2022 Ducati TK-01RR Limited Edition: OFF-ROAD AT TOP-SPEEDS.
Introducing the new 2022 Ducati TK-01RR Limited Edition…
The new Ducati TK-01RR Limited Edition, available in Europe and the United States in just 169 numbered units, is the even more exclusive version of the Ducati e-enduro. This limited edition is a concentrate of technology that confirms the key features and aptitude of the TK-01RR version, but is enriched with more advanced components, with the aim of further improving performance, especially in downhill sections.
The Öhlins DH38 dual-plate motorcycle-style air fork (180 mm travel) and the Öhlins TTX spring shock absorber (170 mm travel) ensure incredible control of the vehicle downhill, while still maintaining great efficiency on uphill stretches. The 11-speed Shimano Di2 XT rear electronic shifter always provides fast and precise shifting, while the Magura MT7 brakes with 220 mm discs at the front and 203 mm at the rear are also of motorcycle derivation and are among the most powerful available on the market.
The differentiated format Crankbrothers Synthesis wheels (29″ front, 27.5″ rear) with variable thickness carbon rims help to further improve riding precision, guaranteeing an excellent weight / strength ratio. The set-up is completed by a Renthal carbon handlebar, a Fizik saddle with a special integrated tool holder, and finally a carbon battery cover and skid plate.
The “Ducati Powered by Thok” e-bikes are manufactured under license by KP Srl and can be ordered through the Ducati dealer network in Europe and online on this website. There is an option to choose delivery to an authorized retailer or to your home.
Off road. At top speeds.
For 2022 the TK-01RR is also in a limited edition: a concentrate of technology that confirms the main features and attitude of the TK-01RR version, but enriched with more advanced components, with the aim of further improving performance, in particular in the downhill sections.
In a nutshell pure adrenaline: the best of Downhill but always efficient on the stretches to be pedaled.
DUCATI 2022 E-BIKES RANGE
The Ducati powered by Thok E-Bikes project is a consolidated reality in the pedal-assist bicycle segment, the result of the collaboration between the Bologna-based manufacturer and Thok E-Bikes.
The goal of the project is to offer unique and exciting experiences to enthusiasts of this world. Ducati E-Bikes focus on high performance, innovative technological solutions and the distinctive design typical of the Borgo Panigale company.
2022 Ducati TK-01RR Limited Edition Totalmotorcycle.com Key Features
Ducati E-Bikes Range is Updated for 2022 and Will Extend into e-Road Segment With New Futa
- The Ducati Futa is the first pedal-assisted road bike in the Ducati E-Bikes range: a high-performance e-road for those who want to train, have fun and pedal to their full potential
- The All Mountain MIG-S takes an important evolutionary step in 2022 thanks to the more high-performance Shimano EP8 drive unit and updated components
- The “Limited Edition” version of the e-enduro TK-01RR is presented with even more sophisticated components to express the full potential of the bike in downhill riding
For the 2022 season, the big news is the Futa: the first Ducati racing bicycle with pedal assistance. The Ducati E-Bikes range is also updated with an evolution of the MIG-S and the presentation of the TK-01RR Limited Edition.
Giorgio Favaretto, Head of Ducati E-Bikes business: “The Ducati E-Bikes project was born in 2019 and immediately set itself the goal of offering pedal-assisted bicycles with which to live unique and memorable experiences. The updates to existing models and the presentation of the new Ducati Futa give a further push in this direction, making up an even more complete and higher-performance range of E-Bikes for 2022. In particular, the inclusion of the Futa allows us to welcome new enthusiasts of this world into our family.”
In 2022 the range expands with the presentation of the new Ducati TK-01RR Limited Edition available now, an even more exclusive version of the Ducati e-enduro with which to tackle off-road challenges. This limited edition is a concentration of technology that confirms the key features of the TK-01RR version, but is enriched with more advanced components, with the aim of further improving performance, especially in difficult downhill sections.
