2021 MV Agusta Brutale 1000RR Guide

2021 MV Agusta Brutale 1000RR: POWERFUL SEDUCTION.

Introducing the 2021 MV Agusta Brutale 1000RR:

Based on the extraordinary Serie Oro, limited production has recently begun, the 2021 MV Agusta Brutale 1000RR will bring the same nuances, and carefully balanced choices of style, technical components and dynamic development onto the road.

Conceived along with the extraordinary Serie Oro, the Brutale 1000 RR seduces with the same powerful appeal, a summary of stylistic, technical and dynamic choices that is unique in the segment. Being easily approachable and accessible performance were the central priorities in designing the new Brutale.

Confidence inspiring performance was one of the main priorities in designing the new Brutale 1000. Continual increases in maximum power of the more sports-oriented models has not been matched by a relative increase in ease of use on the road. This means that motorcycle designers have a responsibility to offer the customer the best possible conditions of: technology, style and ease of control. The goal is to get the best out of chassis, engine and electronics, with minimum effort from the rider, taking into account the exceptional performance levels of models such as the Brutale 1000 RR.

NEW 2021 MV Agusta Brutale 1000RR, POWERFUL SEDUCTION.

In recent years, the continuous increase in power for the sportiest models has not been accompanied by a proportional improvement in road quality and safety. This is why guaranteeing that the bike is particularly manageable in all conditions of use is so necessary. The goal? To obtain the most from chassis architecture, engine and electronics with minimum rider effort, even when performance is exceptional, as in the case of the 2021 MV Agusta Brutale 1000RR. A spectacular Superbike Replica. An exclusive sport naked bike. An incredibly easy bike to ride.

A spectacular Superbike replica. Naked. And available to all.

Check out our exclusive 1 Hour in-depth video on the new Brutale 1000RR!

2020 MV Agusta Dragster 800RR x TheArsenale Totalmotorcycle.com Key Features

DESIGN AND OUTFITTING
The design concept of the new 2021 MV Agusta Brutale 1000RR is deeply rooted in the first Brutale which, along with the F4 supersport bike, marked the Italian brand’s sensational return onto the global stage. Since then, Brutale has been synonymous with “out- standing performance sport naked bike”.

The DNA of that bike, which was so unique in its charm and history, returns now in the form of the new Brutale 1000 RR. The impact of the headlight unit is just as attractive as it was then, modernised by an original and extremely popular stylistic interpretation. Popularity that can be found throughout the many details that contribute to defining the stylistic personality of this bike. With a strong, natural and instinctive dynamic character, captured and simultaneously enhanced by the design of Adrian Morton, the Brutale 1000 RR conveys its personality even with the engine switched off, parked at the side of the road.

The riding position also contributes to defining its character, reflecting one of the qualifying points of the design, namely the natural integration of rider and vehicle, enhanced by the functionality and beauty of the instrumentation and the controls.

The design comes alive with tight lines and perfectly balanced front and rear end shapes: this balance which has been the distinctive trait of the four-cylinder Brutale, right from the first iconic 1997 model. The most typical and personal features, including headlight, fuel tank and tail fairing, were designed and manufactured specifically for this new Brutale.

The full-LED headlight uses Cornering Lights for improved performance, managed from the inertial platform: the light beam changes direction and angle based on the dynamic position of the bike. The headlight, that also stands out because of the internal coloured X-shaped section, another exclusive feature, is enhanced by the Daylight Running Lights, designed to define a lighting effect that makes the new Brutale immediately un- mistakable from any angle.

The emotional experience offered by the Brutale 1000 RR is the same as the Serie Oro, thanks to outfitting choices that make the two models very similar.

The superstructure of the 1000 RR also include elegantly modelled carbon fibre elements. The steel fastening hardware has an optimised design that makes it as light as possible. The rims on the 1000 RR are made of aluminium with a painstaking forging process. They boast a specific design and, thanks to the attention given to reducing their weight, they contribute to the outstanding final result achieved by the 1000 RR, with its 186 kg kerb weight.

