2020 MV Agusta Dragster 800RR RC Guide

2020 MV Agusta Dragster 800RR RC

2020 MV Agusta Dragster 800RR RC 2020 MV Agusta Dragster 800RR RC 2020 MV Agusta Dragster 800RR RC 2020 MV Agusta Dragster 800RR RC 2020 MV Agusta Dragster 800RR RC

RACING DNA.

2020 MV Agusta Dragster 800RR RC:

FROM 0 TO 100 IN A INSTANT

Dragster was born to impress, both at rest and while in motion. Reaction at first sight is pure shock, when you hear it screaming you think “I need it!”. We were told this was madness. We didn’t listen.
MV REPARTO CORSE DNA

A special livery, SC-Project exhaust with a dedicated ECU control unit and the forged aluminum wheels are the finishing touches given to the Dragster 800 RC by the MV Agusta Reparto Corse engineers.
SIGNATURE COLOUR SCHEME

Even in this version, the Dragster remains true to itself and is immediately recognisable. The cut tail, the aggressive handlebars and the huge rear wheel are packaged in an exclusive livery enhanced by the all front fork’s dedicated colour.
CARVED TO MEASURE

The weight distribution, the refined chassis and suspension as well as the Dragster’s unique character are the main features of a machine that was created for the most demanding enthusiasts.
COMPACT, WITH A COUNTER-ROTATING CRANKSHAFT

With its 52 kg and its contained dimensions, the three-cylinder of the Dragster 800 RR is the ideal choice to optimise the distribution of weight. The counter-rotating crankshaft is key to enhancing its dynamics, whilst its incredible performance is due to the new design of the airbox and the improved exhaust.
EXTRAORDINARY POWER

The three-cylinder engine powering the Dragster 800 RC develops 140 Hp at 13.100 rpm and a maximum torque of 87 Nm at 10.100 rpm, with a fluid delivery at lower revs and an extraordinary acceleration harnessed only by the rev limiter stepping in at 13.200 rpm.
REFINED ELECTRONICS

The Dragster 800 RC features the latest evolution of the MVICS system. On top of full multi-map Ride By Wire, it has an 8-level traction control system and a sophisticated EAS 2.0 electronic up & down gearbox mated to a hydraulic slipper clutch. The electronic injection system has two injectors per cylinder with three 50 mm diameter throttle bodies.
MAXIMUM SAFETY FOR TOTAL RIDING PLEASURE

When there’s nothing else to worry about than riding pleasure, fun is at its top, especially when your safety is guaranteed by a Bosch 9 PLUS two channels ABS system with Rear Wheel Lift-up Mitigation. The RLM system shoots in to mitigate excessive braking action on the front wheel and avoid rear-wheel lift.
Warranty

MV Agusta offers a NEW 3 YEARS WARRANTY on the whole range, with a great service support for all customers. Customize your experience riding a model, discovering special kits and the vast range of readily available spare parts.
Get in Touch

Take the next step to reach your dream







2020 MV Agusta Dragster 800RR RC Totalmotorcycle.com Key Features

 MV AGUSTA PRESENTS THE NEW 2020 MODEL RANGE

Varese, 2nd November 2019 – Quality, technology, performance. But also quick delivery of spare parts and professional service. There’s more: expansion and improvement of the dealers network to offer clients timely, impeccable assistance. These are the short-term guidelines for MV Agusta, which has just set off on a growth path clearly envisioned by its CEO, Timur Sardarov.

To mark the company’s determination in pursuing the 2020 objectives, production of the Brutale 1000 RR, the four-cylinder naked Superbike replica, has started in Schiranna. 208 hp maximum power, advanced chassis and suspension as well as leading-edge aerodynamic solutions all make the four-cylinder Brutale a defining example of MV Agusta’s excellence in motorcycle manufacturing. As core priorities of the brand,  these values are reinforced today by the attention and the investments in Research and Development.

From the production line to dealers showrooms: Superveloce 800 Serie Oro and Superveloce 800 bring MV Agusta’s timeless fascination to the roads, with their intoxicating curves, classic and contemporary at the same time. The engine and the chassis are the pinnacle of engineering that position the Superveloce 800 among the most fascinating and dynamic sports bikes on the scene.

Beauty and functionality, exciting and confidence-inspiring riding:  Dragster 800 RR SCS and Brutale 800 RR SCS both feature the revolutionary SCS 2.0 (Smart Clutch System) for clutch-free starts and stopping. A technical innovation that allows to stop and restart without touching the clutch lever, making the most out of the in-line three-cylinder engine mated to a counter-rotating crankshaft. All of this with only 36g weight increase compared to a traditional clutch.

