2022 Yamaha TT-R50E Guide

2022 Yamaha TT-R50E

2022 Yamaha TT-R50E 2022 Yamaha TT-R50E 2022 Yamaha TT-R50E 2022 Yamaha TT-R50E


Introducing the new 2022 Yamaha TT-R50E…

The push‑button electric start, three‑speed automatic transmission and adjustable speed restrictor make this the ideal bike to teach the thrill of riding.

Our littlest TT-R boasts big YZ styling, four-stroke power, a three-speed automatic-clutch gearbox and it even comes with push-button electric starting. So go ahead… play in the dirt!


2022 Yamaha TT-R50E Totalmotorcycle.com Key Features
  • Convenient Electric Start
    Convenient push-button electric start feature for effortless engine startup.
  • Accessible Performance
    Great for learning and playing, the TT-R50E features a fun, 49cc four-stroke engine feeding power through a three-speed automatic-clutch transmission.
  • Ultra-Low Seat Height
    With a seat that’s only 21.9 inches from the dirt, this bike brings big YZ styling to those with smaller statures.
  • Advanced Suspension
    Inverted fork and Monocross® rear end provide great handling.
  • Robust Final Drive
    Large chain cover for maximum protection and minimal maintenance.





2022 Yamaha TT-R50E Totalmotorcycle.com Features and Benefits


  • Useable, Entry-Level Engine
    49cc air-cooled SOHC powerplant puts out smooth, reliable four-stroke power that is perfect for kids and smaller beginners.
  • Automatic Clutch
    Three-speed gearbox with automatic centrifugal clutch makes learning to shift gears a breeze.
  • Convenient Electric Start
    Convenient push-button electric start feature for effortless engine startup.
  • Compact Engine
    Compact design keeps overall engine width down for a narrow feel and great handling.
  • Responsive Power
    Crisp, dependable throttle response from the 11mm Mikuni® VM-type carburetor with automatic on/off electric heater.
  • Low Maintenance Engine
    Automatic cam chain tensioner reduces maintenance.
  • Digital Ignition
    CDI ignition system delivers hot, reliable spark and requires minimal maintenance.
  • Forest-Friendly Exhaust
    Lightweight, upswept exhaust system is quiet and contains a USFS-approved spark arrestor.



  • Simple and Strong Frame
    The curved steel backbone frame keeps the TT-R50E narrow and has three engine-mounting points for excellent rigidity and handling.
  • Compact Inverted Fork
    Inverted fork with 22mm sliders provides 3.8 inches of front wheel travel for great handling and a smooth ride.
  • Lightweight Single Shock
    Monocross® rear suspension is controlled by a single coil-over shock and provides 2.8 inches of bump-smothering rear wheel travel.
  • Enclosed Drum Brakes
    Front and rear 80mm drum brakes deliver strong, dependable stopping power, and the rear is activated by a right foot pedal just like the big YZs.
  • Durable Knobby Tires
    Durable knobby tires mounted on 10-inch front and rear wheels offer great grip and exceptional wear.
  • Ultra-Low Seat Height
    Low 21.9-inch seat height allows easy feet-down control for enhanced confidence.



  • Standard Security
    Key-type ignition switch deters unauthorized riding.
  • Adjustable Restrictor
    Throttle stop screw lets the adult supervisor restrict speed while beginners are learning.
  • Racing Style
    Cool-looking YZ bodywork includes an integrated front fender and number plate.
  • Folding Side Stand
    Standard side stand tucks up out of the way when not in use.
  • Grippy Foot Pegs
    Large folding, cleated foot pegs provide excellent footing.





2022 Yamaha TT-R50E – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $1749 USD
Canada MSRP Price: $2099 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)

Engine Type 49cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke 36.0mm x 48.6mm
Compression Ratio 9.5:1
Fuel Delivery Mikuni® VM11 carburetor
Ignition CDI
Transmission Constant-mesh 3-speed; automatic clutch
Final Drive Chain
Suspension / Front Telescopic fork; 3.8-in travel
Suspension / Rear Single shock; 2.8-in travel
Brakes / Front Drum, 80mm
Brakes / Rear Drum, 80mm
Tires / Front 2.50-10-4PR
Tires / Rear 2.50-10-4PR
L x W x H 51.4 in x 23.4 in x 31.3 in
Seat Height 21.9 in
Wheelbase 36.4 in
Rake (Caster Angle) 25.5°
Trail 1.3 in
Maximum Ground
5.3 in
Fuel Capacity 0.8 gal
Fuel Economy n/a
Wet Weight 128 lb
Warranty 90 Day (Limited Factory Warranty)
Color Team Yamaha Blue

*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as
applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is
useful in making real-world comparisons with other models.


2022 Yamaha TT-R50E – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE 4-stroke, air-cooled, SOHC, 2-valve, single
BORE AND STROKE 36 x 48.6 mm
MAXIMUM TORQUE 0.32 kg-m (2.3 ft-lb) @ 5,500 rpm
TRANSMISSION Constant mesh, 3-speed, semi automatic

SUSPENSION (FRONT) 26 mm conventional fork / 96mm (3.8″) wheel travel
SUSPENSION (REAR) Monocross, single shock / 71mm (2.8″) wheel travel
TIRES (FRONT) 2.50-10 4PR
TIRES (REAR) 2.50-10 4PR

LENGTH 1,305mm (51.4″)
WIDTH 595mm (23.4″)
HEIGHT 795mm (31.3″)
WHEELBASE 925mm (36.4″)
SEAT HEIGHT 555mm (21.9″)
FUEL CAPACITY 3.1 litres (0.7 imp. gal.)
WET WEIGHT 58 kg (128 lb)
COLOUR(S) Yamaha Racing Blue



2022 Yamaha TT-R50E – Totalmotorcycle.com European Specifications/Technical Details



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
