2016 Honda CRF125F Review

2016 Honda CRF125F on www.Totalmotorcycle.com

Sized Right For Fun…

Few things in life are as much pure fun as a dirtbike, as long as it’s the right-sized dirtbike. That’s why Honda builds so many differently sized models, and one of our best is the CRF125F. The next size up from our CRF110F, it’s the perfect choice for both young riders and smaller adults. Loaded with features designed to make trail riding a relaxing, no-hassle experience, it’s also pure Honda when it comes to reliability and durability.

That means you get to concentrate on having a good time rather than trailside repairs or a bike that was designed by cutting corners. And when it comes to looks, the CRF125F takes its styling cues right from our full-on motocross bikes like our CRF450R and CRF250R. An electric starter makes it easy to get underway, while a four-speed transmission gives you all the control of a full-sized bike.

Looking for something just a little bigger? There’s even a big-wheel version for taller riders.

Be A Responsible Rider: All parents need to consider their youngsters’ age, size, ability and maturity before allowing them to ride. Obtain a copy of “Off-Road Safety Tips” from your local Honda Dealer.


Electric Starter

Turn a key, push a button—that’s all it takes to get the CRF125F started. Add in a generous dose of Honda reliability and you’ll find the CRF125F is super easy to own.


Sized Right For Fun

With its 125cc air-cooled, single-overhead-cam engine and four-speed transmission, the CRF125F will fit a wide range of riders. It has enough power for teens and small adults without being intimidating for younger riders.


Stopping Power

Just because it’s a small bike doesn’t mean we scrimped on the details—just the opposite, in fact: The CRF125F’s front disc brake is a perfect example. It’s a big-bike feature that’s pure Honda.




2016 Honda CRF125F www.Totalmotorcycle.com Key Features

Ready when you are.

Pure Honda Through And Through.

Sure, the 2016 Honda CRF125F is loaded with features, especially for such a fun bike: electric start, front disc brake, Pro-Link® rear suspension, powerful 125cc engine with a broad powerband. But there’s something more, and it’s important: Nobody else can touch Honda’s reputation for build quality, reliability and long-term value. After all, a fun bike is only fun if it’s reliable, and you can bet that’s one feature your new CRF125F will offer in spades.






2016 Honda CRF125F www.Totalmotorcycle.com Features and Benefits

Engine / Drivetrain

Easy to start

Convenient electric starter makes starting a breeze.



Smooth from stand-still to start

Heavy-duty manual clutch with light, smooth, progressive engagement



Smooth-shifting transmission

Durable, smooth-shifting four-speed transmission.



Designed to compete

Lightweight, upswept, competition-type exhaust system utilizes a quiet muffler/spark arrester.



Easy starts in any gear

Primary kickstarting for easy starts in any gear.



No engine oil contamination

Closed crankcase vent system safeguards against engine oil contamination.



Light throttle action

20 mm carb with light throttle action



Simplified maintenance

Ultra-reliable electronic ignition simplifies maintenance.



Ideal for beginners

Durable, simple, low-maintenance, 124.9 cc air-cooled single-cylinder 4-stroke engine develops the smooth, tractable power that’s ideal for beginners.




Chassis / Suspension

Easy-to-modulate brakes

Powerful front disc and lightweight rear drum brakes are easy to modulate.



Simplified maintenance

Lightweight, screw-type drive chain adjusters simplify maintenance.



Excellent grip & longevity

Knobby tires fitted to 17-inch front and 14-inch rear rims offer excellent grip and long life.



Excellent wheel travel

Pro-Link, single-shock rear suspension with box-section swingarm offers 114 mm (4.5 in.) of wheel travel.



Compliant suspension travel

31 mm leading-axle front fork offers 140 mm (5.5 in.) of compliant suspension travel.



Ridgid & durable for off-roading

Lightweight, high-tensile steel frame is rigid, durable and offers ideal geometry for recreational off-road riding.




Additional Features

Durable

Durable steel sprockets.



Safeguards the important parts

Fork boots help protect stanchion tubes and fork seals.



