2021 Honda CRF250RX Guide

2021 Honda CRF250RX

2021 Honda CRF250RX

2021 Honda CRF250RX: THE ENDURO RIDER’S CHOICE.

Introducing the 2021 Honda CRF250RX…

Campaigned in national championship off-road racing by JCR Honda’s Tarah Gieger, Phoenix Racing Honda’s Jonathan Johnson and SLR Honda’s Tallon LaFountaine, the CRF250RX features closed-course off-road-focused components like a large fuel tank, aluminum side stand and 18-inch rear wheel. It also has off-road-specific engine mapping and suspension settings, making it ideal for specialties like woods racing, desert racing, off-road grand prix competition and trail riding in legal off-road areas.

If you’re looking for a high-performance trail/enduro machine built to win, then you’ve come to the right place. Honda’s CRF250RX has the power, light weight, and refined handling of our championship-winning motocross bikes, but we’ve given it the touches an enduro rider needs with features like an 18-inch rear wheel, a bigger fuel tank, special suspension settings, a sidestand, and more. Lots of guys show up to the first check riding motocross bikes; the winners show up on a CRF250RX.



2021 Honda CRF250RX Totalmotorcycle.com Key Features

ENGINE / DRIVETRAIN

  • High-performance, DOHC, 249cc single-cylinder engine with dual-overhead-cam design and high rev limit, offering great performance.
  • Finger rocker arms with Diamond Like Coating (DLC) maximize valve lift while retaining a low engine height.
  • Downdraft intake layout produces strong power and enables great throttle response by reducing resistance, thereby improving air-charging efficiency.
  • Gear-position sensor allows dedicated ignition maps for each gear.
  • Large air-filter element for good airflow.
  • Second and third gears have a WPC surface treatment for good durability and minimal friction.
  • 44 mm throttle body provides ideal low-rpm intake airflow for strong corner-exit performance.
  • Piston oil jet uses five nozzle holes for efficient piston-cooling efficiency and minimized knocking, enabling a precise ignition-timing setting for optimum power delivery.
  • Advanced AC generator reduces weight and friction losses.
  • Electric-start standard for easy, fast engine startup.
  • Easily selectable Standard, Smooth, and Aggressive riding modes enable simple tuning depending on rider preference or course conditions.
  • Selectable HRC launch control provides a steady stream of torque for excellent performance on race starts.

CHASSIS / SUSPENSION

  • Aluminum perimeter frame and aluminum swingarm are designed to achieve good yaw-angle stiffness while retaining lateral and torsional stiffness, resulting in nimble, stable handling.
  • 2.2 gallon resin fuel tank for completing long closed-course off-road loops.
  • 18-inch rear wheel to enable taller tire sidewalls for improved traction in technical conditions.
  • Forged aluminum side stand is designed to be lightweight yet strong.
  • Sealed drive chain to withstand the elements.
  • Suspension with settings dedicated to closed-course off-road use.
  • Low center of gravity reduces front-end lift for strong acceleration performance.
  • Lightweight front-brake caliper uses pistons of different diameters (30 mm and 27 mm) for strong braking performance.
  • Front brake hose resists expansion for precise braking.
  • Renthal® Fatbar® reduces weight of the steering system, and flexes for optimal comfort.
  • Top triple clamp features two handlebar-holder locations for moving the handlebar rearward and forward by 26 mm, ensuring rider comfort. When holder is turned 180 degrees, the handlebar can be moved an additional 10 mm from the base position, resulting in four total unique riding positions.
  • Black rims deliver a strong presence on and off the track.
  • Smooth bodywork layout eases rider movement.
  • In-mold graphics are durable and resistant to peeling caused by washing or abrasion.
  • Dunlop Geomax AT81 tires provide optimum feel and traction in challenging riding conditions





2021 Honda CRF250RX Totalmotorcycle.com Features and Benefits

PERFORMANCE
HRC LAUNCH CONTROL
We’re talking about a special ECU program here: push the button to select the mode, hold the throttle open, release the clutch, and the CRF250RX will do the rest, launching you into the first turn with a big advantage. It turns your bike into a holeshot-seeking machine!

