CDN

ENGINE
Engine Inline, transverse mount 4-cylinder, 4-stroke, DOHC
Bore Stroke 79.0 mm (3.110 in) x 64.0 mm (2.520 in)
Cooling medium Liquid cooled main radiator, water-cooled oil cooler
Starter Electric
Compression Ratio 10.5 : 1
Fuel System Fuel injection
Ignition Electronic ignition (Transistorized)
Lubrication Wet sump
CHASSIS
Brakes Front 310 mm floating dual discs
Brakes Rear 240mm single disc
Color Candy Daring Red, Glass Sparkle Black
Curb Weight 254 kg (560 lbs)
Final Drive RK GB50GSVZ3, 118 links
Fuel Tank Capacity 19 L (5.0 US gal) includes reserve
Ground Clearance 135 mm ( 5.3 in)
Overall Length 2130 mm (83.9in)
Overall Width 790 mm (31.1 in)
Seat Height 805mm (31.7 in. ) LOW setting, 825 mm (32.5 in.) HIGH setting
Suspension Front Telescopic, coil spring, oil damped (SHOWA)
Suspension Rear Single shock, coil over oil damper, link-style (SHOWA)
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 180/55ZR17M/C (73W), tubeless
Transmission 6-speed Close ratio, constant mesh, return shift type
Wheelbase 1485 mm (58.5 in)
WARRANTY
Warranty 12 month unlimited mileage limited warranty.






2016 Suzuki Bandit 1250S ABS – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £7299 GBP (On The Road inc 20% Vat)

Dimensions and Weights


Overall length: 2130mm (83.9in)
Overall width: 790mm (31.1in)
Overall height: 1235mm (48.6in)
Wheelbase: 1485mm (58.5in)
Seat height: 805mm (31.7in)
Kerb Mass: 254.0kg (560lbs)
Fuel capacity: 19.0litres (4.2 UK gallons)
Ground clearance: 135mm (5.3in)

Engine Specifications


Engine capacity: 1255cc
Engine: 4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore: 79.0mm x 64.0mm
Compression ratio: 10.5 : 1
Lubrication: Wet sump
Ignition: Electronic ignition (transistorised)
Fuel system: Fuel Injection
Starter: Electric
Transmission: 6-speed constant mesh
Drive: Chain
Power: 72.00kW @ 7500rpm (97.00hp)†
Torque: 108.00N.m @ 3700rpm (80.00lb.ft)†



Chassis Specification

ront suspension: Telescopic, coil spring, oil damped
Rear suspension: Link type, coil spring, oil damped
Front brakes: Disc, twin
Rear brakes: Disc
Front tyres: 120/70ZR17M/C (58W), tubeless
Rear tyres: 180/55ZR17M/C (73W), tubeless





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
