2021 KTM 1290 Super Adventure R Guide

2021 KTM 1290 Super Adventure R

2021 KTM 1290 Super Adventure R 2021 KTM 1290 Super Adventure R 2021 KTM 1290 Super Adventure R 2021 KTM 1290 Super Adventure R 2021 KTM 1290 Super Adventure R

2021 KTM 1290 Super Adventure R : SEEK UNCHARTED TERRITORY.

Introducing the 2021 KTM 1290 Super Adventure R…

Pick a point on a map, drop a pin, and hit the road. The KTM 1290 SUPER ADVENTURE R is engineered to cross the wildest, most challenging terrain with unmatched ability and class-leading performance. It leaves us saying only one thing – Uncharted territory beware! The KTM 1290 SUPER ADVENTURE R is primed and ready to plant its flag anywhere on the planet.

The second instalment in the new generation of liter-class KTM ADVENTURE models comes in the form of the all-new KTM 1290 SUPER ADVENTURE R. Engineered to cross the wildest and most challenging terrain, this motorcycle has the capacity to take adventurers anywhere.

Primed and ready to plant its flag anywhere on the planet, the 2021 KTM 1290 SUPER ADVENTURE R has been designed from the ground up with an extensive list of innovative upgrades.

All-terrain agility
Riding the KTM 1290 SUPER ADVENTURE R across rough terrain in the easiest and most intuitive way has been a development priority for the completely reworked 2021 edition. An all new bodywork providing excellent ergonomics and allowing to hold the fuel in the tank as low as possible has been designed for better agility, a lower center of gravity and an even better feeling in all riding conditions.

A sharper cornering sensation has been achieved by moving the steering head back by 15 mm, re-locating the front section of the engine and introducing a slightly longer new diecast open-lattice swingarm for a greater depth of feeling under acceleration. KTM engineers have analyzed and trimmed every centimeter of the new bodywork in order to provide the right thickness and the optimal rider-bike contact.

The sensation of control and balance is augmented by the new three-part fuel tank that holds 23 l and is positioned lower to assist riding equilibrium. Like the chassis, the subframe has also been reconstructed and is topped with a sporty stepped seat at 880 mm of height with slim dimensions and a handy storage underneath.

Further enhancing handling is the reworked 2021 WP suspension configuration. The KTM 1290 SUPER ADVENTURE R streams elements of KTM’s prolificacy in offroad and embraces the best of WP XPLOR technology. The fully-adjustable 48 mm front forks with an impressive 220 mm of travel feature split damping functions and quick modification potential with a twist of the respective dials. The same travel measurement graces the WP PDS shock. The competence of the system was achieved through tests in the Californian desert-land as well as long stretches of varied landscapes across Europe.

THE KTM 1290 SUPER ADVENTURE R PUT TO THE TEST BY CHRIS BIRCH

From the riding heaven of New Zealand to the rest of the world, Adventure bike guru Chris Birch puts the all-new KTM 1290 SUPER ADVENTURE R through its paces to provide his own review of KTM’s ultimate all-terrain powerhouse.





2021 KTM 1290 Super Adventure R Totalmotorcycle.com Key Features

KTM 1290 SUPER ADVENTURE R – MODEL HIGHLIGHTS
// All-new ergonomics offering extra agility
// Redesigned seat with lower height
// Reworked long-travel, adjustable WP XPLOR suspension
// Optimized weight distribution with lower-placed fuel tanks
// Cutting-edge electronics that enhance the ride
// New, intuitive 7’’ TFT display with redesigned handlebar switches
// New LED headlight with LED daytime light
// Revised V-Twin engine [EURO 5] with improved heat dissipation
// New, Adventure-specced tires by Bridgestone



FRESH IN DEALERS SOON: THE ALL-NEW KTM 1290 SUPER ADVENTURE R ALLOWS FOR LIMITLESS TRAVEL POSSIBILITIES EVEN WHERE THE ROAD ENDS

The second instalment in the new generation of liter-class KTM ADVENTURE models comes in the form of the all-new KTM 1290 SUPER ADVENTURE R. Engineered to cross the wildest and most challenging terrain, this motorcycle has the capacity to take adventurers anywhere.

