2020 Harley-Davidson Street 500 Guide

2020 Harley-Davidson Street 500

2020 Harley-Davidson Street 500 2020 Harley-Davidson Street 500 2020 Harley-Davidson Street 500 2020 Harley-Davidson Street 500 2020 Harley-Davidson Street 500

BUILT TO SHRED THE CITY STREETS.

2020 Harley-Davidson Street 500:

Take on the urban grid with 500cc of easy-handling, authentic Harley-Davidson® Dark Custom style.





2020 Harley-Davidson Street 500 Totalmotorcycle.com Key Features

Built specifically to shred city streets, the Harley-Davidson Street® motorcycles are sleek and nimble with an authentic urban attitude.

Family Features:

  • Liquid-cooled Revolution X™ powertrain
  • Low seat height and broad handlebar sweep for confidence and manoeuvrability
  • Café-style speed screen, black front fork gaiters, all-black exhaust system and aggressive slash on the tail section
  • Smart Security System
  • Optional two-tone paint schemes







2020 Harley-Davidson Street 500 Totalmotorcycle.com Features

500cc Liquid-Cooled Revolution X™ Engine

The blacked-out, liquid-cooled V-Twin engine is built to conquer the hot and heavy traffic of urban streets. You can count on smooth response to the progressive throttle when you want to get through any hole that opens up in front of you.



Optional Anti-Lock Brakes (ABS)

The sophisticated, factory-installed ABS gives you confidence in the saddle knowing your bike’s going to behave when you need it.

Light Lift Off Force on a 2019 Street 500 motorcycle

Light Lift Off Force

Lifting it up off the side stand is easy, thanks to its low weight and low center of gravity. It makes pulling out from the curb feel as effortless as putting your thumb to the starter button.



Low Seat Height

The seat height is just 28-inches. And the frame and seat are narrow, which makes for an even easier reach. The advantages of a low seat also shine when the light turns green. It gives you a low center of gravity for confidence when you’re negotiating traffic, just rolling slow through a parking lot looking for a spot.



Specially Tuned Shocks

Specifically tuned and dialed in for the weight of the bike, the geometry of the frame, and the position of the rider. You’ll experience a smooth ride and excellent handling when you encounter rough urban pavement.



Dark, Aggressive, Custom Look

Sports an all-black two-into-one exhaust, black cast aluminum wheels, blacked-out front end with a café inspired speed screen, and a chrome medallion made of steel on the fuel tank.







2020 Harley-Davidson Street 500 – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price: from $6899
USD
Canada MSRP Price: $6999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

PRICING

  • Vivid Black $6,899
  • Color $7,194
  • Two-Tone $7,349
  • ABS Option $750
  • Security System Option $395
  • California Emissions $50
  • Freight $330

Engine

  • Engine1 Liquid-cooled, Revolution X™ V-Twin
  • Bore 2.72 in.
  • Stroke 2.6 in.
  • Displacement 494 cc (30 cu in)
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Black two into one

Dimensions

  • Length 87.2 in.
  • Seat Height, Laden7 25.7 in.
  • Ground Clearance 5.7 in.
  • Rake (steering head) (deg) 32
  • Trail 4.5 in.
  • Wheelbase 59.8 in.
  • Tires, Front Specification 100/80-17
  • Tires, Rear Specification 140/75 R15
  • Fuel Capacity 3.5 gal.
  • Oil Capacity (w/filter) 3.3 qt.
  • Weight, As Shipped 492 lb.
  • Weight, In Running Order 514 lb.

Performance

  • Engine Torque Testing Method EC 134/2014
  • Engine Torque2 29.5 ft-lb
  • Engine Torque (rpm) 3,750
  • Lean Angle, Right (deg.) 28.5
  • Lean Angle, Left (deg.) 28.5
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy5 64 mpg

Drivetrain

  • Primary Drive Gear, 36/68 ratio
  • Gear Ratios (overall) 1st 14.272
  • Gear Ratios (overall) 2nd 10.074
  • Gear Ratios (overall) 3rd 7.446
  • Gear Ratios (overall) 4th 6.006
  • Gear Ratios (overall) 5th 5.037
  • Gear Ratios (overall) 6th 4.533

Chassis

  • Wheels, Front Type9 Black, 7-spoke Cast Aluminum
  • Wheels, Rear Type Black, 7-spoke Cast Aluminum
  • Brakes, Caliper Type 2-piston floated front and rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
  • Gauges 3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap





2020 Harley-Davidson Street 500 – Totalmotorcycle.com  Canadian Specifications/Technical Details

PRICING

  • Vivid Black $ 6,999
  • Colour $ 7,349
  • Two-Tone $ 7,519
  • ABS Option $ 560
  • Security System Option $ 355

Engine

  • Engine1 Liquid-cooled, Revolution X™ V-Twin
  • Bore 69 mm
  • Stroke 66 mm
  • Displacement 494 cc
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Black two into one

Dimensions

  • Length 2,215 mm
  • Seat Height, Unladen 720 mm
  • Ground Clearance 145 mm
  • Rake (steering head) (deg) 32
  • Trail 115 mm
  • Wheelbase 1,520 mm
  • Tires, Front Specification 100/80-17
  • Tires, Rear Specification 140/75 R15
  • Fuel Capacity 13.1 l
  • Oil Capacity (w/filter) 3.1 l
  • Weight, As Shipped 223 kg
  • Weight, In Running Order 233 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 40 Nm
  • Engine Torque (rpm) 3,750
  • Lean Angle, Right (deg.) 28.5
  • Lean Angle, Left (deg.) 28.5
  • Fuel Economy: Estimated City/Hwy5 3.6 l/100 km

Drivetrain

  • Primary Drive Gear, 36/68 ratio
  • Gear Ratios (overall) 1st 14.272
  • Gear Ratios (overall) 2nd 10.074
  • Gear Ratios (overall) 3rd 7.446
  • Gear Ratios (overall) 4th 6.006
  • Gear Ratios (overall) 5th 5.037
  • Gear Ratios (overall) 6th 4.533

Chassis

  • Wheels, Front Type9 Black, 7-spoke Cast Aluminum
  • Wheels, Rear Type Black, 7-spoke Cast Aluminum
  • Brakes, Caliper Type 2-piston floated front and rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning
  • Gauges 3.5 inch electronic speedometer with high beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, blade key ignition and fork lock, and locking gas cap







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
