2009 Victory Kingpin Low
Back to 2009 Victory Motorcycle Index Page

Click photos to enlarge.
They make great desktop images.

2009 Victory Kingpin Low

2009 Victory Kingpin Low

2009 Victory Kingpin Low

2009 Victory Kingpin Low

2009 Victory Kingpin Low

• 2009 Victory Kingpin Low

2009 Victory Kingpin Low

Riders who seek a low seat height and easily accessible controls will feel like these Low Cruisers have been custom-sized just for them. The ergonomics deliver comfort and inspire confidence.

New model for 2009 plus
– New Stingray cast wheels that are 13.8 lbs lighter
– New LED tail light is twice as bright
– New Headlight lighter and better pattern

Key Features
– Lowered Classic Cruiser: reassuring, stabile, and comfortable – visual mass is a plus
– Narrower and lower 25.2” seat height
– Foot and hand controls moved back 2”
– Passenger seat and pegs removed for clean look

Features & Benefits

• 2 inch Pull back bars

• Foot pegs moved 2.25″ rearward

• Split-Tail fuel tank integrated with solo seat

• Mutli LED Tail light

• Lower seat height and narrower side covers

• Freedom 100 Cubic Inch V-Twin Engine

• Custom-inspired headlight

• Inverted forks

• Stingray billet wheels

• Comfortable riding position





2009 Victory Kingpin Low – USA Specifications

MSRP $16,399.00

ENGINE
Engine 4-stroke, 50° V-twin, single overhead camshafts with 4-valves per cylinder, self-adjusting cam chains, hydraulic lifters

Displacement 100 ci (1,634 cc)

Bore x Stroke 101 x 102 mm

Compression Ratio 8.7:1

Fuel System Electronic Fuel Injection with dual 45 mm throttle bodies

Clutch Wet, multi-plate

Cooling Air / oil

Exhaust Staggered slash-cut dual exhaust with crossover

DIMENSIONS
Length 99.9 in. (2,537 mm)

Weight Dry: 657 lbs. (298 kg)

GVWR: 1,234 lbs. (560 kg)

Ground Clearance 5.3 in. (135 mm)

Wheelbase 65.6 in. (1,666 mm)

Fuel Capacity 4.5 gal. (17 l)

Oil Capacity 5 qt. (4.75 l)

Seat Height 25.2 in. (640 mm)

DRIVETRAIN
Transmission 6-speed overdrive constant mesh

Primary Drive Gear drive with torque compensator

Final Drive Carbon fiber reinforced belt

Suspension Front: Inverted cartridge telescopic fork, 43 mm fork tube; 5.1 in. (130 mm) travel

Rear: Single, mono-tube gas shock, cast aluminum with rising rate linkage swingarm, preload adjustable spring; 3 in. (75 mm) travel

BRAKES/WHEELS/TIRES
Brakes Front: 300 mm floating rotor with 4-piston caliper

Rear: 300 mm floating rotor with 2-piston caliper

Tires Front: 130/70 B18 Dunlop 491 Elite II

Rear: 180 55-B18 Dunlop D417

Rake 32.8°

Trail 5.4 in. (138 mm)

Colors Black, Blue Ice, Super Graphite, Two-tone Blue Ice / Pearl White with Carbon stripe, Two-tone Midnight Cherry / Pearl White with Carbon stripe







2009 Victory Kingpin Low – Canada Specifications
MSRP C$18,285.00

ENGINE
Engine 4-stroke, 50° V-twin, single overhead camshafts with 4-valves per cylinder, self-adjusting cam chains, hydraulic lifters

Displacement 100 ci (1,634 cc)

Bore x Stroke 101 x 102 mm

Compression Ratio 8.7:1

Fuel System Electronic Fuel Injection with dual 45 mm throttle bodies

Clutch Wet, multi-plate

Cooling Air / oil

Exhaust Staggered slash-cut dual exhaust with crossover

DIMENSIONS
Length 99.9 in. (2,537 mm)

Weight Dry: 657 lbs. (298 kg)

GVWR: 1,234 lbs. (560 kg)

Ground Clearance 5.3 in. (135 mm)

Wheelbase 65.6 in. (1,666 mm)

Fuel Capacity 4.5 gal. (17 l)

Oil Capacity 5 qt. (4.75 l)

Seat Height 25.2 in. (640 mm)

DRIVETRAIN
Transmission 6-speed overdrive constant mesh

Primary Drive Gear drive with torque compensator

Final Drive Carbon fiber reinforced belt

Suspension Front: Inverted cartridge telescopic fork, 43 mm fork tube; 5.1 in. (130 mm) travel

Rear: Single, mono-tube gas shock, cast aluminum with rising rate linkage swingarm, preload adjustable spring; 3 in. (75 mm) travel

BRAKES/WHEELS/TIRES
Brakes Front: 300 mm floating rotor with 4-piston caliper

Rear: 300 mm floating rotor with 2-piston caliper

Tires Front: 130/70 B18 Dunlop 491 Elite II

Rear: 180 55-B18 Dunlop D417

Rake 32.8°

Trail 5.4 in. (138 mm)

Colors Black, Blue Ice, Super Graphite, Two-tone Blue Ice / Pearl White with Carbon stripe, Two-tone Midnight Cherry / Pearl White with Carbon stripe
