2019 Kawasaki KLX140G Guide

2019 Kawasaki KLX140G

2019 Kawasaki KLX140G 2019 Kawasaki KLX140G 2019 Kawasaki KLX140G 2019 Kawasaki KLX140G

THE BIG BOY KLX140.

2019 Kawasaki KLX140G:

The KLX140G offers a comfortable fit and a reliable, confidence-inspiring ride with larger wheels that’s ideal for off-road adventures. Light overall weight and roomy ergonomics make learning easier, allowing riders to focus on fun, while the dependability and low-maintenance of the KLX140G make it the ultimate companion on the trail.

The KLX®140G motorcycle is over 30 pounds lighter than all other competitors*, offering confidence-inspiring performance in an easy-to-ride package. This off-road motorcycle features full-size wheels, comfortable ergonomics and light, nimble handling that is appreciated by riders of all skill levels. This combination allows riders to focus on fun, while the dependability and low-maintenance of the KLX140G make it the ultimate companion on the trail.​​​​​

Learning riders come in all sizes, and the lightweight KLX®140G motorcycle offers full-size features for a roomy and comfortable fit to suit a wide variety of off-roaders, while still enabling a reassuring reach to the ground.

The Kawasaki KLX® family of off-road motorcycles are widely popular for their low maintenance, easy-to-ride character, and incredible capabilities while on trails. The five models consist of two engine configurations and are built to suit a variety of riders.

The KLX®140 motorcycle is available in three model variations, and is designed to provide a natural terrain experience with memories to last a lifetime. The powerful 144cc, 4-stroke, air-cooled, single-cylinder engine features an electric starter and keyless ignition. Its broad and smooth high-revving 144cc engine utilizes a manual clutch and 5-speed transmission to offer an efficient and user-friendly feel. The KLX140 uses a 17” front and 14” rear wheel, while the mid-sized KLX140L motorcycle is equipped with a 19” front and 16” rear wheels to accommodate taller riders, providing extra ground clearance on the KLX140L. The KLX140G comes equipped with full-size off-road wheels and tires, using a 21” front and 18” rear.

There’s no better motorcycle than the KLX®110 for a new rider who is looking to experience dirt for the first time. A high-tensile steel frame, 30mm telescopic fork, and single rear shock provide easy handling and maximum longevity. It also incorporates an automatic centrifugal clutch system that allows easy take off and shifting through the gears, helping the rider maintain focus on the terrain and to make the most of the 112cc single-cylinder, 4-stroke engine. The bigger KLX®110L motorcycle has a taller seat height (28.7” compared to 26.8” for the KLX110), longer suspension travel and an extra 1.9” of ground clearance.





2019 Kawasaki KLX140G Totalmotorcycle.com Key Features

LIGHTWEIGHT DIRT-FUELED FUN​

STRONG AND DURABLE 144cc AIR-COOLED ENGINE

ELECTRIC START IS EASY AND DEPENDABLE

FIVE-SPEED GEARBOX WITH MANUAL CLUTCH

DURABLE, LOW-MAINTENANCE PERFORMANCE







2019 Kawasaki KLX140G Totalmotorcycle.com Features and Benefits

Lower seat height enables a reassuring reach to the ground

Open ergonomics offer a roomy riding position

Full-size wheels featuring lightweight aluminum rims offer comfort and performance on the trail ​

​Generous ground clearance to confidently navigate trails

The lightweight chassis with full-size wheels can take on full-size rides. Go the distance on the trail with the smooth, capable engine, comfortable ride and lightweight performance of the KLX®140G motorcycle.

​Full-sized wheels increase rider comfort enabling better navigation over rocky terrain

​Ample ground clearance for navigating technical terrains

​Front and rear disc brakes for confidence-inspiring control

​Adjustable suspension to accommodate varying rider size and skill

The proven 144cc air-cooled four-stroke engine provides strong torque ideal for learning riders. Its low-maintenance requirement and rock solid durability makes it as easy to own as it is to ride.





