Review – Key Features – Features & Benefits – Specifications
2024 Yamaha YZF-R3: INTENSE RIDING EXCITEMENT.
Introducing the new 2024 Yamaha YZF-R3…
R3 is the fastest way to get yourself into R/World and experience a thrilling new lifestyle. Equipped with a high-revving 321cc 2-cylinder engine and featuring radical aerodynamic race-inspired bodywork and high-tech brakes and suspension, the R3 is Yamaha’s ultimate new rider Supersport!
Yamaha’s legendary R-Series is the ultimate range of high performance Supersport bikes. Manufactured with pure racing DNA, each one of them is built to thrill. And with its impressive specification and aggressive style, the R3 has the power to take you into a new dimension of intense riding excitement.
R/WORLD IS CALLING.
The R3’s slim and athletic bodywork features a central air intake that’s inspired by Yamaha’s iconic race-winning M1 MotoGP machine. Its radical good looks, aerodynamic race-bred fairing and aggressive dual LED headlights underline its pure R-Series DNA, making it the most desirable 300 on the road or track.
High-specification 37 mm KYB inverted front forks ensure precise suspension feel and feedback – and the combination of a low fuel tank and low handlebars gives the R3 an ergonomic riding position with plenty of comfort together with precise control. You are now ready to enter R/World.
Every model in the Yamaha R-Series is designed and manufactured to give you a thrilling ride every time. The R3 is no exception. Built to the highest standards without compromise, this supersport is always ready for you to enjoy pure riding excitement.
By taking inspiration from both the M1 MotoGP® bike and the class-leading R1, the lightweight R3 combines a forceful race-bred look with sleek cross-layered bodywork, giving it the presence of a bike twice its size – but you can ride it with an A2 licence.
But it doesn’t just look cool – it’s 321cc 2-cylinder EU5 engine is built to deliver high-revving supersport performance. 37 mm KYB inverted forks work in harmony with the light chassis – while the balanced 50/50 weight distribution ensures superb agility. And with its highly e cient aerodynamics, it’s the fastest R3 ever.
Ultimate lightweight supersport.
Driven by a high-revving 321cc EU5 engine, the R3 comes fully equipped with a wide range of key features that give you outstanding performance, alongside class-leading quality and head-turning style. It’s Yamaha’s ultimate lightweight A2 licence supersport.
2024 Yamaha YZF-R3 Totalmotorcycle.com Key Features
- High revving 321cc EU5 engine
- M1 inspired body with new duo-tone
- Icon Blue colour scheme
- Aggressive R1-inspired face
- Lightweight A2-license supersport bike
- Slim and lightweight sports chassis
- R1 inspired dual LED headlights
- 37mm KYB inverted front forks
- Low fuel tank and handlebar position
- Lightweight wheels and supersport tires
- Powerful braking system with ABS
- Balanced 50/50 weight distribution
- Digital multi-function instruments
Sleek R-Series Styling
Featuring flowing bodywork and ergonomics inspired by the MotoGP® YZR-M1, complemented by new colors and graphics, the YZF-R3 is sleek, aerodynamic and refined.
High-Revving Supersport Engine
Yamaha’s championship-winning technology gives the YZF-R3 a broad spread of power with exciting high-rpm performance.
Advanced Suspension
The R3’s inverted fork works with a Monocross rear shock to provide exceptional handling, with balanced chassis rigidity, a near 50/50 weight balance, and damping and spring settings designed for a wide range of road conditions.
Compact Chassis
With a fully-fueled weight of only 375 pounds and a seat height of only 30.7 inches, the YZF-R3 is ultra-light, nimble and confidence-inspiring on everything from tight city streets to wide-open racetracks.
Practical Performance
A range of exclusive technologies ensures the YZF-R3 combines Yamaha’s legendary refinement and reliability with thrilling performance, all while sipping fuel at an efficient 56 mpg.
Supersport
No other manufacturer offers such a complete line-up of premium Supersport machinery. Each model from the 1000cc R1M and R1 through to the 125cc R125 has Yamaha’s racing DNA running through it, ensuring that every R-Series machine is ready to give the most exhilarating riding experience. As well as the street legal models, the range includes specialist race machinery such as the R1 GYTR, R6 GYTR and R6 RACE models that have been developed for racing and track day use only.
