2024 Harley-Davidson Breakout 117 Guide

Review – Key Features – Features & Benefits – Specifications

2024 Harley-Davidson Breakout 117: WAKE UP YOUR SENSES WHILE STEALING GLANCES.

Introducing the 2024 Harley-Davidson Breakout 117…

Dripping with chrome, the Harley-Davidson Breakout 117 is a raked-out cruiser that packs Milwaukee-Eight™ 117 V-Twin muscle.

2024 CRUISER MOTORCYCLES

Authentic heritage meets modern technology for power, style, and the unadulterated riding experience – around town or along country roads.

2024 Harley-Davidson Breakout 117 Totalmotorcycle.com Key Features

• Stretched riding position
• Forward foot controls
• Passenger seat
• Low
• Rider safety enhancements available

AMERICAN DREAMIN’ – The dawn of a new era has arrived for Harley-Davidson.

HARLEY-DAVIDSON REVEALS 2024 MODEL MOTORCYCLES AVAILABLE NOW AT WORLDWIDE AUTHORIZED DEALERSHIPS

Additional New Models to Premier January 24

MILWAUKEE (January 2, 2024) – Harley-Davidson today revealed a portion of its 2024 motorcycle line and announced these bikes are now available at authorized Harley-Davidson dealerships globally, with additional new motorcycle models to be unveiled soon. The limited-production 2024 models from Harley-Davidson Custom Vehicle Operations (CVO) and more new Harley-Davidson motorcycle models will be revealed at 10 a.m. CST on January 24.

The 2024 returning models represent the following categories in the Harley-Davidson motorcycle portfolio, a collection of the sport’s most desirable motorcycles.

Grand American Touring: For riders responding to the call of the open road. Grand American Touring models take riders beyond the horizon with the comfort and community that makes the journey spectacular, from the company that started the cross-country experience.

Cruiser: Iconic and diverse styling – from nostalgic to very modern – is paired with the ability to customize and make the ultimate personal statement.

Sport: Industry-leading performance and advanced technology offer an exhilarating riding experience combined with styling inspired by Harley-Davidson heritage.

Trike: Harley-Davidson Trike models offer an appealing option for those who appreciate the confidence of a three-wheel platform.

Adventure Touring: For riders who want the ability to go anywhere, those who see touring as detouring. The award-winning Pan America motorcycle is a versatile and inspirational machine that makes any surface a road.

2024 Harley-Davidson Breakout 117 Totalmotorcycle.com Features and Benefits

MILWAUKEE-EIGHT 117 ENGINE
This air- and oil-cooled engine is the pinnacle of torque and displacement in factory-installed, regular-production Harley-Davidson powertrain.

HEAVY BREATHER
High-performance Heavy Breather intake with forward-facing exposed filter element flows more air into the engine.

CHROME APPEAL
Polished chrome adorns everything from the fender supports, side covers, and muffler shields, to the turn signals, mirrors, and Heavy Breather intake.

WHEELS
The 21-inch front and 18-inch rear cast aluminum wheels have 26 spokes with black finishes and machined details.

TWO-INTO-TWO EXHAUST
High-performance, offset shotgun exhaust improves mid-range torque and produces a strong, stirring note.

CHASSIS
Softail chassis reduces weight and improves rigidity while maintaining the classic look of a hard tail.

2024 Harley-Davidson Breakout 117 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: Starting at $22,499 USD
Canada MSRP Price: Starting at $27,499 CDN
Europe/UK MSRP Price: Starting at £24,795 GBP (On The Road inc 20% Vat)

DIMENSIONS

LENGTH

93.3 in.

SEAT HEIGHT, LADEN ⁷

25.6 in.

GROUND CLEARANCE

4.5 in.

RAKE

34

TRAIL

5.7 in.

WHEELBASE

66.7 in.

TIRE, TYPE

Michelin Scorcher 11, front and rear

TIRES, FRONT SPECIFICATION

130/60B21,63H,BW

TIRES, REAR SPECIFICATION

240/40R18,79V,BW

FUEL CAPACITY

5 gal.

OIL CAPACITY (W/FILTER)

5 qt.

WEIGHT, AS SHIPPED

653 lb.

WEIGHT, IN RUNNING ORDER

683 lb.

ENGINE

ENGINE ¹

Milwaukee-Eight 117

BORE

4.075 in.

STROKE

4.5 in.

DISPLACEMENT

117 cu in

COMPRESSION RATIO

10.2:1

FUEL SYSTEM ³

Electronic Sequential Port Fuel Injection (ESPFI)

EXHAUST

2-into-2 staggered; catalyst in muffler

PERFORMANCE

ENGINE TORQUE TESTING METHOD

J1349

ENGINE TORQUE ²

123 ft-lb

ENGINE TORQUE (RPM)

3500

HORSEPOWER

101 HP / 75 kW @ 4750 rpm

LEAN ANGLE, RIGHT (DEG.)

26.8

LEAN ANGLE, LEFT (DEG.)

