2021 Yamaha YZ250 Guide

2021 Yamaha YZ250

2021 Yamaha YZ250 2021 Yamaha YZ250 2021 Yamaha YZ250

2021 Yamaha YZ250 : 2‑STROKES. 1ST PLACE.

2021 Yamaha YZ250:

Pure performance and full‑throttle adrenaline is what you get from this lightweight and reliable 2‑stroke moto machine.

Revive memories of the good ol’ days with a YZ two-stroke! Nothing beats the bark and instantaneous throttle response of the lightweight YZ250. Not only is a two-stroke more affordable and easier to maintain, it also provides a very entertaining ride.

With its explosive power and agile handling, combined with an intense engine sound, there’s a lot to love about the YZ250 2-stroke. Prepare to be hooked!

If you’ve been around dirt bikes for a while you’ll know that the YZ250 has a pretty impressive track record. Over the years this thoroughbred race bike has won just about everything worth winning in motocross and supercross. And some of the sport’s greatest riders have made their name on this legendary 2-stroke.

The chassis is one of the lightest and sweetest handling set ups you’ll ever ride. Its aluminium frame gives a superb balance of rigidity and strength – and the industry-leading suspension package features 48mm spring-type front forks with speed sensitive damping and a link-type monocross rear end. As soon as you kick start the high performance engine into life you’ll experience its manic exhaust sound combined with the evocative smell of a 2-stroke exhaust. With the adrenaline flowing and your pulse racing, you’ll be ready to unleash its explosive performance and head straight for the VictorYZone!

At a glance

  • 250cc, 2-stroke engine with explosive performance
  • Lightweight semi-double cradle aluminium chassis
  • Instant power with agile handling
  • YZ-F type 48mm fork, separate air/oil function
  • YZ-F type Monocross rear suspension system
  • Sharp bodywork for a lean and modern image
  • Fast-action clutch adjuster mechanism
  • Wider footrests for increased controllability
  • 2-stroke engine technology for easier maintenance
  • Easy to adjust 38mm Keihin carburettor
  • Torque-boosting YPVS system
  • Wide range of genuine accessories available

Explosive power with lightweight agility.

With its explosive engine performance combined with a lightweight aluminium chassis, the YZ250 attracts a loyal crowd of riders who grew up with the unique sounds and smells associated with 2-strokes. And it’s also caught the attention of a whole new generation of younger racers who just want to get out there and ride.

There’s a whole lot of reasons why the YZ250 is still one of the best-loved dirt bikes. Its 250cc 2-stroke engine gives you one of the most exciting rides you’ll ever experience – and the high speci cation chassis with the latest KYB suspension from the YZ-F models ensures remarkable handling agility.

Equipped with the premium components including a 270mm front disc brake, wide footrests, colour
coordinated rims and an easy-to-use clutch adjuster, the YZ250 comes with the ultimate speci cation. And with its new Icon Blue bodywork and latest graphics, it’s ready.







2021 Yamaha YZ250 Totalmotorcycle.com Key Features
  • Modern Styling
    The front fender, front number plate, radiator shrouds, side number plates, air box, rear fender, fork guards, as well as the rear brake disc protector, rear brake caliper protector and wider foot pegs offer modern, aggressive styling —just like the 4-strokes.
  • Lightweight Frame
    A light aluminum frame houses the patented YPVS™-equipped ripper of an engine for an awesome power-to-weight ratio.
  • Rider-Friendly Chassis
    Ultra light weight means nimble handling and less fatigue.
  • 270mm Front Brake
    Large 270mm front disc brake coupled with high-performance pad material offers outstanding machine control and performance, plus exceptional stopping power and controllability.



Yamaha Announces Full Lineup of 2021 Motocross Bikes
Race like a Champion with Yamaha’s Redesigned YZ250F and Monster Energy® Yamaha Racing Editions

Yamaha Motor Corporation, USA, introduces its complete lineup of race-ready 2021 motocross bikes including the updated YZ250F. Featuring a thoroughly refined engine, revised frame, new suspension settings and new brakes, the YZ250F continues to dominate the competition with the best balance of power and handling.

