2026 KTM 390 Enduro R: FOR WHEN MOTHER NATURE SAYS NO.
Introducing the 2026 KTM 390 Enduro R…
When deciding the ultimate route between points A and B, the KTM 390 ENDURO R owns every avenue. With exceptional, lightweight handling and punchy performance on both tarmac and dirt tracks, this middle-weight bruiser is ready to take on any road or commute. Packing state-of-the-art rider aids, adjustable suspension, and aggressive, enduro-inspired styling into a complete middle-weight package, the KTM 390 ENDURO R is ready for anything.
2026 KTM 390 Enduro R Totalmotorcycle.com Key Features
2026 KTM 390 Enduro R Totalmotorcycle.com Features and Benefits
PLUSH PERFORMANCE
Adjustablity
Finding that perfect balance when attacking your favorite stretch of dirt or for added comfort around town is easy, thanks to the KTM 390 ENDURO R’s adjustable suspension, brake and clutch levers, and footrests — not to mention a complete PowerPart catalog filled with performance — and style-enhancing add-ons.
INFOTAINMENT
TFT-DISPLAY
The H42 TFT dashboard takes prime position ahead of the rider, featuring a unique, specially-designed user interface to suit the compact screen size. Made from bonded glass, the 4.2″ TFT screen also boasts a special coating and polarization to reduce glare and increase visibility in all lighting conditions. Riders can also access music, incoming calls, turn-by-turn navigation, and Ride modes via the dashboard – with a USB-C port for device charging duties.
READY TO SHRED
Bodywork
With an ergo triangle inspired by its trusted and beloved 690 siblings, the KTM 390 ENDURO R boasts aggressive, offroad-ready bodywork and a compact 2.37 gallon (9 liter) metal fuel tank perfectly styled for easy off-road action. The bodywork is also made from proven, flexible, and long-lasting PP plastic materials better suited for off-roading and aggressive riding.
100% ENDURO
Graphics
The KTM 390 ENDURO R comes with premium looks and a striking graphic design as standard. Thanks to proven in-mold graphics, it looks the part and can handle anything the outdoors throws at it.
POWER HUNGRY
Engine
Boasting the latest generation of KTM’s LC4c engine, the KTM 390 ENDURO R features a compact, 399 cc single-cylinder powerplant, churning out impressive power and effortless acceleration. This makes it ideal for charging through motorway traffic or up steep, gravel mountain passes.
PICK YOUR POWER
Ride Modes
The KTM 390 ENDURO R offers its pilots a selection of RIDE MODES to best suit whatever conditions they find themselves in. STREET Mode is activated as standard, and OFFROAD Mode is for when the tarmac ends. All RIDE MODES and ABS settings are easily toggled via the TFT display.
BRAKE YOUR WAY
ABS
The KTM 390 ENDURO R boasts a Bosch 10.3MB Modulator, which is the brain responsible for its impressive ABS system. This enables standard ABS and an OFFROAD ABS option for dirt applications. However, should you want more control and better “skidablity”. The dedicated ABS-off button allows all ABS to be disabled.
LIGHT UP THE DARKNESS
LED Lighting
Tearing a deep gash into the night, the KTM 390 ENDURO R is equipped with powerful LED lights taken from its bigger brother, the KTM 690 ENDURO R. These lights not only work when the world becomes dark but also provide improved visibility when navigating heavy traffic or misty road conditions.
RACE TO COMFORT
Ergonomics
With an ergo-triangle inspired by its bigger brother, the KTM 690 ENDURO R, the KTM 390 ENDURO R features an aggressive handlebar shape, upright seating angle, and generous space for easy on-bike mobility.
TAKE A SEAT
Seat
Taking inspiration from the KTM EXC range but with added comfort for longer commutes or trips, the KTM 390 ENDURO R has a single-piece flat seat design for easy on-board mobility and when standing on the pegs.
FIND YOUR FOOTING
Footpegs
All-new, grippy footrests ensure riders have an uninterrupted foothold when banging through the gears or carving up a muddy track. These are also adjustable in two positions.