Primed and ready to plant its flag anywhere on the planet, the 2021 KTM 1290 SUPER ADVENTURE R has been designed from the ground up with an extensive list of innovative upgrades.

All-terrain agility
Riding the KTM 1290 SUPER ADVENTURE R across rough terrain in the easiest and most intuitive way has been a development priority for the completely reworked 2021 edition. An all new bodywork providing excellent ergonomics and allowing to hold the fuel in the tank as low as possible has been designed for better agility, a lower center of gravity and an even better feeling in all riding conditions.

A sharper cornering sensation has been achieved by moving the steering head back by 15 mm, re-locating the front section of the engine and introducing a slightly longer new diecast open-lattice swingarm for a greater depth of feeling under acceleration. KTM engineers have analyzed and trimmed every centimeter of the new bodywork in order to provide the right thickness and the optimal rider-bike contact.

The sensation of control and balance is augmented by the new three-part fuel tank that holds 23 l and is positioned lower to assist riding equilibrium. Like the chassis, the subframe has also been reconstructed and is topped with a sporty stepped seat at 880 mm of height with slim dimensions and a handy storage underneath.

Further enhancing handling is the reworked 2021 WP suspension configuration. The KTM 1290 SUPER ADVENTURE R streams elements of KTM’s prolificacy in offroad and embraces the best of WP XPLOR technology. The fully-adjustable 48 mm front forks with an impressive 220 mm of travel feature split damping functions and quick modification potential with a twist of the respective dials. The same travel measurement graces the WP PDS shock. The competence of the system was achieved through tests in the Californian desert-land as well as long stretches of varied landscapes across Europe.

Performance-tailored technology
The 2021 KTM 1290 SUPER ADVENTURE R is a vessel for the latest electronics packages and continuation of the collaboration with first-rate pioneers like Bosch. A new 6-axis lean angle sensor filters information on the exact pitch and position of the bike and its behaviour. In turn, this affects the degree of Motorcycle Traction Control, Motor Slip Regulation, Motorcycle Stability Control and forces of Offroad ABS. To fit the needs of the modern all-terrain riding enthusiast, all rider assists can be tweaked or disengaged.

Alongside the standards RAIN, STREET, SPORT and OFFROAD ride modes, the optional RALLY mode permits riders to set throttle response to aggressive and select one of nine different levels of wheel spin. The changes to suit any kind of topography are all charted through the all-new and more use-friendly 7’’ TFT dash, which is hooked to a new Connectivity Unit. The larger view has quicker and more practical menus and clearly shows turn-by-turn directions indicated by the KTM MY RIDE app.

Premium-spec components
The KTM 1290 SUPER ADVENTURE R relies on the new Euro 5-ready LC8 that is now 1.6 kg lighter and froths out 160 hp at 9,000 rpm and 138 Nm of torque at 6,500 rpm for the best power-to-weight offering in the segment. KTM has combed through the internals of the V-Twin powerplant to improve heat dissipation and shave grams in the quest for improved rideability.

With a lot of effort going towards optimizing the air flow through the bike, the 2021 KTM 1290 SUPER ADVENTURE R features two separate radiators instead of the one-piece unit of its predecessor. With cleverly designed air ducts, the amount of hot air streaming towards the rider´s legs has been significantly reduced and the difference becomes easily noticeable in the slow, tight sections.

Thanks to a reworked airbox, riders can now easily access the air filter by simply removing four screws. The filter itself now features vertical ribs, instead of horizontal, which helps direct dust or sand towards the bottom of the air box. Overall, a better design for hardcore adventurers.