The magic and technology of MV Agusta, at a competitive price. Thanks to the rationalisation of the production process and to efficiencies gained in the engineering phase, MV Agusta proudly presents its new Rosso Range, made up of Brutale 800, Dragster 800 and Turismo Veloce 800. The Rosso Range models stand out for their bright red livery and their comprehensive outfitting, despite a price tag that is lower than that of the models they derive from.

Vision, futuristic technology, and the pursuit of a dream: these are the values behind the creation of a new Concept Bike that will be revealed at EICMA as world premiere and which production is due to start in the coming months. The irreverent spirit of American drag races was the inspiration for a project that elevates the performance of the bike it derives from in the most daring of interpretations.







2020 MV Agusta Dragster 800RR RC Totalmotorcycle.com Features and Benefits









2020 MV Agusta Dragster 800RR RC – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: $  USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: €21990 Euro

Type Three cylinder, 4 stroke, 12 valve
Timing system “D.O.H.C” with mechanical chain tensioner
Total displacement 798 cm3 (48.68 cu. in.)
Compression ratio 13.3:1
Starting Electric
Bore x stroke 79 mm x 54.3 mm (3.1 in. x 2.1 in.) Max. power – r.p.m. (at the crankshaft) 103 kW (140 hp) at 12.300 r.p.m.
110 kW (150 hp) at 12.800 r.p.m**.
Max. torque – r.p.m. 87 Nm (8.87 kgm) at 10.100 r.p.m.

Cooling system Cooling with separeted liquid and oil radiators.
Engine management system Integrated ignition – injection system MVICS 2.0
(Motor & Vehicle Integrated Control System) with six injectors. Engine control unit Eldor EM2.0, throttle body full ride by wire Mikuni, pencil-coil with ion-sensing technology, control of detonation and misfire. Torque control with four maps, Traction Control with eight levels of intervention with lean angle sensor

Electronic quick-shift MV EAS 2.1 (Electronically Assisted Shift up & down)
Clutch Multi-disk wet clutch with hydraulic actuation and back torque limiting device
Transmission Cassette style; six speed, constant mesh
Primary drive 22/41
Gear ratio
First gear: 13/37
Second gear: 16/34
Third gear: 18/32
Fourth gear: 19/30
Fifth gear: 21/30
Sixth gear: 22/29
Final drive ratio 16/41

Voltage 12 V
Alternator 350 W at 5000 r.p.m.
Battery 12 V – 8.5 Ah

Wheelbase 1400 mm (55.12 in.)
Overall length 2035 mm (80.12 in.)
Overall width 935 mm (36.81 in.)
Saddle height 485 mm (33.27 in.)
Min. ground clearance 135 mm (5.31 in.)
Trail 103.5 mm (4.07 in.)
Dry weight 168 kg (370.38 lbs.) – 160 kg (352.74 lbs.)**
Fuel tank capacity 16.5 l (4.36 U.S. gal.)

Maximum speed* 244.0 km/h (151.6 mph)

Type ALS Steel tubular trellis
Rear swing arm pivot plates material Aluminium alloy

Type Marzocchi “UPSIDE DOWN” telescopic hydraulic fork in DLC treated aluminium, with anodized fork legs and having
rebound-compression damping and spring preload external and separate adjustment
Fork dia. 43 mm (1.69 in.)
Fork travel 125 mm (4.92 in.)

Type Progressive Sachs, single shock
absorber with rebound and compression damping and spring preload adjustment
Single sided swing arm material Aluminium alloy Wheel travel 124 mm (4.88 in.)

Front brake Double floating disc with Ø 320 mm (Ø 12.6 in.) diameter, with steel braking disc and flange
Front brake caliper Brembo radial-type, with 4 pistons Ø 32 mm (Ø 1.26 in.)
Rear brake Single steel disc with Ø 220 mm (Ø 8.66 in.) dia.
Rear brake caliper Brembo with 2 pistons – Ø 34 mm (Ø 1.34 in.)
ABS System Bosch 9 Plus with RLM
(Rear wheel Lift-up Mitigation

Front: Material/size Forged aluminium alloy 3.50” x 17”
Rear: Material/size Forged aluminium alloy 6.00” x 17”

Front 120/70 – ZR 17 M/C (58 W)
Rear 200/50 – ZR 17 M/C (75 W)

Material Carbon fiber and thermoplastic

Steering damper Manually adjustable with 8 settings Immobilizer

SC Project exhaust silencer

Rh/Lh front mudguard support brackets Dashboard cover – Fuel tank side covers Rear fender

SC-Project Titanium exhaust silencer Power unit for SC exhaust silencer carry-over (with special mapping) – Motorcycle cover Certificate of origin – Limited Edition

Environmental Standard Euro 4
Combined fuel consumption 6.7 l/100 km
CO2 Emissions 163 g/km



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
