2018 Honda CB500X Review on Total Motorcycle:

Big adventure doesn’t always call for a big motorcycle, as many of the most serious two-wheel explorers insist on minimum weight and maximum maneuverability. For these aficionados, it’s hard to beat Honda’s CB500X. Powered by a fuel-injected, 471cc parallel-twin engine, the CB500X offers features like an upright riding position, good wind protection and ample suspension travel, which make it equally adept for adventure or commuting.









2018 Honda CB500X Totalmotorcycle.com Key Features









2018 Honda CB500X Totalmotorcycle.com Features and Benefits

Engine/Drivetrain
•DOHC, liquid-cooled 471cc parallel-twin engine has good torque and a broad spread of power for maximum versatility.

Chassis/Suspension
•Bodywork with aggressive lines for a powerful, adventure-ready look.
•LED headlights, taillight for a unique look and great visibility.
•Tall, adjustable windscreen provides ample wind protection.
•User-friendly hinged fuel-tank cap.
•Roomy seat with a step design and 32-inch height provides an unrestricted rider position and room for a passenger.
•Front brake lever has a five-step adjustment mechanism and is adaptable to suit rider preference.
•Fork has external preload adjuster dial to allow adjusting to the situation (i.e., riding with a passenger or cargo).
•Optional Anti-lock Braking System (ABS) allows smooth, controlled stops.

One-year, transferable, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.
•Meets current EPA and CARB standards
•California version differs slightly due to emissions equipment







2018 Honda CB500X – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ USD


2018 HONDA CB500X
SPECIFICATIONS
Model CB500X ABS CB500X
ENGINE
Type 471cc liquid-cooled 20º parallel twin
Valve Train DOHC; four valves per cylinder
Bore x Stroke 67.0mm x 66.8mm
Compression Ratio 10.7:1
Induction PGM-FI fuel injection w/ 34mm throttle bodies
Ignition Computer-controlled digital transistorized w/ electronic advance
Starter Electric
Transmission 6-speed manual
Clutch Multiplate wet
Final Drive 15T/41T; O-ring-sealed chain
SUSPENSION
Front 41mm telescopic fork; 5.5 in. travel
Rear Pro-Link® single shock w/ nine-position spring preload adjustability; 4.7 in. travel
BRAKES
Front Single two-piston caliper w/ 320mm wave disc; ABS Single two-piston caliper w/ 320mm wave disc
Rear Single one-piston caliper w/ 240mm wave disc; ABS Single one-piston caliper w/ 240mm wave disc
TIRES
Front 120/70-17
Rear 160/60-17
MEASUREMENTS
Rake (Caster Angle) 26º 5′
Trail 109mm (4.29 in.)
Length 81.9 in.
Width 29.5 in.
Height 45.1 in.
Ground Clearance 6.69 in.
Seat Height 31.9 in.
Wheelbase 55.9 in.
Fuel Capacity 4.6 gal.
Color Force Metallic Silver
Curb Weight* 432 lbs. 428 lbs.
*Includes all standard equipment, required fluids and full tank of fuel—ready to ride
Meets current EPA standards
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment
Specifications subject to change







2018 Honda CB500X – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ CDN


2018 HONDA CB500X
SPECIFICATIONS
Model CB500X ABS CB500X
ENGINE
Type 471cc liquid-cooled 20º parallel twin
Valve Train DOHC; four valves per cylinder
Bore x Stroke 67.0mm x 66.8mm
Compression Ratio 10.7:1
Induction PGM-FI fuel injection w/ 34mm throttle bodies
Ignition Computer-controlled digital transistorized w/ electronic advance
Starter Electric
Transmission 6-speed manual
Clutch Multiplate wet
Final Drive 15T/41T; O-ring-sealed chain
SUSPENSION
Front 41mm telescopic fork; 5.5 in. travel
Rear Pro-Link® single shock w/ nine-position spring preload adjustability; 4.7 in. travel
BRAKES
Front Single two-piston caliper w/ 320mm wave disc; ABS Single two-piston caliper w/ 320mm wave disc
Rear Single one-piston caliper w/ 240mm wave disc; ABS Single one-piston caliper w/ 240mm wave disc
TIRES
Front 120/70-17
Rear 160/60-17
MEASUREMENTS
Rake (Caster Angle) 26º 5′
Trail 109mm (4.29 in.)
Length 81.9 in.
Width 29.5 in.
Height 45.1 in.
Ground Clearance 6.69 in.
Seat Height 31.9 in.
Wheelbase 55.9 in.
Fuel Capacity 4.6 gal.
Color Force Metallic Silver
Curb Weight* 432 lbs. 428 lbs.
*Includes all standard equipment, required fluids and full tank of fuel—ready to ride
Meets current EPA standards
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment
Specifications subject to change







2018 Honda CB500X – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)


2018 HONDA CB500X
SPECIFICATIONS
Model CB500X ABS CB500X
ENGINE
Type 471cc liquid-cooled 20º parallel twin
Valve Train DOHC; four valves per cylinder
Bore x Stroke 67.0mm x 66.8mm
Compression Ratio 10.7:1
Induction PGM-FI fuel injection w/ 34mm throttle bodies
Ignition Computer-controlled digital transistorized w/ electronic advance
Starter Electric
Transmission 6-speed manual
Clutch Multiplate wet
Final Drive 15T/41T; O-ring-sealed chain
SUSPENSION
Front 41mm telescopic fork; 5.5 in. travel
Rear Pro-Link® single shock w/ nine-position spring preload adjustability; 4.7 in. travel
BRAKES
Front Single two-piston caliper w/ 320mm wave disc; ABS Single two-piston caliper w/ 320mm wave disc
Rear Single one-piston caliper w/ 240mm wave disc; ABS Single one-piston caliper w/ 240mm wave disc
TIRES
Front 120/70-17
Rear 160/60-17
MEASUREMENTS
Rake (Caster Angle) 26º 5′
Trail 109mm (4.29 in.)
Length 81.9 in.
Width 29.5 in.
Height 45.1 in.
Ground Clearance 6.69 in.
Seat Height 31.9 in.
Wheelbase 55.9 in.
Fuel Capacity 4.6 gal.
Color Force Metallic Silver
Curb Weight* 432 lbs. 428 lbs.
*Includes all standard equipment, required fluids and full tank of fuel—ready to ride
Meets current EPA standards
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment
Specifications subject to change





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