Some additional engine updates include lighter engine cases, new pistons, improved shifting, altered coatings and easier filter access and a re-jigged two-header exhaust unit, with the updated package making the LC8 flighty, more reliable and more dependable for all types of trail. 15,000 km service intervals have again been achieved with low fuel consumption at 5.7 l / 100 km. Together with PANKL, KTM has also reworked the gearbox shifting mechanism for faster, lighter and more responsive actions. The full force of this update can be felt through the optional Quickshifter+, which now has a faster and even more precise operation.

To cope with the rigours of life away from the beaten track, the KTM 1290 SUPER ADVENTURE R is armed with premium level equipment. New, Adventure-specific Bridgestone tires are wrapped around ALPINA aluminum spoked wheels, which can be run tubeless with a reassuring O-ring sealant in the spoke nipples. This new generation 2021 KTM 1290 SUPER ADVENTURE R comes with modern and eye-catching paint and graphic set.

KTM RACE ON tech takes keyless ignition to a new level of autonomy, separate Tire Pressure Monitor system sensors provide more detailed customisation and four piston radial mounted Brembo callipers bring the whole show to a fearsome stop or satisfying slide. The windshield, the levers, the pegs and the handlebars all are adjustable to further enhance rider adaptability.

As is the case with its S model counterpart, the new KTM 1290 SUPER ADVENTURE R benefits from a remodelled optional software package policy. With the Rally Pack offering the RALLY riding mode, the MTC slip adjuster and the adjustable throttle response, the all-in-one Tech Pack includes the Quickshifter+, the Motor Slip Regulation, the Hill Hold Control, the adaptive brake light and all the features of the Rally Pack.

Joachim Sauer – KTM Product Manager: “For KTM, ‘R’ stands for ‘Rally’ and ‘Racing’ so with the new KTM 1290 SUPER ADVENTURE R we really feel in our element. Adopting all the great benefits of the recently launched S model, the KTM 1290 SUPER ADVENTURE R is here to set new standards of all-terrain performance. With this new offroad powerhouse we wanted even more rideability and to achieve it, we looked into rider-focused ergonomics and improved suspension performance. The new bike also offers a big step forward in terms of weight distribution and riding agility. Making gains with the overall performance of our LC8, we were also able to give the 2021 KTM 1290 SUPER ADVENTURE R innovative technical features. If some of the best moments of adventuring come about by discovering the unknown, with this bike riders could not have a better tool for the job.”

The new generation KTM 1290 SUPER ADVENTURE R will be available at KTM dealers internationally starting March 2021. For the North American markets, it will become available in the fall of 2021.



2021 KTM 1290 Super Adventure R Totalmotorcycle.com Features and Benefits

Engine & Exhaust

Cooling

The KTM 1290 SUPER ADVENTURE R now features 2 separate radiators instead of a one-piece unit. The result is better heat dissipation, and improved cooling all-round. Cleverly designed air ducts now also stream cool air towards the engine, not only keeping the motorcycle cool, but the rider’s legs cool too.



Engine

With a sledgehammer hit of 160 hp and a massive 138 Nm of earth-twisting torque, the proven V-twin LC8 engine once again takes the accolades as the most compact, lightest, and best performing engine in the segment. Its greener too, meeting all EURO5 regulations and will deliver 15.000 km service intervals and low fuel consumption, trip after trip, mile after mile.



Transmission

Helping the KTM 1290 SUPER ADVENTURE R shift – in more ways than one – is a 6-speed PANKL transmission with a new, lighter aluminum shifting drum with optimized tracks for faster, smoother gear changes. Shifting forks have also been coated in copper to reduce wear and tear. This also helps the Quickshifter+ engage quicker for ultra-fast, slick gear changes.



PASC Clutch

Not only does the slipper clutch open when the engine back-torque becomes too high, it also assists when you open up the throttle. The former prevents destabilizing rear wheel chatter when braking sharply or decelerating; the latter reduces the lever force required for changing gears, allowing the clutch to be controlled with one trigger happy finger – saving you energy while riding.



