2021 Kawasaki KLX140RL Guide

2021 Kawasaki KLX140RL

2021 Kawasaki KLX140RL 2021 Kawasaki KLX140RL 2021 Kawasaki KLX140RL 2021 Kawasaki KLX140RL

2021 Kawasaki KLX140RL : LARGER WHEELS. MORE CLEARANCE.

Introducing the 2021 Kawasaki KLX140RL.

The KLX140R motorcycles are the third variation of the KLX 140 models and is designed to provide a natural terrain experience with memories to last a lifetime. The powerful 144cc, four-stroke, air-cooled, single-cylinder engine features an electric starter and keyless ignition. Its broad and smooth high-revving 144cc engine utilizes a manual clutch and five-speed transmission to offer an efficient and user-friendly feel.

Featuring confident handling, KLX®140R motorcycles are the ideal entry into off-road riding. The easy-to-ride KLX140R lineup offers a 144cc engine, plush suspension and a push button electric start, making for great trailblazers.

ADDITIONAL VEHICLE FEATURES:
Larger wheels (19F, 16R), taller seat height (31.5-inch) and higher 10-inch ground clearance
7.1 inches of front and rear suspension travel





2021 Kawasaki KLX140RL Totalmotorcycle.com Key Features

Larger wheels (F19”, R16”) contribute to a taller seat height (800 mm [31.5 in]) and higher 255 mm (10.0 in) ground clearance
180 mm (7.1 in) of front and rear suspension travel
Disc brakes front and rear

PUSH BUTTON ELECTRIC START
HIGH-REVVING 144cc AIR-COOLED, SOHC, FOUR-STROKE ENGINE
5-SPEED TRANSMISSION WITH MANUAL CLUTCH
FRONT AND REAR DISC BRAKES



A fan favorite, the Kawasaki KLX® family of off-road motorcycles are widely popular for their low maintenance, easy-to-ride character, and incredible capabilities while out on the trails. Completing the rest of the 2021 KLX family line up are five additional models, which consist of four engine configurations and are built to suit a variety of riders.







2021 Kawasaki KLX140RL Totalmotorcycle.com Features and Benefits

CONFIDENT HANDLING
LIGHTWEIGHT RIGID FRAME
A lightweight box-section perimeter frame made from high-tensile steel provides exceptional rigidity and strength. The narrow profile contributes to an easier rider grip and smoother movement on the bike. Working together, the highly capable suspension and lightweight chassis deliver handling that exudes confidence.

SMOOTH POWER
ELECTRIC START
The high-revving, 144cc, air-cooled SOHC 4-stroke engine easily starts with the push of a button. Air-cooling eliminates the need for radiators, keeping the chassis slim and lightweight while a 5-speed transmission with manual clutch delivers smooth shifting and acceleration.

RELIABLE BRAKING
FRONT AND REAR DISC BRAKES
Front and rear disc brakes provide strong progressive stopping power. The 220mm front petal disc with a dual-piston caliper is complemented by a 186mm rear petal disc with single-piston caliper, inspiring confidence on the trails.







2021 Kawasaki KLX140RL – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $3,449 USD
Canada MSRP Price: $4249 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
POWER
Engine
4-stroke single, SOHC, air-cooled
Displacement
144cc
Bore x Stroke
58.0 x 54.4mm
Compression Ratio
9.5:1
Fuel System
20mm Keihin carburetor
Ignition
Digital DC-CDI
Transmission
5-speed, return shift, with wet multi-disc manual clutch
Final Drive
Chain
PERFORMANCE
Front Suspension / Wheel Travel
33mm telescopic fork/7.1 in
Rear Suspension / Wheel Travel
Uni-Trak® linkage system and single shock with piggyback reservoir, fully adjustable preload and 22-way rebound damping/7.1 in
Front Tire
70/100-19
Rear Tire
90/100-16
Front Brakes
Single 220mm petal disc with a dual-piston caliper
Rear Brakes
Single 186mm petal disc with single-piston caliper
DETAILS
Frame Type
High-tensile steel, box-section perimeter
Rake/Trail
27/3.8 in
Overall Length
74.6 in
Overall Width
31.1 in
Overall Height
42.3 in
Ground Clearance
10.0 in
Seat Height
31.5 in
Curb Weight
209.4 lb**
Fuel Capacity
1.5 gal
Wheelbase
50.6 in
Color Choices
Lime Green
Warranty
6 Months
Kawasaki Protection Plus™ (optional)
12, 24, or 36 months





2021 Kawasaki KLX140RL – Totalmotorcycle.com  Canadian Specifications/Technical Details



POWER

Engine 144cc, air-cooled, 4-stroke, SOHC 2-valve single
Bore x Stroke 58.0 x 54.4 mm
Compression Ratio 9.5:1
Fuel System Carburettor: Keihin PB20
Ignition Digital DC-CDI
Starting Electric
Lubrication Forced lubrication, wet sump
Transmission 5-speed, return
Clutch Wet multi-disc, manual
Final Drive Chain

PERFORMANCE

Frame Perimeter, box-section, high-tensile steel
Front Suspension / Wheel Travel ø33 mm telescopic fork / 180 mm (7.1 in)
Rear Suspension / Wheel Travel Uni Trak, single shock with piggyback reservoir, adjustable compression and rebound damping, and adjustable preload / 180 mm (7.1 in)
Rake / Trail 27.0° / 96 mm
Steering Angle (L/R) 41° / 41°
Front Tire 70/100-19 42M
Rear Tire 90/100-16 52M
Front Brake Single ø220 mm petal disc with dual-piston caliper
Rear Brake ø186 mm petal disc with single-piston caliper

DETAILS

Dimensions (L x W x H) 1,895 x 790 x 1,075 mm (74.6 x 31.1 x 42.3 in)
Wheelbase 1,285 mm (50.6 in)
Road Clearance 255 mm (10.0 in)
Seat Height 800 mm (31.5 in)
Curb Mass** 95 kg (209 lb)
Fuel Capacity 5.8 litres
Warranty 6 months
Kawasaki Protection Plus 12 / 24 / 36 / 48 months

**Curb weight includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90 percent capacity) and tool kit (if supplied).

KAWASAKI CARES: Always wear a helmet, eye protection, and proper apparel. Never ride under the influence of drugs or alcohol. Read Owner’s Manual and all on-product warnings. Professional rider shown on a closed course. 2019 Canadian Kawasaki Motors, Inc.

Specifications subject to change.





2021 Kawasaki KLX140RL – Totalmotorcycle.com European Specifications/Technical Details

NA





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
