2024 BMW CE04: FULL OF ENERGY, EFFICIENT AND FULLY ELECTRIC.
Introducing the 2024 BMW CE04…
THE SILENT REVOLUTION
You move around the world’s cities and metropolitan regions exactly at the point where each neighborhood represents the first step towards the next new idea. And you are also always on the move. We are familiar with this captivating dynamism as we have been applying it for over 10 years to develop solutions and concepts for urban electromobility, something that means far more now than just getting from A to B. It is from this long-term innovative leadership that the BMW CE 04 is launching into a new era of design, to seamlessly integrate into your everyday life thanks to its intelligent connectivity solutions. Quite simply #PluggedToLife.
Design brings us together
The two color concepts have been accurately adapted to the modern and unmistakable design of the BMW CE 04. They emphasize the pioneering design and set striking highlights.
Ahead of the time and yet timeless
The design of the BMW CE 04 centers around the slim energy storage unit in the underfloor assembly and the compact drivetrain. The design liberties and solutions here have led to new aesthetics, for instance the charging compartment that folds out towards the side or the floating seat. The low center of gravity represents a further benefit: fun handling, surprising dynamism and timeless riding pleasure. As a result, one innovation seamlessly leads to another, in terms of design. Ample, calm and minimalistic surfaces dominate the overall design. In this context, the front end is excitingly broken up while the rear end reveals technological components, a typical feature of motorcycles.
2024 BMW CE04 Totalmotorcycle.com Key Features
The BMW CE 04 sparks a passion with its revolutionary design, its technology as well as the resulting opportunities. Find out all about the technical data and extensive equipment here.
42 hp maximum output
2.6 seconds from 0 to 30 mph
80 mile range
65 minutes from 0% to 80% charging power at maximum charge current using optional quick charge capability @ 30 A / 230 V / 6.9 kW
EQUIPMENT
Standard equipment
Full LED headlight
10.25” TFT display including BMW Motorrad Connectivity
Keyless Ride
Three Ride Modes (Eco, Rain, Road)
BMW Motorrad ABS
ASC
Electronic reverse
Ventilated storage compartment with USB C
Side Loading storage compartment featuring lighting
Standard charging cable for domestic sockets
ECall intelligent emergency call
Optional equipment
Style Avantgarde
Various seat options
Quick charge capability
Heated grips
Center stand
Anti-theft alarm system
Tire pressure monitor (TPM)
High windscreen
Optional accessories
Luggage carrier
Urban Vario topcase
Urban Collection side bag, small
Holder for side bag
Decorative sticker sets
and much more
2024 BMW CE04 Totalmotorcycle.com Features and Benefits
“In future we will convert our coffee break around the corner to miles. ”
Florian Römhild (Project Lead of BMW CE 04 project)
- Stylish decorative sticker sets
- Large TFT color display
- Electric drivetrain
- Practical storage compartment
- Iconic light design
- Striking disc wheel
- Integrated side stand
- Comfortable Pro seat
Mobile and perfectly linked up
Don’t overlook or miss anything and enjoy everything. Thanks to BMW Motorrad Connectivity and the BMW Motorrad Connected app the BMW CE 04 makes new connections. The 10.25” TFT display featuring split screen option turns into the interface between the digital and analog world. Be it performance data, range, charging time, the favorite playlist, next destination or a phone call: Mobility and communication merge into one. Quite simply your everyday life. Your smartphone can just stay in the watertight and ventilated storage compartment and it is also charged in the process thanks to a USB C connection.
Revolution meets evolution
In terms of comfort, convenience and protection with the BMW CE 04 you can rely on tried-and-tested BMW Motorrad technology. ABS and ASC are standard features, DTC, and ABS Pro are optionally available. Additionally available seat variants featuring an integrated backrest pad and seat heating as well as the electric reverse provide convenience and comfort in big cities. And with Keyless Ride you launch into the seamless integration of the BMW CE 04 into your mobile life – in the true sense of the word: just hop on and ride off, you can leave the key in the pocket.
3 year warranty
Ride on and on and on.
Get up to 3-years or 36,000 miles warranty on all new motorcycles. You will generally be on the move quite a lot anyway, considering the first service interval of the BMW CE 04 is a whole 24 months or 6,214 miles
Your ideas count
More storage space, more convenience, better appearance? Regardless of what you are planning with your scooter: we offer you countless customization options with our comprehensive optional equipment and genuine BMW Motorrad accessories range. Store your shopping in the Vario topcase or the Urban Collection side bag. It’s chilly, but the sun’s out? Thanks to optional heated grips and seat heating you can really enjoy the ride. Plus optional sticker sets are further design highlights.
