SMALL PACKAGE ‑ BIG FUN.

2019 Yamaha TT-R110E:

The bike that produces big fun for both young and old and everyone in between.

Spark your kids’ 2-wheel passion with a TT-R110E! Learning is a snap with electric start, smooth power delivery and automatic clutch design for easy shifting.

Yamaha’s leading TT-R range includes the beautifully-styled TT-R110E, which is aimed at new riders as well as those graduating from the smaller TT-R50E.

Competition-winning inspiration.

Its radical racing-blue, motocross-style bodywork has been directly inspired by our MXGP-winning YZ race bikes. For easy steering and high levels of rider comfort, this good-looking youth bike features long-travel front and rear suspension.

New and experienced off-road riders will love the smooth and strong performance of the 110cc 4-stroke engine, and the 4-speed semi-automatic gearbox means that there is no clutch lever for riders to worry about.

///Power

The TT-R110E’s air-cooled, 110 cc, SOHC, 2-valve, 4-stroke powerplant produces smooth, reliable, novice-friendly power.

///EASY TO RIDE

The mid-size steel backbone-type frame features a compact 1,080 mm (42.5″) wheelbase for easy, agile handling with a low, confidence-inspiring seat height. The convenient push-button electric start makes it easier to get going!

Yamaha’s leading TT-R range includes the beautifully-styled TT-R110E, which is aimed at new riders as well as those graduating from the smaller TT-R50E.

2019 Yamaha TT-R110E Totalmotorcycle.com Key Features

Top Features

• Electric Starter
  Convenient electric starter for effortless starting.
• Accessible Performance
  Big fun for the whole family, the YZ-styled, four-stroke-powered TT-R110 begs to be ridden by everyone.
• Low Seat Height
  A seat height of only 26.4 inches makes this one accessible to most riders, but 7.1 inches of ground clearance and great suspension at both ends means it can go places
• Auto-Clutch Convenience
  Four-speed auto-clutch transmission has an easily accessible gear for nearly any terrain.

2019 Yamaha TT-R110E Totalmotorcycle.com Features and Benefits

Engine

• Torque-Rich Motor
  Powerful 110cc air-cooled SOHC four-stroke powerplant is tuned for maximum off-road performance in a wide range of trail conditions.
• Compact Cylinder Design
  Compact hemispherical combustion chamber with 9.3:1 compression produces max torque at 4000 rpm, max horsepower at 7500 rpm.
• Auto-Clutch Convenience
  Four-speed gearbox with automatic clutch has the right gear for wherever you ride.
• Electric Starter
  Convenient electric starter for effortless starting, and backup kick starting.
• Digital Ignition
  CDI ignition system is ultra-reliable and never needs maintenance.
• Low Maintenance Engine
  Automatic cam chain tensioner means minimal maintenance and longer engine life.
• Easy Serviceability
  Easy-access, tool-free air filter adds extra convenience during maintenance.
• Forestry-Friendly Exhaust
  Lightweight exhaust system features quiet, USFS-approved spark arrestor.

Chassis/Suspension

• Robust, Compact Frame
  Steel backbone frame ties steering head and swingarm pivot together via a straight line, with the engine mounted at three places for optimum strength and high ground clearance.
• Well-Damped Front Fork
  31mm fork with high-tech internals including a damper valve with oil lock provides excellent damping, great bottoming resistance and 4.5 inches of smooth travel.
• Advanced Rear Suspension
  Monocross® rear suspension pivoting on a strong, 12mm shaft, along with a gusseted steel swingarm, provide excellent rear wheel control through 4.3 inches of travel.
• Stylish Aluminum Top Clamp
  Die-cast aluminum top triple clamp helps provide light, precise handling and looks great, too.
• Trail-Ready Dimensions
  26.4-inch seat height and 7.1 inches of ground clearance help inspire confident performance on rugged trails.
• Enclosed Drum Brakes
  Front and rear drum brakes deliver strong, dependable stopping power.
• Nimble Wheels and Tires
  14-inch front and 12-inch rear wheels inspire great rider confidence by keeping the seat low and the steering light.
• Durable Knobby Tires
  Knobby tires offer superb grip and exceptional wear.

Additional Features

• Low Seat Heigh
  Long, YZ-style gripper seat is low, comfortable, and allows easy rider movement.
• Racy Styling
  Team Yamaha-inspired colors, graphics and front and side number plates create styling similar to larger YZ lineup.
• Grippy Footpegs
  Large, folding, cleated foot pegs provide excellent footing, even in wet or muddy conditions.
• Standard Security
  Key-type ignition switch deters unauthorized riding.

2019 Yamaha TT-R110E – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2299 USD
Canada MSRP Price: $2999 CDN
Europe/UK MSRP Price: £ See dealer for pricing in GBP (On The Road inc 20% Vat)
Australia MSRP Price: See dealer for pricing in AU

MSRP*

$2,299 – Team Yamaha Blue – Available from October 2018

Engine

Engine Type

110cc air-cooled SOHC 4-stroke; 2 valves

Bore x Stroke

51.0mm x 54.0mm

Compression Ratio

9.3:1

Fuel Delivery

Mikuni® VM16 carburetor

Ignition

CDI

Transmission

Constant-mesh 4-speed; multiple wet clutch

Final Drive

Chain

Chassis

Suspension / Front

31mm telescopic fork; 4.5-in travel

Suspension / Rear

Monocross® shock; 4.3-in travel

Brakes / Front

Drum, 95mm

Brakes / Rear

Drum, 110mm

Tires / Front

2.50-14-4PR

Tirres / Rear

3.00-12-4PR

Dimensions

L x W x H

61.6 in x 26.8 in x 36.3 in

Seat Height

26.4 in

Wheelbase

42.5 in

Rake (Caster Angle)

26.0°

Trail

2.4 in

Maximum Ground Clearance

7.1 in

Fuel Capacity

1.0 gal

Fuel Economy**

n/a

Wet Weight***

159 lb

Other

Warranty

90 Day (Limited Factory Warranty)

*** Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as
applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is
useful in making real-world comparisons with other models.

2019 Yamaha TT-R110E – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Chassis

Critical Data

2019 Yamaha TT-R110E – Totalmotorcycle.com European Specifications/Technical Details

• Engine

Engine type

air-cooled, 4-stroke, SOHC, 2-valves

Displacement

110cc

Bore x stroke

51.0 mm x 54.0 mm

Compression ratio

9.3 : 1

Lubrication system

Wet sump

Clutch type

Wet, Multiple Disc, centrifugal automatic

Ignition system

CDI

Starter system

Electric and kick

Transmission system

Constant Mesh, 4-speed

Final transmission

Chain

Fuel system

Fuel system

• Chassis

Frame

Steel tube backbone

Front travel

115 mm

Caster angle

26º

Trail

60mm

Front suspension system

Telescopic forks

Rear suspension system

Swingarm, (monocross)

Rear travel

110 mm

Front brake

Drum, Ø95 mm

Rear brake

Drum, Ø110 mm

Front tyre

2.50-14 4PR

Rear tyre

3.00-12 4PR

• Dimensions

Overall length

1,565 mm

Overall width

680 mm

Overall height

920 mm

Seat height

670 mm

Wheel base

1,080 mm

Minimum ground clearance

180 mm

Wet weight (including full oil and fuel tank)

72 kg

Fuel tank capacity

3.8litres

Oil tank capacity

1.0litres

2019 Yamaha TT-R110E – Totalmotorcycle.com Australian Specifications/Technical Details

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
