2023 BMW R nineT Scrambler Guide

2023 BMW R nineT Scrambler

2023 BMW R nineT Scrambler 2023 BMW R nineT Scrambler 2023 BMW R nineT Scrambler 2023 BMW R nineT Scrambler

2023 BMW R nineT Scrambler: SCRAMBLED EGGS TASTE BETTER.

Introducing the 2023 BMW R nineT Scrambler…

POWERFUL, ROBUST, CREATIVE

The R nineT Scrambler knows no conventions: rough, unadapted, individual. Its handling is balanced and unique. With the boxer, you can ride around with your head held high, it is available for every spontaneity. And the typical Scrambler look together with the relaxed seating position makes a lot of difference – and above all is a lot of fun. Design your R nineT Scrambler so that it fits perfectly into your life. No matter what the others say. Just typical #Soulfuel.

Relaxed, unconventional and incredibly dynamic. The R nineT Scrambler promises lots of freedom and pleasure. And it is just waiting for what you have to offer.

“The design makes you want more. Robust, rough, rebellious – only your own rules count.” – Ulf Musekamp (Automotive engineer R nineT)



2023 BMW R nineT Scrambler Totalmotorcycle.com Key Features

Standard equipment:

  • LED headlights
  • Speedometer with on-board computer
  • Automatic Stability Control (ASC)
  • Ride Modes: Rain & Road
  • Drivetrain and final drive in black
  • USB charging socket



Optional equipment:

  • Ride Modes Pro with Dirt mode
  • Heated grips and cruise control
  • New paintwork
  • Cross-spoked wheels I & II
  • Option 719 billet packs I & II
  • Off-road tires



Optional accessories:

  • Rev counter with on-board computer
  • Short rear
  • Rear tracker
  • Functionally-integrated turn indicators
  • Cylinder head covers in 2V style







2023 BMW R nineT Scrambler Totalmotorcycle.com Features and Benefits

WILD BEAUTY – THE DESIGN
Let yourself be swept away
Each of the four paint variants emphasizes the character of the R nineT Scrambler in its own unique way.

  • Telescopic forks with gaiters
  • Rough-toothed footrests
  • Boxer engine
  • Tank shape and air box cover
  • Classic round instrument speedometer
  • Elevated exhaust system
  • Seat in patented leather style
  • LED headlights and turn signal indicators

Do what you want
What the others do has never been your thing. So probably you want to do your own thing? The R nineT Scrambler is ideal for individualization. The Option 719 Shadow II billet pack is manufactured to our highest standards of craftsmanship and quality. The short rear end integrates rear light, brake light and indicator. It may be the end of your bike … but it is only the beginning of your possibilities.

LET’S GO SCRAMBLING

Turn on the power: With the air/oil-cooled boxer of the Scrambler, you can do this in a playful way. We have optimized its power and torque curve and noticeably increased it in the 4,000 to 6,000 rpm range. This way, you have the power exactly where you need it and can remain powerful out on the road. The peak torque remains at 85 lbs-ft. at 6,000 rpm.

  • 85lbs-ft. torque at 6,000 rpm
  • 492lbs. unladen weight, road ready, fully fuelled
  • 1,170cc capacity
  • 32.3in. seat height
  • Air/oil-cooled twin-cylinder four-stroke boxer engine

MORE FUN

Relaxed control doesn’t need to be a contradiction
In the Dirt Mode of the available Ride Mode Pro, you can take it easy: On loose ground, the ASC and DTC control systems take effect much later – for dynamic maneuvers providing even more fun on the bike. At the same time, the available adaptive headlight improves illumination within the bend between a lean angle of 7° and 25°: Wherever you head, your light is already there.

3 year warranty
Ride on & on & on.

Get up to 3-years or 36,000 miles warranty on all new motorcycles.

