2017 Harley-Davidson Breakout Review

Back to the 2017 Harley-Davidson Motorcycle Model Review Page

You have come to the right spot. Total Motorcycle – Built by Riders, For Riders; Enjoy the ride…

2017 Harley-Davidson Breakout
2017 Harley-Davidson Breakout

2017 Harley-Davidson Breakout
2017 Harley-Davidson Breakout

2017 Harley-Davidson Breakout
2017 Harley-Davidson Breakout

2017 Harley-Davidson Breakout
2017 Harley-Davidson Breakout

2017 Harley-Davidson Breakout
2017 Harley-Davidson Breakout



2017 Harley-Davidson Breakout Review

2017 Harley-Davidson Breakout on www.Totalmotorcycle.com

Big wheels, big paint and classic drag-bike attitude meet modern refinement. Then we stuff it brimful with raw power…

There’s nothing like a fistful of American street muscle.

Feast your eyes on the Breakout™. Its profile is low, stretched out and undeniably aggressive. We top it with drag bars and enhance its custom look with 21-spoke Turbine wheels. The High Output Twin Cam 103B™ engine delivers loads of torque to a wide 240mm rear tire. ABS comes standard. Go out and put a hard pounding on the pavement. It doesn’t get any better.

The Breakout® model is inspired by the classic Gasser drag cars of the ‘50s and ‘60s. Its flawless stretched styling, a fat rear tyre and crowd-stopping finishes coupled with drag bars, a low-slung stance, and raw engine power makes the Breakout® model the around-town, custom motorcycle riders want in their garages.

SOFTAIL®

A rigid mounted engine and twin hidden rear shocks give Softail models the clean look of a vintage hardtail, while cutting-edge technology delivers the smooth ride and comfort expected from a modern Harley-Davidson motorcycle. The counter-balanced High Output Twin Cam 103B engine delivers pounding torque, and the 6-Speed Cruise Drive® transmission provides smooth delivery of power.

Family features:

High Output Twin Cam 103 counter balanced engine
6-speed Cruise Drive transmission
ABS available on all models

2017 Harley-Davidson Breakout www.Totalmotorcycle.com Key Features

NEW IN 2017

Gloss Black Turbine wheels with Machined Highlights

Battery tender harness

Paint color options including Custom paint and Hard Candy Custom™ color

MODEL UNIQUE FEATURES
Style
• Long wheelbase with premium fit and finishes throughout
• Low-slung profile with wide, powerful stance
• Gloss Black Turbine wheels with Machined Highlights, 21-inch 130 mm front tire, 18-inch 240 mm rear tire
• Chopped fenders
• Wide, thick front forks
• Clean tank console with riser-mounted speedometer
• Air cleaner cover with High Output 103 badging
• Wide drag-style 1.25-inch handlebar
• Low seat height
• Premium black and chrome engine
• Side-mounted license plate
• Minimal 3-in-1 stop/turn/tail lights
• Premium paint and graphics with unique fuel tank medallion

Fit
• Two-piece, two-up seat with removable rear pillion for riding solo or with passenger
• Low, wide drag-style handlebar
• Forward-mounted foot controls

Function
• Electronic throttle control
• Electronic cruise control
• Riser-mounted speedometer with RPM/gear display, fuel gauge

Performance
• Rigid-mounted, Air-cooled, 1690 cc High Output Twin Cam 103B™ counter-balanced engine with Automatic Compression Release (ACR)
• 6-Speed Cruise Drive® transmission
• Anti-lock Braking System (ABS)1, standard
• Smart Security System2 with proximity-based, hands-free security fob, standard







2017 Harley-Davidson Breakout www.Totalmotorcycle.com Features and Benefits

Authentic Styling

Get an eyeful of a Softail® motorcycle and you see more than some weepy-eyed exercise in nostalgia. You’re looking at the kind of style that has the power to defy time. Honest. Uncluttered. Unaffected by the fad of the moment. There’s a good reason for this. We’ve used our long decades on the road, riding, wrenching, talking to other custom bike fanatics, to discover what works. Then we stick with it, and use it to push the boundaries of motorcycle design ever further. Take a look at the horseshoe oil tank adorning our Softail models. It’s the same one you’d see on a restored dresser from the ‘50s, or a radical Panhead chopper from the ‘70s. And you’ll find it right now on future Harley-Davidson® models that still on the drawing board. Other companies may be content to imitate bits and pieces from our long history. On a Softail motorcycle every part down to the axle nut cover comes from an authentic tradition. With a genuine reason for looking the way it looks.