The second generation, 5-inch colour TFT display, with 800 by 480 pixel resolution, is the main interface between rider and vehicle. Bright and easy to read in any light conditions, in just a few steps, it provides access to the myriad possibilities of personalising the bike. Access to the numerous configuration menus is immediate thanks to the electric handlebar controls and the logical linear menu structure.

Instrumentation allows Bluetooth connection with your smart- phone to manage incoming calls, messages and music.

Cruise control comes standard and proves to be extremely convenient, even on a hyper naked like the 1000 RR.

And then, with the new MV Ride app, it is super easy to persona- lise every detail of the bike, with the engine, suspension and safety menus just a click away. For example, in just a few simple steps, you can adjust the response of the Öhlins EC control unit directly from your smartphone. Just a touch to the screen will adjust the fork, rear shock absorber or steering damper.

Traction control and ABS can also be adjusted using the app, as well as the Custom map on the MVICS 2.0 platform.

ENGINE AND ELECTRONICS
Like the Brutale 1000 Serie Oro, the 1000 RR engine represents the most recent evolution of the in-line, four-cylinder MV Agusta design.

This new version stands out for its significant redesign, across all sections; the use of the finest materials; and complete review of electronic-management parameters, enormously perfected compared to previous versions.

All of this makes this the highest performance hyper naked bike in the world. In fact, the power and torque values set new records: 208 HP at 13,450 rpm and 116.5 Nm. The radial valve timing and central timing chain, technical choices that have characterised all of the most recent MV Agusta four-cylinder engines, underwent significant redesigning, inspired by Formula 1 and MotoGP technology. Specifically, the combustion chamber uses F1 technology, whilst the titanium piston rods, indispensable in MotoGP bikes, contribute to reducing mass, loads and inertia of the engine. The central timing chain technical solution is also a MotoGP-inspired component, capable of mitigating the torsion effects of camshafts at high rpm.

There are new valve guides and camshafts, the latter with unprecedented new timings on both the intake and the exhaust side. The pistons use low-friction Asso circlips, and there is a new crankshaft that is balanced to limit absorption at low revs.

Based on MV Agusta’s direct experience in factory-derivative competition, it has created the new splitter lubrication system, which allows oil to be separated from moving mechanical parts.

The semi-dry sump lubrication is capable of guaranteeing mechanical protection under extreme riding conditions such as sharp leans and wheelies, yet without compromises in terms of friction levels, that remain significantly low.

A large portion of the design and development work in fact focused on friction levels, also in terms of the transmission, revamped with gears that reduce both friction and overall noise. This goal is supported by tone wheel and clutch covers that partially absorb noise.

Redesign of the airbox has been followed by definition of a new intake system: the ducts have different lengths to maximise engine yield, power and torque.

The current structure features double injectors: four upper Mikuni and four lower Magneti Marelli shower injectors, with greater capacity and mounted above the intake duct.

The Arrow exhaust system uses the 4-1-4 set-up, with throttle valve.

Electronic engine management has evolved, thanks to collaboration with Eldor, which has created the new EM2.0 control unit specifically for this in-line four-cylinder design.

The bike also features a full ride-by-wire multimap system (Sport, Race, Rain, Custom) and IMU inertial platform, which manages traction control (with eight different settings and the option to deactivate it) and modulates intervention based on lean-angle data provided by the IMU.

The Front Lift Control, an evolution of the anti-wheelie system, has “active” and “non-active” options. Launch control is availa- ble for starts, intervening on both engine rpm and torque based on the speed during the start.

A handy contribution to comfort and easy use is the EAS 2.1 Up&Down electronic gearbox, active both in up and downshifting.

CHASSIS, SUSPENSION AND BRAKE
In true MV Agusta tradition, the frame on the new Brutale offers a highly evolved “mixed structure” with steel lattice and aluminium side plates, aligning it with engine performance and the requirements of and increasingly sporty driving style that is simultaneously immediate and easy.

