2018 Kawasaki KLX110 Review

2018 Kawasaki KLX110
2018 Kawasaki KLX110

2018 Kawasaki KLX110

2018 Kawasaki KLX110

2018 Kawasaki KLX110

2018 Kawasaki KLX110

THIS IS WHERE THE ADVENTURE STARTS.

THE KLX®110 MOTORCYCLE IS A VERSATILE OFF-ROAD BIKE WITH A LOW SEAT HEIGHT, PLUSH SUSPENSION AND AN AUTOMATIC CLUTCH FOR A FUN, CONFIDENCE-INSPIRING RIDE.
  • 112cc air-cooled, 4-stroke engine provides smooth power and rock solid reliability
  • 4-speed transmission with automatic clutch for stall-free shifting
  • Low 26.8-inch seat height
  • Sporty styling featuring Lime Green bodywork for race-inspired good looks

The biggest challenge in enjoying the KLX110 or KLX110L’s amazing off-road capabilities is figuring out who’s going to ride it first – because its compact dimensions, simple-to-use features, and choice of 2 models were designed for a wide range of beginning riders aged 13 and up.

 Small bike equals big fun in the KLX110. This is where the adventure starts.



2018 Kawasaki KLX110 Totalmotorcycle.com Key Features

 The Kawasaki KLX® family of off-road motorcycles are widely popular for their low maintenance, easy-to-ride character, and incredible capabilities while on trails. The five models consist of two engine configurations and are built to suit a variety of riders.

The same team that developed the championship winning Kawasaki KX™ family has engineered the KLX models, injecting the model range with a performance racing heritage and unmatched durability, ensuring all-day enjoyment with family and friends.







2018 Kawasaki KLX110 Totalmotorcycle.com Features and Benefits

KAWASAKI KLX® 110 & KLX®110L

There’s no better motorcycle than the KLX®110 for a new rider who is looking to experience dirt for the first time. A high-tensile steel frame, 30mm telescopic fork, and single rear shock provide easy handling and maximum longevity. It also incorporates an automatic centrifugal clutch system that allows easy take off and shifting through the gears, helping the rider maintain focus on the terrain and to make the most of the 112cc single-cylinder, 4-stroke engine.

There is an electric start with an “off” switch right alongside it. The start button is located on the left-hand grip to allow throttle use during start-up, and traditional kickstarter as a back up.

The bigger KLX®110L motorcycle offers a natural progression as a rider grows in stature and experience. The bike has a taller seat height (28.7” compared to 26.8” for the KLX110), longer suspension travel and an extra 1.9” of ground clearance. A manual clutch can also be found to provide a more exciting experience, while an electric (with kickstarter back up) helps get the fun started quickly.







2018 Kawasaki KLX110 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2299 USD

POWER

Engine

4-stroke, 1-cylinder, SOHC, air-cooled



Displacement

112cc



Bore x Stroke

53.0 x 50.6mm



Compression ratio

9.5:1



Fuel System

Keihin PB18



Ignition

DC-CDI



Transmission

4-speed, return shift



Final Drive

Chain



PERFORMANCE

Front Suspension / Wheel Travel

30mm hydraulic telescopic fork/4.3 in



Rear Suspension / Wheel Travel

Swingarm w/single hydraulic shock/4.3 in



Front Tire

2.50×14



Rear Tire

3.00×12



Front Brakes

Mechanical Drum



Rear Brakes

Mechanical Drum



DETAILS

Frame Type

Backbone frame, high-tensile steel



Rake/Trail

24.8°/2.0 in



Overall Length

61.4 in



Overall Width

25.6 in



Overall Height

37.6 in



Ground Clearance

8.5 in



Seat Height

26.8 in



Curb Weight

167.5 lb**



Fuel Capacity

1.0 gal



Wheelbase

42.3 in



Color Choices

Lime Green



Warranty

6 Months



Kawasaki Protection Plus™ (optional)