The Öhlins DH38 dual-plate motorcycle-style air fork (180 mm / 7 inch travel) and the Öhlins TTX spring shock absorber (170 mm / 6.7 inch travel) ensure incredible control of the vehicle downhill, while still maintaining great efficiency on uphill stretches. The 11-speed Shimano Di2 XT rear electronic shifter always provides fast and precise shifting, while the Magura MT7 brakes with 220 mm (8.7 inch) discs at the front and 203 mm (8 inch) at the rear are also of motorcycle derivation and are among the most powerful available on the market.
The differentiated format Crankbrothers Synthesis wheels (29″ front, 27.5″ rear) with variable thickness carbon rims help to further improve riding precision, guaranteeing an excellent weight / strength ratio. The set-up is completed by a Renthal carbon handlebar, a Fizik saddle with a special integrated tool holder, and finally a carbon battery cover and skid plate.
The Ducati MIG-S is an agile, high-performance and fun “All Mountain,” born to tackle any trail and ensure maximum fun in any condition. For 2022, the electric mountain bike is renewed in its aesthetics with a brand-new sporty livery which, as in all models in the range, was designed by Aldo Drudi in collaboration with the Centro Stile Ducati. The MIG-S also takes an important evolutionary step from a technical point of view by welcoming the more high-performance Shimano EP8 engine together with updated components.
The new Shimano EP8 drive unit represents a benchmark for the category. It is an exceptionally light engine (2.6 kg / 5.7 lb in weight), capable of delivering up to 85 Nm of torque (62.7 lb-ft) with a maximum servo assistance ratio of 400%. In this engine the torque is always delivered with fluidity and naturalness to ensure excellent control of the bicycle. Thanks to the Shimano Etube Project App, it is also possible at any time to adapt the character of the motor to your needs via your smartphone wirelessly, by adjusting maximum torque and assistance timing.
The Ducati MIG-S can explore any path, ensuring excellent handling for the rider. The handling of this e-mtb is made possible by the high-level components it is equipped with.
The new suspensions (RockShox 35 RC fork and RockShox SuperDeluxe shock absorber) are adjustable and have a travel of 150 mm (5.9 inches) at the front and 140 mm (5.5 inches) at the rear, ideal for tackling any type of path in safety. The 12-speed SRAM transmission is even more precise and reliable, while the brakes are the powerful 4-piston SRAM Guide T with 203 mm (8-inch) discs. The 29″ front and 27.5″ THOK e-plus wheels are equipped with Pirelli Scorpion Enduro S tires at the front and Pirelli Scorpion EMTB-S at the rear to offer maximum grip and traction on the most demanding stretches and at higher speeds. The 630Wh Shimano battery is positioned externally, under the downtube, ensuring an extremely low center of gravity and maximizing stability.
The most important Ducati powered by Thok news for the 2022 E-Bikes range is called Ducati Futa. The name derives from the Futa Pass, the road that crosses the Apennines connecting Bologna to Florence, well-known and much-appreciated by many Ducatisti. The Ducati Futa is a performing e-road, for those who want to train, have fun and pedal to their maximum even over long distances and when covering the most demanding climbs. A light e-bike that embodies the Ducati spirit by focusing on design, innovation and fun in a perfect combination of comfort and performance.
The UD carbon fiber monocoque frame features sport endurance geometry, but with technical choices oriented to aerodynamics and speed. The compact seatstays, with lowered liners, makes the E-Bike comfortable, while generating less aerodynamic drag. The rear frame is stiff laterally, precisely by virtue of the choice of liners positioning and favors a better transmission of power to the wheel, as well as increasing the responsiveness of the bike. Downtube, seat post and fork blades are expertly profiled, and their reliefs are highlighted by the play of colors of the livery, which sees grey and black as the main colors with accents in Ducati Red.