HOLESHOT-WINNING POWER
Feel free to hold that throttle open and head for the first turn—the CRF250RX is designed to win that critical holeshot drag race. You’ll also feel the increased low-end to mid-range torque.

BRIDGED-BOX PISTON
The CRF250RX’s bridged-box piston is final piece to the CRF250RX’s engine performance package. The design features a reinforcing structure between the skirts and the wrist-pin bosses that helps enable the CRF250RX’s high redline.

HIGH REDLINE
With our better-breathing DOHC design and the big-bore/short-stroke engine, the CRF250RX’s rev limit is way impressive. The same goes for peak power and peak torque.

HIGH-VOLUME AIR CLEANER
The 2021 CRF250RX features an air-cleaner element with plenty of surface area and volume. The result? More power!

LARGE-CAPACITY RADIATOR
A bigger radiator means better cooling, and better cooling means more power, from the start of your ride to the finish.

LARGE VALVE DIAMETERS
The CRF250RX’s valves don’t just have impressive lift, the valves themselves are large-diameter too—33mm intakes and 26mm exhausts. Combined with the high lift, the twin-cam CRF250RX flows a lot more, especially at high revs when you’re wicking it up.

HIGH-PERFORMANCE CAM PROFILES
With input directly from our HRC factory team, we’ve given the CRF250RX cams that help the engine produce better bottom end torque and power, while still retaining the CRF250RX’s screaming peak.

DOUBLE-SPRAY INJECTOR SETTINGS
The CRF250RX’s fuel-injection system sprays twice per intake cycle. That helps increase fuel atomization without adding the weight or complexity of a second injector. The better fuel atomization means more power in the midrange and on overrev—you’ll feel it the first time you ride.

THROTTLE BODY
With a 44mm venturi designed to speed up airflow, the CRF250RX’s throttle body really reaps benefits at low engine operating speeds. You get power and snap, right now.

CONVENIENCE
ELECTRIC START
The CRF250RX is equipped with an effortless electric starter. Convenient and lightweight, it’s a huge deal if you need to restart a stalled bike in the heat of battle.

ENGINEERING
DOHC ENGINE LAYOUT
The CRF250RX uses a double-overhead-cam (DOHC) engine layout with a unique finger-follower rocker design. Together with the rest of the engine’s architecture (bore and stroke, intake tract, piston, and more), you get more power and a higher redline.

BIG BORE/SHORT STROKE
The CRF250RX’s 79mm bore and short 50.9mm stroke let our engineers create a high-revving engine with plenty of room for large valves. The engine breaths and revs—the two keys to making power in the enduro world.

CLUTCH DESIGN AND MATERIALS
The CRF250RX’s clutch uses two different types of friction material. Why? The clutch can handle the increased power of the engine without being any larger. The lighter rotating weight is directly related to how fast the engine revs.

DOWNDRAFT INTAKE AND EXHAUST LAYOUT
The DOHC cylinder-head design let our engineers straighten out the CRF250RX’s intake and exhaust tracts. The intake is shorter and just about arrow straight, and the exhaust flows more efficiently too. No athlete’s going to win a sprint if he tries to run while holding his breath, and it’s no different with your bike’s engine. You’ll experience both more power and better throttle response.

ENGINE MODE SELECT BUTTON
This simple handlebar-mounted button lets you dial in engine power delivery character with a push of your thumb. Choose between Standard, Smooth and Aggressive, depending on course conditions.

ENGINE OIL SCAVENGE PUMP
Deep in the engine, there’s a special oil scavenge pump. While you may never see it, it helps keep the CRF250RX’s overall design compact.

GEAR-POSITION ENGINE MAPPING
Talk about smart: The CRF250RX features an ECU with special engine mapping for each gear. You can’t give an inch in this class, so having your engine deliver optimal power for each gear choice is one of the features that separates CRF250RX riders from the rest.