“The YZ250F is clearly the leader in its class, winning back-to-back Monster Energy AMA Supercross West Coast 250SX Championships, dominating media shootouts year after year, and by offering industry-exclusive features like the free Power Tuner app, which allows riders to wirelessly tune engine performance for changing track conditions,” said Derek Brooks, Yamaha Motorsports Motorcycle Product Line Manager. “For 2021 the YZ250F gets significant engine, frame, suspension and brake updates to deliver more class-leading power and offer a superior balance of nimble yet confidence-inspiring handling. Yamaha’s entire 2021 motocross lineup continues to raise the bar of competitive performance.”

Also new for 2021, the YZ250F and YZ450F will be offered in special Monster Energy Yamaha Racing Editions, pairing Yamaha’s legendary YZ performance with a new, race team-inspired aesthetic.

In addition to the updated YZ250F and the Monster Energy Racing Edition models, the full two-stroke lineup consisting of the YZ65, YZ85, YZ125 and YZ250, as well as the four-stroke YZ450F, all return for 2021 with the next-generation Team Yamaha Blue color and graphics scheme to further accentuate the advances of the YZ series.

Welcome to the victorYZone
Yamaha’s off-road competition bikes offer the very latest in technology with performance features designed to help racing enthusiasts reach their maximum potential, win races, and stand on top of the podium.

New 2021 YZ250F: Tune, Race, Win
The new 2021 Yamaha YZ250 has been redesigned for a more competitive, greater performing motocross experience. The new 250cc, liquid-cooled, four-stroke, electric start engine features an all-new cylinder head with an improved intake port shape and new camshaft profile, as well a new airbox and intake track, a new silencer, and an updated ECU. These modifications, along with other refinements like an updated transmission and shift cam, a revised clutch design and improved water pump impeller, all help to produce stronger mid- to top-end power and increased peak power, while retaining its class-leading low-end torque.

Tuned specifically for the 2021 YZ250F, the updated lightweight aluminum, bilateral beam frame, and new engine mounts have been redesigned with all-new flex characteristics to improve bump absorption, traction, and cornering performance. The industry-leading, fully adjustable KYB® coil spring-type fork, with enhanced speed-sensitive damping, provides an exceptional balance between comfort and bottoming resistance while the link-type rear suspension features a KYB shock with revised damping characteristics to match the updated chassis. Other chassis components such as the top triple clamp, handlebar mounts, and front axle were also redesigned to complement the new frame. Improved braking performance is achieved with newly engineered lighter weight front and rear brake calipers, larger surface area brake pads, and redesigned front (270mm) and rear (240mm) discs.

The 2021 YZ250F gives racers the edge right out of the gate. Standard equipment includes electric start, a lightweight lithium battery, advanced fuel injection, a front-positioned intake, and rear-positioned exhaust layout to deliver the widest spread of power with reliable performance while balancing the weight for excellent mass-centralization. Racers can adjust their engine performance straight from their phone using the onboard wireless connectivity through the industry’s only free-of-charge complete tuning system, which is highlighted by the Yamaha Power Tuner App. Once settings are dialed in, racers can then choose between two user-defined ECU maps on the fly via the handlebar mounted dual-mode engine map switch. Complemented by new next-generation Team Yamaha Blue color and graphics, the 2021 YZ250F showcases Yamaha’s race-winning pedigree.

New for 2021: Monster Energy Yamaha Racing Editions
Stand out from the crowd. The 2021 YZ250F and 2021 YZ450F now come in new Monster Energy Yamaha Racing Editions. With a factory team-inspired color and graphics package, riders can feel as if they too are part of a Yamaha championship-winning Supercross team.

2021 YZ450F: Tune into Victory
The 2021 YZ450F returns with all of the class-leading features first introduced on the 2020 YZ450F, including an updated engine, cylinder head, frame and technology features for a more powerful and better handling motocross experience. Racers can achieve quicker, smoother race starts through Yamaha’s Launch Control System, adjust their on-track performance using the onboard wireless connectivity through the free-of-charge Yamaha Power Tuner App right from their phone, and choose between two user-defined ECU maps on the fly through the handlebar-mounted dual-mode engine map switch.

