2021 Yamaha XSR700 Guide

2021 Yamaha XSR700

2021 Yamaha XSR700 2021 Yamaha XSR700 2021 Yamaha XSR700 2021 Yamaha XSR700 2021 Yamaha XSR700

2021 Yamaha XSR700 : BORN TOMORROW.

Introducing the new 2021 Yamaha XSR700…

Modern classic styling and crossplane concept twin for fun performance, all built to be uniquely customized.

Based on the popular MT-07, the XSR700 is a beautiful blend of twin cylinder performance and eye catching “authentic sports” styling. The XSR incorporates most of the MT-07’s key features including ABS equipped brakes. A natural riding position offers solid riding comfort while the short swingarm and lightweight design highlights the more serious sports side of the XSR. Tasty, timeless styling combined with plenty of Yamaha’s latest technologies, the XSR is guaranteed to provide a fun, exciting ride.

Retro cool, accessible and affordable
The retro styled XSR700 captures everything cool about iconic motorcycles with the latest technology and ride experience. The perfect handling bike for new riders and an expression of the best of motorcycling for experienced riders.

The XSR delivers on its promise. Building on Yamaha’s Faster Sons philosophy it pays homage to design icons of Yamaha’s past such as the XS650 whilst showcasing the best of tomorrow’s technical features.

Underneath the XS650 inspired design this retro street bike comes with the latest chassis technology. Light and agile, it’s a class leading package guaranteed to deliver.

2021 XSR700 and XSR900

With timeless neo-retro style and performance-driven technology, the 2021 XSR700 and XSR900 are modern classics. The XSR700’s standout style and compact twin-cylinder engine not only give the bike unique power characteristics but a unique look while the XSR900 blends world-class engineering, a thrilling triple-cylinder engine and cutting-edge electronics with retro-influenced bodywork for a nostalgic yet modern ride.

The 2021 XSR700 will be available in Radical White/Rapid Red for an MSRP of $8,499 and the 2021 XSR900 will also be available in Radical White/Rapid Red for an MSRP of $9,499. Both models will begin arriving at authorized Yamaha dealers in December.









2021 Yamaha XSR700 Totalmotorcycle.com Key Features
  • Standout Style
    The XSR700™ blends Yamaha’s world-class engineering with timeless style, creating a new type of machine for riders looking for an authentic and honest motorcycle that doesn’t sacrifice performance. Drawing influence from Yamaha’s classic “XS” series of motorcycles, the XSR® oozes class with its exposed aluminum details, retro-influenced bodywork, stepped seat and custom lighting and instrumentation.
  • Advanced Crossplane Crankshaft Concept Engine
    The compact 2-cylinder engine provides a unique power character with its outstanding torque and throttle response and complemented with strong high-rpm pulling power. It also features Yamaha’s “Crossplane Concept” 270-degree crank that provides linear torque development in response to the rider’s throttle input.
  • Powerful Braking with ABS
    The XSR700 provides exceptional and confident braking power thanks to its modern brake components which are backed up by the security of ABS.
  • Compact, Sporty Chassis
    The narrow frame design features sport-oriented geometry to achieve light and nimble handling and is aided by the minimalist 410-pound wet weight and refined ergonomics.