Cylinder heads

A key element in the smooth power delivery of the 75° V-twin is each cylinder’s state-of-the-art 4-valve DOHC cylinder head. These combine twin plug ignition, flow-optimized ports and a slick low-friction valve drive train with cams from each cylinder’s twin overhead camshafts driving DLC-coated cam followers.



DLC coating

Diamond-Like Carbon – or DLC for short – is an extremely hard, durable coating used in many engine parts, such as cam followers, to assist sliding behavior. It improves performance and our engines love it!



Twin ignition

The twin plug ignition system controls the two differently sized spark plugs in each cylinder head independently of each other. This results in improved combustion and a smoother, optimally controlled combustion sequence. What that means to you, is better-controlled power, lower fuel consumption, and reduced emissions.



Pistons

The KTM 1290 SUPER ADVENTURE R’s forged piston structure is derived from Formula 1 technology. The result is a high loading capacity despite its extremely short and lightweight design. The piston skirts have an additional state-of-the-art, Grafal® finish. It further reduces friction and is particularly hard wearing.



Crankshaft

The extremely low crankshaft reciprocating weight enhances the responsiveness and free-revving nature of the engine. With a flow-optimized crank web shape, the particularly low-loss running of the crank drive is further enhanced.



Overdrive

The sixth gear serves as a long overdrive in the KTM 1290 SUPER ADVENTURE R’s well-spaced gearbox. This saves fuel and adds to your cruising comfort.



Ride-by-wire

Smooth throttle response is what you get, beyond simply being free of a throttle cable, which is why the KTM 1290 SUPER ADVENTURE R’s ride-by-wire system is so attractive. It ensures perfect dosage of the readily available and plentiful torque, while electronically translating rider throttle commands into throttle valve positions, which are perfectly adjusted to suit different riding conditions.



Exhaust

Providing the bark for the bite, the KTM 1290 SUPER ADVENTURE R features a completely reworked exhaust system. Two new headers lead the exhaust gas to a hydroformed collector chamber with two catalytic converters. These, in conjunction with 3 lambda sensors allow the emissions to stay within the latest EURO 5 limits. Meanwhile, at the business end, a newly designed stainless-steel silencer provides a typically v-twin tone.



Airfilter

Thanks to a reworked airbox, riders can now easily access the air filter by simply removing 4 screws to remove the storage compartment ahead of the fuel filler cap. Also, the filter itself now features vertical ribs, instead of horizontal. Which helps direct dust or sand towards the bottom of the air box, without getting sucked into the filter slats. Overall, a better design for hardcore adventurers.



Cooling

The KTM 1290 SUPER ADVENTURE R now features 2 separate radiators instead of a one-piece unit. The result is better heat dissipation, and improved cooling all-round. Cleverly designed air ducts now also stream cool air towards the engine, not only keeping the motorcycle cool, but the rider’s legs cool too.



Engine

With a sledgehammer hit of 160 hp and a massive 138 Nm of earth-twisting torque, the proven V-twin LC8 engine once again takes the accolades as the most compact, lightest, and best performing engine in the segment. Its greener too, meeting all EURO5 regulations and will deliver 15.000 km service intervals and low fuel consumption, trip after trip, mile after mile.



Chassis

Fuel tank

A completely redesigned 23 liter, 3-part fuel tank. This is made up of two large fuel cells on each side of the frame, with an upper, central vessel that supplies fuel to the lateral units. The fuel cap is also new and electronically controlled. But the best bit? A storage compartment reminiscent of the iconic KTM 990 ADVENTURE has been included in the new design, complete with a USB socket and big enough to hold your cellphone, sunglasses or wallet.