2024 BMW CE04 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $12,195 USD
Canada MSRP Price: $ See Dealer CDN
Europe/UK MSRP Price: £12,850 GBP (total selling price)
Motor Type
Permanent-magnet liquid-cooled synchronous motor
Rated capacity
20 hp
Maximum power
42 hp at 4,900 rpm
Max. torque
45.7 lb-ft at 1,500 rpm
Performance/consumption
Maximum speed
75 mph (electronically limited)
Acceleration
2.6 s from 0 – 50 km/h (31.1 mph)
Range according to WMTC
Approximately 80 mi
Recuperation
Automatic recuperation in overrun mode
Electrical system
Traction battery
Traction storage with high-voltage technology integrated into the vehicle underbody, 8.9/8.5kWh (gross/net) (8.9/6.2 kWh, 11 kW with optional power reduction)
Battery voltage (nominal)
148 V
Charging capacity
1.2 kW with integrated charger
Charging power
Charging cable with country-specific power plug
Standard charging time
Approx. 4h:20min for 0-100% and approx. 3h:30min for 0-80% @ 10A / 230V / 2.3 kW
1)
Charging time with optional quick charge capability
Approx. 1h:40min for 0-100% and approx. 1h:05min for 0-80% @ 30A / 230V / 6.9 kW
2)
Secondary battery
12 V / 5 Ah
Alternator
DC/DC converter with 500 watts that has been integrated into the charger
1) Depending on temperature and charging capacity
2) Depending on temperature and charging capacity
Power transmission
Transmission
1-speed transmission, integrated into motor housing
Secondary drive
Toothed belt and gearbox with fixed transmission
Chassis/brakes
Frame
Steel double loop frame
Front suspension/suspension elements
Single-bridge telescopic forks with 110 mm spring travel
Rear-wheel guide/suspension elements
Single-sided swing arm/directly hinged suspension strut with 92 mm spring travel
Wheelbase
1,675 mm (66″)
Castor
120 mm (4.7″)
Steering head angle
63.5°
Wheels
Cast aluminum wheels (disc wheel or disc wheel optics)
Rim, front
3.50 x 15”
Rim, rear
4.50 x 15”
Tire, front
120/70 R15
Tire, rear
160/60 R15
Brake, front
Double disc brake 265 mm (4 piston fixed caliper)
Brake, rear
Single disc brake 265 mm (1 piston floating caliper)
ABS
BMW Motorrad ABS
Dimensions/weights
Seat height at vehicle curb weight
780 mm (30 .7″)
(800 mm with optional comfort seat) ( 31.5″)
Inner leg curve at vehicle curb weight
1,810 mm (71.3″)
(1,856 mm with optional comfort seat) (73.1″)
Length
2,285 mm (90″)
Height (above windshield)
1,150 mm (45.3″)
Width (over mirrors)
855 mm (33.7″)
Unladen weight, road ready
231 kg (509 lbs)
Permitted total weight
410 kg (904 lbs)
Payload (with standard equipment)
179 kg (395 lbs)
2024 BMW CE04 – Totalmotorcycle.com Canada Specifications/Technical Details
Motor Type
Permanent-magnet liquid-cooled synchronous motor
Rated capacity
20 hp
Maximum power
42 hp at 4,900 rpm
Max. torque
45.7 lb-ft at 1,500 rpm
Performance/consumption
Maximum speed
75 mph (electronically limited)
Acceleration
2.6 s from 0 – 50 km/h (31.1 mph)
Range according to WMTC
Approximately 80 mi
Recuperation
Automatic recuperation in overrun mode
Electrical system
Traction battery
Traction storage with high-voltage technology integrated into the vehicle underbody, 8.9/8.5kWh (gross/net) (8.9/6.2 kWh, 11 kW with optional power reduction)
Battery voltage (nominal)
148 V
Charging capacity
1.2 kW with integrated charger
Charging power
Charging cable with country-specific power plug
Standard charging time
Approx. 4h:20min for 0-100% and approx. 3h:30min for 0-80% @ 10A / 230V / 2.3 kW
1)
Charging time with optional quick charge capability
Approx. 1h:40min for 0-100% and approx. 1h:05min for 0-80% @ 30A / 230V / 6.9 kW
2)
Secondary battery
12 V / 5 Ah
Alternator
DC/DC converter with 500 watts that has been integrated into the charger
1) Depending on temperature and charging capacity
2) Depending on temperature and charging capacity
Power transmission
Transmission
1-speed transmission, integrated into motor housing
Secondary drive
Toothed belt and gearbox with fixed transmission
Chassis/brakes
Frame
Steel double loop frame
Front suspension/suspension elements