2021 YZ125 and YZ250
Yamaha’s YZ125 and YZ250 models return for 2021 to complete Yamaha’s full-size lineup of motocross bikes. With their modern styling, lightweight aluminum frame and industry-leading KYB Speed Sensitive System front forks and KYB fully-adjustable rear shock, the 2021 YZ125 and YZ250 continue their outstanding performance and durability with a rider-friendly chassis and race-ready features.

2021 YZ65 and YZ85
The 2021 youth models are once again ready to tackle the track. The YZ65 and YZ85 are powered by confidence-inspiring 65cc and 85cc two-stroke engines. Featuring the Yamaha Power Valve System, these engines deliver a broad spread of power and torque across the entire rev range, without losing any power at high RPM. Fully adjustable, industry-leading 36mm KYB spring type forks and KYB rear shock contribute to class-leading handling and performance in a wide range of conditions. Four-way, adjustable handlebar positioning, as well as lever-reach adjustability are designed for ultimate rider comfort, regardless of size. Finally, with two-stroke ease of maintenance and Yamaha’s proven durability, the 2021 YZ65 and YZ85 are built to keep kids on the track.

Yamaha bLU cRU Off-Road Racing Contingency Program
All 2021 YZ models are eligible for Yamaha’s current 2020 bLU cRU Off-Road Racing Contingency Program, which features nearly $5 million for Yamaha bLU cRU riders competing in off-road motorcycle racing. YZ riders can earn contingency payouts via a bLU cRU debit card, receive a 10 percent rebate on GYTR parts and accessory purchases of up to $1,000, and receive an instant $45 credit.







2021 Yamaha YZ250 Totalmotorcycle.com Features and Benefits
  • Two-Stroke Power
    The 249cc liquid-cooled reed-valve-inducted two-stroke engine is lightweight, compact and features an incredibly wide, hard-hitting powerband.
  • Yamaha Power Valve System
    Patented YPVS™ combines crisp, hard-hitting bottom-end acceleration with strong midrange and eye-opening top-end.
  • Advanced Carburetor
    38mm Keihin® PWK carburetor with power jet and throttle position sensor (TPS) provides precise fuel/air mixing and extra-crisp throttle response throughout the powerband.
  • Race-Developed Intake
    Special-design carbon fiber reed-valve petals improve the throttle response and engine performance across the entire rpm range.
  • Close-Ratio Transmission
    Smooth-shifting, five-speed, close-ratio transmission with heavy-duty, multiplate clutch.
  • High-Capacity Radiator
    Large-capacity radiator features a ten-row core with four louvers for maximum cooling efficiency.
  • Digital Ignition
    Digital CDI system delivers precise spark for faster, stronger response anywhere in the powerband.



  • 270mm Front Brake
    Large 270mm front disc brake coupled with high-performance pad material offers outstanding machine control and performance, plus exceptional stopping power and controllability.
  • Industry-Leading Fork
    The KYB® 48mm forks feature the Speed-Sensitive System that uses piston speed to control the damping force for super-precise handling and a smooth ride.
  • Aluminum Frame
    A carefully engineered, advanced aluminum frame and swingarm give the YZ250 the best handling in the 250 class.
  • Lightweight Subframe
    Removable aluminum rear subframe is constructed of square-section tubing for reduced weight.
  • Advanced KYB® Shock
    Fully adjustable KYB® shock features reduced-friction Kashima Coat™ internals, 12.4 inches of travel, separate adjusters for high- and low-speed compression damping, and a full lock oil rebound system for increased comfort. All add up for fantastic rear wheel control and a sweet ride.
  • Excel® Rims
    Lightweight 21-inch front and 19-inch rear Excel® rims provide exceptional durability and help reduce unsprung weight for optimal suspension, performance and handling.
  • Race-Ready Tires
    Premium Dunlop® knobbies offer race-spec traction and wear.