26.8

FUEL ECONOMY TESTING METHOD

Estimated City/Hwy

FUEL ECONOMY ⁵

47 mpg

DRIVE TRAIN

PRIMARY DRIVE

Chain, 34/46 ratio

GEAR RATIOS (OVERALL) 1ST

9.311

GEAR RATIOS (OVERALL) 2ND

6.454

GEAR RATIOS (OVERALL) 3RD

4.793

GEAR RATIOS (OVERALL) 4TH

3.882

GEAR RATIOS (OVERALL) 5TH

3.307

GEAR RATIOS (OVERALL) 6TH

2.79

CHASSIS

FRONT FORK

Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring

REAR SHOCKS

Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment

WHEELS, FRONT TYPE ⁹

Gloss black, 26-spoke cast aluminum

WHEELS, REAR TYPE ⁹

Gloss black, 26-spoke cast aluminum

BRAKES, CALIPER TYPE

4-piston fixed front and 2-piston floating rear

BRAKES, ROTOR TYPE

Front and rear black, Split 7-spoke floating rotors

ELECTRIC

LIGHTS (AS PER COUNTRY REGULATION), HEADLAMP, TAIL/STOP/FRONT SIGNAL LIGHTS ⁸

All LED, low beam, high beam and signature position lamp; Bullet-style, dual-element incandescent stop/tail/turn signals; Incandescent bullet turn signals

GAUGES

2.14-inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication

RIDER SAFETY ENHANCEMENTS

ANTI-LOCK BRAKE SYSTEM (ABS)

Included

TRACTION CONTROL SYSTEM (TCS)

Included

1. Recommended 91 octane (95 RON) or higher fuel (R+M)/2.
2. Values shown are nominal. Performance may vary by country and region.
3. Standard and optional fuel systems may vary by country.
4. See motorcycle owner’s manual for complete details.
5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
6. Prices listed are the Manufacturer’s Suggested Retail Prices for base models. Options such as color are available at additional cost. Prices exclude tax, title, licensing, registration fees, destination charges, surcharges (attributable to raw materials costs in the product supply chain), added accessories, and additional dealer charges, if any, and are subject to change. Harley-Davidson reimburses dealers for performing manufacturer-specified pre-delivery inspection and setup tasks. Dealer prices may vary.
7. Measurement reflects 180 lb. (81.7 kg) operator weight.
8. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
9. Standard and optional wheels may vary by country and region.

2024 Harley-Davidson Breakout 117 – Totalmotorcycle.com Canada Specifications/Technical Details

DIMENSIONS

LENGTH

2,370 mm

SEAT HEIGHT, UNLADEN

665 mm

GROUND CLEARANCE

115 mm

RAKE

34

TRAIL

145 mm

WHEELBASE

1,695 mm

TIRE, TYPE

Michelin^™ Scorcher 11, front and rear

TIRES, FRONT SPECIFICATION

130/60B21,63H,BW

TIRES, REAR SPECIFICATION

240/40R18,79V,BW

FUEL CAPACITY

18.9 l

OIL CAPACITY (W/FILTER)

4.7 l

WEIGHT, AS SHIPPED

296 kg

WEIGHT, IN RUNNING ORDER

310 kg

ENGINE

ENGINE ²

Milwaukee-Eight^™ 117

BORE

103.5 mm

STROKE

114.3 mm

DISPLACEMENT

1,923 cc

COMPRESSION RATIO

10.2:1

FUEL SYSTEM ³

Electronic Sequential Port Fuel Injection (ESPFI)

EXHAUST

2-into-2 staggered; catalyst in muffler

PERFORMANCE

ENGINE TORQUE TESTING METHOD

J1349

ENGINE TORQUE ³

167 Nm

ENGINE TORQUE (RPM)

3,500

HORSEPOWER

101 HP / 75 kW @ 4750 rpm

LEAN ANGLE, RIGHT (DEG.)

26.8

LEAN ANGLE, LEFT (DEG.)

26.8

FUEL ECONOMY TESTING METHOD

Estimated City/Hwy

FUEL ECONOMY ⁷

5 l/100 km

DRIVE TRAIN

PRIMARY DRIVE

Chain, 34/46 ratio

GEAR RATIOS (OVERALL) 1ST

9.311

GEAR RATIOS (OVERALL) 2ND

6.454

GEAR RATIOS (OVERALL) 3RD

4.793

GEAR RATIOS (OVERALL) 4TH

3.882

GEAR RATIOS (OVERALL) 5TH

3.307

GEAR RATIOS (OVERALL) 6TH

2.79

CHASSIS

FRONT FORK

Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring

REAR SHOCKS

Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment

WHEELS, FRONT TYPE ⁴

Gloss black, 26-spoke cast aluminum

WHEELS, REAR TYPE ⁴

Gloss black, 26-spoke cast aluminum

BRAKES, CALIPER TYPE

4-piston fixed front and 2-piston floating rear

BRAKES, ROTOR TYPE

Front and rear black, Split 7-spoke floating rotors

ELECTRIC

LIGHTS (AS PER COUNTRY REGULATION), HEADLAMP, TAIL/STOP/FRONT SIGNAL LIGHTS

All LED, low beam, high beam and signature position lamp; Centre mounted LED stop/tail lamp with incandescent bullet stop/tail/turn lights (CAN only)

