2010 Triumph Street Triple
2010 Triumph Street Triple
2010 Triumph Street Triple
2010 Triumph Street Triple
– 2010 Triumph Street Triple
2010 Triumph Street Triple
The naked street bike.
A global hit since its introduction in 2007, the Street Triple fuses the style and attitude of the iconic Speed Triple with the performance and agility of the class leading Daytona 675 supersports machine.
The result is a truly impressive middleweight streetfighter that has attained critical success around the world.
At the heart of the Street Triple is a retuned version of Triumph’s unique 675cc triple, delivering 107 bph and 51 ft.lbs of torque. It’s so good you’ll have trouble believing its only 675cc.
The torque and sound of the liquid cooled 12 valve triple, combined with a close ratio six speed gearbox produce an exciting, exhilarating ride that has made the Street Triple our best selling model since its launch.
The look is pure factory streetfighter and pure Triumph. With the iconic twin headlamps, upside down forks and twin high-level exhaust, you’d be forgiven for mistaking it for our legendary Speed Triple.
Features and Benefits
Engine
Derived from the class leading Daytona 675, the Street Triple’s 675cc water-cooled, three-cylinder, 12-valve engine delivers strong low and mid-range performance from start to redline, and produces more than 44ft.lbs of torque from 3,500rpm right through to 12,300rpm. The close-ratio six-speed gearbox maximizes the effectiveness of the engine’s impressive power and torque, always giving you the perfect gear.
Exhaust System
Echoing the style of the iconic Speed Triple the twin-level oval section exhaust pipes enhance the engine’s distinctive and addictive roar.
Handlebars
Wide, easy to reach handlebars give a comfortable riding position.
Chassis
Derived from the Daytona 675, the chassis gives supreme agility and feedback. Handling will give you confidence whether you’re new to bikes or pushing hard on the track.
Brakes
Braking power is at the top of its class thanks to the Nissin, two pot, sliding calipers with sintered pads.
2010 Triumph Street Triple – USA Specifications
MSRP: $8,899 USD
Engine
Type
Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Capacity
675cc
Bore/Stroke
74 x 52.3 mm
Compression Ratio
12.65:1
Fuel System
Multipoint sequential electronic fuel injection with SAI
Transmission
Final Drive
O ring chain
Clutch
Wet, multi-plate
Gearbox
6-speed, close ratio
Cycle Parts
Frame
Aluminum beam twin-spar
Swingarm
Braced, twin-sided, aluminum alloy
Front Wheel
Cast aluminum alloy 5-spoke 17 x 3.5in
Rear Wheel
Cast aluminium alloy 5-spoke, 17 x 5.5in
Front Tyre
120/70 ZR 17
Rear Tyre
180/55 ZR 17
Front Suspension
Kayaba 41mm upside down forks, 120mm travel
Rear Suspension
Kayaba monoshock with adjustable preload, 126mm rear wheel travel
Front Brakes
Twin 308mm floating discs, Nissin 2-piston sliding calipers
Rear Brakes
Single 220mm disc, Nissin single piston caliper
Dimensions
Length
78.7 in
Width (Handlebars)
28.9 in
Height
41.7 in
Seat Height
31.5 in
Wheelbase
54.7 in
Rake/Trail
24.3 degree / 95.3 mm
Wet Weight
416 lbs
Fuel Tank Capacity
4.6 US gals
Performance (measured at crankshaft to 95/1/EC)
Maximum Power EC
105bhp @ 11700 rpm
Maximum Torque EC
50 ft.lbs @ 9200 rpm
Colours
Jet Black, Fusion White, Tornado Red
Price
$8,899
2010 Triumph Street Triple – Canada Specifications
MSRP: Please contact your local Triumph dealer
Engine
Type
Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Capacity
675cc
Bore/Stroke
74 x 52.3 mm
Compression Ratio
12.65:1
Fuel System
Multipoint sequential electronic fuel injection with SAI
Transmission
Final Drive
O ring chain
Clutch
Wet, multi-plate
Gearbox
6-speed, close ratio
Cycle Parts
Frame
Aluminium beam twin-spar
Swingarm
Braced, twin-sided, aluminium alloy
Front Wheel
Cast aluminium alloy 5-spoke 17 x 3.5in
Rear Wheel
Cast aluminium alloy 5-spoke, 17 x 5.5in
Front Tyre
120/70 ZR 17
Rear Tyre
180/55 ZR 17
Front Suspension
Kayaba 41mm upside down forks, 120mm travel
Rear Suspension
Kayaba monoshock with adjustable preload, 126mm rear wheel travel
Front Brakes
Twin 308mm floating discs, Nissin 2-piston sliding calipers
Rear Brakes
Single 220mm disc, Nissin single piston caliper
Dimensions
Length
2000 mm (78.7 in)
Width (Handlebars)
735 mm (28.9 in)
Height
1060 (41.7 in)
Seat Height
800 mm (31.5 in)
Wheelbase
1390 mm (54.7 in)
Rake/Trail
24.3 degree / 95.3 mm
Wet weight
189 kg (416 lbs)
Fuel Tank Capacity
17.4 litres (4.6 US gals)
Performance (measured at crankshaft to 95/1/EC)
Maximum Power EC
106PS / 105bhp / 78kW @ 11700 rpm
Maximum Torque EC
68Nm (50 ft.lbs) @ 9200 rpm
Colours
Jet Black, Fusion White, Tornado Red
2010 Triumph Street Triple – UK Specifications
MSRP £5,949 OTR
Engine
Type
Liquid-cooled, 12 valve, DOHC, in-line 3-cylinder
Capacity
675cc
Bore/Stroke
74 x 52.3 mm
Compression Ratio
12.65:1
Fuel System
Multipoint sequential electronic fuel injection with SAI
Transmission
Final Drive
O ring chain
Clutch
Wet, multi-plate
Gearbox
6-speed, close ratio
Cycle Parts
Frame
Aluminium beam twin-spar
Swingarm
Braced, twin-sided, aluminium alloy
Front Wheel
Cast aluminium alloy 5-spoke 17 x 3.5in
Rear Wheel
Cast aluminium alloy 5-spoke, 17 x 5.5in
Front Tyre
120/70 ZR 17
Rear Tyre
180/55 ZR 17
Front Suspension
Kayaba 41mm upside down forks, 120mm travel
Rear Suspension
Kayaba monoshock with adjustable preload, 126mm rear wheel travel
Front Brakes
Twin 308mm floating discs, Nissin 2-piston sliding calipers
Rear Brakes
Single 220mm disc, Nissin single piston caliper
Dimensions
Length
2000 mm (78.7 in)
Width (Handlebars)
735 mm (28.9 in)
Height
1060 (41.7 in)
Seat Height
800 mm (31.5 in)
Wheelbase
1390 mm (54.7 in)
Rake/Trail
24.3 degree / 95.3 mm
Wet weight (homologated)
189 kg (416 lbs)
Fuel Tank Capacity
17.4 litres (4.6 US gals)
Performance (measured at crankshaft to 95/1/EC)
Maximum Power EC
106PS / 105bhp / 78kW @ 11700 rpm
Maximum Torque EC
68Nm (50 ft.lbs) @ 9200 rpm
Colours
Jet Black, Fusion White, Tornado Red
Price
£5,949 OTR
