2019 Kawasaki Ninja 400 ABS KRT Guide

2019 Kawasaki Ninja 400 ABS KRT

2019 Kawasaki Ninja 400 ABS KRT 2019 Kawasaki Ninja 400 ABS KRT 2019 Kawasaki Ninja 400 ABS KRT

KAWASAKI RACING TEAM EDITION.

2019 Kawasaki Ninja 400 ABS KRT:

Get ahead with class-leading power and performance with the all-new Ninja 400. Clad in sharp new Ninja styling, the Ninja 400 has an engine and chassis that are more powerful and significantly lighter than its Ninja 300 predecessor. Its stronger engine performance, light, predictable handling and relaxed, sporty riding position make the Ninja 400 both fun and easy to ride.

Your ride to greatness starts here.

The Ninja® 400 is a street-born, track-inspired lightweight sportbike. Unlike other lightweight sportbike competitors, the Ninja 400 has more power with its larger displacement engine; fresh, angular bodywork with LED headlights for the most modern styling; and has the Kawasaki Racing Team DNA from the only manufacturer that currently holds four consecutive FIM Superbike World Championships (2015/2016/2017/2018). Every ride thrills as only a true Ninja sport bike can.





2019 Kawasaki Ninja 400 ABS KRT Totalmotorcycle.com Key Features

▪Uni-Trak® rear suspension
▪310mm semi-floating petal front disc brake
▪Twin LED headlights
▪High-grade multifunction dash instrumentation





2019 Kawasaki Ninja 400 ABS KRT Totalmotorcycle.com Features and Benefits

Parallel Twin Engine
The engine has a rider-friendly character, smooth response and abundant low-end torque to please both new and experienced riders
• Downdraft intake tract provides a short, direct path for intake air to enter the cylinder, improving cylinder-filling efficiency and contributing to power, especially at high rpm. The downdraft intake also helps eliminate space under the seat so that it could be designed to provide an easier reach to the ground.
• Large airbox contributes to intake efficiency for more power. The airbox design helps the rider more clearly hear the engine’s intake note during acceleration.
• Unequal height of the intake funnels help smooth throttle response by tuning out torque valleys.
• The 32mm throttle valves are oval shaped so that their closed position is at an angle, which contributes to quick throttle response as the valves open quickly from initial valve rotation.
• Fine-atomizing injectors positioned close to the throttle valves allows them to spray fuel directly onto the valves, which contributes to combustion efficiency and linear throttle response.
• 27.7mm intake and 23.5mm exhaust valves contribute to performance at all engine speeds.
• Forged camshafts, usually found only on largerdisplacement machines, contribute to weight reduction.
• Oil jets cool the underside of the pistons, enabling a lighter piston design.
• Aluminum die-cast cylinder has an open deck design for excellent heat dissipation and reduced engine weight. Cylinders are sleeveless with plated bores.
• The cylinder is tilted forward 20 degrees to help reduce overall engine height.
• Lightweight flywheel lets the engine rev quickly for sharp response and direct power feeling.

ENGINE
• Machined balancer shaft helps offset engine vibration for a more comfortable ride.
• Oil pan design allows the exhaust system to trace a straighter line, which contributes to weight savings.
• Large-diameter header pipes contribute to performance throughout the rev range.
• Cooling system layout minimizes weight and external coolant pipes.
• Radiator fan cover directs hot air out to the sides and away from the rider for increased comfort when riding in heavy traffic. It also helps keep the tank, frame and other parts that the rider contacts cooler, further increasing comfort.

Transmission/Clutch
• The assist and slipper clutch(KP) is compact, and it’s operating plates help reduce lever pull for an extremely light feel at the lever. A wide engagement range helps
make it easy to control.
• Using the rotational forces of the clutch hub and pressure plate, the clutch is forced together during acceleration (assist function) so that fewer and lighter clutch springs can be used for a lighter feel at the lever. During high back torque, such as when too low of gear is selected during downshifting, the slipper function allows some clutch slippage to help prevent rear wheel hop and stalling due to engine lock-up.
• Close gear ratios facilitate smooth shifting.

Lightweight Trellis Frame
• Trellis frame is similar in design to that of the Ninja H2™. Kawasaki’s advanced dynamic rigidity analysis was used to ensure optimum rigidity with minimal weight, so the frame significantly contributes to the bikes low overall curb mass.
• Supersport-style chassis design has a short wheelbase and long swingarm complemented by a steep steering angle that provides light, nimble handling.

Suspension
• Square-tube swingarm construction provides rigidity without unnecessary gusseting, which contributes to weight savings.
• Uni-Trak®(KP) rear suspension linkage ratios and shock settings enhance the ride feel.
• 41mm fork provides rigidity and smooth suspension action so the front wheel has a better planted feel. Brakes
• Large 310mm semi-floating petal front disc is gripped by a balanced actuation dual-piston caliper. The front brake is the largest in the class and disc size is the same as the ones on the Ninja® ZX™-14R.
• Rigid front brake master cylinder helps eliminate idle stroke for a more positive feel.
• Rear dual-piston caliper with large pistons clamps a 220mm rear petal disc.
• ABS model feature Nissin’s latest compact ABS control unit that assists braking under certain conditions.