  • Version Basic: New color Manhattan metallic matt. Kalamata metallic matt no longer available.
  • Option 719: New color Underground uni/Lightwhite uni. Blackstorm metallic/Racing red no longer available.
  • Option 719: New color Pollux metallic/Lightwhite uni. Cosmic blue metallic/Lightwhite no longer available.
  • Colors
    • Manhattan Metallic Matte replaces Kalamata Metallic Matte.
    • Option 719 Underground / Light White replaces Blackstorm Metallic / Racing Red.
    • Option 719 Pollux Metallic / Light White replaces Cosmic Blue Metallic / Light White.
    • Granite Gray Metallic remains unchanged.

    Equipment

    • No equipment changes.

    All US R nineT Scrambler models automatically add Select Package.

    ZSL Select Package – Ride Modes Pro, Heated Grips, Cruise Control, Adaptive Headlight, MSR Dynamic Engine Brake Control, Dynamic Traction Control.

    Individual Options – Spoked Wheels (only with Low Suspension), Design Option Gold Wheels (not with Low Suspension), Black Cross Spoked Wheels (not with Low Suspension), Low Suspension, Off Road Tires, High Brown Seat and Billet Packs.







2023 BMW R nineT Scrambler – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: from $12,995 USD
Canada MSRP Price: $15,045 CDN
Europe/UK MSRP Price: from £12,350 GBP (total selling price)

Engine

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Rated output

109 hp at 7,250 rpm

Max. torque

85 lbs-ft. at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic port fuel injection

Emission Control

Closed-loop 3-way catalytic converter

Performance / fuel consumption

Maximum speed

over 124 mph

Fuel type

Unleaded super(premium)

Electrical system

Alternator

Three-phase alternator with 720 Watt nominal power

Battery

12 V / 12 Ah

Power transmission

Clutch

Single dry plate clutch, hydraulically operated

Gearbox

Constant mesh 6-speed gearbox with helical gear teeth

Drive

Shaft drive

Chassis / brakes

Frame

Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removeable pillion frame for single ride use

Front wheel location / suspension

Telescopic forks with 43 mm fixed-tube diameter

Rear wheel location / suspension

Cast aluminum single-sided swing arm with BMW Motorrad paralever, central spring strut, spring preload continuously adjustable by handwheel, rebound damping continuously adjustable

Suspension travel, front / rear

4.9″ / 5.5″

Wheelbase

60.1”

Caster

4.4″

Steering head angle

61.5°

Wheels

Cast wheels

Rim, front

3.00 x 19″

Rim, rear

4.50 x 17″

Tire, front

120/70 R 19

Tire, rear

170/60 R 17

Brake, front

Twin-disc brakes, diameter 12.6″, 4-piston calipers

Brake, rear

Single disc brake, diameter 10.4″, double-piston floating caliper

ABS

BMW Motorrad ABS Pro

Dimensions / weights

Seat height

32.3”

Inner leg curve

72.0”

Usable tank volume

4.5 gal.

Reserve

app. 0.9 gal.

Length

85.6”

Height (incl. mirrors)

52.4”

Width (incl. hand levers)

34.1”

Unladen weight, road ready, fully fueled

492 lbs.

1)

Permitted total weight

948 lbs.

Payload (with standard equipment)

456 lbs.

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.







2023 BMW R nineT Scrambler – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Ratet output

80 kW (109 hp) at 7,250 rpm

Max. torque

116 Nm at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic intake pipe injection

Emission Control

Closed-loop 3-way catalytic converter, emission standard EU-5

Performance / fuel consumption

Maximum speed

over 200 km/h

Fuel consumption per 100 km based on WMTC

5.1 l

CO2 emission based on WMTC

119 g/km

Fuel type

Unleaded super(premium), octane number 95-98 (RON) (rated output at 98 RON)

Electrical system

Alternator

Three-phase alternator with 720 Watt nominal power

Battery

12 V / 12 Ah, maintenance-free

Power transmission

Clutch

Single dry plate clutch, hydraulically operated

Gearbox

Constant mesh 6-speed gearbox with helical gear teeth

Drive

Shaft drive

Chassis / brakes

Frame

Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removeable pillion frame for single ride use

