THIS IS WHERE THE ADVENTURE STARTS.
- 112cc air-cooled, 4-stroke engine provides smooth power and rock solid reliability
- 4-speed transmission with automatic clutch for stall-free shifting
- Low 26.8-inch seat height
- Sporty styling featuring Lime Green bodywork for race-inspired good looks
The biggest challenge in enjoying the KLX110 or KLX110L’s amazing off-road capabilities is figuring out who’s going to ride it first – because its compact dimensions, simple-to-use features, and choice of 2 models were designed for a wide range of beginning riders aged 13 and up.
2018 Kawasaki KLX110 Totalmotorcycle.com Key Features
The Kawasaki KLX® family of off-road motorcycles are widely popular for their low maintenance, easy-to-ride character, and incredible capabilities while on trails. The five models consist of two engine configurations and are built to suit a variety of riders.
The same team that developed the championship winning Kawasaki KX™ family has engineered the KLX models, injecting the model range with a performance racing heritage and unmatched durability, ensuring all-day enjoyment with family and friends.
2018 Kawasaki KLX110 Totalmotorcycle.com Features and Benefits
KAWASAKI KLX® 110 & KLX®110L
There’s no better motorcycle than the KLX®110 for a new rider who is looking to experience dirt for the first time. A high-tensile steel frame, 30mm telescopic fork, and single rear shock provide easy handling and maximum longevity. It also incorporates an automatic centrifugal clutch system that allows easy take off and shifting through the gears, helping the rider maintain focus on the terrain and to make the most of the 112cc single-cylinder, 4-stroke engine.
There is an electric start with an “off” switch right alongside it. The start button is located on the left-hand grip to allow throttle use during start-up, and traditional kickstarter as a back up.
The bigger KLX®110L motorcycle offers a natural progression as a rider grows in stature and experience. The bike has a taller seat height (28.7” compared to 26.8” for the KLX110), longer suspension travel and an extra 1.9” of ground clearance. A manual clutch can also be found to provide a more exciting experience, while an electric (with kickstarter back up) helps get the fun started quickly.
2018 Kawasaki KLX110 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2299 USD
POWER
Engine
4-stroke, 1-cylinder, SOHC, air-cooled
Displacement
112cc
Bore x Stroke
53.0 x 50.6mm
Compression ratio
9.5:1
Fuel System
Keihin PB18
Ignition
DC-CDI
Transmission
4-speed, return shift
Final Drive
Chain
PERFORMANCE
Front Suspension / Wheel Travel
30mm hydraulic telescopic fork/4.3 in
Rear Suspension / Wheel Travel
Swingarm w/single hydraulic shock/4.3 in
Front Tire
2.50×14
Rear Tire
3.00×12
Front Brakes
Mechanical Drum
Rear Brakes
Mechanical Drum
DETAILS
Frame Type
Backbone frame, high-tensile steel
Rake/Trail
24.8°/2.0 in
Overall Length
61.4 in
Overall Width
25.6 in
Overall Height
37.6 in
Ground Clearance
8.5 in
Seat Height
26.8 in
Curb Weight
167.5 lb**
Fuel Capacity
1.0 gal
Wheelbase
42.3 in
Color Choices
Lime Green
Warranty
6 Months
Kawasaki Protection Plus™ (optional)
2018 Kawasaki KLX110 – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $2699 CDN
ENGINE
| Displacement | 112cc |
| Type | 4-stroke, Single |
| Bore and stroke | 53.0 x 50.6 mm |
| Cooling | Air |
| Compression ratio | 9.5:1 |
| Valve system | SOHC, 2 valves |
| Fuel system | Keihin PB18 carburetor |
| Ignition | Digital DC-CDI |
| Lubrication | Forced lubrication (wet sump) |
| Starting | Electric & Primary Kick |
BRAKES
| Front: type | Drum (90 mm) |
| Rear: type | Drum (110 mm) |
DIMENSIONS
| Overall length | 1,560 mm (61.4 in.) |
| Overall width | 650 mm (25.6 in.) |
| Overall height | 955 mm (37.6 in.) |
| Wheelbase | 1,075 mm (42.3 in.) |
| Ground clearance | 215 mm (8.5 in.) |
| Seat height | 680 mm (26.8 in.) |
| Curb mass** | 76 kg (167.6 lbs.) |
| Fuel capacity | 3.8 litres (0.8 gal.) |
DRIVETRAIN
| Transmission | 4-speed, constant mesh, return shift |
| Final drive | Chain |
| Primary reduction ratio | 3.409 (75/22) |
| Gear ratio: 1st | 3.000 (36/12) |
| Gear ratio: 2nd | 1.938 (31/16) |
| Gear ratio: 3rd | 1.350 (27/20) |
| Gear ratio: 4th | 1.087 (25/23) |
| Final reduction ratio | 2.923 (38/13) |
| Clutch | Centrifugal, wet multi-disc |
FRAME
| Type | Hgh-tensile steel backbone |
| Wheel travel: front | 110 mm (4.3 in.) |
| Tire: front | 2.50-14 4PR |
| Wheel travel: rear | 110 mm (4.3 in.) |
| Tire: rear | 3.00-12 4PR |
| Caster (rake) | 24.8° |
| Trail | 50 mm (2.0 in.) |
| Steering angle (left/right) | 45° / 45° |
PERFORMANCE
| Maximum Power‡ | 5.4 kW {7.3 PS} @ 7,500 rpm |
| Maximum Torque‡ | 8.0 N·m {0.82 kgƒ·m} @ 4,000 rpm |
SUSPENSION
| Suspension, front | 30 mm telescopic fork |
| Suspension, rear | Single shock |
DETAILS
| Warranty | 6 months warranty |
2018 Kawasaki KLX110 – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £2249 GBP (On The Road inc 20% Vat)
Engine
Engine type Air-cooled, 4-stroke Single
Displacement 112 cm³
Bore x stroke 53 x 50.6 mm
Compression ratio 9.5:1
Valve system SOHC, 2 valves
Fuel system Carburettor: PB18 (Keihin)
Ignition Digital DC-CDI
Starting System Electric & Kick
Lubrication Forced lubrication, wet sump
Gear Performance & Transmission
Maximum power 5.4 kW {7.3 PS} / 7,500 rpm
Maximum torque 8.0 N•m {0.82 kgƒ•m} / 4,000 rpm
Transmission 4-speed
Final drive Chain
Primary Reduction Ratio 3.409 (75/22)
Gear Ratios 1st 3.000 (36/12)
Gear Ratios 2nd 1.938 (31/16)
Gear Ratios 3rd 1.350 (27/20)
Gear Ratios 4th 1.087 (25/23)
Final reduction ratio 2.923 (38/13)
Clutch Centrifugal, wet multi-disc
Suspensions Brakes & Suspension
Brakes, front Drum (Ø 90 mm)
Brakes, rear Drum (Ø 110 mm)
Suspension, front 30 mm telescopic fork
Suspension, rear Single shock
Dimensions Frame & Dimensions
Frame type Backbone, Steel
Trail 50 mm
Wheel travel front 110 mm
Wheel travel rear 110 mm
Tyre, front 2.50-14 4PR
Tyre, rear 3.00-12 4PR
Steering angle, left / right 45° / 45°
L x W x H 1,560 x 650 x 955 mm
Wheelbase 1,075 mm
Ground clearance 215 mm
Fuel capacity 3.6 litres
Seat height 680 mm
Curb Mass 76 kg
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
