2002 Yamaha TT-R125

Back to 2002 Yamaha Motorcycle Index Page

Click photo to enlarge.
It makes a great desktop image.

2002 Yamaha TT-R125
2002 Yamaha TT-R125


– 2002 Yamaha TT-R125 Review

2002 Yamaha TT-R125

17″ Front and 14″ Rear tires are ideal for shorter riders…

A motorcycle for off-road riders (and little brother to the 125L) the TT-R125 has slightly smaller wheels and tires, thus able to fit shorter riders.

A powerful, 124cc, 4-stroke powerplant provides a broad powerband for friendly off-road performance in a wide range of trail conditions.

The smooth shifting, YZ-type 5-speed transmission with heavy-duty manual clutch is geared for maximum versatility and usable power delivery.


2002 Yamaha TT-R125 Features and Benefits




2002 Yamaha TT-R125 – Specifications/Technical Details
USA MSRP Price: $2,399 USD
Canadian MSRP Price: See dealer for pricing in CDN

Length 72″

Height 41.5″

Width 30.9″

Weight 170 lbs.

Ground Clearance 10.4″

Wheelbase 49.2″

Seat Height 30.5″

Engine 124cc, Air-cooled, SOHC, 4-stroke single

Displacement 124cc

Bore x Stroke 54 X 54mm

Compression Ratio 10:01

Carburetion 20mm Mikuni

Fuel Capacity 1.7 gal.

Ignition CDI

Transmission 5-speed w/manual clutch

Final Drive Chain

Brakes Front: Drum
Rear: Drum

Tires Front: 70/100-17
Rear: 90/100-14

Suspension Front: Telescopic Fork, 7.1″ of Travel
Rear: Single Shock, 6.6″ of Travel

Team Yamaha Blue/White

Specifications are subject to change without notice, in accordance with national regulation and legislations. Suggested Starting Price shown does not include tax, title, or destination charge. Dealer prices may vary.