Front wheel location / suspension

Telescopic forks with 43 mm fixed-tube diameter

Rear wheel location / suspension

Cast aluminium single swinging arm with BMW Motorrad Paralever; central spring strut, spring preload adjustable by hook wrench, rebound-stage damping adjustable

Suspension travel, front / rear

125 mm / 140 mm

Wheelbase

1,527 mm

Castor

110.60 mm

Steering head angle

61.5°

Wheels

Cast wheels

Rim, front

3.00 x 19″

Rim, rear

4.50 x 17″

Tire, front

120/70 R 19

Tire, rear

170/60 R 17

Brake, front

Twin-disc brakes, diameter 320 mm, 4-piston callipers

Brake, rear

Single disc brake, diameter 265 mm, double-piston floating calliper

ABS

BMW Motorrad ABS Pro

Dimensions / weights

Seat height

820 mm

Inner leg curve

1,830 mm

Usable tank volume

17 l

Reserve

app. 3.5 l

Length

2,175 mm

Height (incl. mirrors)

1,330 mm

Width (incl. hand levers)

865 mm

Unladen weight, road ready, fully fuelled

223 kg

1)

Permitted total weight

430 kg

Payload (with standard equipment)

207 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.







2023 BMW R nineT Scrambler – Totalmotorcycle.com European Specifications/Technical Details

Engine

Type

Air/oil-cooled two-cylinder, four-stroke boxer engine with two camshafts and four radially arranged valves per cylinder as well as central counterbalance shaft

Bore x stroke

101 mm x 73 mm

Capacity

1,170 cc

Ratet output

80 kW (109 hp) at 7,250 rpm

Max. torque

116 Nm at 6,000 rpm

Compression ratio

12.0 : 1

Mixture control

Electronic intake pipe injection

Emission Control

Closed-loop 3-way catalytic converter, emission standard EU-5

Performance / fuel consumption

Maximum speed

over 200 km/h

Fuel consumption per 100 km based on WMTC

5.1 l

CO2 emission based on WMTC

119 g/km

Fuel type

Unleaded super(premium), octane number 95-98 (RON) (rated output at 98 RON)

Electrical system

Alternator

Three-phase alternator with 720 Watt nominal power

Battery

12 V / 12 Ah, maintenance-free

Power transmission

Clutch

Single dry plate clutch, hydraulically operated

Gearbox

Constant mesh 6-speed gearbox with helical gear teeth

Drive

Shaft drive

Chassis / brakes

Frame

Three-section frame consisting of one front and two rear sections, load-bearing engine-gearbox unit, removeable pillion frame for single ride use

Front wheel location / suspension

Telescopic forks with 43 mm fixed-tube diameter

Rear wheel location / suspension

Cast aluminum single-sided swingarm with BMW Motorrad paralever, central spring strut, spring preload continuously adjustable by handwheel, rebound damping continuously adjustable

Suspension travel, front / rear

125 mm / 140 mm

Wheelbase

1,527 mm

Castor

110.60 mm

Steering head angle

61.5°

Wheels

Cast wheels

Rim, front

3.00 x 19″

Rim, rear

4.50 x 17″

Tyre, front

120/70 R 19

Tyre, rear

170/60 R 17

Brake, front

Twin-disc brakes, diameter 320 mm, 4-piston callipers

Brake, rear

Single disc brake, diameter 265 mm, double-piston floating calliper

ABS

BMW Motorrad ABS Pro

Dimensions / weights

Seat height

820 mm

Inner leg curve

1,830 mm

Usable tank volume

17 l

Reserve

app. 3.5 l

Length

2,175 mm

Height (incl. mirrors)

1,330 mm

Width (incl. hand levers)

865 mm

Unladen weight, road ready, fully fuelled

223 kg

1)

Permitted total weight

430 kg

Payload (with standard equipment)

207 kg

1) According to Guideline (EU) 168/2013 with all operating fluids, with standard equipment and refuelled with min. 90% of the usable fuel tank capacity.





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