Iconic Engine

The air-cooled 45° V-Twin engine at the heart of every Softail model is a prime example of what makes a Harley-Davidson motorcycle more satisfying than anything else. Its clean, uncluttered shape fits perfectly in the downtubes of the frame. Twist the throttle and the surge of torque hits you exactly where it counts. The knowledge of what makes an engine truly move a rider runs deep at The Motor Company, and it’s been put to particular good use to power the Softail family. We counterbalance the engine, which means we can bolt it directly to the frame. It keeps the styling tight at the center of the bike. It lets the rider feel the pulse of the V-Twin. With the High Output Twin Cam 103B™ engine, there aren’t any vibrations rattling the fillings out of your teeth. More power is always a Harley-Davidson tradition.

Handling

If you’ve never experienced a Harley-Davidson® Softail® motorcycle, it’s time to find out what you’ve been missing. The venerable Softail frame has logged untold millions of miles, and we’ve put every one of them to good use. The result: one of the most fun rides in all of motorcycling. We’ve spent the years making the frame stiffer, the geometry more balanced and the braking more precise. The dazzling wheels are wrapped in premium Dunlop rubber. The low seats give you a confident feeling of being a part of the motorcycle. Get out on a rolling stretch of backcountry highway and it all comes together. The crisp and responsive ride. The killer looks. As long as we build motorcycles like this having a good time will never go out of style.

Comfort

The authentic look of a Softail motorcycle comes from the days before anyone knew much about building a suspension. The rigid hardtail frames of yesteryear had a pure, uncluttered look that riders still love. But the bone-rattling ride meant your grandpa needed to strap on a kidney belt to keep his internals intact. The Softail family uses modern technology to consign the kidney belt to the museum. We’ve kept all the modern comforts where they belong—below the surface of a rad bike loaded with authentic style. You get the classic lines of a vintage “hardtail” frame with the horizontal rear shocks hidden in the guts. It’s a signature rigid look, and you’ll only find it on a Softail model.






2017 Harley-Davidson Breakout – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $19299 to $20499 USD

PRICING 6
Vivid Black $19,299
Color Option $19,699
Custom Color Option $20,249
Hard Candy Color Option $20,499
ABS Option Standard
Security Option Standard
California Emissions $200
Freight $390
DIMENSIONS
Length 95.7 in.
Seat Height, Laden 7 24.7 in.
Seat Height, Unladen 7 25.8 in.
Ground Clearance 4.3 in.
Rake (steering head) (deg) 35
Trail 5.7 in.
Wheelbase 67.3 in.
Tires, Front Specification 130/60B21 63H
Tires, Rear Specification 240/40R18 79V
Fuel Capacity 5 gal.
Oil Capacity (w/filter) 3.5 qt.
Weight, As Shipped 678 lb.
Weight, In Running Order 707 lb.
ENGINE
Engine 1 Air-cooled, High Output Twin Cam 103B™
Bore 3.87 in.
Stroke 4.374 in.
Displacement 103.1 cu in
Compression Ratio 9.6:1
Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Gear Ratios (overall) 1st 9.311
Gear Ratios (overall) 2nd 6.454
Gear Ratios (overall) 3rd 4.793
Gear Ratios (overall) 4th 3.882
Gear Ratios (overall) 5th 3.307
Gear Ratios (overall) 6th 2.79
CHASSIS
Exhaust Staggered, straight cut chrome mufflers with gloss black muffler shields
Wheels, Front Type 9 Gloss Black Turbine with machined highlights
Wheels, Rear Type Gloss Black Turbine with machined highlights
Brakes, Caliper Type 4-piston fixed front; 2-piston floating rear
PERFORMANCE
Engine Torque Testing Method J1349
Engine Torque 2 99.5 ft-lb
Engine Torque (rpm) 3,000
Lean Angle, Right (deg.) 23.4
Lean Angle, Left (deg.) 23.4
Fuel Economy: Combined City/Hwy 5 42 mpg
ELECTRIC
Lights (as per country regulation), Indicator Lamps 8 High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings, low battery, ABS
Gauges Clean tank console with a riser mounted speedometer
1. Recommended 91 octane or higher fuel (R+M)/2.
2. Values shown are nominal. Performance may vary by country and region.
3. Standard and optional fuel systems may vary by country.
4. See motorcycle owner’s manual for complete details.
5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
6. Prices listed are the Manufacturer’s Suggested Retail Prices. Options such as color are available at additional cost. Prices exclude dealer setup, taxes, title and licensing and are subject to change. Dealer prices may vary.
7. Measurement reflects 180 lb. (81.7 kg) operator weight.
8. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
9. Standard and optional wheels may vary by country and region.