Frame

A new, reworked, and lightweight, chrome-molybdenum stainless steel trellis frame featuring laser-cut tubes, combines with forged elements for an ultra-strong component on the KTM 1290 SUPER ADVENTURE R. The steering head has been moved 15 mm rearwards, to shorten the overall frame for improved cornering behavior, while the front engine mount has been rotated forward by 2 degrees to aid in hard acceleration, keeping the front end firmly planted on the ground.



Swingarm

Extended by 15 mm to optimize tracking stability in conjunction with the shorter frame, the die-cast, open-lattice swingarm retained it’s lightweight and pin-point manufacturing to provide stiffness and uncompromised control when hitting the dirt.



Wheels

Serious offroad exploration demands hardcore equipment. The spoked wheels of the KTM 1290 SUPER ADVENTURE R feature new and robust aluminum rims made for KTM by ALPINA, with an improved sealing system to make them 100% tubeless. What’s more, is that instead of the typical rubber band sealing the rim to prevent air from leaking through the nipples, the wheels have an O-ring seal on each nipple.



Suspension

The KTM 1290 SUPER ADVENTURE R is fitted with high-performance WP XPLOR suspension which was co-developed with test rider Quinn Cody at the helm. A WP XPLOR fork with 48 mm inner tubes takes care of business at the front and has been derived from the successful KTM off-road models, and features split fork technology and all-new settings for even better offroad performance. At the rear, is a high-end PDS monoshock, which is fully adjustable in spring preload with an external handwheel, rebound, and compression including high and low-speed compression damping.



Steering Damper

Heading off the beaten track often leads to encountering some pretty rough roads. Thankfully, things are kept in check by a WP steering damper as standard. Linked between the frame and the triple clamp, the steering damper ensures things are kept tidy when the road isn’t.



Brakes

Precise. Powerful. Consistent. Just as you would expect from a set of BREMBO brakes. Up front you’ll find twin 320 mm diameter discs, which are radially mounted, plus 4-piston fixed calipers. At the rear, excess speed is taken care of by a generously dimensioned 267 mm diameter disc. And in case of an emergency, Bosch’s two-channel 9M+ ABS is there to save the day.



Fuel tank

A completely redesigned 23 liter, 3-part fuel tank. This is made up of two large fuel cells on each side of the frame, with an upper, central vessel that supplies fuel to the lateral units. The fuel cap is also new and electronically controlled. But the best bit? A storage compartment reminiscent of the iconic KTM 990 ADVENTURE has been included in the new design, complete with a USB socket and big enough to hold your cellphone, sunglasses or wallet.



Frame

A new, reworked, and lightweight, chrome-molybdenum stainless steel trellis frame featuring laser-cut tubes, combines with forged elements for an ultra-strong component on the KTM 1290 SUPER ADVENTURE R. The steering head has been moved 15 mm rearwards, to shorten the overall frame for improved cornering behavior, while the front engine mount has been rotated forward by 2 degrees to aid in hard acceleration, keeping the front end firmly planted on the ground.



Ergonomics & Comfort

Windshield

The KTM 1290 SUPER ADVENTURE R boasts a short, adjustable rally-inspired windshield that has been optimized in the wind tunnel to provide maximum wind protection, but also rider movement when standing on the pegs and attacking tricky terrain. Adjustment is easy too, thanks to right and left mounted handwheels controlling 55 mm of screen height.



Handlebar

Wide, adjustable, and ready for long hours in the saddle, the high-strength tapered aluminum handlebars are designed to provide riders with greater control, and uncompromised comfort. Newly developed and robust handguards have also been designed for optimal aerodynamic behavior when it comes to high-speed stability.



Illuminated Menu Switch

Illuminated switches don’t only look good, but make sense when you’re out in low light conditions and need to locate the important buttons in the blink of an eye.



Seats

Where you’ll be spending most of your time, the all-new seat on the KTM 1290 SUPER ADVENTURE R is designed to guarantee maximum comfort, thanks to high-quality foam padding. This one-piece, stepped seat sits 880 mm off the deck and allows for seamless rider movement when traversing difficult terrain. Accessing the under-seat area is also made easier, with the seat latch released at the push of a button.



