2016 Honda CRF110F Review

2016 Honda CRF110F on www.Totalmotorcycle.com

Packed With Features, Filled With Fun…

About the same size as our CRF70F, the CRF110F offers a bigger 110cc air-cooled engine that’s just as reliable and built to deliver the kind of power your young Red Rider needs. In addition, the CRF110F features both an effortless electric starter and a kick starter, as well. And it all teams up with our four-speed transmission with automatic clutch that’s been proven in thousands of bikes, so younger riders never have to worry about stalling or a handlebar-mounted clutch.

The CRF110F is a great off-road, fun bike that younger riders are going to love. And, better than that, they’re going to remember all the fun they had riding it—and with you—for the rest of their lives.

Be A Responsible Rider: All parents need to consider their youngsters’ age, size, ability and maturity before allowing them to ride. Obtain a copy of “Off-Road Safety Tips” from your local Honda Dealer.

Plenty of Power

The CRF110F’s 110cc engine offers a generous, wide powerband without revving too high—perfect for young riders to learn on. Plus, the CRF110F offers a throttle limiter to allow parents to choose the appropriate amount of available power.

No Clutch Lever, No Worries

With our proven four-speed transmission with automatic clutch, riders can concentrate on shifting gears without the worry of a manual clutch or stalling.

Get Them Off To A Great Start

The CRF110F includes an effortless electric starter. We’ve even included a backup kick starter, so getting underway is a cinch, even if the battery charge gets low.

2016 Honda CRF110F www.Totalmotorcycle.com Key Features

Stylish Stepping Stone.

Graduate to the next level.

The CRF110 is all about big-bike feel and huge fun. Built for the 8-11 age range, it’s got a sturdy chassis, electric starter and reliable 4-stroke engine. It is the perfect stepping-stone up to more competition-focused 125cc/150cc MX and enduro machines.

Journey of a lifetime

When a youngster gets that unstoppable urge to ride there’s no better starting point than a bright red Honda CRF off-roader.

Honda’s rugged CRF110F gives easy riding confidence to young riders, and opens doors to enjoyment that lasts a lifetime. It features an electric starter, a brand new steel frame with improved suspension, which adds to the ‘big-bike’ feel and performance. Keeping young guns riding – and grinning – all day long.

The Off Road look

The CRF450R-inspired looks give it MX credibility.

Not only does the CRF110F have a strong engine, it has a robust suspension system and a strong chassis too.

A completely new body kit, with echoes of the CRF450R’s ‘triangle proportion’ gives the CRF110F a crisp and modern appearance. The newly designed chain cover looks great and with the addition of a handlebar pad aids safety.

Better than tough

New riders are tough on machinery, and that’s why you need a bike that’s just as tough. With a new 110cc engine, the new CRF110F comes through with flying colors. And to keep it running flawlessly, it’s loaded with features like a maintenance-free Capacitor Discharge Ignition (CDI), automatic cam-chain tensioner, plus proven Honda engineering and build quality.

Easy riding

Growing skills and experience.

The days riding off-road, in trail parks, motocross tracks or even back yards, can be very much a family activity that involves everyone. The CRF110F is a great, and enjoyable, introduction to motorcycling, the perfect bike on which to build skills and machine control, so useful later on, whether out on the road or in competition.

Better Than Just Tough. It’s built Honda Tough.

New riders are tough on machinery, and that’s why you need a bike that’s just as tough. With a 110cc engine, the CRF110F comes through with flying colors. And to keep it running flawlessly, it’s loaded with features like a maintenance-free CD ignition, automatic cam-chain tensioner and proven Honda engineering and build quality.

2016 Honda CRF110F www.Totalmotorcycle.com Features and Benefits

Engine / Drivetrain

Not too loud

Quiet muffler won’t annoy the neighbors.

Easy start

Convenient electric starter with kickstart backup.

Parental control

Adjustable throttle limiter allows parents to tune performance to match rider ability.

No-stall take-offs

Four-speed gearbox with automatic clutch offers simple operation with easy, no-stall take offs.

Simplified maintenance

Maintenance-free CD ignition and automatic cam-chain tensioner simplify maintenance.

Tuned for the beginner

Dependable air-cooled single-cylinder 4-stroke 110 cc engine is tuned for the beginning rider.

Chassis / Suspension

Improved rider protection

Exhaust muffler cover provides improved rider protection.

Great traction & stability

Upgraded suspension offers excellent traction and stability. The 31 mm telescopic front fork has 100 mm of travel, while the rear shock absorber features a 28 mm piston damper with 87 mm travel.

Easy to mount & control

Low seat height of only 667 mm (26.3 inches).

Excellent handling

Steel backbone frame and swingarm blend a high degree of rigidity with a certain amount of tuned flex for excellent handling. The frame also incorporates safety covers at heat points and carrying handles for easy transport.

