2016 Yamaha VMAX Review

2016 Yamaha VMAX on www.Totalmotorcycle.com

Brawn meets brains. The iconic VMAX features a 1679cc V4, light chassis, slipper clutch, and wave-style brakes for huge performance & style…

ASPHALT BUCKLING POWER

Brawn meets brains. The iconic VMAX features a 1679cc V4 for huge performance & style.


Conquer Road

Unlike any other motorcycle available today, the VMAX is truly in a class of its own. The awesome acceleration and muscular beauty combines with sporty handling and Yamaha’s electronic engine management technologies to offer an incredibly exhilarating riding experience.

/// Power
Liquid-cooled, 1,679cc, DOHC, 16-valve, 65°, V-4 engine has no equal in its class. The compact engine design has allowed the engineers to place the engine in the “sweet spot” of the frame to optimize handling.


/// Performance
DOHC 4-valve “pent roof” cylinder head design provides optimum breathing efficiency for incredible engine performance. Valve actuation is via under bucket shims. Compression ratio is 11.3:1








2016 Yamaha VMAX www.Totalmotorcycle.com Key Features

Power Unrelenting
The ultimate power cruiser delivers unmatched performance from its 65-degree, four-valves-per-cylinder, 1679cc V-four—producing eye opening amounts of perfectly controllable acceleration, flowing from a compact engine that looks as powerful as it is.
•Advanced Ride-by-Wire Throttle
Downdraft four-bore fuel injection with YCC-I® intake technology and YCC-T® fly-by-wire throttle provide awesome acceleration throughout the broad powerband.
•High-Tech Aluminum Chassis
Lightweight aluminum chassis puts the engine low and forward for mass centralization, resulting in a machine designed to handle curves as well as straightaways.
•Performance Technology
Borrowing liberally from advanced sportbike technology, Vmax® features a slipper clutch, wave-style brake discs, ABS, and complete suspension adjustability front and rear.
•Unmatched Fit and Finish
Functionality and forward-thinking style uniquely combine with features like oxidized-titanium-coated 52mm front fork tubes, magnesium engine side covers, fluorinated polyethylene fuel tank and the organic electroluminescence multifunction display.




2016 Yamaha VMAX www.Totalmotorcycle.com Features and Benefits

ENGINE

Power Unrelenting
The thunderous 1679cc, 65-degree, liquid-cooled, fuel-injected four valves-per-cylinder, DOHC engine pumps out astonishing power to reinvent the VMAX legend. You’ve never experienced anything like it.
•Variable Length Intakes
The superbike-proven Yamaha Chip Controlled Intake (YCC-I) switches nearly instantaneously between 150mm and 54mm height intake funnels as needed for a broad powerband that delivers optimum performance at any rpm.
•Ride-by-Wire Throttle
Yamaha Chip Controlled Throttle (YCC-T), the fly-by-wire system, delivers optimum acceleration under all conditions.
•Race-derived Combustion
Engine combines four-valve technology with a high 11.3:1 compression ratio, forged aluminum pistons and NGK® Iridium spark plugs with R1-type direct ignition coils to extract maximum horsepower from the fuel charge.
•Compact Cam Drive
Cams are driven by a combined chain and gear system to precisely control valves while keeping cylinder heads remarkably compact for such a large displacement engine.
•Slipper Clutch
Hydraulically activated clutch includes racetrack-proven ramp-type slipper clutch system that makes braking from speed while downshifting smoother.
•Robust Five Speed Transmission
Five-speed transmission has superbly spaced gear ratios to take full advantage of the engine’s awesome power in straight-line acceleration or through the canyons.
•Unique Shaft Drive
Delivering this power cruiser’s muscle to the street means a beefy shaft drive. Special shaft design includes two cross joints to accommodate the fat 200/50R18 rear tire.
•High Volume Cooling
The high-performance engine is cooled by two radiators for efficiency and clean looks. Lubrication is via a simple, reliable wet sump system.
•V-four Voice
Four-into-one-into-two-into-four exhaust system with EXUP® delivers a broad, seamless powerband with the right VMAX look… and a sound unlike anything on two wheels.
•Custom Styling
The iconic VMAX aluminum intake covers are hand buffed by craftsmen for superb quality and individuality.




CHASSIS / SUSPENSION

High-Tech Aluminum Chassis
The chassis is light and compact, with a cast aluminum main frame, Controlled-Fill die-cast and extruded aluminum rear frame and cast aluminum swingarm.
•Huge, High-tech Fork
Cartridge-damper-type front forks have substantial 52mm inner tubes with oxidized titanium coating. Forks have both compression and rebound damping adjustability plus spring preload.
•Fully Adjustable Remote Reservoir Shock
Link-type Monocross® rear suspension has a remote reservoir and features compression and rebound clickers plus remote preload adjustment.
•Class Leading Brakes
VMAX uses Brembo® master cylinders, the front with radial pump master cylinder. Large 320mm wave-style dual front discs are matched to radial-mount monoblock 6-piston calipers. On the rear wheel, there’s a 298mm wave design disc and single-piston caliper. These high-tech brakes also incorporate advanced ABS.
•Beefy Handlebar
Tapered handlebar provides a muscular 1-1/8” diameter look at the triple clamp while using conventionally sized controls.
•Grippy Radial Tires
18-inch radial tires, 120/70R18 front and 200/50R18 rear, are mounted on cast aluminum five-spoke wheels.
•Underseat Fuel Tank
For mass centralization that contributes to the bike’s lean looks, the 4-gallon fuel tank is mounted under the seat, with the filler under the rider’s backrest.