2021 Yamaha XSR700 Totalmotorcycle.com Features and Benefits
  • Advanced Twin Cylinder Engine
    The XSR700 features a compact 689cc liquid-cooled, inline twin-cylinder, DOHC engine with fuel injection. This engine provides a unique power character with its outstanding low- to mid-range torque and very linear throttle response and complemented with strong high-rpm pulling power. This motor develops 50 foot pounds of torque and is designed to maximize riding excitement in the real world.
  • Crossplane Crankshaft Concept
    The 2-cylinder engine features Yamaha’s “Crossplane Concept” 270 degree crank that provides linear torque development in response to the rider’s throttle input. The CP2® engine is also light, slim and compact and offers an excellent level of rider-to-machine communication.
  • Offset Cylinder Block
    The paired cylinders of the XSR engine are shifted slightly forward compared to the center of the crankshaft. This reduces drag during each combustion stroke of the pistons and improves efficiency.
  • Vibration-Reducing Counterbalancer
    To reduce vibration and provide a smooth, modern engine character, the motor uses a geared counterbalancer that is mounted low and forward on the engine.
  • Refined, Efficient Fuel Injection
    Electronic fuel injection settings deliver a smooth throttle response to enhance riding enjoyment from the open roads to the urban sprawl. The system delivers outstanding torque in the low- and mid-rpm range along with exciting acceleration in the upper rpm range. Combined with the efficient overall engine design, the XSR700 delivers an exceptional 58 mpg.
  • Compact 6-Speed Transmission
    The XSR700’s 6-speed transmission takes full advantage of the low-to- mid-range torque and excellent response of the twin-cylinder motor while further enhancing the compact engine design thanks to triangulated input and outputs shafts.
  • Standout Style
    The XSR700 blends Yamaha’s world-class engineering with timeless style, creating a new type of machine for riders looking for an authentic and honest motorcycle that doesn’t sacrifice performance. Drawing influence from Yamaha’s classic “XS” series of motorcycles, the XSR oozes class with its exposed aluminum details, retro-influenced bodywork, stepped seat and custom lighting and instrumentation.
  • Compact, Sporty Chassis
    A lightweight diamond-type high tensile steel frame provides an optimized rigidity balance for light, agile handling and stability. The engine is a stressed member of the chassis which allows for a lighter, more compact main frame design.
  • Street-Focused Suspension
    The 41mm front fork and link-type Monocross rear shock each provide 5.1 inches of suspension travel and are tuned to provide a balance of comfort and control, making it ideal for the street. The shock uses an almost horizontal alignment which helps make the chassis much more compact while rear spring preload adjustment allows the rider to tailor the suspension to match rider weight or load.
  • Powerful Braking with ABS
    The XSR700 provides strong, controllable braking power thanks to its modern braking components including paired floating 282mm front discs with 4-piston calipers and a 245mm rear disc. ABS comes standard to prevent wheel lock under hard deceleration.
  • Lightweight Wheels
    Lightweight 10-spoke cast aluminum wheels are fitted with a 120/70ZR17 front tire and 180/55ZR17 rear tire that provide excellent traction and handling feel. The XSR700 also features Pirelli® Phantom Sportcomp tires that combine modern construction and performance with a stylish retro design.
  • Advanced Instrumentation
    The round LCD panel features a ton of information: digital tachometer, speedometer, gear position, eco mode indicator, ambient and coolant temperature, a fuel gauge and range of trip computer functions including a clock, instant and average fuel consumption, fuel reserve trip meter and the usual trip meters.
  • Classically-styled Lighting
    Up front, a large, round multi-reflector headlight provides both style and illumination in equal measure, complete with trick aluminum supports while out back, a round all-LED tail and brake light is mounted above the rear fender.
  • Stylish and Ergonomic Fuel Tank
    A compact 3.7 gallon fuel tank is shrouded by beautifully shaped and hand-finished aluminum side covers for a timeless design.
  • Casual but Sporty Ergonomics
    A tall, wide handlebar, stitched two-level seat and perfectly placed foot controls provide a comfortable upright riding position that is ideal for either urban traffic or hustling down a twisty road.
  • Unique XSR700 Detailing
    Every aspect of the XSR700 shows Yamaha’s attention to detail: the single-piece stitched saddle, the classic teardrop mirrors with excellent rearward visibility, the compact radiator which is flanked by exposed aluminum covers, a removable subframe that simplifies customization, and the naked aluminum accents and fender mount. The XSR700 demands a second look, every time.









2021 Yamaha XSR700 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8499 USD
Canada MSRP Price: Starting at $9699 CDN
Europe/UK MSRP Price: £7447  GBP (On The Road inc 20% Vat)