THE BACKBONE
Frame
The new design features a 2-piece construction composed of a steel trellis main frame and a bolt-on steel trellis subframe. The frame design is not only intended to enhance overall aesthetics but also to improve vehicle dynamics by increasing torsional rigidity, delivering better agility, and providing enhanced chassis feedback on both tarmac and dirt tracks.
CURVED PIVOT
Swingarm
A gravity die-cast swingarm has been specifically developed for the KTM 390 ENDURO R and provides a sturdy and durable platform for the rear suspension system. Featuring a direct shock absorber mount offset to the side, it creates additional space for the unique exhaust system.
SPRING INTO ACTION
Suspension
Upfront, a 43 mm WP APEX open cartridge fork with 230 mm travel keeps things in check, with adjustable compression and rebound in 30 easy clicks for easy adjustment. On the rear, any big hits are handled by a WP APEX Separate piston shock absorber with 230 mm of travel. The shock is also rebound adjustable with 20 clicks on the fly, while preload adjustment can be taken care of with a tool.
ROLLING THUNDER
Wheels and Tires
Emphasizing its undeniable offroad character, the KTM 390 ENDURO R boasts spoked 21″ front and 18″ rear wheels
STOPPING POWER
Brakes
Pulling out all the stops, the KTM 390 ENDURO R is equipped with a 285 mm brake disc and Bybre caliper up front and a 240 mm brake disc and single-piston caliper at the rear. These are supported by KTM’s proven ABS technology, but this can also be disabled completely for added agility offroad.
RIDE WORRY FREE
Premium Manufacturer’s Warranty
This motorcycle comes with a PREMIUM MANUFACTURER’S WARRANTY. Riders enjoy up to 4 years of coverage; ride worry-free and experience the thrill of KTM with added peace of mind. To keep the warranty valid, regular services must be performed according to the service plan at an authorized KTM dealer. More information and details on how to benefit from this offer can be found on the KTM warranty page. Valid from Model Year 2025 onwards for all street legal motorcycles across the entire street range. Previously limited to selected models, the Premium Manufacturer’s Warranty now covers the entire street range.
2026 KTM 390 Enduro R – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $6,049 USD
Canada MSRP Price: $ See Dealer CDN
Europe/UK MSRP Price: £5,699 GBP (On The Road inc 20% Vat)
Engine
Design
1-cylinder, 4-stroke engine
Displacement
398.7 cm³
Power
45 PS
Torque
39 Nm
Transmission
6-speed
CO2 emissions
78 g/km
Cooling
Liquid cooled
Engine cylinder
Single cylinder
EMS
Bosch EMS with RBW
Engine oil
Motorex Formula 4T 15W/50
Engine stroke
4-Stroke
Chassis
Front brake disc diameter
285 mm
Rear brake disc diameter
240 mm
Front brake
Bybre axial floating calipers with 2 pistons
Rear brake
Bybre floating caliper 1 piston
Chain
520 X-Ring
Frame design
Steel trellis frame, powder coated
Steering head angle
62.9 °
Rear subframe design
Bolt on steel trellis frame, powder coated
Trail
107 mm
Wheelbase
1475 mm
Suspension
Front suspension
WP APEX open cartridge 43mm
Rear suspension
WP APEX Split Piston
Suspension travel (front)
230 mm
Suspension travel (rear)
230 mm
Front suspension adjustment
Compression and rebound adjustable
Front suspension addition
Comp. and Reb. Adjustable – 30 Clicks
Rear suspension setting
Preload with top ring
Rear suspension addition
Preloand with top ring and Reb. with 20 clicks
Dimensions
Seat height
890 mm
Tank capacity (approx.)
9 l
Ground clearance
272 mm
Weight (without fuel)
159 kg
Weight fully fueled
165 kg
Front wheel diameter
21 “
Rear wheel diameter
18 “
Front wheel width
1.85 “
Rear wheel width
2.5 “
Wheels
1.85 x 21″; 2.5 x 18″
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