The riding position is the product of careful ergonomic analysis, aimed to guarantee optimal vehicle control, good wind protection and surprising overall comfort: the semi-handlebars emphasise the bike’s undeniable sporty calling. Careful attention to aero- dynamics, fundamental for a bike that can reach a maximum speed of over 300 km/h, is clear from the spoilers positioned alongside the radiator, to improve downforce and adding load to the front end, limiting lift at high speed. The effect can be clearly felt over 200 km/h and guarantees the steering precision typical of MV Agusta bikes

The chassis dimensions are identical to those of the Serie Oro: compact wheelbase of 1,415 mm, with front wheel trail of 97 mm. The Öhlins Nix EC fork, with TIN surface treatment features electronic adjustment of the hydraulic brake in application and release. Adjustment of the spring preload is manual. The same electronic management is offered by the shock absorber fixed to the aluminium single-sided swing arm and the Öhlins EC electronic steering damper, that adjusts constantly based on the bike’s speed and is fixed by plates specially designed for the new Brutale. Even the braking system is the same as the Serie Oro, with the prestigious Brembo Stylema front callipers, radial callipers and 320-mm-diameter floating discs. The rear disc is 220 mm and is combined with a dual-piston calliper.

Electronic management is assigned to the ABS Bosch 9 Plus system with Race Mode, particularly light and effective.

2020 MV Agusta Dragster 800RR x TheArsenale Totalmotorcycle.com Features and Benefits

Design and details

The design draws on tight lines and forms which are perfectly integrated between the front and rear end: this balance has long been a distinctive trait of the four-cylinder Brutale, right from the first iconic model that marked the relaunch of the Italian brand along with the F4. The stand-out features, including headlight, fuel tank and tail fairing, have been designed and manufactured specifically for this new Brutale. The full-LED headlight uses Cornering Lights for improved illumination, managed from the inertial platform: the light beam, in fact, changes direction and angle based on the dynamic position of the bike. The headlight, that boasts an internal coloured X-shaped section, another exclusive feature, is enhanced by the Daylight Running Lights, designed to provide a lighting effect that makes the new Brutale unmistakable from any angle.

The emotional experience offered by the 2021 MV Agusta Brutale 1000RR is the same as the Serie Oro: this is thanks to outfitting choices that make the two models virtually identical. The superstructures on the 1000 RR, for example, also use precisely modelled carbon-fibre elements, ideal to outline and enhance the frame and engine; although the exclusive “red wire” is reserved for the Serie Oro. The latter features a full kit of additional components: some of these can be purchased for the 1000 RR, such as GPS tracking, available as an original accessory. Another difference is seen in the bolts and screws, made of steel instead of titanium. The Serie Oro’s light carbon-fibre wheel rims have been replaced on the 1000 RR with forged aluminium components, featuring a special design and weight specifications that contribute to the optimal overall 186 kg dry weight.

The second generation 5” TFT display colour panel, with 800×480 pixel resolution, is the main interface between rider and the many customisable settings on the Brutale 1000 RR. Access to the numerous configuration menus is immediate via intuitive electric handlebar controls, that allow you to access the various sections without delay. Instrumentation allows Bluetooth connection with your smartphone to manage incoming calls, messages and music. Cruise control is also included, very handy also on a hyper naked motorcycle like the 1000 RR. The dashboard allows optimal use of the many functions offered by the MV Ride navigation app, that opens a world of possibilities. For example, bike electronics can be customised directly via smartphone, as well as creating and saving routes, which can then be shared with friends. Extremely useful navigation functions can also be immediately accessed via mirroring on the dashboard with the MV Ride App.

Engine and electronics

Like the Brutale 1000 Serie Oro, the 1000 RR engine represents the most recent evolution of the in-line, four-cylinder MV Agusta design. This new version stands out for its significant redesign, across all areas; the use of the finest materials; and complete review of electronic-management parameters which are greatly refined compared to previous versions. All of this makes this hyper naked bike the most powerful of its type in the world. In fact, the power and torque values set new records: 208 hp at 13,450 rpm and 116.5 Nm.

The radial valve timing and central timing chain, technical choices that have characterised all of the most recent MV Agusta four-cylinder engines, are used here following significant redesign, inspired by Formula 1 and MotoGP technology. Specifically, the radial valves in the combustion chamber uses F1 technology, whilst the titanium piston rods, typical in MotoGP vehicles, contribute to reducing mass, loads and inertia of the engine. The central timing chain is also a MotoGP-inspired component, and is capable of mitigating the torsion effects of camshafts at high rpm.