The engine, located on the rear hub, is the FSA System HM 1.0 with 250W and 42Nm (31 lb-ft) of torque which boasts a fluid and natural delivery in all conditions and is among the lightest and most compact in its category (3.98 kg / 8.8 lb). This engine is equipped with 5 assistance levels that can be selected via the Garmin control on the handlebar, which allows you to manage the desired level of support. The FSA app, available for iOS and Android devices, allows the rider to view statistics, system status, remaining battery life and charge status quickly and intuitively. Through the app it is also possible to download any software updates and communicate with FSA service centres around the world.
Thanks to its low weight (12.4Kg / 27.3 lb in M size) and to an almost imperceptible engine resistance, exceeding 25Km/h*, the Ducati Futa is always responsive and fast on flat stretches. The standard FSA K-Force WE group set features an exceptionally smooth and fast 2×12-speed wireless electronic shifting, powerful 160 mm (6.3 inch) disc brakes with adjustable UD carbon interchangeable levers and crankset with pedal arms in carbon.
The Vision AGX30 wheels with carbon rims are fitted with 35 mm (1.4 inch) Pirelli Cinturato Velo TLR tires, which guarantee smoothness, comfort and grip, combined with considerable strength. The 250Wh FSA battery is integrated in the downtube and an optional 250Wh range extender is available to cover even longer distances.
2022 Ducati TK-01RR Limited Edition Totalmotorcycle.com Features and Benefits
Double plate fork and Öhlins spring shock absorber
Same technology as the RXF38 but stiffer to ensure incredible wheel control on the ground in the most extreme conditions. The Öhlins DH38 180mm travel fork, developed in racing, is the benchmark in its category for its ability to absorb both small and large bumps while always maintaining a fluid, fast and controlled ride.
The Öhlins spring shock absorber with 170 mm travel uses exclusive TTX technology long proven in the motorcycle sector and now applied to MTBs. This exceptional performance suspension package elevates the riding experience by increasing stability, absorbing roughness and transmitting excellent traction.
Wheels with carbon rims
Crankbrothers Synthesis always in differentiated format (29″ x 31 mm front, 27.5″ x 35 mm rear) with variable thickness carbon rims are smoother than the aluminum version supplied with the TK-01RR and help to improve further riding precision, guaranteeing an exceptional weight / strength ratio.
Magura MT7 brakes
4-piston aluminum monobloc with 220mm discs at the front and 203mm at the rear, they are of motorcycle origin and are among the most powerful on the market. The shape of the levers favour the ergonomics and are interchangeable.
Shimano electronic gearshift
The 11-speed Shimano Di2 XT rear derailleur (11-46T) ensures precise and instant stable shifting on all types of terrain and reliable over time. The gear cage is equipped with Shadow RD+ technology, that is a clutch that minimizes chain slap. Through Shimano’s E-Tube program, gearshifting can be programmed and customized.
Fizik saddle with Alpaca Tool Carrier
With an innovative multitool system, characterized by a minimal design and where objects remain almost invisible under the saddle, but always ready in case of repair. The Crankbrothers Highline 7 dropper post with handlebar control always has a smooth and long-lasting operation.
Carbon components
The Renthal Fatbar handlebar, the battery cover and the carbon fibre engine guard, as well as being light and resistant, give further prestige to the model.
