2021 KTM 250 XC-W TPI Guide

2021 KTM 250 XC-W TPI

2021 KTM 250 XC-W TPI

2021 KTM 250 XC-W TPI : RACE TO NEW HEIGHTS.

Introducing the 2021 KTM 250 XC-W TPI…

The new generation KTM 250 XC-W TPI is the ultimate combination of power and rideability and sets a clear benchmark for intuitive handling, unique style and top performance. Thanks to its groundbreaking TPI (transfer port injection) technology, this extreme machine continues to reach new heights, clearly demonstrating KTM’s unrelenting commitment to 2-stroke development. Besides the renowned benefits of excellent fuel efficiency, clean exhaust emissions and the removed need for jetting, the KTM 250 XC-W TPI features a dynamic, lightweight frame. It was developed with feedback from factory riders and in hindsight, returns the favor by offering excellent rider feedback.









2021 KTM 250 XC-W TPI Totalmotorcycle.com Key Features







2021 KTM 250 XC-W TPI Totalmotorcycle.com Features and Benefits

Exhaust

When it comes to improved power delivery and performance, the new exhaust plays a key role and packs a punch that is hard to beat. The 250 cc and 300 cc models feature new HD exhaust pipes (heavy-duty) made by using an innovative 3D stamping process which produces a rippled surface finish. This makes the pipe much stronger, with better resistance against rocks, while also helping to reduce noise drastically. The silencer features a new shape and end cap with reworked internal designs individually developed for each model. The plastic silencer holder is now replaced with lightweight, welded mounting brackets. In addition, the exhaust’s new shape provides slimmer ergonomics and more ground clearance, while a new perforated inner silencer tube works with lighter damping wool for more efficient and more durable noise reduction. This adds up to a weight reduction of approximately 200 grams.

Engine

The 250cc 2-stroke engine has plenty power and torque, but remains light enough for riders to muscle their way through the toughest obstacles. Thanks to state-of-the-art engineering, innovative 2-stroke design and revolutionary TPI fuel injection technology, the powerplant is even more refined than ever before. The compact and lightweight 2-stroke is a great choice for offroad riders who want usable enduro performance that is ready to conquer in the most extreme terrain



Airbox

The air filter box design offers maximum protection of the air filter against soiling, while ensuring maximum airflow, and together with the intake snorkels, results in optimal power and throttle response. The large Twin Air air filter is mounted on a stiff cage, which at the same time holds the system in place. This design is so simple, you could still pop a fresh one in with a face full of mud. Without tools. In seconds.

Frame

All XC-W models feature new high-tech, lightweight chromoly steel frames. This includes hydro-formed elements produced by state-of-the-art robot welding. They retain their race-proven geometries, but by re-designing certain areas, the stiffness has been optimized, resulting in better feedback for the rider, playful handling and improved stability. The laterally attached engine head stays (the connection between cylinder, head and frame) are now made of aluminum, reducing vibration and further contributing to precise cornering. The bikes also feature newly designed lateral frame guards with a structured surface, improving grip, while also serving as a heat protector against the muffler on the right side. On the KTM 250 XC-W TPI frame, the engine is lowered by 1° around the swing arm pivot improving front wheel traction significantly. The subframe is made of extra-light and stable aluminum profiles, weighing less than 2 lbs (900 gr) and is 40 mm longer than before, providing better rear fender stability.

Swingarm

The KTM 250 XC-W TPI’s one-piece aluminum swingarm is manufactured using a gravity die-cast production process, offering exceptional strength at the lowest possible weight. The single-component casting process offers low weight, perfect flex behavior and also allows for a large number of geometry solutions.

Wheels

The KTM 250 XC-W TPI is fitted with lightweight, CNC-machined hubs, high-end Giant rims and black spokes with lightweight aluminum nipples providing maximum stability at minimum weight. The latest Dunlop Geomax AT81 tires guarantee perfect traction and outstanding performance.

Front suspension

All XC-W models are fitted with the latest 48 mm diameter WP XPLOR upside-down forks, featuring a split fork design developed by WP and KTM. It is fitted with a spring on both sides, but features separated functions for each fork leg: compression damping is fitted on the left side, while rebound is on the right. So the fork can easily be adjusted for compression and rebound with the twist of a dial on top of the fork tubes (30 clicks each). Although already distinguished for outstanding response and damping characteristics, the fork features a calibrated mid-valve piston for consistent damping. The settings keep the front end higher in the stroke, providing impressive reserves against bottoming out.