Footpegs

Two foot peg positions: stock or 10 mm up and back (diagonally), allow riders to set the comfort level to suit their height and riding preference, which can make a big difference on a long adventure ride.



Windshield

The KTM 1290 SUPER ADVENTURE R boasts a short, adjustable rally-inspired windshield that has been optimized in the wind tunnel to provide maximum wind protection, but also rider movement when standing on the pegs and attacking tricky terrain. Adjustment is easy too, thanks to right and left mounted handwheels controlling 55 mm of screen height.



Handlebar

Wide, adjustable, and ready for long hours in the saddle, the high-strength tapered aluminum handlebars are designed to provide riders with greater control, and uncompromised comfort. Newly developed and robust handguards have also been designed for optimal aerodynamic behavior when it comes to high-speed stability.



Bodywork & Graphics

LED headlight

Turning night into day, the LED headlight on the KTM 1290 SUPER ADVENTURE R has been designed to light the way on any adventure. Flanked by cornering and day time running lights. This results in a clean, KTM-distinctive look which provides impeccable illumination with a wide beam pattern to light up the road ahead.



Software & Electronics

KTM MyRide

There won’t be any Wi-Fi where you’re going, but with the KTM MY RIDE system, you’ll still have a connection to your smartphone. Syncing via Bluetooth, KTM MY RIDE allows you to access your phone, giving you access to incoming calls, your music library, and turn-by-turn navigation right on your TFT display. Find more info at ktm.com/my-ride



Dashboard

Taking charge at the helm is an all-new scratch-resistant 7-inch TFT display. Unmatched in terms of graphics and readability, adventurers can access information on the fly, quickly and easily without navigating complex menus. This comes thanks to a 6-way switch cube on the handlebar and the new quick select and favorites buttons. Connectivity is also taken care of by way of KTM MY RIDE, which connects via Bluetooth for turn-by-turn navigation, music, and even answering calls. Still catching glare? The TFT screen is tilt-angle adjustable.



USB Phone Pocket

No bar-mounted cellphone cradle? No problem. A convenient compartment keeps your smartphone safe on the road. It keeps it charged too, thanks to its integrated USB socket. The optional incoming call and audio functions link the phone to the TFT via Bluetooth, so less time is spend staring at the screen, and more time is spent looking ahead.



Rider Aids

Electronic rider aids provide more control, performance and enjoyment to the rider under a wider range of circumstances. The latest ABS and MTC (Motorcycle Traction Control) technology is designed to enhance your riding experience. Different ride modes are tailored for easy adjustment of the rider aid functions to suit a range of riding conditions. The simple adjustability of these features maximizes the powerful V-twin’s innovative technology and equipment across a much wider range of terrain.



MSC with C-ABS

Controlling traction isn’t only relevant when putting the power down, but also when you back off the throttle and get onto the brakes. Thanks to the state-of-the-art MSC (Motorcycle Stability Control) system made by Bosch, riders can push on in complete confidence. Lean-sensitive cornering ABS works in conjunction with the MSC systems to allows riders to always use the full power of their brakes while taking lean angle, stability, and road conditions into account. A unique Offroad ABS function will also allow you to push harder before there is any ABS interference.



TPMS

A critical part of your adventure ride is, arguably, your tire pressure. Thankfully, the KTM 1290 SUPER ADVENTURE R is fitted with a TPMS (Tire Pressure Monitoring System) which monitors front and rear tire pressure and displays it on the TFT for easy viewing. Should there be any pressure loss, a warning will display on the dash.



MTC

Lean-angle-sensitive Motorcycle Traction Control (MTC) reacts to any disproportionate slippage of the rear wheel. This is done via two separate controllers, reading wheel-slip and pitch respectively, making calculations and adjustments in milliseconds. The result? Both straight-line acceleration and cornering efficiency are unhindered with power reduction less abrupt – even when the front wheel lifts off the deck. Want to take the power into your own hands? MTC can be turned off for hardcore offroad adventures.