Engine Type 689cc liquid-cooled DOHC inline twin cylinder; 8
valves
Bore x Stroke 80.0mm x 68.6mm
Compression Ratio 11.5:1
Fuel Delivery Fuel injection
Ignition TCI: Transistor Controlled Ignition
Transmission Constant mesh 6-speed; multiplate wet clutch
Final Drive Chain
Suspension / Front 41mm telescopic fork; 5.1-in travel
Suspension / Rear Single shock, adjustable preload; 5.1-in travel
Brakes / Front Dual hydraulic disc, 282mm; ABS
Brakes / Rear Hydraulic disc, 245mm; ABS
Tires / Front 120/70ZR17 Pirelli® Phantom Sportcomp
Tires / Rear 180/55ZR17 Pirelli® Phantom Sportcomp
L x W x H 81.7 in x 32.3 in x 44.5 in
Seat Height 32.9 in
Wheelbase 55.3 in
Rake (Caster Angle) 25.0°
Trail 3.5 in
Maximum Ground
Clearance
5.5 in
Fuel Capacity 3.7 gal
Fuel Economy** 58 mpg
Wet Weight*** 410 lb
Warranty 1 Year (Limited Factory Warranty)
Color Radical White/Rapid Red







2021 Yamaha XSR700 – Totalmotorcycle.com Canada Specifications/Technical Details

ENGINE
ENGINE Liquid-cooled, DOHC, 8-valves (4-valves/cylinder), inline twin cylinder
DISPLACEMENT 689cc
BORE AND STROKE 80 x 68.6 mm
COMPRESSION RATIO 11.5:1
MAXIMUM TORQUE 6.9 kg-m (50 ft-lbs.) @ 6,500 rpm
FUEL DELIVERY Mikuni 38 mm dual bore throttle body F.I.
ESTIMATED FUEL CONSUMPTION± 24.5 kpl / 69.2 mpg (Imp.)
LUBRICATION Wet sump
IGNITION / STARTING TCI / Electric
TRANSMISSION 6-speed
FINAL DRIVE “O”-ring chain

CHASSIS
SUSPENSION (FRONT) 41 mm fork / 130mm (5.1″) wheel travel
SUSPENSION (REAR) Adjustable link Monocross / 130 mm (5.1″) wheel travel
BRAKES (FRONT) Dual 282 mm discs / 4-piston calipers / ABS equipped
BRAKES (REAR) 245 mm disc / single piston caliper / ABS equipped
TIRES (FRONT) 120/70ZR17
TIRES (REAR) 180/55ZR17

CRITICAL DATA
LENGTH 2,075mm (81.7″)
WIDTH 820 mm (32.3″)
HEIGHT 1,130 mm (44.5″)
WHEELBASE 1,405 mm (55.3″)
RAKE / TRAIL 25° / 90 mm
GROUND CLEARANCE 140 mm (5.5″)
SEAT HEIGHT 835 mm (32.9″)
FUEL CAPACITY 14 litres (3.1 imp. gallons)
WET WEIGHT 186 kg (410 lb.)
COLOUR(S) Radical White







2021 Yamaha XSR700 – Totalmotorcycle.com European Specifications/Technical Details

Engine
Engine type 2-Cylinder;4-stroke;Liquid-cooled;DOHC;4-valves
Displacement 689 cm³
Bore x stroke 80.0 mm x 68.6 mm
Compression ratio 11.5 : 1
Maximum power 55.0kW (74.8PS) @ 9,000 rpm
Limited power version 35.0kW
Maximum Torque 68.0Nm (6.9kg-m) @ 6,500 rpm
Lubrication system Wet sump
Clutch Type Wet;Multiple Disc
Ignition system TCI
Starter system Electric
Transmission system Constant Mesh;6-speed
Final transmission Chain
Fuel consumption 4.3l/100km
CO2 emission 100g/km
Chassis
Frame Diamond
Caster Angle 24º50
Trail 90mm
Front suspension system Telescopic forks
Rear suspension system Swingarm;(Link type suspension)
Front travel 130 mm
Rear Travel 130 mm
Front brake Hydraulic dual disc, Ø282 mm
Rear brake Hydraulic single disc, Ø245 mm
Front tyre 120/70 ZR 17M/C(58V) (Tubeless)
Rear tyre 180/55 ZR 17M/C(73V) (Tubeless)
Remark EU4 compliant
Dimensions
Overall length 2,075 mm
Overall width 820 mm
Overall height 1,130 mm
Seat height 835 mm
Wheel base 1,405 mm
Minimum ground clearance 140 mm
Wet weight (including full oil and fuel tank) 186 kg ABS
Fuel tank capacity 14L
Oil tank capacity 2.7L



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