Single-bridge telescopic forks with 110 mm spring travel
Rear-wheel guide/suspension elements
Single-sided swing arm/directly hinged suspension strut with 92 mm spring travel
Wheelbase
1,675 mm (66″)
Castor
120 mm (4.7″)
Steering head angle
63.5°
Wheels
Cast aluminum wheels (disc wheel or disc wheel optics)
Rim, front
3.50 x 15”
Rim, rear
4.50 x 15”
Tire, front
120/70 R15
Tire, rear
160/60 R15
Brake, front
Double disc brake 265 mm (4 piston fixed caliper)
Brake, rear
Single disc brake 265 mm (1 piston floating caliper)
ABS
BMW Motorrad ABS
Dimensions/weights
Seat height at vehicle curb weight
780 mm (30 .7″)
(800 mm with optional comfort seat) ( 31.5″)
Inner leg curve at vehicle curb weight
1,810 mm (71.3″)
(1,856 mm with optional comfort seat) (73.1″)
Length
2,285 mm (90″)
Height (above windshield)
1,150 mm (45.3″)
Width (over mirrors)
855 mm (33.7″)
Unladen weight, road ready
231 kg (509 lbs)
Permitted total weight
410 kg (904 lbs)
Payload (with standard equipment)
179 kg (395 lbs)
2024 BMW CE04 – Totalmotorcycle.com European Specifications/Technical Details
Engine
Type
Permanent-magnet liquid-cooled synchronous motor
Rated capacity
15 kW (20 hp)
11 KW (15 hp) with optional derating to 11 kW
Maximum power
31 kW (42 hp) at 4,900 rpm
23 kW (31 hp) at 4,000 rpm with optional derating to 11 kW
Max. torque
62 Nm at 1,500 rpm
Performance/consumption
Maximum speed
120 km/h (electronically limited)
Acceleration
2.6 s from 0 – 50 km/h
2.7 s from 0 – 50 km/h with optional derating to 11 kW
Range according to WMTC
130 km
100 km with optional derating to 11 kW
Consumption of electrical energy according to WMTC
7.7 kWh/100 km
Recuperation
Automatic recuperation in overrun mode
Electrical system
Traction battery
Traction storage with high-voltage technology integrated in the vehicle underbody, central air cooling, permanently installed battery module, 40 lithium-ion battery cells, 8.5kWh (6.3 kWh with optional derating to 11 kW)
Battery voltage (nominal)
148 V
Charging capacity
2.3 kW with integrated charger
6.9 kW with optional quick charger
Charging power
Charging socket on vehicle type 2 (not US and CN); Charging cable with country-specific power plug
Standard charging time
Approx. 4h:20min for 0-100% and approx. 3h:30min for 0-80%
Approx. 3h:20min for 0-100% and approx. 2h:25min for 0-80% with optional derating to 11 kW
1)
Charging time with optional quick charger
Approx. 1h:40min for 0-100% and approx. 1h:05min for 0-80%
Approx. 1h:10min for 0-100% and approx. 50min for 0-80% with optional derating to 11 kW
2)
Secondary battery
12 V / 5 Ah, maintenance-free
Alternator
DC/DC converter with 500 watts that has been integrated into the charger
ECALL
Intelligent Emergency Call
1) Depending on temperature and charging capacity
2) Depending on temperature and charging capacity
Power transmission
Transmission
1-speed transmission, integrated into motor housing
Secondary drive
Drive unit swing arm, toothed belt and gearbox with fixed transmission
Chassis/brakes
Frame
Steel double loop frame
Front suspension/suspension elements
Single-bridge telescopic forks with 110 mm spring travel
Rear-wheel guide/suspension elements
Single-sided swinging arm/central spring strut with 92 mm suspension travel
Wheelbase
1,675 mm
Castor
120 mm
Steering head angle
63.5°
Wheels
Cast aluminium wheels (disc wheel or disc wheel optics)
Rim, front
3.50 x 15”
Rim, rear
4.50 x 15”
Tyre, front
120/70 R15
Tyre, rear
160/60 R15
Brake, front
Double disc brake 265 mm (4 piston fixed caliper)
Brake, rear
Single disc brake 265 mm (1 piston floating caliper)
ABS
BMW Motorrad ABS
Dimensions/weights
Seat height at vehicle kerb weight
780 mm
(800 mm with optional comfort seat)
Inner leg curve at vehicle kerb weight
1,810 mm
(1,856 mm with optional comfort seat)
Length
2,285 mm
Height (above windshield)
1,150 mm
Width (over mirrors)
855 mm
Unladen weight, road ready
231 kg
Permitted total weight
410 kg
Payload (with standard equipment)
179 kg
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