ATIR

Failure to indicate is one thing. Forgetting to cancel your tune indicator is another. Thankfully, the KTM 1290 SUPER ADVENTURE R is fitted with an Automatic Turn Indicator Reset or ATIR. After 10 seconds of movement and 150 meters of riding distance, the turn indicator will reset automatically. A big improvement in terms of safety, as it is now impossible to forget to reset the indicators.



Offroad Ride Mode

The real adventure starts when the tarmac ends. For that, we give you Offroad Mode. One engaged, ride-by-wire smooths out the throttle response and limits peak power output to better suit offroad conditions. This means riders can lock the rear wheel with the rear brake- a prerequisite for committed offroad riding and deliberately executed slides – while allowing some wheel spin out of corners. Most importantly, the rider is able to hoist the front wheel over obstacles. The rider can also activate the Offroad ABS function to get optimal control in offroad conditions while maintaining full safety.



Offroad Traction Control

Offroad Traction Control allows a certain slippage at the rear wheel. This is for those moments when you want full control, without any unwanted interference mastering controlled drifts.



Offroad ABS

In this mode, three things happen – ABS functionality is deactivated on the rear wheel but maintains some ABS functionality of the front wheel, rear-wheel lift-up detention is disable, and cornering ABS is disabled. All this together means riders have complete control offroad with confidence. For advanced riders, it allows them to push harder before there is any ABS interference.



KTM MyRide

There won’t be any Wi-Fi where you’re going, but with the KTM MY RIDE system, you’ll still have a connection to your smartphone. Syncing via Bluetooth, KTM MY RIDE allows you to access your phone, giving you access to incoming calls, your music library, and turn-by-turn navigation right on your TFT display. Find more info at ktm.com/my-ride



Dashboard

Taking charge at the helm is an all-new scratch-resistant 7-inch TFT display. Unmatched in terms of graphics and readability, adventurers can access information on the fly, quickly and easily without navigating complex menus. This comes thanks to a 6-way switch cube on the handlebar and the new quick select and favorites buttons. Connectivity is also taken care of by way of KTM MY RIDE, which connects via Bluetooth for turn-by-turn navigation, music, and even answering calls. Still catching glare? The TFT screen is tilt-angle adjustable.





2021 KTM 1290 Super Adventure R – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $ TBA USD
Canada MSRP Price: $ TBA CDN
Europe/UK MSRP Price: £15999 (On The Road inc 20% Vat)



Engine
◼ Torque 138Nm
◼ Transmission 6-speed
◼ Cooling Liquid cooled
◼ Power in KW 118kW
◼ Starter Electric starter
◼ Stroke 71mm
◼ Bore 108mm
◼ Clutch PASC (TM) slipper clutch, hydraulically actuated
◼ CO2 emissions 134g/km
◼ Displacement 1301cm³
◼ EMS Keihin EMS with RBW and cruise control, double ignition
◼ Design 2-cylinder, 4-stroke, V 75°
◼ Fuel consumption 5.7l/100 km
◼ Lubrication Forced oil lubrication with 3 oil pumps



Chassis
◼ Tank capacity (approx.) 23l
◼ ABS Bosch 10.3ME Combined-ABS (incl. Cornering-ABS and offroad mode)
◼ Front brake disc diameter 320mm
◼ Rear brake disc diameter 267mm
◼ Chain 525 X-Ring
◼ dry weight 221kg
◼ Frame design Chrome-moly tubular space frame, powder-coated
◼ Front suspension WP XPLOR-USD, Ø 48 mm
◼ Ground clearance 242mm
◼ Rear suspension WP Xplor PDS shock absorber
◼ Seat height 880mm
◼ Steering head angle 64.7°
◼ Suspension travel (front) 220mm
◼ Suspension travel (rear) 220mm



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