ADDITIONAL FEATURES

Calculating Power
The Electronic Control Unit (ECU) uses three microprocessors to control fuel injection, ignition, YCC-T, YCC-I, meters and other electrical components.
•Drag-style Instruments
The instrument panel includes an analog, step-motor driven tachometer, and digital speedometer with LED indicator lights. Prominent LED shift timing indicator adds to the performance character of the VMAX.
•OLED Display
Organic electroluminescence multifunction display provides a more precise display vs. LCD and includes clock, fuel meter, trip meter with fuel reserve trip meter, transmission gear position, coolant temperature, stop watch, and more.
•Bright Lighting
H4 60/55W headlight provides excellent visibility and distinctive style, while the trick-looking LED taillight is light, bright and highly efficient.







2016 Yamaha VMAX – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $17,990 – Galaxy Blue – Available from November 2015

Engine Type 102-cubic-inch (1679cc) liquid-cooled 65° V-four,
DOHC; 16 valves
Bore x Stroke 90.0mm x 66.0mm
Compression Ratio 11.3:1
Fuel Delivery Fuel Injection with YCC-T and YCC-I
Ignition TCI: Transistor Controlled Ignition
Transmission 5-speed, multiplate slipper clutch
Final Drive Shaft
Suspension / Front 52mm telescopic cartridge fork w/oxidized
titanium coating. Fully adjustable preload,
compression and rebound; 4.7 in travel
Suspension / Rear Single shock w/remote reservoir and remote
adjustable for preload, compression and rebound;
4.3 in travel
Brakes / Front Dual 320mm wave-type discs; radial mount 6-
piston calipers, Brembo® radial pump master
cylinder
Brakes / Rear 298mm wave-type disc, single-piston caliper and
Brembo® master cylinder
Tires / Front 120/70R18
Tires / Rear 200/50R18
L x W x H 94.3 in x 32.3 in x 46.9 in
Seat Height 30.5 in
Wheelbase 66.9 in
Rake (Caster Angle) n/a
Trail n/a
Ground Clearance n/a
Fuel Capacity 4.0 gal
Fuel Economy 27 mpg
Wet Weight 683 lb / CA model 686 lb
Warranty 1 Year (Limited Factory Warranty)


** Fuel economy estimates are based on US EPA exhaust emission certification data obtained by Yamaha.
Your actual mileage will vary depending on road conditions, how you ride and maintain your vehicle,
accessories, cargo and operator/passenger weight.
*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as
applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is
useful in making real-world comparisons with other models.







2016 Yamaha VMAX – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: Starting from $22999 CDN

/// ENGINE
ENGINE
Liquid-cooled, DOHC, 16-valves (4-valves/cyl), 65 degree V-4
DISPLACEMENT
1679cc
BORE AND STROKE
90 x 66mm
COMPRESSION RATIO
11.3:1
MAXIMUM TORQUE
17 kg-m (123 ft-lb) @ 6,500 rpm
ENGINE MANAGEMENT
YCC-T, YCC-I
FUEL DELIVERY
Mikuni 48mm fuel injection
ESTIMATED FUEL CONSUMPTION±
11.4kpl / 32mpg (Imp.)
LUBRICATION
Wet sump
IGNITION / STARTING
TCI / Electric Start
TRANSMISSION
5-speed (with slipper clutch)
FINAL DRIVE
Shaft


/// CHASSIS
SUSPENSION (FRONT)
Fully adjustable 52mm cartridge fork
SUSPENSION (REAR)
Fully adjustable Link Monocross
BRAKES (FRONT)
Dual 320mm discs with ABS / radial mount 6-piston calipers
BRAKES (REAR)
298mm disc with ABS / single piston caliper
TIRES (FRONT)
120/70R18
TIRES (REAR)
200/50R18


/// CRITICAL DATA
LENGTH
2,395mm (94.3″)
WIDTH
820mm (32.3″)
HEIGHT
1,190mm (46.9″)
WHEELBASE
1,700 mm (66.9″)
RAKE / TRAIL
31° / 148mm (5.8″)
GROUND CLEARANCE
140mm (5.5″)
SEAT HEIGHT
775mm (30.5″)
FUEL CAPACITY
15 litres
WET WEIGHT
310 kg (683 lb)
COLOUR(S)
Dark Purplish Blue Metallic


Specifications, appearance, and price of product are subject to change without notice.
* MSRP does not include freight, PDI (Pre Delivery Inspection), pre-rigging (boats), or taxes. Dealer may sell for less. See your local dealer for out the door pricing.
± Fuel economy estimates are based on US EPA exhaust emission certification data obtained by Yamaha and converted into Canadian measurements. Your actual mileage will vary depending on road condition, how you ride, maintain your vehicle, accessories, cargo and operator/passenger weight.







2016 Yamaha VMAX – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: See Dealer for pricing in GBP (On The Road inc 20% Vat)

Not Available

*Starting at MSRP is the manufactured suggested price and excludes delivery, setup, tax, title, license, and additional fees and expenses. Bikes may be shown with optional accessories. Final sale price determined by an authorized dealer. Specifications and MSRP are subject to change.