2024 Yamaha YZF-R3 Totalmotorcycle.com Features and Benefits
High revving 321cc EU5 engine
With a compression ratio of 11.2:1, double overhead cams (DOHC) and four-valve cylinder heads, the 321cc two-cylinder motor is designed for quick-revving performance and high-rpm efficiency. With a maximum power output of 30.9 kW (42PS) at 10.750 rpm, the R3’s potent EU5 engine delivers thrilling acceleration with an exciting ride and a broad spread of power.
M1 inspired body with Icon Blue colour scheme
Featuring radical bodywork inspired by the race-winning YZR-M1 – and available in a duo-tone Icon Blue colour scheme – this is the sharpest R3 ever built. The central M1-style air duct gives a pure race-bred look – and with a high overall specification and idealised 50/50 weight distribution, the R3 is ready to thrill you on the road and track.
Aggressive R1-inspired face
With its glaring face, this bike is pure R-Series, and features an aggressive front fairing and a race-type screen inspired by the iconic R1. Dual LED headlights and a central air duct work with the cross-layered fairing panels to maximise cooling airflow for the EU5 engine, making this the most outstanding supersport in the 300cc A2 licence class.
Lightweight A2-license supersport bike
Whether you’re an A2 licence rider or someone who wants the ultimate lightweight supersport, the R3 has the technology, performance and style that you’re looking for. Developed using the same no-compromise philosophy that goes into every R-Series model, this bike’s race-bred DNA is built to thrill.
Slim and lightweight sports chassis
The compact and lightweight chassis is manufactured from high tensile steel tubing that gives an optimum balance of strength and rigidity. For sporty and agile handling characteristics the R3’s short wheelbase gives outstanding agility – while the near 50/50 front/rear weight distribution and accessible seat height deliver a confident and balanced ride.
R1 inspired dual LED headlights
The front fairing is equipped with R1-style headlights that underline the R3’s strong genetic links with Yamaha’s larger R-Series supersport models. Utilising bright and long-lasting LED technology, the dual headlights produce excellent visibility and illumination with minimal power draw – and give the bike a radical race-bred look.
37 mm KYB inverted front forks
The R3 features 37 mm KYB inverted forks with optimised spring and damping settings. This design gives a large surface area for the sliding tube that ensures high levels of fork rigidity for sporty front-end feel and feedback without losing real-world comfort – and the special top clamp reinforces the radical YZR-M1 inspired style.
Low fuel tank and handlebar position
Thanks to the low fuel tank design and low handlebars, the R3’s ergonomics give a pure supersport riding experience. As well as being extremely comfortable, the riding position makes it easy to grip the machine with your knees for improved confidence, especially when you’re tucking in close to the bodywork for maximum aerodynamic efficiency.
Lightweight wheels and supersport tires
Featuring five pairs of thin cast spokes that complement the bike’s sleek R-Series image, the 17-inch wheels are fitted with a 110/70-17 radial front tire and a wide 140/70-17 radial rear tire. These cast aluminium wheels with light hollow axles are both strong and stylish, while also minimising unsprung weight for refined handling performance.
Powerful braking system with ABS
The 298 mm floating-mount front disc brake ensures excellent stopping power with plenty of feel at the lever, while a 220 mm floating disc handles the braking performance at the rear. And with its ABS anti-lock braking system, the R3 rider can ride confidently – even when traction is reduced in wet or slippery conditions.
Balanced 50/50 weight distribution
Thanks to the engine placement and overall machine dimensions, the R3 features a near 50/50 front/rear weight distribution – widely regarded as being the ideal set up for supersport bikes – giving precise handling performance, easy agility and plenty of feedback from the road.
Digital multi-function instruments
The R3 features multi-function LCD instruments that display information on gear position, fuel capacity, real time and average fuel economy. There’s also a water temp gauge, clock, oil change indicator and trip meter – all presented in a clean, modern layout.
ENGINE
Potent Twin-Cylinder Powerplant
Yamaha’s 321cc liquid-cooled, inline 2-cylinder engine delivers excellent power and performance throughout the rpm range. With a 180-degree crank design and integrated counterbalancer, the layout minimizes vibrations for a smooth, refined engine character.