In addition, there are new valve guides and camshafts, with unprecedented new timing on both the intake and the exhaust side. The pistons use low-friction Asso piston rings, and there is a new crankshaft that is balanced to limit vibrations at low revs.

Based on MV Agusta’s direct experience in factory-derivative competition, it has created the new splitter lubrication system, which allows oil to be separated from moving mechanical parts. The semi-dry sump lubrication is capable of guaranteeing mechanical protection under extreme riding conditions such as during high lean angles and wheelies, yet without compromises in terms of reducing friction levels, that remain significantly low. A large portion of the design and development work has been focused on reducing friction levels, also in terms of the transmission, revamped with gears that reduce both friction and overall noise. This goal is supported by tone wheel and clutch covers that partially absorb noise.

Redesign of the airbox has been implemented by a complete redesign of the intake system: the ducts have different lengths to maximise engine efficiency, power and torque. The current structure features dual injectors per cylinder: four lower Mikuni and four upper Magneti Marelli shower head injectors, with greater capacity and positioned above the intake duct. The Arrow exhaust system uses the 4-1-4 set-up, with a throttle valve for maximum torque at lower RPM’s.

Electronic engine management has also evolved, thanks to collaboration with Eldor, which has created the new EM2.0 control unit specifically for this four-cylinder platform. The bike also features a full ride by wire multimap system (Sport, Race, Rain and Custom) with IMU inertial platform, which manages traction control with slip strategies (with eight different settings and the option to deactivate it) and modulates intervention based on lean-angle data provided by the IMU. The Front Lift Control, an evolution of the anti-wheelie system, has active and non-active options. Launch control is provided for starting, which acts on the engine revs and torque based on velocity during departure; the electronic EAS 2.1 Up&Down gearbox offers both comfort and ease of use.

Chassis, suspension and brakes

In true MV Agusta tradition, the frame on the new 2021 MV Agusta Brutale 1000RR offers a highly evolved “mixed structure” with steel lattice and aluminium side plates, aligning it with engine performance and the requirements of increasingly sporty riding style that is also immediate and easy. The riding position is the product of careful ergonomic analysis, aimed to guarantee optimal vehicle control and comfort: the semi-clip on handlebars reveal the bike’s sporty calling. Careful attention to aerodynamics, fundamental for a bike that can reach a maximum speed of over 300 km/h, is clear from the aerodynamic wings positioned beside the radiators, to improve downforce and adding load to the front end, limiting lift at high speed. The effect can be clearly felt over 200 km/h and guarantees the steering precision typical of MV Agusta bikes.

The chassis dimensions are identical to those of the Serie Oro: compact wheelbase of 1,415 mm, with front wheel trail of 97 mm. The Öhlins Nix EC fork, with TIN surface treatment features electronic adjustment of the hydraulic brake in application and release. Adjustment of the spring preload is manual. The same electronic management is offered by the Öhlins TTX rear shock absorber fixed to the aluminium single-sided swing arm and the Öhlins EC electronic steering damper, that continually adjusts on the basis of the bike’s speed and is fixed by supports specially designed for the new Brutale.

The braking system is the same as the Serie Oro, with the prestigious Brembo Stylema front callipers, radial callipers and 320 mm diameter floating discs. The rear disc is 220 mm and is combined with a dual-piston calliper. Electronic management is assigned to the ABS Bosch 9 Plus system with Race Mode, particularly light and effective.

2020 MV Agusta Dragster 800RR x TheArsenale – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: $ See Dealer for Pricing  USD
Canada MSRP Price: $ See Dealer for Pricing CDN
Europe/UK MSRP Price: € See Dealer for Pricing Euro