GRADUAL PIPE-BEND RADIUS
Notice how the CRF250RX’s dual exhaust pipes make gradual, large-radius bends out of the head, then flow straight back to the mufflers with no abrupt angle changes. Getting the exhaust out of the engine—while still maintaining a tuned exhaust length, is the key to power, while the pipes’ low mass and twin-silencer design optimize the CRF250RX’s center of mass for superior handling.

“H” SECTION CRANK
Look closely at the CRF250RX’s crankshaft profile and you’ll see its “H” cross-section design. What’s up with that? Just like a structural “I” beam in an aircraft wing or a skyscraper, it boosts strength and cuts weight over a conventional crank’s shape—a big deal when you consider this part spins at over 14,000 rpm!

HIGH CAPACITY RESIN FUEL TANK
For longer enduro loops, the CRF250RX features a bigger fuel tank that holds a full 2.25 gallons.

LITHIUM-ION BATTERY
Like the rest of the CRF250RX, the bike’s Lithium-Ion battery is both super light and high performing. In fact, it weighs less than half the weight of a conventional lead-acid battery.

REFINED DUAL-EXHAUST SYSTEM
The CRF250RX’s dual-exhaust system is light, compact, and positioned close and low in the frame to take weight off the rear end and bring more mass to the bike’s center for improved handling. It also allows for more airflow, and that equals added horsepower.

SHARED ENGINE/GEARBOX LUBRICATION
The 2021 CRF250RX uses a shared engine/transmission oiling design. Why? Combining the two systems shaves weight and helps make the engine more compact, especially when it comes to placing the right-side cam drive and the clutch so close together.

TITANIUM INTAKE AND EXHAUST VALVES
Light is right when it comes to a high-revving engine’s reciprocating masses. That’s why the CRF250RX uses titanium intake and exhaust valves. Plus, the valve angle is a super-narrow 20.5 degrees (included). Ovalized valve springs and long-wearing Diamond-Like Carbon (DLC) treated finger rockers complete the package.

TOTAL AIR MANAGEMENT
Total air management means complete attention to how efficiently air gets through the intake, through the head, and out the exhaust. Eliminate losses here, and you make more power everywhere. And the best part? It’s free horsepower—you just need a bike with smart design.

HANDLING
DUNLOP GEOMAX TIRES
The CRF250RX’s Dunlop Geomax tires are specially designed for enduro use. The AT81 tires are spec’d at 80/100-21 for the front and 110/100-18 for the rear. You read that right: the CRF250RX rolls on an 18-inch rear wheel.

260mm FRONT BRAKE
The CRF250RX’s large front-brake disc measures a whopping 260mm. You get great brake feel and a pattern that cuts down on weight. Front and rear brake-disc guards are part of the package too.

LOW BATTERY MOUNTING
Locating the battery low in the chassis helps to lower the CRF250RX’s center of gravity—and that always helps overall handling.

LOW REAR SHOCK MOUNT
With its low rear shock mount on the frame, the CRF250RX benefits from both a lower center of gravity (cg) as well as chassis stability.

SHORT SWINGARM
The CRF250RX’s short swingarm helps make it light, and also helps give the bike better rear-wheel traction, and reduces unsprung mass, important considering how much power you have on tap.

SHOWA® SPRING FORK
The 49mm Showa® fork features a conventional spring design that helps increase the CRF250RX’s front-suspension precision, handling and feel. The 39mm piston diameter and 25mm rod diameter guarantee a plush feel and supple action.

TWIN SPAR ALUMINUM FRAME
The CRF250RX’s latest twin-spar aluminum frame is identical to the CRF450R motocrosser’s except for the lower engine cradle where the engine mounts. It’s the foundation for the 250’s superb handling.

COMFORT
BLACK RIMS
They may not help you go faster, but the sweet black DID rims sure look good.

FLAT SEAT/TANK JUNCTION
The CRF250RX features a flat seat/tank junction, including a titanium fuel tank. The superior ergonomics make it easier to move forward and back on the bike, increasing your control.

