2011 Victory Vision Tour

Back to 2011 Victory Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2011 Victory Vision Tour
2011 Victory Vision Tour

2011 Victory Vision Tour
2011 Victory Vision Tour

2011 Victory Vision Tour
2011 Victory Vision Tour




– 2011 Victory Vision Tour

2011 Victory Vision Tour

The Victory Vision Tour is the most progressive luxury touring bike out there, loaded with state-of-the-art features designed specifically to make you feel guilty when you’re not running up the odometer. Every inch of this touring machine is designed to keep you out doing what you love the most.




Key Victory Vision Tour Key Features

New 106-Cubic-Inch Freedom V-Twin: The ultra-reliable, smooth-running, counter-balanced Freedom 106/6 Stage 1 V-Twin delivers outstanding power for city driving and long-distance touring.










2011 Victory Vision Tour – Specifications
USA MSRP – $23,199 USD
Canada MSRP – $25,869 CDN

Engine

Engine Type 4-stroke 50o V-Twin
Cooling System Air / oil
Displacement 106 ci / 1731 cc
Bore x Stroke 101 x 108 mm
Compression ratio 9.4 : 1
Valve train Single overhead camshafts with 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Fuel Capacity 6.0 gal / 22.7 ltr
Exhaust Split dual exhaust with crossover
Oil capacity 5.0 qts / 4.75 ltr
Charging System 48 amps max output
Battery 12 volts / 18 amp hours
Primary Drive Gear drive with torque compensator
Clutch Wet, multi-plate
Transmission 6-speed overdrive constant mesh
Final Drive Carbon Fiber Reinforced Belt



Chassis Dimensions

Length 104.9 in/2,665 mm
Wheelbase 65.7 in / 1670 mm
Seat Height 26.5 in / 673 mm
Ground Clearance 5.8 in / 148 mm
Rake/trail 29.0o / 5.6 in / 142 mm
Dry Weight 869 Lbs / 395 Kg
GVWR 1414 lbs / 643 kg


Suspension

Front Suspension Conventional telescopic fork, 46 mm diameter, 5.1 in / 130 mm travel
Rear Suspension Single, mono-tube, cast aluminum with constant rate linkage, 4.7 in / 120 mm travel, air adjustable



Brakes

Brake Systmen Type Linked (ABS)
Front braking system Dual 300mm floating rotors with 4-piston calipers
Rear braking system 300mm floating rotor with 2-piston caliper



Wheels and Tires

Front Wheel 18 x 3.0 in
Rear Wheel 16 x 5.0 in
Front Tire 130/70R18 Dunlop Elite 3
Rear Tire 180/60R16 Dunlop Elite 3



Color Options

Colors Crimson & Black; Two Tone Vogue Silver & Black; Solid Pearl White.
