CALL OF THE WILD.

2019 Kawasaki Z125 Pro:

DESIGNED TO DEFY

Small in size. Big on fun. The Kawasaki Z125 PRO is a nimble streetfigher that’s designed to defy what a lightweight motorcycle can be. This easy to ride bike delivers the freedom and excitement of motorcycling for new and experienced riders alike. With radical Kawasaki “Z” styling, the Z125 PRO is your invitation to the rebellious side of fun.

Compact and lightweight, Kawasaki’s Z125 PRO is the ideal way to have fun while navigating the urban landscape. Don’t let its size fool you, the Z125 PRO is designed to provide a high level of riding performance on par with its much larger Z siblings.

Designed to have a sporty character, the quick-revving engine pulls smoothly from the bottom all the way to redline and provides superb passing performance for negotiating city traffic.

Fuel-injected 125cc engine
Four-speed manual transmission
Offset laydown single-shock
Digital LCD screen with analogue tachometer and gear position indicator







2019 Kawasaki Z125 Pro Totalmotorcycle.com Key Features

• Aggressive headlight design
• Sharp LED taillight design
• Distinctive shrouds and sharp lower cowl
• Lightweight chassis
• 12-inch cast wheels

• DISTINCTIVE STYLING EMULATES THE AGGRESSIVE DESIGN OF ITS LARGER Z SIBLINGS.
• COMPACT CHASSIS COMBINES WITH SPORTY SUSPENSION AND TIRES FOR LIGHT, NIMBLE HANDLING
• QUICK-REVVING, FUEL-INJECTED ENGINE PROVIDES AMPLE PERFORMANCE FOR NEGOTIATING CITY TRAFFIC
• CONFIDENCE-INSPIRING LOW SEAT HEIGHT
• PETAL DISC BRAKES
• HIGH-TECH INSTRUMENTATION INCLUDES GEAR POSITION INDICATOR AND FUEL GAUGE







2019 Kawasaki Z125 Pro Totalmotorcycle.com Features and Benefits

• Simple and reliable air-cooled, SOHC, 2-valve Single is tuned for strong acceleration throughout the rev range.
• Cam profiles and intake port design contribute to the smooth, quick-revving engine character.
• Fuel injection ensures stable fuel delivery regardless of outside air temperature or atmospheric pressure. It also ensures reliable engine starting, whether the engine is hot or cold.
• The airbox is positioned above and forward of the cylinder head, contributing to the sporty power feeling and helping to minimize intake noise.
• 24 mm throttle body adds to the quick-revving character with its long-nose type injector.
• Stainless steel exhaust pipe offers excellent durability, while the under-engine muffler design contributes to a compact package as well as mass centralization for light handling and increased maneuverability.
• Smart regulator with built-in microprocessor reviews the battery charging level and engine rpm, cutting the generating current when the battery is fully charged or during acceleration to minimize
power loss. The system also helps to improve fuel efficiency.
• 4-Speed transmission with manual clutch
• Link-type shift lever, similar to that found on largerdisplacement models, reduces the input load required to shift gears for a light shift touch.

The compact chassis combined with sporty suspension and tires provides light, nimble handling.

• High-tensile steel backbone frame is robust and capable of handling two-up riding.
• Offset laydown rear suspension enables a compact package while contributing to sporty handling. The shock’s mounting angle is designed to provide superb shock action and excellent ride comfort.
• The rear shock is a 4-way preload adjustable, allowing riders to set the preload for their weight and to adjust for carrying a passenger.
• Highly rigid box-section swingarm enhances to the handling while providing the strength for carrying a passenger.
• 30mm inverted front fork with lightweight aluminum upper triple clamp offers excellent rigidity and low unsprung weight for sporty riding potential. The fork settings also contribute to the Z125 PRO’s nimble handling.
• Cast aluminium wheels reduce unsprung weight and are fitted with tubeless tires for great sporty street performance.
• Tire sizes and tread pattern were selected to deliver sporty, nimble handling.
• Rear rim is wide enough to accommodate a larger 130 mm rear tire.
• Front and rear disc brakes provide stopping power to match the Z125 PRO’s sporty handling. The petal discs are just like those of its larger brothers in the Kawasaki line-up and add to the sporty look.

The Z125 PRO incorporate both the looks and quality of a much larger bike. Styling emulates the aggressive design of Kawasaki’s Z model lineup, creating an eye-catching package that appears ready to launch into action even when sitting still.
• Compact headlamp cowl is one of the key styling elements of the aggressive Z design.
• Sporty, single headlamp design helps provide a slim image. The multi-reflector headlamp throws a clear beam of light.
• Compact engine shrouds contribute to the bike’s hourglass figure as well as its overall aggressive design.
• The slim fuel tank is flared at the top edges and slants forward to add to the aggressive design.
• Ignition switch is located at the front of the tan, adding to the bike’s sporty image and a tidy cockpit design.
• Sharp, supernaked-style under-cowl with an aggressive chiseled design adds to the sporty image.
• Sporty front fender has integrated fork guards that help protect the fork tubes from road debris.
• Front and rear turn signals feature a sharp design and clear, transparent lenses, adding to the sporty image.
• Stepped seat design adds to the sporty look while accommodating both a rider and passenger.
• Slim tail section is complemented by a sharp LED tail light, where the LED bulbs form a “Z” pattern.
• Rear inner fender adds to the sharp design and helps to keep the under-tail and rear suspension clean.
• Machined footpegs for the rider and passenger further contribute to the sporty image while offering direct feedback to the rider.
• Stylish front sprocket cover adds to the sharp look.
• Instrument console combines a race analog-style tachometer with a multi-function LCD screen.
• In addition to premium features like a gear position indicator and fuel gauge, there are the standard functions such as speedometer, clock, odometer
and trip meter.

