2005 Harley-Davidson Heritage Softail Classic FLSTC/FLSTCI
Back to 2005 Harley-Davidson Motorcycle Index Page




– 2005 Harley-Davidson Heritage Softail Classic FLSTC/FLSTCI

Twist the throttle of the timeless Heritage Softail® Classic and you are propelled forward and back all at once. Generously studded leather bags. Massive fenders with chrome accents. Wide tires on wire-laced wheels. Detachable king-size windshield. Low two-up seat with backrest. Giant chrome headlight and passing lamps. An eyeful of all these goodies and it’s easy to see the inspiration for this bike was the early dressers. But in keeping with Harley philosophy, tradition isn’t something to be left standing still. So we set the classic hardtail styling in motion with 88 cubic inches of refined internal combustion. The Classic’s wrinkle black and chrome Twin Cam 88B™, available in carb or EFI, is rigid-mounted but has two counterbalancers to make your ride from yesteryear to modern day a very smooth one.

—————————————
SPECIFICATIONS:

DIMENSIONS
Length 2400.3 mm

Seat Height

Laden(1) 647.7 mm

Unladen 696.0 mm

Ground Clearance 129.5 mm

Rake Steering Head/Trail 32.0º / 147.3 mm

Wheelbase 1638.3 mm

Fuel Capacity(2) 18.9 L

Oil Capacity 3.3 L

Weight

Dry Weight 316.0 kg

Running Order 335.0 kg

POWERTRAIN
Engine(3) Twin Cam 88B™

Displacement 1450 cm³

Bore x Stroke 95.18 mm x 101.52 mm

Engine Torque(4)(5) 115.0 nm @ 3000 rpm

Fuel System(6) Carburetor or Electronic Sequential Port Fuel Injection (ESPFI )

Compression Ratio 8.9:1

Liters per 100 KM(7)

Carb. 4.9 hwy / 5.7 city

ESPFI 4.9 hwy / 5.5 city

Primary Drive Chain

Gear Ratio (overall)

1st 10.110

2nd 6.958

3rd 4.953

4th 3.862

5th 3.150

WHEELS/TIRES
Wheels(8)

Front Laced

Rear Laced

Tire Size

Front MT90B16 72H

Rear 150/80B16 71H

ELECTRICAL
Electronics Optional security system

Instruments Electronic speedometer; odometer; resettable tripmeter; diagnostic readout

Indicator Lamps Oil pressure; engine diagnostics

CHASSIS
Brakes (diameter x width)

Front 292.1 mm x 5.08 mm

Rear 292.1 mm x 5.84 mm

Lean Angle (per SAEJ1168) 28º / 29º

Exhaust System Staggered shorty duals

COLOR OPTIONS(9)
Vivid black, brilliant silver, sierra red, luxury teal, luxury blue, glacier white pearl, lava red sunglo, two-tone luxury blue and impact blue, two-tone luxury teal and brilliant silver, two-tone sierra red and brilliant silver, two-tone smokey gold and vivid black


UNIQUE FEATURES
Black powder-coated engine with chrome covers; detachable king-size windshield; leather saddlebags with quick detach buckles; passenger backrest; touring handlebars; full front fender with chrome accents; chrome hub cover; chrome passing lamps; chrome-plated directional light bar


PRICING(10)
MSRP

Base Carb: $28,750
ESPFI: $29,750

Two-tone Carb: $29,250
ESPFI: $30,250

H-D® factory security system See your dealer for pricing information.

ESPFI Optional
