2019 Harley-Davidson Fat Boy 114 Guide

2019 Harley-Davidson Fat Boy 114

2019 Harley-Davidson Fat Boy 114 2019 Harley-Davidson Fat Boy 114 2019 Harley-Davidson Fat Boy 114 2019 Harley-Davidson Fat Boy 114

THE NAME MAY BE “FAT BOY”, BUT THE LOOK IS ALL MUSCLE.

2019 Harley-Davidson Fat Boy 114:

The Fat Boy® is an icon, riding on a 240mm rear tire, 160mm front tire and solid disc wheels. Get satin chrome finishes and signature LED lighting. This version is 30 pounds lighter than the previous generation Fat Boy models, and its slinging torque from a Milwaukee-Eight® 114 engine.

2019 FAT BOY®

The original fat custom icon. Now lighter than the previous generation Fat Boy, and slinging torque from a Milwaukee-Eight® 107 or 114. You’ll feel the difference the instant you crack the throttle.

RIPPED, REFINED, AND READY FOR ITS CLOSE-UP





2019 Harley-Davidson Fat Boy 114 Totalmotorcycle.com Key Features

SOFTAIL®

One look at the FXDR™ 114 is all it takes to see how far the Softail® family has come. It’s the latest in a new revolution of custom motorcycles we launched last year. With every Softail, you get a lighter frame, responsive new suspension, and the power of the Milwaukee-Eight® v-twin engine. In keeping with the custom tradition, each model has its own attitude and style. Ranging from the blacked-out nostalgia of the Heritage Classic to the futuristic edge of the Fat Bob® and FXDR 114 models. Find the one that fits your style. You’re in for one hell of a ride.

The FXDR™ 114 model combines the power of the Milwaukee-Eight® 114 engine with the latest Softail® frame and a cast aluminum swing arm rear suspension, breaking all-new ground for 2019.



Engine

Milwaukee-Eight®
107 OR 114

Engine Torque

109 ft-lb

Weight, As Shipped

670 lb.

Seat Height, Laden

25.9 in.





2019 Harley-Davidson Fat Boy 114 Totalmotorcycle.com Features and Benefits

Chrome finish on a 2019 Fat Boy Motorcycle
Satin Chrome Finishes

An all-you-can eat portion of sculpted satin chrome gives the Fat Boy® motorcycle a look that’ll make a big impact.

Steamroller Stance

A muscular look thanks to solid-disc Lakester wheels wrapped in the widest front tire we’ve ever offered from the factory at 160mm combined with a rear tire at 240mm.

Milwaukee-Eight 114 Engine on a 2019 Fat Boy Motorcycle
Milwaukee-Eight® Big Twin Engine

A powerful, smooth-running engine with crisp throttle response and a pure, soul-satisfying rumble. Available in 107 and 114 engine displacements.

Headlight on a 2019 Fat Boy Motorcycle
Signature LED Forward Lighting

Darkness-defying lighting that gives you great visibility at night.

Softail® Frame

The reinvented frame retains the classic Softail® lines, but its lightweight design and stiffness translate to a responsive ride unlike anything you’ve felt before.

Front suspension on a 2019 Fat Boy Motorcycle
High Performance Front Suspension

Sophisticated suspension technology provides the performance of a racing-style cartridge fork for reduced weight with linear damping characteristics.

Rear shocks on a 2019 Fat Boy Motorcycle
High Performance Rear Mono Shoc

Easily adjustable mono-shock rear suspension allows for dynamic cornering while preserving the hardtail look.







2019 Harley-Davidson Fat Boy 114 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $20449 – $21399
USD
Canada MSRP Price: $25599 – 28099 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing6

  • Vivid Black $20,449
  • Color $20,849
  • Two-Tone $21,199
  • Custom Color $21,399
  • Two-Tone Custom Color $21,599
  • ABS Option Standard
  • Security System Option Standard
  • California Emissions $200
  • Freight $390

Engine

  • Engine 1 Milwaukee-Eight® 114
  • Bore 4.016 in.
  • Stroke 4.5 in.
  • Displacement 1,868 cc (114 cu in)
  • Compression Ratio 10.5:1
  • Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-2 staggered; catalyst in muffler

Dimensions

  • Length 93.3 in.
  • Seat Height, Laden 7 25.9 in.
  • Seat Height, Unladen 26.6 in.
  • Ground Clearance 4.5 in.
  • Rake (steering head) (deg) 30
  • Trail 4.1 in.
  • Wheelbase 65.6 in.
  • Tires, Front Specification 160/60R18,70V,BW
  • Tires, Rear Specification 240/40R18,79V,BW
  • Fuel Capacity 5 gal.
  • Oil Capacity (w/filter) 5 qt.
  • Weight, As Shipped 671 lb.
  • Weight, In Running Order 699 lb.

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque 2 119 ft-lb
  • Engine Torque (rpm) 3,000
  • Lean Angle, Right (deg.) 25.6
  • Lean Angle, Left (deg.) 25.6
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy 5 47 mpg

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type 9 Machined, Lakester cast aluminum
  • Wheels, Rear Type Machined, Lakester cast aluminum
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps 8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS, security, low battery voltage, low fuel
  • Gauges 5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication
2019 Harley-Davidson Fat Boy 114 – Totalmotorcycle.com Canada Specifications/Technical Details

Pricing6

  • Vivid Black $ 25,599
  • Colour $ 26,049
  • Two-Tone $ 26,449
  • Custom Colour $ 26,799
  • ABS Option Standard
  • Security System Option Standard
  • Two Tone Custom Colour $ 28,099

Engine

  • Engine 1 Milwaukee-Eight™ 114
  • Bore 102 mm
  • Stroke 114 mm
  • Displacement 1,868 cc
  • Compression Ratio 10.5:1
  • Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-2 staggered; catalyst in muffler

Dimensions

  • Length 2,370 mm
  • Seat Height, Unladen 675 mm
  • Ground Clearance 115 mm
  • Rake (steering head) (deg) 30
  • Trail 104 mm
  • Wheelbase 1,665 mm
  • Tires, Front Specification 160/60R18,70V,BW
  • Tires, Rear Specification 240/40R18,79V,BW
  • Fuel Capacity 18.9 l
  • Oil Capacity (w/filter) 4.7 l
  • Weight, As Shipped 304 kg
  • Weight, In Running Order 317 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque 2 161 Nm
  • Engine Torque (rpm) 3,000
  • Lean Angle, Right (deg.) 25.6
  • Lean Angle, Left (deg.) 25.6
  • Fuel Economy: Estimated City/Hwy 5 5 l/100 km

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type 9 Machined, Lakester cast aluminum
  • Wheels, Rear Type Machined, Lakester cast aluminum
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps 8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS, security, low battery voltage, low fuel
  • Gauges 5-inch analog speedometer with digital gear, odometer, fuel level, clock, trip, range and tachometer indication



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