High-Revving Engine Architecture
With a compression ratio of 11.2:1, double overhead cams (DOHC) and four-valve cylinder heads, the YZF-R3 motor is designed for quick-revving performance and high-rpm efficiency to deliver an exciting ride with a broad spread of power.
Six-Speed Transmission
A smooth-shifting six-speed gearbox ensures the rider always has the right ratio, whether riding through tight canyon corners or racetrack straightaways.
Modern Fuel Injection
Downdraft induction fuel injection system provides easy starting, excellent fuel economy and responsive performance in all conditions.
Advanced Cylinder Construction
Yamaha’s unique DiASil—a high-silicon aluminum alloy—engine block is used to ensure excellent heat dissipation, with an innovative offset cylinder design that reduces horsepower loss and improves both power and fuel efficiency.
Strong, Lightweight Pistons
Forged aluminum pistons—the same technology used for the YZF- R1—mean lighter weight and excellent strength at extreme temperatures, ensuring reliability at higher rpm.
Compact Exhaust System
The short muffler design features modern styling and helps to centralize mass, improving agility for ultra-responsive handling.
CHASSIS/SUSPENSION
Inverted Front Fork
The YZF-R3 features an inverted fork with optimized spring and damping settings, significantly improving fork rigidity, front-end feedback and control. The design also includes a YZR-M1-inspired top clamp for improved Supersport style.
Monocross Rear Shock
The single-shock design further centralizes mass and is tuned to strike a balance between ride comfort and sporty performance, for capability across a wide range of uses, from urban commuting to track days. It’s also adjustable for spring preload which accounts for passengers or cargo.
Potent Braking with ABS
The 298mm floating-mount front disc brake ensures excellent stopping power, supported by a 220mm rear disc, and an anti-lock braking system boosts rider confidence and prevents wheel lock-ups in reduced-traction conditions.
Sportbike-Spec Wheels & Tires
Stylish 10-spoke cast aluminum wheels minimize unsprung weight for improved suspension responsiveness and refined handling. Grippy Dunlop® radial tires offer enhanced traction and feedback for sporty riding too.
Perfectly Balanced
Thanks to the engine placement and overall machine dimensions, the YZF-R3 features a near 50/50 front/rear weight distribution for enhanced performance, especially in dynamic canyon-carving or racetrack riding environments.
ADDITIONAL FEATURES
Sleek R-Series Styling
The R3’s aggressive design continues the legendary styling born from the YZR-M1 MotoGP® machine and improves overall aerodynamics at high speeds too. The glaring face of the R3 features compact LED headlights with a central air duct that maximizes cooling airflow for the engine.
LED Lighting
Light Emitted Diode (LED) elements are used for both the taillight unit and headlights. Not only do LEDs offer long life with minimal power draw, they provide brilliant illumination for confidence and visibility day or night.
Refined Sportbike Ergonomics
Thanks to the low-profile fuel tank design and relatively compact handlebar position, the rider is able to naturally grip the machine for confidence, especially when tucking aggressively behind the windscreen on the racetrack.
Digital Instrumentation
The compact multi-function meter informs the rider of gear position, fuel capacity, real time and average fuel economy, water temp, clock, and an oil change trip meter—all presented in a clean, modern layout.
*Manufacturer’s Suggested Retail Price (MSRP) shown. Does not include tax, title, prep or destination charges. Actual prices set by dealer.