2022 Ducati TK-01RR Limited Edition – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $10995 USD
Canada MSRP Price: $ CDN
Europe/UK MSRP Price: £10890 GBP (On The Road inc 20% Vat)
Frame
Thok 6061 aluminum, forged and CNC machined, headtube tapared 1.8”
Battery
Shimano – 630 Wh integrated. Carbon fiber battery cover
Fork
Öhlins – RXF DH38 Air, Boost – 29″, 180 mm of tr avel, HS/LS compression and rebound adjust
Rear shock
Öhlins – TTX22M Coil- 170 mm travel, custom tuned Ducati, metric 230 x 65 mm
Brakes
MAGURA- MT7, 4 pistons caliper with MDR-P rotor : 220 front and 203 mm rear
Crank
FSA – 165 mm with chainring 34T
Stem
Ducati – CNC Alloy 35 mm, 45 mm length
Handlebar
Renthal Carbon 35 mm, rise 20 mm, 800 mm width
Wheels
Crankbrothers – Synthesis – Carbon 29″ x 31 mm, 27.5″ x 35 mm
Tires
Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6
Seatpost
Crankbrothers Highline 7 Dropper post micro height adjustable with remote control (S-125, M-150, L/XL-170 mm)
Saddle
FIZIK – Alpaca Tool Carrier (integrated multitool & Co2 )
Pedals
Alloy pedals
Engine
Shimano Steps EP8 (250 Watt – 62.7 lb-ft – 5.7 lb). Carbon fiber skidplate
Display
Shimano – Display SC-EM800 LCD display with remote control
Rear derailleur
Shimano – Deore XT Di2 11 S 11-46T
Shift lever
Shimano – Deore XT Di2 11 S
Size
S – M – L – XL
2022 Ducati TK-01RR Limited Edition – Totalmotorcycle.com Canada Specifications/Technical Details
Frame
Thok 6061 aluminum, forged and CNC machined, headtube tapared 1.8”
Battery
Shimano – 630 Wh integrated. Carbon fiber battery cover
Fork
Öhlins – RXF DH38 Air, Boost – 29″, 180 mm of tr avel, HS/LS compression and rebound adjust
Rear shock
Öhlins – TTX22M Coil- 170 mm travel, custom tuned Ducati, metric 230 x 65 mm
Brakes
MAGURA- MT7, 4 pistons caliper with MDR-P rotor : 220 front and 203 mm rear
Crank
FSA – 165 mm with chainring 34T
Stem
Ducati – CNC Alloy 35 mm, 45 mm length
Handlebar
Renthal Carbon 35 mm, rise 20 mm, 800 mm width
Wheels
Crankbrothers – Synthesis – Carbon 29″ x 31 mm, 27.5″ x 35 mm
Tires
Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6
Seatpost
Crankbrothers Highline 7 Dropper post micro height adjustable with remote control (S-125, M-150, L/XL-170 mm)
Saddle
FIZIK – Alpaca Tool Carrier (integrated multitool & Co2 )
Pedals
Alloy pedals
Engine
Shimano Steps EP8 (250 Watt – 62.7 lb-ft – 5.7 lb). Carbon fiber skidplate
Display
Shimano – Display SC-EM800 LCD display with remote control
Rear derailleur
Shimano – Deore XT Di2 11 S 11-46T
Shift lever
Shimano – Deore XT Di2 11 S
Size
S – M – L – XL
2022 Ducati TK-01RR Limited Edition – Totalmotorcycle.com European Specifications/Technical Details
Frame
Thok 6061 aluminium forged and CNC machined, headtube tapared 1.8”
Battery
Shimano – 630 Wh (integrated)
Fork
Öhlins – RXF38 Air TTX18, Boost – 29″, 180 mm of tr avel, HS/LS compression and rebound adjust
Rear shock
Öhlins – TTX Air- 170 mm travel, custom tuned Ducati
Brakes
Shimano – Deore XT – 4 pistons caliper with “Ice Technologies” rotor 203 mm diameter
Crank
FSA – 165 mm with chainring 34T
Stem
Ducati – CNC Alloy 35 mm, 45 mm length
Handlebar
Renthal Carbon 35 mm, rise 20 mm, 800 mm width
Wheels
Crankbrothers – Synthesis – Alloy 29″ x 31 mm, 27.5″ x 35 mm
Tires
Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6Front: Pirelli Scorpion Enduro S, TR, SmartGrip, HyperWall 29″ x 2.6 Rear: Pirelli Scorpion E-MTB S, TR, SmartGrip, HyperWall, 27.5” x 2.6
Seatpost
KS – Dropper post micro height adjustable with remote control
Saddle
Ducati Fit – hollow Cr.Mo rail
Pedals
Alloy pedals
Display
Shimano – Display SC-EM800 LCD display with remote control
Rear derailleur
Shimano – Deore XT 12 S
Shift lever
Shimano – 12 SLX
Size
S – M – L – XL
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