2019 Kawasaki KLX140G – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $3699 USD
Canada MSRP Price: $4299 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU

POWER
Engine 4-stroke, 1-cylinder, SOHC, air-cooled
Displacement 144cc
Bore x Stroke 58.0 x 54.4mm
Compression Ratio 9.5:1
Fuel System Keihin PB20
Ignition Digital DC-CDI
Transmission 5-speed with wet multi-disc manual clutch
Final Drive Chain
PERFORMANCE
Front Suspension / Wheel Travel 33mm telescopic fork/7.5 in
Rear Suspension / Wheel Travel Uni-Trak® linkage system and single shock with piggyback reservoir, fully adjustable preload and
22-way rebound damping/7.9 in
Front Tire 2.75×21
Rear Tire 4.10×18
Front Brakes Disc
Rear Brakes Disc
DETAILS
Frame Type Tube, semi-double cradle
Rake/Trail 27°/4.6 in
Overall Length 78.9 in
Overall Width 31.1 in
Overall Height 44.7 in
Ground Clearance 12.4 in
Seat Height 33.9 in
Curb Weight 218.2 lb**
Fuel Capacity 1.5 gal
Wheelbase 52.4 in
Color Choices Lime Green
Warranty 6 Months
Kawasaki Protection Plus™ (optional) 12, 24, or 36 months
**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).





2019 Kawasaki KLX140G – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Displacement 144cc
Type 4-stroke, Single
Bore and stroke 58.0 x 54.4 mm
Cooling Air
Compression ratio 9.5:1
Valve system SOHC, 2 valves, screw type adjusters
Fuel system Keihin PB20 carburetor
Ignition Digital DC-CDI
Lubrication Forced lubrication (wet sump)
Starting Electric

Brakes

Front: type Single 220 mm petal disc
Front: calipers Dual-piston caliper
Rear: type Single 190 mm petal disc
Rear: calipers Single-piston caliper

Dimensions

Overall length 2,005 mm
Overall width 790 mm (31.1 in.)
Overall height 1,135 mm
Wheelbase 1,330 mm
Ground clearance 315 mm
Seat height 860 mm
Curb mass** 99 kg
Fuel capacity 5.8 litres (1.3 gal.)

Drivetrain

Transmission 5-speed
Final drive Chain
Primary reduction ratio 2.880 (72/25)
Gear ratio: 1st 2.667 (40/15)
Gear ratio: 2nd 1.895 (36/19)
Gear ratio: 3rd 1.474 (28/19)
Gear ratio: 4th 1.182 (26/22)
Gear ratio: 5th 1.000 (24/24)
Final reduction ratio 4.385 (57/13)
Clutch Wet multi-disc, manual, cable operation

Frame

Type Box section perimeter, high-tensile steel
Wheel travel: front 190 mm
Tire: front 2.75-21 45M
Wheel travel: rear 200 mm
Tire: rear 4.10-18 59M
Caster (rake) 27°
Trail 116 mm

Suspension

Suspension, front 33 mm telescopic fork
Suspension, rear Uni-Trak linkage system and single shock with piggyback reservoir, fully adjustable preload and rebound damping

Details

Warranty 6 months warranty



* The Manufacturer’s Suggested Retail Price does not include freight, pre-delivery inspection or applicable taxes. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice. The amount indicated as “Your price” may include an optional instant Mega Cash credit that is deducted from the manufacturer’s suggested retail price before taxes. This promotion is time limited and certain conditions will apply. See your dealer for complete details. Offer not available on financed purchases and cannot be combined with any other special offers. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice.

** Includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90% of capacity) and tool kit (if supplied)

‡ Power / Torque figures measured at the crankshaft.

The specifications mentioned here apply to and have been achieved by production models under standard operating conditions. We intend only to give a fair description of the vehicle and its performance capabilities but these specifications may not apply to every machine supplied for sale. Kawasaki Heavy Industries, Ltd. reserves the right to alter specifications without prior notice. Equipment illustrated and specifications may vary to meet individual markets. Available colours may vary by market.







2019 Kawasaki KLX140G – Totalmotorcycle.com European Specifications/Technical Details

TBA







2019 Kawasaki KLX140G – Totalmotorcycle.com Australian Specifications/Technical Details

TBA