GAUGES

2.14-inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication

RIDER SAFETY ENHANCEMENTS

ANTI-LOCK BRAKE SYSTEM (ABS)

Included

TRACTION CONTROL SYSTEM (TCS)

Included

1. Prices listed are the Manufacturer’s Suggested Retail Prices for base models. Options such as colour are available at additional cost. Prices exclude tax, title, licensing, registration fees, destination charges, added accessories, and additional dealer charges, if any, and are subject to change.
2. Recommended 91 octane (95 RON) or higher fuel (R+M)/2.
3. Values shown are nominal. Performance may vary by country and region.
4. Standard and optional wheels may vary by country and region.
5. Riding range estimates provided following the SAE J2982 and are based on expected performance of a fully-charged battery when operated under specified conditions. Actual range will vary depending on riding habits, ambient weather and equipment conditions.
6. As measured using the MIC City and MIC Combined (115 km/h) tests.
7. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.

2024 Harley-Davidson Breakout 117 – Totalmotorcycle.com Europe Specifications/Technical Details

DIMENSIONS

LENGTH

2,370 mm

SEAT HEIGHT, UNLADEN

665 mm

GROUND CLEARANCE

115 mm

RAKE

34

TRAIL

145 mm

WHEELBASE

1,695 mm

TIRE, TYPE

Michelin^™ Scorcher 11, front and rear

TIRES, FRONT SPECIFICATION

130/60B21,63H,BW

TIRES, REAR SPECIFICATION

240/40R18,79V,BW

FUEL CAPACITY

18.9 l

OIL CAPACITY (W/FILTER)

4.7 l

WEIGHT, AS SHIPPED

296 kg

WEIGHT, IN RUNNING ORDER

310 kg

ENGINE

ENGINE ²

Milwaukee-Eight^™ 117

BORE

103.5 mm

STROKE

114.3 mm

DISPLACEMENT

1,923 cc

COMPRESSION RATIO

10.2:1

FUEL SYSTEM

Electronic Sequential Port Fuel Injection (ESPFI)

EXHAUST

2-into-2 staggered; catalyst in muffler

PERFORMANCE

ENGINE TORQUE TESTING METHOD

EC 134/2014

ENGINE TORQUE ³

168 Nm

ENGINE TORQUE (RPM)

3500

HORSEPOWER

102 HP / 76 kW @ 5020 rpm

LEAN ANGLE, RIGHT (DEG.)

26.8

LEAN ANGLE, LEFT (DEG.)

26.8

FUEL ECONOMY TESTING METHOD

EU 134/2014

FUEL ECONOMY

5.6 l/100 km

CO₂ EMISSIONS TESTING METHOD

EU 134/2014

CO₂ EMISSIONS

135 g/km CO²

DRIVE TRAIN

PRIMARY DRIVE

Chain, 34/46 ratio

GEAR RATIOS (OVERALL) 1ST

9.311

GEAR RATIOS (OVERALL) 2ND

6.454

GEAR RATIOS (OVERALL) 3RD

4.793

GEAR RATIOS (OVERALL) 4TH

3.882

GEAR RATIOS (OVERALL) 5TH

3.307

GEAR RATIOS (OVERALL) 6TH

2.79

CHASSIS

FRONT FORK

Dual-bending valve 49 mm telescopic with aluminum fork triple clamps; dual rate spring

REAR SHOCKS

Hidden, free piston, coil-over monoshock; 43mm stroke; toolless hydraulic preload adjustment

WHEELS, FRONT TYPE ⁴

Gloss black, 26-spoke cast aluminum

WHEELS, REAR TYPE ⁴

Gloss black, 26-spoke cast aluminum

BRAKES, CALIPER TYPE

4-piston fixed front and 2-piston floating rear

BRAKES, ROTOR TYPE

Front and rear black, Split 7-spoke floating rotors

ELECTRIC

LIGHTS (AS PER COUNTRY REGULATION), HEADLAMP, TAIL/STOP/FRONT SIGNAL LIGHTS

All LED, low beam, high beam and signature position lamp; Integrated, multi-function LED stop/tail/turn signals; Incandescent bullet turn signals; Integrated, multi-function LED stop/tail/turn signals

GAUGES

2.14-inch viewable area LCD display with speedometer, gear, odometer, fuel level, clock, trip, range and tachometer indication

RIDER SAFETY ENHANCEMENTS

ANTI-LOCK BRAKE SYSTEM (ABS)

Included

TRACTION CONTROL SYSTEM (TCS)

Included

1. All prices shown are suggested retail prices only. Please speak with the dealership team for further details and to obtain a final on the road price.
2. Recommended 91 octane (95 RON) or higher fuel (R+M)/2.
3. Values shown are nominal. Performance may vary by country and region.
4. Standard and optional wheels may vary by country and region.
5. Riding range estimates provided following the SAE J2982 and are based on expected performance of a fully-charged battery when operated under specified conditions. Actual range will vary depending on riding habits, ambient weather and equipment conditions.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