Wheels/Tires
• Stylish star-pattern 5-spoke wheels are similar to those of the Ninja® 650, contribute weight savings, and their optimized lateral rigidity benefits handling by adding to cornering performance.
• Radial tires offer light weight, excellent grip and contribute to both agile handling and riding comfort.

CHASSIS

Styling
• Large-volume bodywork helps make the Ninja 400 appear bigger than an entry-class machine and more in line with the Ninja ZX™-6R/10R.
• Sharp front cowl with chin spoilers invoke images of the Kawasaki supersport flagship Ninja H2™ and Ninja ZX-10R.
• Slim LED headlights enhance the aggressive look, are highly visible to other motorists and provide increased brightness over conventional bulbs.
• Tail cowl features the same triple-peak design of the Ninja H2, further reinforcing the Ninja 400’s bloodline. An LED tail light similar in design to that of the Ninja ZX-10R finishes off the Ninja 400’s sharp impression.

Ergonomics
• Relaxed riding position accommodates a wide range of rider sizes and riding situations. Unlike some competitors with more extreme ergonomics, the Ninja 400’s elevated handlegrip position
and slightly forward footpegs put the rider in a comfortable position.
• The large-volume bodywork provides great wind protection and promotes clean airflow around the rider, adding to comfort. The design also helps dissipate engine heat out the side openings of the
fairing.
• The seat cushioning is thick, uses low-rebound urethane for added comfort, and is relatively narrow, so that it is easier for rider’s feet to reach the ground.
• Supersport-style aluminium footpegs provide direct feel when sport riding.

High Grade Instrumentation
• Equipped with the same instrument panel as the Ninja 650 with a large analog tachometer flanked by warning lamps on the left and gear-position indicator and multi-function LCD screen on the right.
• LCD screen has a negative display for a sporty, modern appearance.
• Gear position indicator helps with shifting
precision and confidence.
• Other display functions include odometer, dual trip meters, remaining fuel range, current and average fuel consumption, coolant temperature, clock and Economical Riding Indicator.
• The Economical Riding Indicator appears to indicate favorable fuel consumption to help riders maximize fuel mileage.







2019 Kawasaki Ninja 400 ABS KRT – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ USD
Canada MSRP Price: $6,399 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU

NA











2019 Kawasaki Ninja 400 ABS KRT – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Displacement 399cc
Type 4-stroke Parallel Twin
Bore and stroke 70.0 x 51.8 mm
Cooling Liquid-cooled
Compression ratio 11.5:1
Valve system DOHC, 8 valves
Fuel system Fuel Injection: 32mm x 2 (Keihin)
Ignition Digital
Lubrication Forced Lubrication, wet sump

Brakes

Front: type Single semi-floating 310 mm petal disc
Front: calipers Single balanced actuation dual-piston
Rear: type Single 220 mm petal disc
Rear: calipers Dual-piston

Dimensions

Overall length 1,990 mm
Overall width 710 mm
Overall height 1,120 mm
Wheelbase 1,370 mm
Ground clearance 140mm
Seat height 785mm
Curb mass** 166 kg
Fuel capacity 14 litres

Drivetrain

Transmission 6-speed, return
Final drive Chain
Primary reduction ratio 2.219 (71/32)
Gear ratio: 1st 2.929 (41/14)
Gear ratio: 2nd 2.056 (37/18) [
Gear ratio: 3rd 1.619 (34/21)
Gear ratio: 4th 1.333 (32/24)
Gear ratio: 5th 1.154 (30/26)
Gear ratio: 6th 1.037 (28/27)
Final reduction ratio 2.929 (41/14)
Clutch Wet multi-disc, manual

Frame

Type Trellis, high-tensile steel
Wheel travel: front 120mm
Tire: front 110/70-17 M/C 54S
Wheel travel: rear 130 mm
Tire: rear 150/60R17 M/C 66H
Caster (rake) 24.7°
Trail 92 mm
Steering angle (left/right) 35° / 35°

Performance

Maximum Power 36 kW {49 PS} / 10,000 rpm
Maximum Torque 38 N.m {3.9 kgf.m} / 8,000 rpm

Suspension

Suspension, front 41 mm telescopic fork
Suspension, rear Bottom-Link Uni-Trak, gas-charged shock with adjustable preload

Details

Warranty 12 months warranty





* The Manufacturer’s Suggested Retail Price does not include freight, pre-delivery inspection or applicable taxes. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice. The amount indicated as “Your price” may include an optional instant Mega Cash credit that is deducted from the manufacturer’s suggested retail price before taxes. This promotion is time limited and certain conditions will apply. See your dealer for complete details. Offer not available on financed purchases and cannot be combined with any other special offers. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice.

** Includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90% of capacity) and tool kit (if supplied)

‡ Power / Torque figures measured at the crankshaft.

The specifications mentioned here apply to and have been achieved by production models under standard operating conditions. We intend only to give a fair description of the vehicle and its performance capabilities but these specifications may not apply to every machine supplied for sale. Kawasaki Heavy Industries, Ltd. reserves the right to alter specifications without prior notice. Equipment illustrated and specifications may vary to meet individual markets. Available colours may vary by market.







2019 Kawasaki Ninja 400 ABS KRT – Totalmotorcycle.com European Specifications/Technical Details

TBA







2019 Kawasaki Ninja 400 ABS KRT – Totalmotorcycle.com Australian Specifications/Technical Details

TBA









Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