ENGINE
Type Four cylinder, 4 stroke, 16 valve
Timing system “D.O.H.C”, radial valve
Total displacement 998 cm3 (60.9 cu. in.)
Compression ratio 13.4:1
Starting Electric
Bore x stroke 79 mm x 50.9 mm (3.1 in. x 2.0 in.)
Max. power – r.p.m. (at the crankshaft) 153,0 kW (208 hp) at 13.000 r.p.m.
Max. torque – r.p.m. 116,5 Nm (11,9 kgm) at 11.000 r.p.m.
Cooling system Cooling with separated liquid and oil radiators
Engine management system Integrated ignition – injection system MVICS
(Motor & Vehicle Integrated Control System)
with eight injectors (4 lower fuel injectors
by Mikuni + 4 upper fuel injectors by Magneti
Marelli with increased fuel flow). Engine
control unit Eldor EM2.10, throttle body full
ride by wire Mikuni, pencil-coil with ion-
sensing technology, control of detonation and
misfire – Torque control with four maps –
Traction control with 8 levels + off and wheelie control with inertial platform
Electronic quick-shift MV EAS 2.1 (Electronically Assisted Shift
Up & Down)
Clutch Wet, multi-disc with back torque limiting device
and Brembo radial pump/lever assembly
Transmission Cassette style; six speed, constant mesh
Primary drive 48/82
Gear ratio
First gear: Speed 14/37
Second gear: Speed 16/33
Third gear: Speed 18/31
Fourth gear: Speed 20/30
Fifth gear: Speed 22/29
Sixth gear: Speed 21/25
Final drive ratio 16/41
ELECTRICAL EQUIPMENT
Voltage 12 V
Alternator 350 W at 5000 r.p.m.
Battery Li-ion 12 V – 4.0 Ah
DIMENSIONS AND WEIGHT
Wheelbase 1415 mm (55.71 in.)
Overall length 2080 mm (81.89 in.)
Overall width 805 mm (31.69 in.)
Saddle height 845 mm (33.27 in.)
Min. ground clearance 141 mm (5.55 in.)
Trail 97 mm (3.82 in.)
Dry weight 186 kg (410.06 lbs.)
Fuel tank capacity 16 l (4.23 U.S. gal.)
PERFORMANCE
Maximum speed* over 300 km/h (186 mph)
MV Agusta is committed to the constant improvement of our products. Therefore the information and technical characteristics of the vehicles are subject to change without notice.
FRAME
Type CrMo Steel tubular trellis
Rear swing arm pivot plates material Aluminium alloy – Adjustable swingarm
pivot height
FRONT SUSPENSION
Type Öhlins Nix EC hydraulic “upside down” front forks with TiN superficial treatment.Completely
adjustable with electronically controlled
compression and rebound damping with
manually controlled spring preload.
Fork dia. 43 mm (1.69 in.)
Fork travel 120 mm (4.72 in.)
REAR SUSPENSION
Type Progressive, single shock absorber Öhlins EC
TTX completely adjustable with electronically
controlled compression and rebound
damping and spring preload
Single sided swing arm material Aluminium alloy
Wheel travel 120 mm (4.72 in.)
BRAKES
Front brake Double floating disc with Ø 320 mm
(Ø 12.6 in.) diameter, with steel braking disc
and aluminium flange – Brembo radial
pump/level assembly
Front brake caliper Brembo Stylema radial-type, single-piece with 4 pistons Ø 30 mm (Ø 1.18 in.)
Rear brake Single steel disc with Ø 220 mm (Ø 8.66 in.) dia.- Brembo PS13 brake pump
Rear brake caliper Brembo with 2 pistons Ø 34 mm (Ø 1.34 in.) ABS System Bosch 9 Plus with Race Mode and RLM (Rear wheel Lift-up Mitigation)
WHEELS
Front: Material/size Forged aluminium alloy 3,50 ” x 17 ”
Rear: Material/size Forged aluminium alloy 6,00 ” x 17 ”
TYRES
Front 120/70 – ZR 17 M/C (58 W)
Rear 200/55 – ZR 17 M/C (78 W)
FAIRING
Material Carbon fiber and thermoplastic material
CONTENTS
Steering damper Öhlins EC with electronic manual and
automatic adjustment modes
Rider’s footpegs CNC adjustable height
Exclusive features Light crankshaft – New combustion chamber Titanium connecting rods – Dashboard TFT 5”color display – Cruise control – Bluetooth GPS – App MVride for navigation mirroring, app-controlled engine, suspension and rider aids setup – Launch Control – FLC Front lift control – Immobilizer
EMMISIONS
Environmental Standard Euro 4
Combined fuel consumption 6.7 l/100 km
CO2 Emissions 153 g/km

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
