2016 KTM 690 Duke

2016 KTM 1290 Duke

2016 KTM 690 Duke

2016 KTM 690 Duke Review

2016 KTM 690 Duke on www.Totalmotorcycle.com

Smooth Criminal…

Two decades ago, the original Duke was nothing short of revolutionary. KTM’s first single-cylinder street bike grew into a cult classic, adding extreme fun to a raw and radical concept. In 2016, the fully revised 690 DUKE stays faithful to its ancestor’s ways, but adds future-proof refinements: impressive smoothness, sophisticated electronics, improved ergonomics and a good old power boost over last year’s model. This firmly cements the world’s strongest single-cylinder production motorcycle at the cutting edge of engineering. Speaking of which: carving corners has never been more fun, thanks to its revised fork offset. Long live the Duke!

2016 KTM 690 Duke www.Totalmotorcycle.com Key Features

See Below

2016 KTM 690 Duke www.Totalmotorcycle.com Features and Benefits

A polished powerhouse

Engine
The brilliant LC4 showcases twenty-four carats of fun. From the trademark 690 cm³ thumper, the engineers have now extracted a whopping 73 hp (54 kW) and 74 Nm of torque, making light work of the equally lightweight 690 Duke. How it happened? They completely reworked the cylinder head, inserted a new, ultra light and extremely strong piston and connection rod, rerouted the air intake through a resonator chamber and provided the new crankshaft with new sleeve bearings. As a result, the powerband now is a thousand rpm wider, which means an even more uniform power delivery, especially in the mid to high rev range. Twin ignition featuring plug-selective mapping, rock solid but featherweight internals and optimized intake and exhaust systems cultivate this massive mono to be as strong as it is smooth, assisted by an advanced ride-by-wire system with three riding modes, which guarantees great refinement as well as low fuel consumption and emission figures. You’re green, while they’re green with envy. And you haven’t even begun mentioning upmarket goodies like a standard slipper clutch.

New cylinder head
Inside the new cylinder head, the exhaust valves are actuated by roller rockers while the camshaft powers the intake valves. Therefore, the ignition timings can be controlled with far greater accuracy. The result is more peak power over a broader rev range. Win-win!

Second balancer shaft
In a free-revving firecracker like this, you want to smooth things out a bit. That’s why the camshaft serves as a bonus balancer shaft, nipping annoying vibrations in the bud.

Engine management
The electronic engine management system lives to make the LC4 shine. Twin ignition with individual mappings for each spark plug ensures that your precious fuel is always burned to perfection, irrespective of load and engine speed. And then there is genuine ride-by-wire, in other words: Electronically controlled throttle valve actuation without any mechanical linkage. You’d be forgiven for thinking it runs on cream. Whipped cream, that is.

Awesome cornering

FRAME AND SWINGARM
The 9 kg tubular trellis frame made from chrome-molybdenum steel and the equally lightweight, smoking hot swingarm, die-cast in aluminum, impress with extreme levels of torsional stiffness, providing the 148,5 kg Duke with excellent tracking stability and a continuous flow of information to the rider. New triple clamps lower the fork offset, which underlines this characteristic even further. You’ll notice.

SUSPENSION
The upside-down fork on the Duke (with a 43 mm diameter) and pivot-arm articulated pressurized-gas monoshock, both by WP, excel with flawless tuning and a broad spectrum of use for all demands, from relaxed cruising to hammering around on closed circuits. The options are limitless, and so is your lean angle.

BRAKES
The Duke’s extremely powerful, precise and easily applied Brembo® brakes impress with outstanding controllability. At the front wheel, a radially-mounted, four-piston, fixed brake caliper bites onto a floating 320 mm disc. Thanks to a forgiving setup of the two-channel ABS, the huge potential of these brakes can always be fully utilized.

Full-loving electronics

RIDE MODE TECHNOLOGY
Three different ride modes (‘Sport’, ‘Street’ and ‘Rain’) not only moderate the power delivery, but also tell the traction control system how crazy the rear wheel can get, depending on the situation. ‘Sport’ and ‘Rain’ ride modes are available as optional extra in the ‘Track pack’.

TRACTION CONTROL (TC)
In relation to the selected ride mode, traction control allows for different amounts of rear wheel slippage. From being in full control in the rain, to mastering controlled power slides out of corners: It’s all within the push of a button. TC is available as an integrated part of the optional ‘Track pack’.

MOTOR SLIP REGULATION (MSR)
MSR avoids rear wheel lock-up when you chop the throttle or drop the clutch on downshifts. Feeling lucky? Just turn it off entirely, so you can get your slide on like a boss. Just as TC, MSR is offered as an optional extra or as an integrated part of the optional ‘Track pack’.

