2014 Yamaha XT250 Review
2014 Yamaha XT250
The 2014 XT250 may look the same on the outside, but there are a significant number of changes on the inside. A new fuel injection system leads the list. Whether commuting to work or hitting the back country for some exploring, the ultra-reliable XT250 is a fun loving dual sport that is easy to ride. Your adventure starts here.
2014 Yamaha XT250 Total Motorcycle Key Features
Revised, 249cc, air-cooled, fuel injected, single overhead cam (SOHC), 2-valve, 4-stroke single produces easy to use power for daily commuting or exploring our back country.
4-stroke engine produces strong, predictable torque across the entire RPM range for great on- and off-road fun. It is very fuel efficient and environmentally friendly too.
2014 Yamaha XT250 Total Motorcycle Features and Benefits
• 249cc, air-cooled, fuel injected, single overhead cam (SOHC), 2-valve, 4-stroke single produces easy to use power for daily commuting or exploring the back country.
• 4-stroke engine produces strong, predictable torque across the entire RPM range for great on- and off-road fun. It is very fuel efficient and environmentally friendly too.
• Convenient, no hassle push-button electric starting.
• 2-valve cylinder head. Straight design intake and exhaust tracts provide excellent cylinder filling efficiency for strong low and mid-range power.
• Single overhead camshaft is designed to provide good low and mid rpm torque. The conventional rocker arm design means fast, easy valve clearance adjustments.
• Automatic cam chain tensioner reduces mechanical engine noise and maintenance.
• Ceramic composite cylinder “bore” is a “liner less” design with the ceramic coating sprayed directly on the aluminum block. Benefits include; excellent heat dissipation for consistent power delivery, reduced weight and reduced friction.
• 74mm lightweight forged piston provides fast throttle response, excellent durability and less mechanical vibration.
• Lightweight ball bearing mounted crankshaft for excellent durability and fast engine response.
• Internal engine counter balancer reduces engine vibration to maximize rider comfort.
• Multi plate wet type clutch is utilized. Clutch lever pull is light and easy.
• Easy access element type oil filter. Oil filter housing is located on the right hand side of the engine for easy servicing.
• Maintenance-free TCI (transistor controlled) ignition controls the ignition mapping and produces a hot spark for fast, sure starts.
• 16 bit ECU (electronic control unit) controls the fuel injection process.
• 33mm, Mikuni throttle body fuel injection system. This system is a return-less FI system with TPS (throttle position sensor). It provides excellent throttle response, great fuel economy, reduced emissions and a choke-free design.
• A 10-hole fuel injector is used and provides a 22 degree spray pattern for excellent fuel atomization and strong performance.
• 235 watt ACM (alternating current magneto) is used to power the fuel injection system plus the reminder of the electrical components.
• 2.8 litre air box is located under the seat and utilizes an easy to access viscous (paper type) air filter.
• Wide-ratio, 5-speed transmission and manual clutch are well suited to the engine’s power output for easy, relaxed riding.
• Steel exhaust system with heat shields on both the header pipe and muffler protect rider and passenger from accidental contact. Exhaust note is quiet and environmentally friendly. A US Forestry Approved spark arrestor protects Mother Nature.
• Air Induction System (AIS) injects fresh oxygen into the exhaust to insure complete combustion thereby reducing harmful hydro carbon and carbon monoxide (HC & CO) exhaust emissions.
• Semi-double cradle steel frame and an overall “wet” weight of only 132kg (291 lbs.), make the XT250 one of the lightest, most compact dual purpose machines on the market.
• Rugged, box section steel swing arm is fitted with easy-to-use eccentric chain adjusters
• 35mm KYB fork with 225mm (8.9″) of wheel travel soaks up the rough stuff, both on-road and off. Rubber boots protect fork seals and tubes from dirt and grit damage.
• Lightweight aluminium lower triple clamp reduces weight.
• Link Monocross rear suspension features a spring preload adjustable shock. The adjustment range is 20mm (0.8″). Rear wheel travel is 180mm (7.1″)
• Low seat height of 810mm (31.9″) creates a low centre of gravity for added manoeuvrability and inspires confidence by allowing most riders to put both feet firmly on the ground.
• 285mm (11.2″) of ground clearance enhances off road use.
• 245mm front disc brake with twin piston Nissin caliper provides plenty of stopping power.
• 203mm rear disc brake is squeezed by a single piston Nissin caliper with rugged plastic caliper protector and an integrated (or 1 piece) rear master cylinder.
• 9.6 litre fuel tank features an in tank electric fuel pump. The low fuel warning light will come on with 2 litres of fuel remaining.
• 21″ front and 18″ rear lightweight DID alloy wheels are extremely durable and reduce unsprung weight for enhanced suspension performance.
• Long, YZ-inspired seat creates a balanced riding position and provides roomy comfort for both rider and passenger. The seat features a “pebble style” seat cover.
• Frame-mounted passenger footpegs provide two-up riding capability.
• Powerful, 60/55-watt, enduro-style, halogen headlight
• Small fairing reduces wind buffeting at highway speeds
• Compact digital instrumentation includes: speedometer, odometer, dual tripmeters and a clock. Other features include low fuel warning light, engine warning light and self-diagnosis function.
• Serrated, folding steel footpegs
• Folding gear shift and rear brake lever tip
• Steering and helmet locks
• Locking fuel cap
• Convenient passenger hand rails
• Durable “O” ring chain
• Dependable, low-maintenance, sealed battery
• Flexible turn signals
• Easy-to-use, push-to-cancel turn signals
• Rubber “boots” on brake and clutch levers help reduce mud and dirt damage.
2014 Yamaha XT250 – Total Motorcycle USA Specifications/Technical Details
US MSRP Price: $NA
Model not available.
2014 Yamaha XT250 – Total Motorcycle Canadian Specifications/Technical Details
Canada MSRP Price: $5,099.00 CDN
Air-cooled, SOHC, 2-valve, single
BORE AND STROKE
74 x 58mm
2.0kg-m (14.5 ft-lb)@ 6,500 rpm
Mikuni 33mm throttle body fuel injection
ESTIMATED FUEL CONSUMPTION*
30.5kpl / 87mpg (Imp.)
IGNITION / STARTING
TCI / Electric Start
“O” ring chain
35mm fork / 225mm (8.9″) travel
Adjustable Link Monocross / 180mm (7.1″) travel
245mm disc / twin piston
203mm disc / single piston
2.75 x 21
9.6 litres (2.1 imp. gallons)
132kg (291 lb)
2014 Yamaha XT250 – Total Motorcycle UK/Europe Specifications/Technical Details
UK/European MSRP Price: £NA.
Details to follow shortly.
2014 Yamaha XT250 – Total Motorcycle Australian Specifications/Technical Details
AU MSRP Price: See dealer for pricing AUD
Details to follow shortly.
Specifications, features and prices to change by manufacturer without notice. All information correct as of posted date.