Rear suspension

The WP XPLOR shock absorber is the key element in the proven PDS rear suspension design (progressive damping system), where the shock is directly linked to the swingarm without an additional linkage system. This keeps weight lower and reduces the chances of hooking on rocks. Optimal dual-sport specific damping progression is achieved by using a second damping piston in combination with a closed cup towards the end of the stroke, and supported by a progressive shock spring. For 2020, improvements to the second piston, as well as a reworked shape and sealing of the cup, lead to improved resistance against bottoming without any sacrifice of comfort. New settings on the XPLOR shock with PDS technology provide better damping characteristics and match the new frame and reworked front-end set-up perfectly. It is fully adjustable, including high and low-speed compression, so you can set the shock up to suit any track, trail and rider preferences.

Triple clamp

The 250 XC-W TPI is fitted with forged triple clamps with an offset of 22mm, ensuring a solid grip of the fork and precise handling. The handlebar is adjustable forwards and backwards over 4 positions; this XC-W will fit you like your favorite gloves.

Brakes

These high-tech Brembo brakes are combined with lightweight Wave brake discs. You couldn’t brake any harder or with better feel on an offroad motorcycle.

Fuel tank

This is a lightweight polyethylene tank with a capacity of 2.4 gallons. Manufactured using see‐through plastic, you will always be able to see how much fuel remains at a glance. Additionally, the XC-W TPI models incorporate an integrated fuel pump system and an additional fuel level sensor so you’ll always know when you’re running low on gas.

Airbox

The air filter box design offers maximum protection of the air filter against soiling, while ensuring maximum airflow, and together with the intake snorkels, results in optimal power and throttle response. The large Twin Air air filter is mounted on a stiff cage, which at the same time holds the system in place. This design is so simple, you could still pop a fresh one in with a face full of mud. Without tools. In seconds.

Frame

All XC-W models feature new high-tech, lightweight chromoly steel frames. This includes hydro-formed elements produced by state-of-the-art robot welding. They retain their race-proven geometries, but by re-designing certain areas, the stiffness has been optimized, resulting in better feedback for the rider, playful handling and improved stability. The laterally attached engine head stays (the connection between cylinder, head and frame) are now made of aluminum, reducing vibration and further contributing to precise cornering. The bikes also feature newly designed lateral frame guards with a structured surface, improving grip, while also serving as a heat protector against the muffler on the right side. On the KTM 250 XC-W TPI frame, the engine is lowered by 1° around the swing arm pivot improving front wheel traction significantly. The subframe is made of extra-light and stable aluminum profiles, weighing less than 2 lbs (900 gr) and is 40 mm longer than before, providing better rear fender stability.

Seat

The XC-W range features state-of-the-art seat technology with a newly shaped surface that provides improved ergonomics and much better seat comfort thanks to higher foam padding. The seat is conveniently fixed to the bike using one long, lateral screw, making it safe and easy to handle.

Handlebar

All KTM XC-W models are equipped with the same high-strength aluminum tapered handlebar, made by NEKEN. The handlebar allows for four different positions. The handlebars come standard with an ODI vulcanized grip on the right side and a comfortable ODI.





2021 KTM 250 XC-W TPI – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $ 9999 USD
Canada MSRP Price: $ 11299 CDN
Europe/UK MSRP Price: £ NA (On The Road inc 20% Vat)

ENGINE

  • TRANSMISSION6-speed
  • STARTERElectric starter
  • STROKE72 mm
  • BORE66.4 mm
  • CLUTCHwet multi-disc clutch, Brembo hydraulics
  • DISPLACEMENT249 cm³
  • EMSContinental EMS
  • DESIGN1-cylinder, 2-stroke engine

CHASSIS

  • WEIGHT (WITHOUT FUEL)103.4 kg
  • TANK CAPACITY (APPROX.)9 l
  • FRONT BRAKE DISC DIAMETER260 mm
  • REAR BRAKE DISC DIAMETER220 mm
  • FRONT BRAKEDisc brake
  • REAR BRAKEDisc brake
  • CHAINX-Ring 5/8 x 1/4″
  • FRAME DESIGNCentral double-cradle-type 25CrMo4 steel
  • FRONT SUSPENSIONWP XPLOR-USD, Ø 48 mm
  • GROUND CLEARANCE370 mm
  • REAR SUSPENSIONWP Xplor PDS shock absorber
  • SEAT HEIGHT950 mm
  • STEERING HEAD ANGLE63.5 °
  • SUSPENSION TRAVEL (FRONT)300 mm
  • SUSPENSION TRAVEL (REAR)310 mm