High-quality controls

High-quality controls feature comfortable grips, and adjustable front brake lever.



Undercarriage protection

Generous ground clearance and rugged skidplate for undercarriage protection.



Extended range

Large-capacity fuel tank and thrifty 4-stroke engine for extended range.



Durable body

Durable body components.



Inspired graphics

CRF-R-inspired graphics.









2016 Honda CRF125F – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2799 USD

ENGINE
Engine Type 124.9cc air-cooled single-cylinder four-stroke
Bore And Stroke 52.4mm x 57.9mm
Compression Ratio 9.0:1
Valve Train SOHC; two-valve
Induction 20mm piston-valve carburetor
Ignition DC-CDI


DRIVE TRAIN
Transmission Four-speed
Final Drive 13T/46T


CHASSIS / SUSPENSION / BRAKES
Front Suspension 31mm telescopic fork; 5.5 inches of travel
Rear Suspension Pro-Link single-shock; 4.5 inches of travel
Front Brake 220mm hydraulic disc
Rear Brake Drum
Front Tire 70/100-17
Rear Tire 90/100-14


DIMENSIONS
Rake 25°30′ (Caster Angle)
Trail 81mm (3.2 inches)
Wheelbase 48.0 inches
Seat Height 28.9 inches
Curb Weight 192 pounds (Includes all standard equipment, required fluids and full tank of fuel-ready to ride)
Fuel Capacity 1.1 gallons, including 0.2-gallon reserve
Ground Clearance 8.5 Inches


OTHER
Emissions Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.
Available Colors Red
Model Id CRF125F


FACTORY WARRANTY INFORMATION
Duration Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.









2016 Honda CRF125F – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $3099 CDN


Engine & Drivetrain


Engine Type

Air-cooled, single-cylinder, four stroke


Displacement

124.9 cc


Bore & Stroke

52.4 mm x 57.9 mm


Compression Ratio

9.0:1


Valve Train

SOHC; two-valve


Fuel Delivery

20mm piston-valve carburetor


Transmission

Four-speed


Final Drive

Chain, 13T/46T


Chassis & Suspension


Front Suspension

31 mm leading-axle fork; 140 mm (5.5 in.) travel


Rear Suspension

Pro-Link single shock; 114 mm (4.5 in.) travel


Dimensions & Additional Information


Tires

Front: 70/100-17, Rear: 90/100-14


Brakes

Front: 220 mm hydraulic disc, Rear: Drum


Ground Clearance

216 mm (8.5 in.)


Seat Height

734 mm (28.9 in.)


Wheelbase

1,219 mm (48.0 in.)


Curb Weight

87.1kg (192 lbs.)


Fuel Capacity

4.2 litres


Colour

Red







2016 Honda CRF125F – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £1999 GBP (On The Road inc 20% Vat)

Engine

Bore × Stroke (mm) 52.4 x 57.9
Carburation Carburetor
Compression Ratio 9.5:1
Engine Displacement (cm³) 124.9
Engine Type Air cooled 4-stroke SOHC single
Ignition System Capacitor Discharge (CDI)
Max. Power Output 6.6 kW / 7,000 rpm
Max. Torque 10.2 Nm / 4,500 rpm
Starter Kick

Wheels

Brakes Front 220mm Hydraulic Disc
Brakes Rear 95mm leading/trailing drum
Suspension Front 31mm telescopic fork
Suspension Rear Single shock, Pro-Link
Tyre Size Front 70/100-17
Tyre Size Rear 90/100-14
Wheels Front Wire spoke
Wheels Rear Wire spoke

Dimensions and Weights

Caster Angle 27°
Dimensions (L×W×H) (mm) 1,770 x 740 x 1,010
Frame type Diamond; steel
Fuel Capacity (Litres) 4.3 litres
Ground Clearance (mm) 219
Kerb Weight (kg) 88
Seat Height (mm) 735
Trail (mm) 81
Wheelbase (mm) 1220

Transmission

Clutch Wet, multiplate
Final Drive Chain
Gearbox 4-speed



Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S., European and/or Canadian models.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