Race-Ready Features
Complete with an aluminum handlebar, 2-position adjustable handlebar clamp, wide foot pegs, gripper seat and adjustable clutch lever with works-style cable adjuster, the YZ250 is ready to race out of the crate.





2021 Yamaha YZ250 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $7499 USD
Canada MSRP Price: Starting at $8,299 CDN
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)

Engine Type 249cc liquid-cooled 2-stroke; reed-valve inducted
Bore x Stroke 66.4mm × 72.0mm
Compression Ratio 8.9~10.6:1
Fuel Delivery Keihin® PWK38S
Ignition CDI
Transmission Constant-mesh 5-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front KYB® Speed-Sensitive System inverted fork;
fully adjustable, 11.8-in travel
Suspension / Rear KYB® single shock; fully adjustable, 12.4-in
travel
Brakes / Front Hydraulic disc, 270mm
Brakes / Rear Hydraulic disc, 245mm
Tires / Front 80/100-21 Dunlop® MX52
Tires / Rear 110/90-19 Dunlop® MX52
L x W x H 85.7 in x 32.6 in x 51.4 in
Seat Height 39.1 in
Wheelbase 58.3 in
Rake (Caster Angle) 27.7°
Trail 4.8 in
Ground Clearance 14.2 in
Fuel Capacity** 2.1 gal
Wet Weight*** 227 lb
Warranty 30 Day (Limited Factory Warranty)
Color Team Yamaha Blue







2021 Yamaha YZ250 – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE

ENGINE2-stroke, liquid-cooled, crankcase reed-valve, single
DISPLACEMENT249 cc
BORE AND STROKE66.4 x 72 mm
COMPRESSION RATIO8.9~10.6:1
FUEL DELIVERYKeihin PWK38S
IGNITION / STARTINGCDI / Kick
TRANSMISSIONConstant mesh, 5-speed
FINAL DRIVEChain

CHASSIS

SUSPENSION (FRONT)Fully adjustable 48 mm inverted fork / 300 mm (11.8″) wheel travel
SUSPENSION (REAR)Fully adjustable link Monocross / 315 mm (12.4″) wheel travel
BRAKES (FRONT)270 mm floating disc / twin piston caliper
BRAKES (REAR)245 mm disc / single piston caliper
TIRES (FRONT)80/100-21
TIRES (REAR)110/90-19



CRITICAL DATA

LENGTH2,185 mm (86″)
WIDTH825 mm (32.5″)
HEIGHT1,290 mm (50.8″)
WHEELBASE1,485 mm (58.5″)
GROUND CLEARANCE360 mm (14.2″)
SEAT HEIGHT970 mm (38.2″)
FUEL CAPACITY8 litres (1.8 imp. gallons)
WET WEIGHT103 kg (227 lbs)
COLOUR(S)Yamaha Racing Blue





2021 Yamaha YZ250 – Totalmotorcycle.com European Specifications/Technical Details

Engine
Engine type 2-stroke;Single cylinder;liquid-cooled;reed valve with
YPVS
Displacement 249cc
Bore x stroke 66.4 mm x 72.0 mm
Compression ratio 8.9 ~ 10.6 : 1
Lubrication system Premix
Clutch Type Wet;multiple-disc coil spring
Ignition system CDI
Starter system Kick
Transmission system Constant Mesh;5-speed
Final transmission Chain
Carburettor Keihin PWK38S/1
Chassis
Frame Semi double cradle
Caster Angle 27º 40″
Trail 122mm
Front suspension system Upside-down telescopic fork
Rear suspension system Swingarm;(link suspension)
Front travel 300 mm
Rear Travel 315 mm
Front brake Single Disc, Ø270 mm
Rear brake Single Disc, Ø245 mm
Front tyre 80/100-21 51M
Rear tyre 110/90-19 62M
Dimensions
Overall length 2,185 mm
Overall width 825 mm
Overall height 1,290 mm
Seat height 970 mm
Wheel base 1,485 mm
Minimum ground clearance 360 mm
Wet weight (including full oil and fuel tank) 103 kg
Fuel tank capacity 8.0litres
Oil tank capacity 0.8litres



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