Convenient Features
• Large-volume fuel tank and superb fuel efficiency enable a long riding range.
• Locking fuel tank cap deters tampering.
• Low seat height makes it easy for riders to reach the ground with both feet.
• The Z125 PRO’s light weight and compact chassis make it easy to handle, whether maneuvering in tight quarters or walking beside the bike.
• Tight turning radius makes it easy to navigate urban
traffic.









2019 Kawasaki Z125 Pro – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $3199 USD
Canada MSRP Price: $3499 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU

Power

Engine

4-stroke, 1 cylinder, SOHC, 2-valve, air-cooled

Displacement

125cc

Bore x Stroke

56.0 x 50.6mm

Compression Ratio

9.8:1

Maximum Torque

7.1 lb-ft @ 6,000 rpm

Fuel System

DFI® with 24mm throttle bodies

Ignition

TCBI with electronic advance

Transmission

4-speed, return shift

Final Drive

Sealed chain

Performance

Front Suspension / Wheel Travel

Telescopic fork/3.9 in

Rear Suspension / Wheel Travel

Swingarm, single shock/4.1 in

Front Tire

100/90-12

Rear Tire

120/70-12

Front Brakes

Single 200mm petal style disc

Rear Brakes

Single 184mm petal-style disc

Details

Frame Type

Backbone

Rake/Trail

26.0°/2.7 in

Overall Length

66.9 in

Overall Width

29.5 in

Overall Height

39.6 in

Ground Clearance

6.1 in

Seat Height

31.7 in

Curb Weight

224.8 lb**

Fuel Capacity

2.0 gal

Wheelbase

46.3 in

Color Choices

Ebony, Candy Steel Furnace Orange

Warranty

12 Month Limited Warranty

Kawasaki Protection Plus™ (optional)

12, 24, 36 or 48 months













2019 Kawasaki Z125 Pro – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Displacement 125 cc
Type 4-stroke, Single
Bore and stroke 56 x 50.6 mm
Cooling Air
Compression ratio 9.8:1
Valve system SOHC, 2 Valves
Fuel system Fuel injection: 24mm x 1
Ignition Digital
Lubrication Forced lubrication (wet sump)

Brakes

Front: type Single 200 mm petal disc
Front: calipers Single piston
Rear: type Single 184 mm petal disc
Rear: calipers Single-piston caliper

Dimensions

Overall length 1,700 mm
Overall width 750mm
Overall height 1,005 mm
Wheelbase 1,175 mm
Ground clearance 155 mm
Seat height 805 mm
Curb mass** 102 kg
Fuel capacity 7.4 litres

Drivetrain

Transmission 4-speed, return
Final drive Chain
Primary reduction ratio 3.409 (75/22)
Gear ratio: 1st 3.000 (36/12)
Gear ratio: 2nd 1.938 (31/16)
Gear ratio: 3rd 1.350 (27/20)
Gear ratio: 4th 1.087 (25/23)
Final reduction ratio 2.143 (30/14)
Clutch Wet multi-disc, manual

Frame

Type Backbone, high-tensile steel
Wheel travel: front 100 mm
Tire: front 100/90-12 49J
Wheel travel: rear 104 mm
Tire: rear 120/70-12 51L
Caster (rake) 26°
Trail 69 mm
Steering angle (left/right) 35° / 35°

Performance

Maximum Power 7.1 kW {7.9 PS} @ 8,000 rpm
Maximum Torque 9.6 N.m {0.98 kgf.m} @ 6,000 rpm

Suspension

Suspension, front 30 mm inverted fork
Suspension, rear Offset laydown single-shock with adjustable preload

Details

Warranty 12 months warranty





* The Manufacturer’s Suggested Retail Price does not include freight, pre-delivery inspection or applicable taxes. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice. The amount indicated as “Your price” may include an optional instant Mega Cash credit that is deducted from the manufacturer’s suggested retail price before taxes. This promotion is time limited and certain conditions will apply. See your dealer for complete details. Offer not available on financed purchases and cannot be combined with any other special offers. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice.

** Includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90% of capacity) and tool kit (if supplied)

‡ Power / Torque figures measured at the crankshaft.

The specifications mentioned here apply to and have been achieved by production models under standard operating conditions. We intend only to give a fair description of the vehicle and its performance capabilities but these specifications may not apply to every machine supplied for sale. Kawasaki Heavy Industries, Ltd. reserves the right to alter specifications without prior notice. Equipment illustrated and specifications may vary to meet individual markets. Available colours may vary by market.







2019 Kawasaki Z125 Pro – Totalmotorcycle.com European Specifications/Technical Details

TBA









2019 Kawasaki Z125 Pro – Totalmotorcycle.com Australian Specifications/Technical Details

TBA