**Fuel Economy is estimated.
***Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2024 Yamaha YZF-R3 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $5499 USD
Canada MSRP Price: $6999 CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)
ENGINE
| Engine Type | 321cc liquid-cooled, 4-stroke, DOHC inline twin-cylinder; 4-valves per cylinder |
| Bore x Stroke | 68.0mm x 44.1mm |
| Compression Ratio | 11.2:1 |
| Fuel Delivery | Fuel injection |
| Transmission | 6-speed; multiplate wet clutch |
| Final Drive | Chain |
| Fuel Capacity | 3.7 gal |
CHASSIS
| Suspension/Front | Inverted telescopic fork; 5.1-in travel |
| Suspension/Rear | Monocross single shock, adjustable preload; 4.9- in travel |
| Brakes/Front | 298mm hydraulic disc with ABS |
| Brakes/Rear | 220mm hydraulic disc with ABS |
| Tires/Front | 110/70-17 Dunlop® Sportmax GPR-300F |
| Tires/Rear | 140/70-17 Dunlop® Sportmax GPR-300R |
DIMENSIONS
| LxWxH | 82.3 in x 28.7 in x 44.9 in |
| Seat Height | 30.7 in |
| Wheelbase | 54.3 in |
| Rake (Caster Angle) | 25.0° |
| Trail | 3.7 in |
| Max. Ground Clearance | 6.3 in |
| Fuel Capacity | 3.7 gal |
| Fuel Economy** | 56 mpg |
| Wet Weight*** | 375 lb |
OTHER
| Warranty | 1 Year (Limited Factory Warranty) |
2024 Yamaha YZF-R3 – Totalmotorcycle.com Canada Specifications/Technical Details
ENGINE
| ENGINE | Liquid-cooled, DOHC, 8 valves (4 valves/cyl.), inline twin |
| DISPLACEMENT | 321 cc |
| BORE AND STROKE | 68 x 44.1 mm |
| COMPRESSION RATIO | 11.2:1 |
| FUEL DELIVERY | 32 mm throttle body F.I. |
| ESTIMATED FUEL CONSUMPTION± | 23.5 kpl / 66 mpg (Imp.) |
| LUBRICATION | Wet sump |
| IGNITION / STARTING | TCI / Electric |
| TRANSMISSION | 6-speed |
| FINAL DRIVE | O-ring chain |
CHASSIS
| SUSPENSION (FRONT) | 37 mm upside-down fork / 130 mm (5.1″) wheel travel |
| SUSPENSION (REAR) | Adjustable Monocross / 125 mm (4.9″) wheel travel |
| BRAKES (FRONT) | 298 mm floating disc / twin-piston caliper / ABS equipped |
| BRAKES (REAR) | 220 mm disc / single-piston caliper / ABS equipped |
| TIRES (FRONT) | 110/70-17 |
| TIRES (REAR) | 140/70-17 |
CRITICAL DATA
| LENGTH | 2,090 mm (82.3″) |
| WIDTH | 730 mm (28.7″) |
| HEIGHT | 1,140 mm (44.9″) |
| WHEELBASE | 1,380 mm (54.3″) |
| RAKE / TRAIL | 25 degrees / 95 mm (3.7″) |
| GROUND CLEARANCE | 160 mm (6.3″) |
| SEAT HEIGHT | 780 mm (30.7″) |
2024 Yamaha YZF-R3 – Totalmotorcycle.com European Specifications/Technical Details
Engine
Engine type 4-stroke, 2-cylinder, Liquid-cooled, DOHC, 4-valves
Displacement 321cc
Bore x stroke 68,0 × 44,1 mm
Compression ratio 11,2 : 1
Maximum power 30,9 kW (42,0PS) @ 10.750 rpm
Maximum torque 29,5 Nm (3,0 kg-m) @ 9.000 rpm
Lubrication system Wet sump
Clutch type Wet, Multiple Disc
Ignition system Electric
Starter system TCI
Transmission system Constant Mesh, 6-speed
Final transmission Chain
Fuel consumption 4,1 L/100 km
CO2 emission 94 g/km
Fuel system Fuel Injection
Chassis
Frame Diamond
Caster angle 25° 00
Trail 95 mm
Front suspension system Telescopic forks
Rear suspension system Swingarm
Front travel 130 mm
Rear travel 125 mm
Front brake Hydraulic single disc, Ø298 mm
Rear brake Hydraulic single disc, Ø220 mm
Front tyre 110/70 R17M/C 54H Tubeless
Rear tyre 140/70 R17M/C 66H Tubeless
Dimensions
Overall length 2.090 mm
Overall width 730 mm
Overall height 1.140 mm
Seat height 780 mm
Wheel base 1.380 mm
Minimum ground clearance 160 mm
Wet weight (including full oil and fuel tank) 169 kg
Fuel tank capacity 14 L
Oil tank capacity 2,50 L
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
