2020 Harley-Davidson Softail FXDR 114 Guide

2020 Harley-Davidson Softail FXDR 114

2020 Harley-Davidson Softail FXDR 114 2020 Harley-Davidson Softail FXDR 114 2020 Harley-Davidson Softail FXDR 114 2020 Harley-Davidson Softail FXDR 114 2020 Harley-Davidson Softail FXDR 114

MOVES YOU IN WAYS YOU’VE NEVER BEEN MOVED BEFORE.

2020 Harley-Davidson Softail FXDR 114:

The FXDR™ 114 features the Milwaukee-Eight® 114 V-Twin engine, the most powerful engine in a Softail® motorcycle. There’s an all-new lightweight cast aluminum swing arm. Bump-devouring racing-style front fork. Mono shock rear suspension. It’s all dialed in for quick response and agility.

The all-new FXDR™ 114 is a feast for the eyes with performance and attitude that’s off the leash. Fast on the straights. Agile in the corners. It’ll blow away your senses.



2020 Harley-Davidson Softail FXDR 114 Totalmotorcycle.com Key Features

One look at the Low Rider S is all it takes to see how far the Softail® family has come. It’s the latest in a new revolution of custom motorcycles we launched in 2018. With every Softail, you get a lighter frame, responsive new suspension, and the power of the Milwaukee-Eight® v-twin engine. In keeping with the custom tradition, each model has its own attitude and style. Ranging from the blacked-out nostalgia of the Heritage Classic to the futuristic edge of the Fat Bob® and FXDR 114 models. Find the one that fits your style. You’re in for one hell of a ride.

Engine

Milwaukee-Eight® 114

Engine Torque

119 ft-lb

Weight, As Shipped

637 lb.

Seat Height, Laden

27.7 in.







2020 Harley-Davidson Softail FXDR 114 Totalmotorcycle.com Features

Milwaukee-Eight® 114 Engine

Loads of torque for blasting off from stoplights, hitting entrance ramps, and rolling on the passing power. Pure sound with a soul-satisfying rumble.



Minimal Weight for Maximum Performance

Designed with a number of alloy and composite components to reduce the overall weight, including an aluminum swingarm and subframe. Maximizes acceleration, braking and handling performance.



Bold 2-into-1 Exhaust

Tuned to emit a throaty rumble. Plus dramatic performance-inspired design that won’t interfere with lean angle.



Racing-Style Fork

Inverted race-style design, with single-cartridge technology that improves response to steering input and braking and handling performance.



Air Intake

Inspired by Screamin’ Eagle® NHRA drag bikes and shaped to enhance air flow to the engine. A fresh interpretation of the Heavy Breather with an exposed, forward-facing filter element.



Softail® Frame

The frame retains the classic Softail® lines, but its lightweight design and stiffness translate to a responsive ride unlike anything you’ve felt before.



High Performance Rear Suspension

Easily adjustable mono-shock rear suspension allows for dynamic cornering, quick acceleration and braking while preserving the hardtail look.



Stretched Fuel Tank

A sleek design that lengthens the profile of the bike to give it an aggressive look.



Modern Technologies

You get a LED Daymaker™ headlamp, LED rear lighting and LED turn signals; digital riser gauge, and a keyless ignition.







2020 Harley-Davidson Softail FXDR 114 – Totalmotorcycle.com  American Specifications/Technical Details
US MSRP Price from: $18999
USD
Canada MSRP Price from: $23799 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing

  • Vivid Black $18,999
  • Color $19,399
  • ABS Option Standard
  • Security System Option Standard
  • California Emissions $200
  • Freight $390

Engine

  • Engine1 Milwaukee-Eight® 114
  • Bore 4.016 in.
  • Stroke 4.5 in.
  • Displacement 114 cu in
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-1; catalyst in header

Dimensions

  • Length 95.5 in.
  • Seat Height, Laden7 27.7 in.
  • Ground Clearance 5.5 in.
  • Rake (steering head) (deg) 34
  • Trail 4.7 in.
  • Wheelbase 68.3 in.
  • Tires, Front Specification 120/70ZR-19 60W
  • Tires, Rear Specification 240/40R-18 79V
  • Fuel Capacity 4.4 gal.
  • Oil Capacity (w/filter) 5 qt.
  • Weight, As Shipped 637 lb.
  • Weight, In Running Order 668 lb.

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 119 ft-lb
  • Engine Torque (rpm) 3,500
  • Lean Angle, Right (deg.) 32.6
  • Lean Angle, Left (deg.) 32.8
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy5 46 mpg

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type9 Gloss/satin black, split 5-spoke, cast aluminum with laser etched graphics
  • Wheels, Rear Type Gloss/satin black, solid disc, cast aluminum with laser etched graphics
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS, security, low battery voltage, low fuel
  • Gauges 2.14 inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication







2020 Harley-Davidson Softail FXDR 114 – Totalmotorcycle.com  Canadian Specifications/Technical Details

Pricing

  • Vivid Black $ 23,799
  • Colour $ 24,249
  • ABS Option Standard
  • Security System Option Standard

Engine

  • Engine1 Milwaukee-Eight® 114
  • Bore 102 mm
  • Stroke 114 mm
  • Displacement 1,868 cc
  • Compression Ratio 10.5:1
  • Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-1; catalyst in header

Dimensions

  • Length 2,425 mm
  • Seat Height, Unladen 720 mm
  • Ground Clearance 140 mm
  • Rake 34
  • Trail 120 mm
  • Wheelbase 1,735 mm
  • Tires, Front Specification 120/70ZR-19 60W
  • Tires, Rear Specification 240/40R-18 79V
  • Fuel Capacity 16.7 l
  • Oil Capacity 4.7 l
  • Weight, As Shipped 289 kg
  • Weight, In Running Order 303 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque2 162 Nm
  • Engine Torque (rpm) 3,500
  • Lean Angle, Right (deg.) 32.6
  • Lean Angle, Left (deg.) 32.8
  • Fuel Economy: Estimated City/Hwy5 5.1 l/100 km

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type9 Gloss/satin black, split 5-spoke, cast aluminum with laser etched graphics
  • Wheels, Rear Type Gloss/satin black, solid disc, cast aluminum with laser etched graphics
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS, security, low battery voltage, low fuel
  • Gauges 2.14 inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication











Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