2018 Kawasaki KLX110 – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $2699 CDN

ENGINE

Displacement 112cc
Type 4-stroke, Single
Bore and stroke 53.0 x 50.6 mm
Cooling Air
Compression ratio 9.5:1
Valve system SOHC, 2 valves
Fuel system Keihin PB18 carburetor
Ignition Digital DC-CDI
Lubrication Forced lubrication (wet sump)
Starting Electric & Primary Kick

BRAKES

Front: type Drum (90 mm)
Rear: type Drum (110 mm)

DIMENSIONS

Overall length 1,560 mm (61.4 in.)
Overall width 650 mm (25.6 in.)
Overall height 955 mm (37.6 in.)
Wheelbase 1,075 mm (42.3 in.)
Ground clearance 215 mm (8.5 in.)
Seat height 680 mm (26.8 in.)
Curb mass** 76 kg (167.6 lbs.)
Fuel capacity 3.8 litres (0.8 gal.)

DRIVETRAIN

Transmission 4-speed, constant mesh, return shift
Final drive Chain
Primary reduction ratio 3.409 (75/22)
Gear ratio: 1st 3.000 (36/12)
Gear ratio: 2nd 1.938 (31/16)
Gear ratio: 3rd 1.350 (27/20)
Gear ratio: 4th 1.087 (25/23)
Final reduction ratio 2.923 (38/13)
Clutch Centrifugal, wet multi-disc

FRAME

Type Hgh-tensile steel backbone
Wheel travel: front 110 mm (4.3 in.)
Tire: front 2.50-14 4PR
Wheel travel: rear 110 mm (4.3 in.)
Tire: rear 3.00-12 4PR
Caster (rake) 24.8°
Trail 50 mm (2.0 in.)
Steering angle (left/right) 45° / 45°

PERFORMANCE

Maximum Power 5.4 kW {7.3 PS} @ 7,500 rpm
Maximum Torque 8.0 N·m {0.82 kgƒ·m} @ 4,000 rpm

SUSPENSION

Suspension, front 30 mm telescopic fork
Suspension, rear Single shock

DETAILS

Warranty 6 months warranty







2018 Kawasaki KLX110 – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £2249 GBP (On The Road inc 20% Vat)

Engine

Engine type Air-cooled, 4-stroke Single

Displacement 112 cm³

Bore x stroke 53 x 50.6 mm

Compression ratio 9.5:1

Valve system SOHC, 2 valves

Fuel system Carburettor: PB18 (Keihin)

Ignition Digital DC-CDI

Starting System Electric & Kick

Lubrication Forced lubrication, wet sump

Gear      Performance & Transmission

Maximum power 5.4 kW {7.3 PS} / 7,500 rpm

Maximum torque 8.0 N•m {0.82 kgƒ•m} / 4,000 rpm

Transmission 4-speed

Final drive Chain

Primary Reduction Ratio 3.409 (75/22)

Gear Ratios 1st 3.000 (36/12)

Gear Ratios 2nd 1.938 (31/16)

Gear Ratios 3rd 1.350 (27/20)

Gear Ratios 4th 1.087 (25/23)

Final reduction ratio 2.923 (38/13)

Clutch Centrifugal, wet multi-disc

Suspensions       Brakes & Suspension

Brakes, front Drum (Ø 90 mm)

Brakes, rear Drum (Ø 110 mm)

Suspension, front 30 mm telescopic fork

Suspension, rear Single shock

Dimensions        Frame & Dimensions

Frame type Backbone, Steel

Trail 50 mm

Wheel travel front 110 mm

Wheel travel rear 110 mm

Tyre, front 2.50-14 4PR

Tyre, rear 3.00-12 4PR

Steering angle, left / right 45° / 45°

L x W x H 1,560 x 650 x 955 mm

Wheelbase 1,075 mm

Ground clearance 215 mm

Fuel capacity 3.6 litres

Seat height 680 mm

Curb Mass 76 kg





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