“IN MOLD” GRAPHICS
With the all the time you’ll be spending in victory circle, you need to look your best. The CRF250RX has you covered. Our “in mold” graphics look great, and stay looking good longer.

REAR SUBFRAME
The CRF250RX’s subframe uses extruded rear members that produce a 20-percent reduction in weight versus the previous generation CRF250R. Since that weight comes off the top of the bike, it also contributes to the CRF250RX’s low center of gravity.

SIDESTAND
Real enduro bikes need a sidestand, and we’ve given the CRF250RX a great one. Tucked up high and out of the way, this forged alloy piece is just another example of how the CRF250RX gets it right.

SMOOTH STYLING
Blending the CRF250RX’s body panels does more than just make the bike look smooth, fast, and stylish. It also helps you move around on the bike while riding. Nothing wrong with smooth, fast, and stylish, though.





2021 Honda CRF250RX – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8399 USD
Canada MSRP Price: $ 9899 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
ENGINE
Type 249cc liquid-cooled single-cylinder four-stroke
Valve Train DOHC, four-valve; 33mm intake, titanium; 26mm exhaust, titanium
Bore x Stroke 79.0mm x 50.9mm
Compression Ratio 13.9:1
Induction Programmed fuel-injection system (PGM-FI); 44mm throttle bore
Ignition Full transistorized
Starter Push-button electric starter
Transmission Constant-mesh 5-speed return; manual
Clutch Multiplate wet (6 springs)
Final Drive #520 sealed chain; 13T/48T
SUSPENSION
Front 49mm fully adjustable leading-axle inverted telescopic Showa coil-spring fork w/ 12.0 in. travel
Rear Pro-Link system; fully adjustable Showa single shock w/ 12.4 in. wheel travel
BRAKES
Front 2-piston caliper (30mm, 27mm) hydraulic; single 260mm disc
Rear 1-piston caliper hydraulic; single 240mm disc
TIRES
Front Dunlop Geomax AT81 80/100-21 w/ tube
Rear Dunlop Geomax AT81 110/100-18 w/ tube
MEASUREMENTS
Rake (Caster Angle) 27°18’
Trail 115mm (4.5 in.)
Length 86.0 in.
Width 32.6 in.
Height 49.7 in.
Ground Clearance 13.0 in.
Seat Height 37.8 in.
Wheelbase 58.5 in.
Fuel Capacity 2.25 gal.
Color Red
Curb Weight* 244 lbs.

*Includes all standard equipment, required fluids and full tank of fuel—ready to ride
Specifications subject to change



2021 Honda CRF250RX – Totalmotorcycle.com Canada Specifications/Technical Details

Engine & Drivetrain
Engine type Liquid-cooled single-cylinder
Displacement 249 cc
Bore & stroke 79.0 mm x 50.9 mm
Compression ratio 13.9:1
Valve train DOHC, four-valves
Fuel delivery PGM-FI electronic fuel injection with 44 mm throttle body
Transmission Close-ratio five-speed
Final drive #520 sealed chain; 13T/48T
Chassis & Suspension
Front suspension 49 mm fully adjustable leading-axle inverted telescopic Showa SPG coilspring fork; 268 mm (10.6 in.) travel
Rear suspension Pro-Link® Showa single shock with adjustable spring preload, rebound and compression damping adjustability; 317 mm (12.5 in.) travel
Dimensions & Additional Information
Tires Front: 90/90-21
Rear: 110/100-18
Brakes Front: 260 mm disc with dual-piston caliper
Rear: 240 mm disc with single-piston caliper
Ground clearance 329 mm (13.0 in.)
Seat height 961 mm (37.8 in.)
Wheelbase 1,486 mm (58.5 in.)
Curb weight 111 kg (245 lb.) *
Fuel capacity 8.5 litres
Colour Extreme Red
Warranty No warrranty





2021 Honda CRF250RX – Totalmotorcycle.com European Specifications/Technical Details

NA





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