ABS
The dual-circuit ABS system with 9M+ modulator, fine-tuned in cooperation with Bosch, offers total protection against over-braking, while maintaining the full effect and glorious feedback of a genuine sports brake thanks to hypersensitive sensors. This ABS system, weighing no more than one kilogram, therefore allows extremely sporty braking, while actively preventing loop-outs. And just so you know: It’s disengageable. So stoppies are still allowed.

SUPERMOTO MODE
Expert riders will love the added fun-factor (and extra racetrack safety) of this optional mode, activated at the push of a button. When engaged, the system will only control the front brake. Rear brake pressure is entirely up to the rider’s right foot. And its party mood.

TFT COLOR DISPLAY
A multicolor combination of relevant information, presented in a clear-cut, uncluttered way. This shot of data of course includes speed, revs and the current gear, but you’ll also find coolant temperature, fuel status, time, date and ambient temperature on there. As you rev the engine, the display bars even change color, either spurring you on or telling you to back off when the engine’s still cold. The display also automatically adapts its illumination to the ambient light. Furthermore, you can access an overview of the selected riding options and adjust them on the go via four illuminated keys on the left handlebar. Knowledge is power, right?

One for all

MASS CENTRALIZATION
The Duke does not only impress with its low weight and perfect chassis geometry; the centralization of weight – for example, by positioning the brushed stainless steel pre-silencer under the engine – also contributes to its playful handling and razor-sharp precision.

ERGONOMICS
Despite its pronounced lust for cornering, the 690 Duke also presents versatile real-world capabilities. On a daily basis, particularly the new two-piece seat will prove a valuable friend. It’s comfortable and spacious, while still being set up for all dynamic riding situations. The seating position and freedom of movement behind the wide aluminum handlebar provide perfect support for controlling the bike both in traffic hell as well as cornering heaven. Workday commute or weekend blast: the 690 Duke has your back.

A2 ALLOWED
A restricted power version is available for those riders who have just started their two-wheeled career. But restricted power doesn´t necessary mean restricted fun: thanks to its lightweight and dynamic chassis, the KTM 690 Duke is the perfect playmate for all ages. Regardless of your experience level, the 690 Duke is your license to thrill.

EURO IV HOMOLOGATED
Thanks to its optimized intake and exhaust systems, the new LC4 engine even complies with the Euro IV emission control standards. A first in KTM’s history.

COLORS AND GRAPHICS
The 2016 Duke is instantly recognizable by its fresh colors with new, racy graphics and a jet-black frame. Because looks matter, don’t they? .

2016 KTM 690 Duke – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See Local Dealer for Pricing in USD

Engine
” Design
1-cylinder, 4-stroke engine
” Displacement
690 cm³
” Bore
105 mm
” Stroke
80 mm
” Power in KW
54 kW
” Starter
Electric starter
” Lubrication
Forced oil lubrication with 2 oil pumps
” Transmission
6-speed
” Primary drive
36:79
” Secondary gear ratio
16:40
” Cooling
Liquid cooled
” Clutch
APTC(TM) slipper clutch, hydraulically actuated
” EMS
Keihin EMS with RBW, twin ignition
Chassis
” Frame design
Chromium-Molybdenum steel trellis frame, powder coated
” Front suspension
WP upside-down Ã˜ 43 mm
” Rear suspension
WP shock absorber with Pro-Lever linkage
” Suspension travel (front)
135 mm
” Suspension travel (rear)
135 mm
” Front brake
Brembo four-piston radial fixed calliper, brake disc
” Rear brake
Brembo single-piston floating calliper, brake disc
” Front brake disc diameter
320 mm
” Rear brake disc diameter
240 mm
” ABS
Bosch 9M+ two-channel ABS (disengageable, optional Supermoto mode)
” Chain
X-Ring 5/8 x 1/4″
” Steering head angle
63.5 °
” Wheelbase
1466 ± 15 mm
” Ground clearance
192 mm
” Seat height
835 mm
” Tank capacity (approx.)
14 l

2016 KTM 690 Duke – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See dealer for pricing in CDN

2016 KTM 690 Duke – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £7699 GBP (On The Road inc 20% Vat)

*Starting at MSRP is the manufactured suggested price and excludes delivery, setup, tax, title, license, and additional fees and expenses. Bikes may be shown with optional accessories. Final sale price determined by an authorized dealer. Specifications and MSRP are subject to change.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