Additional Features

Transferable warranty

Transferable six-month limited warranty.

Secure footing

Folding, cleated footpegs offer secure footing even in muddy conditions.

Simplified maintenance

Easy-access washable foam air filter simplifies maintenance.

Controls designed for young rIders

Small-size control levers enhance young rider comfort and confidence.

Additional protection

Handlebar pad for additional protection.

Secure against unauthorized use

Keyed ignition switch prevents unauthorized use.

Parental speed governor

Adjustable throttle limiter.

Great aesthetics

CRF-R-inspired bodywork.

2016 Honda CRF110F – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $2099 USD

ENGINE
Engine Type 109cc air-cooled single-cylinder four-stroke
Bore And Stroke 50.0mm x 55.6mm
Compression Ratio 9.0:1
Valve Train SOHC; two-valve
Induction 13mm piston-valve carburetor
Ignition CDI

DRIVE TRAIN
Transmission Four-speed with automatic clutch
Final Drive Chain

CHASSIS / SUSPENSION / BRAKES
Front Suspension 31.0mm telescopic fork; 3.9 inches of travel
Rear Suspension Single-shock; 3.4 inches of travel
Front Brake Drum
Rear Brake Drum
Front Tire 70/100-14
Rear Tire 80/100-12

DIMENSIONS
Rake 24°25′ (Caster Angle)
Trail 52.5mm (2.0 inches)
Wheelbase 41.9 inches
Seat Height 26.3 inches
Curb Weight 163 pounds (Includes all standard equipment, required fluids and full tank of fuel-ready to ride)
Fuel Capacity 1.1 gallons, including 0.3-gallon reserve
Ground Clearance 6.9 Inches

OTHER
Emissions Meets current California Air Resource Board (CARB) and EPA off-road emissions standards.
Available Colors Red
Model Id CRF110F

FACTORY WARRANTY INFORMATION
Duration Six Months transferable limited warranty; extended warranty available with a Honda Protection Plan.

2016 Honda CRF110F – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $2499 CDN

Engine & Drivetrain

Engine Type

Air-cooled single-cylinder four-stroke

Displacement

109 cc

Bore & Stroke

50 mm x 55.6 mm

Compression Ratio

9.0:1

Valve Train

SOHC, 2-valve

Fuel Delivery

Single 13 mm piston-valve carb

Transmission

Four-speed with automatic clutch

Chassis & Suspension

Front Suspension

31 mm telescopic fork; 90 mm (3.5 in.) travel

Rear Suspension

Single shock; 87 mm (3.4 in.) travel

Dimensions & Additional Information

Tires

70/100 – 14 front; 80/100 – 12 rear

Brakes

Front drum; rear drum

Ground Clearance

175 mm (6.9 in.)

Seat Height

667 mm (26.3 in.)

Wheelbase

1,064 mm (41.9 in.)

Curb Weight

74 kg (163 lbs.) including required fluids and full tank of gas – ready to ride

Fuel Capacity

4.0 litres, including 1.0-litre reserve

Colour

Extreme Red

Warranty

6 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus

2016 Honda CRF110F – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £1899 GBP (On The Road inc 20% Vat)

Engine

Bore × Stroke (mm) 50 x 55.6
Carburation Carburetor
Compression Ratio 9.0:1
Engine Displacement (cm³) 109
Engine Type Air-cooled 4-stroke 2-valve SOHC single
Ignition System Capacitor Discharge (CDI)
Max. Power Output 5.35 kW / 7500 rpm
Max. Torque 8.85 Nm / 3500 rpm
Starter Kick

Wheels

Brakes Front 95mm Drum
Brakes Rear 95mm Drum
Suspension Front 31mm fork, 100mm stroke, 90mm axle travel
Suspension Rear Mono shock, 59mm stroke
Tyre Size Front 70/100-14
Tyre Size Rear 80/100-12
Wheels Front Wire spoke
Wheels Rear Wire spoke

Dimensions and Weights

Caster Angle 24°
Dimensions (L×W×H) (mm) 1,560 x 686 x 912
Frame type Steel Backbone
Fuel Capacity (Litres) 5 litres (including reserve of 1 litre)
Ground Clearance (mm) 175
Kerb Weight (kg) 74
Seat Height (mm) 667
Trail (mm) 52
Wheelbase (mm) 1064

Transmission

Clutch Wet, multiplate
Final Drive Chain
Gearbox 4-speed, constant mesh

Specifications, features, illustrations and equipment shown are believed to be correct – however, accuracy cannot be guaranteed. Honda Inc. reserves the right to make changes at any time, without notice or obligation, in colours, specifications, accessories, materials and models. Some vehicles are shown with optional equipment. Some vehicles shown are U.S., European and/or Canadian models.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