2017 Harley-Davidson Breakout – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $22799 to $23899 CDN

PRICING
Vivid Black $ 22,799
Color Option $ 23,249
Custom Color Option $ 23,899
Hard Candy Custom $ 24,199
ABS Option Standard
Security Option Standard
Freight $ 250
DIMENSIONS
Length 2430 mm
Seat Height, Laden 6 627 mm
Seat Height, Unladen 6 655 mm
Ground Clearance 110 mm
Rake (steering head) (deg) 35
Trail 146 mm
Wheelbase 1710 mm
Tires, Front Specification 130/60B21 63H
Tires, Rear Specification 240/40R18 79V
Fuel Capacity 18.9 l
Oil Capacity (w/filter) 3.3 l
Weight, As Shipped 308 kg
Weight, In Running Order 321 kg
ENGINE
Engine 1 Air-Cooled, High Output Twin Cam 103B™
Bore 98.4 mm
Stroke 111.1 mm
Displacement 1,690 cc
Compression Ratio 9.6:1
Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Gear Ratios (overall) 1st 9.311
Gear Ratios (overall) 2nd 6.454
Gear Ratios (overall) 3rd 4.793
Gear Ratios (overall) 4th 3.882
Gear Ratios (overall) 5th 3.307
Gear Ratios (overall) 6th 2.79
CHASSIS
Exhaust Staggered, straight cut chrome mufflers with Gloss Black muffler shields
Wheels, Front Type Gloss Black Turbine with machine highlights
Wheels, Rear Type 8 Gloss Black Turbine with machine highlights
Brakes, Caliper Type 4-piston fixed front; 2-piston floating rear
PERFORMANCE
Engine Torque Testing Method J1349
Engine Torque 2 135 Nm
Engine Torque (rpm) 3,000
Lean Angle, Right (deg.) 23.4
Lean Angle, Left (deg.) 23.4
Fuel Economy: Combined City/Hwy 5 5.6 l/100 km
ELECTRIC
Lights (as per country regulation), Indicator Lamps 7 High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system (optional), 6-speed, low fuel warnings, low battery, ABS
Gauges Clean tank console with a riser mounted speedometer
1. Recommended 91 octane or higher fuel (R+M)/2.
2. Values shown are nominal. Performance may vary by country and region.
3. Standard and optional fuel systems may vary by country.
4. See motorcycle owner’s manual for complete details.
5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
6. Measurement reflects 180 lb. (81.7 kg) operator weight.
7. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
8. Standard and optional wheels may vary by country and region.






2017 Harley-Davidson Breakout – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £16595 to £17735 GBP (On The Road inc 20% Vat)

PRICING 5
Vivid Black £ 16,595
Color Option £ 16,945
Custom Color Option £ 17,735
Hard Candy Color Option £ 17,225
DIMENSIONS
Length 2,385 mm
Seat Height, Unladen 650 mm
Ground Clearance 120 mm
Rake (steering head) (deg) 35
Trail 146 mm
Wheelbase 1,710 mm
Tyres, Front Specification 130/60B21 63H
Tyres, Rear Specification 240/40R18 79V
Fuel Capacity 18.9 l
Oil Capacity (w/filter) 3.3 l
Weight, As Shipped 310 kg
Weight, In Running Order 320 kg
ENGINE
Engine Air-Cooled, High Output Twin Cam 103B™
Bore 98.4 mm
Stroke 111.1 mm
Displacement 1,690 cc
Compression Ratio 9.7:1
Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Gear Ratios (overall) 1st 9.311
Gear Ratios (overall) 2nd 6.454
Gear Ratios (overall) 3rd 4.793
Gear Ratios (overall) 4th 3.882
Gear Ratios (overall) 5th 3.307
Gear Ratios (overall) 6th 2.79
CHASSIS
Exhaust Staggered, straight cut chrome mufflers with Gloss Black muffler shields
Wheels, Front Type Gloss Black Turbine with machine highlights
Wheels, Rear Type Gloss Black Turbine with machine highlights
Brakes, Caliper Type 4-piston fixed front; 2-piston floating rear
PERFORMANCE
Engine Torque Testing Method EC 134/2014
Engine Torque 125 Nm
Engine Torque (rpm) 3,000
Lean Angle, Right (deg.) 23.4
Lean Angle, Left (deg.) 23.4
Fuel Economy: Combined City/Hwy 5.6 l/100 km
ELECTRIC
Lights (as per country regulation), Indicator Lamps High beam, neutral, low oil pressure, turn signals, engine diagnostics, security system, 6-speed, low fuel warnings, low battery, ABS
Gauges Clean tank console with a riser mounted speedometer
1. Availability of colours may vary from dealer to dealer and is subject to change without further notice.
2. Recommended 95 octane or higher fuel (R+M)/2.
3. Values shown are nominal. Performance may vary by country and region.
4. See motorcycle owner’s manual for complete details.
5. Prices shown are suggested retail prices only. Please contact your nearest dealer for further details.
6. Measurement reflects 81.7 kg operator weight.
7. Security system includes immobiliser and siren.
8. Standard and optional wheels may vary by country and region.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
