2014 BMW S1000R Review

2014 BMW S1000R on Totalmotorcycle.com

THE ALL-NEW S 1000 R. CONQUER THE STREETS…

The BMW S 1000 R – new high-performance roadster based on the S 1000 RR.

Superbike riding dynamics and powerful, emotive roadster styling – these are the hallmarks of the new BMW S 1000 R. The new naked bike from BMW Motorrad is directly derived from the S 1000 RR superbike and uses the same innovative technology. The close family resemblance to the “RR” is instantly obvious. The pared down appearance of the new S 1000 R exudes an aggressive, dynamic energy. Based on a well-thought-out overall concept, with 160 hp maximum power and a weight of 207 kg, as well as Race ABS, ASC and a choice of two riding modes as standard, the BMW S 1000 R sets new standards in the sports roadster segment.

In-line four-cylinder engine with optimised low to mid-range performance.
When modifying the S 1000 RR’s 999 cc four-cylinder in-line engine for use in the S 1000 R, the engineers were looking in particular to provide punchy response all the way through the rpm range. To provide the ideal set-up both for everyday use and for sporty riding on the open road, they significantly increased the low and mid-range power and torque. At the same time, maximum rpm has been reduced by approximately 2,000 rpm. Maximum power of 118 kW (160 hp) is reached at 11,000 rpm and peak torque of 112 Nm (approx. 83 lb-ft) at 9,250 rpm. Up to 7500 rpm, this engine version develops 10 Newton metres (approx. 7 lb-ft) more torque than the S 1000 RR. This provides punchy low-end response that is ideal on twisty single-carriageway roads. Among other things, this was achieved by using redesigned cylinder head ducts, modified cam profiles and appropriately modified engine management. The new BMS-X engine management system also supports an E-Gas “throttle-by-wire” system.

ASC (Automatic Stability Control), Race ABS and a choice of two riding modes as standard. Riding mode Pro with two additional modes and DTC optionally available.
For optimal adaptation to different conditions and rider requirements, the S 1000 R comes with two riding modes and ASC (Automatic Stability Control) as standard. The “Rain” and “Road” modes cater to different road surface conditions using different power and torque curves, and applying different levels of Race ABS and ASC intervention. This provides an important safety bonus, particularly under changeable road conditions.

Dynamic Traction Control (DTC), incorporating a further two riding modes – “Dynamic” and “Dynamic Pro” – is available as an ex-works option. This option allows riders to make the most of the S 1000 R’s sporty performance potential both on the road and on the race track. Dynamic Traction Control, which includes a banking angle sensor, offers safe and dynamic acceleration which is currently state-of-the-art for a production motorcycle.

Innovative chassis and suspension technology with large damping reserves and high-performance brakes. Dynamic Damping Control (DDC) optionally available.
However ambitious the riding style, the chassis and suspension of the S 1000 R is a match for the dynamic power delivery of the four-in-line engine. Based on that of the S 1000 RR, it uses the proven aluminium alloy perimeter frame, in which the engine forms part of the load-bearing structure. As on the RR, an adjustable upside-down fork and a dual swingarm with adjustable central spring strut guide the wheels front and rear. Roadster-specific suspension requirements are met by a slight change in geometry. As on the RR, vigorous, stable and above all safe braking is provided by a braking system that comprises a twin-disc brake with two radial 4-piston fixed callipers at the front and a single-disc brake at the rear, with partially integral Race ABS. Dynamic Damping Control (DDC), available as an ex-works optional extra, offers the benefits of electronic damping control. For further enhanced performance, in combination with enhanced active safety, this system dynamically adapts the damping to the current riding situation with split-second speed.

Dynamic styling.
The new S 1000 R’s sports roadster personality is also mirrored in the styling. With its “tail up – nose down” stance, the S 1000 R’s appearance immediately suggests aggressive performance and dynamism. Like the RR, the S 1000 R, too, is distinctive and instantly recognisable. It has a face that stands out in a crowd.

Multifunctional instrument cluster.
Last but not least, race-inspired features also extend to the cockpit of the S 1000 R. With an LC display with analogue rev counter, the instrumentation offers an unrivalled amount of information in this segment, from the gear display and riding mode display to a lap timer. For optimal gear changes, an individually programmable quick-shifter is fitted.







2014 BMW S1000R Totalmotorcycle.com Key Features

•Well-thought-out overall concept sets new standards in the sports roadster segment.
•Pared down styling with an aggressively dynamic look; clear family similarities with S 1000 RR.
•Liquid-cooled 999 cc four-cylinder in-line engine. Max. power 118 kW (160 hp) at 11,000 rpm, max. torque 112 Nm (approx. 83 ft-lb) at 9,250 rpm.
•207 kg kerb weight with full fuel tank.
•Standard-fitted Race ABS for superior braking performance and safety.
•Standard-fitted ASC (Automatic Stability Control) for safe acceleration on surfaces with variable grip.
•Standard-fitted steering damper.
•Choice of two standard, rider-selectable riding modes, “Rain” and “Road”.
•Optional Dynamic Traction Control DTC including Riding mode Pro maximises both riding enjoyment and active safety in all road situations.
•Optional Riding mode Pro comprising two additional riding modes – “Dynamic” and “Dynamic Pro” – for road and track use.
•Full synchronisation of Race ABS, ASC/ DTC, DDC and engine management.
•Innovative exhaust system with small rear silencer, front silencer, electronically controlled exhaust flap and two closed-loop, three-way catalytic converters.
•E-Gas system for optimal throttle control and maximum reliability.
•Suspension components with large damping reserves.
•DDC (Dynamic Damping Control) – electronically controlled damping system for optimal, dynamic adaptation of damping to the current riding situation and to the load the bike is carrying.
•Aluminium fuel tank brings further weight savings and is unique in this segment.
•Infectious handling with highest standards of stability at high speeds and when braking.
•Multifunctional instrument cluster with extensive range of features.
•Extensive equipment and tailored accessories conforming to the customary high BMW Motorrad standards.



2014 BMW S1000R Totalmotorcycle.com Features and Benefits

Conquer the roads – on the BMW S 1000 R.

A roadster, reduced to the essentials: maximum performance. 160 bhp, 83 lb/ft torque and a power-to-weight ratio of 2.85 pounds per bhp – and the competition disappears in the rear mirror.

Linear power: the engine.

The high-performance 4-cylinder in-line engine derives from the RR but has now been further optimized. The result: extremely linear torque delivery for constant forward drive across the entire engine rev range. The engine of the S 1000 R has an output of 160 bhp/118 kW at 11,000 rpm, while a maximum of 83 lb/ft torque at 9,250 rpm puts a smile on the rider’s face at every twist of the throttle.

Ready for attack: the design.

The lines of the S 1000 R are striking at first sight, too: aggressive tail-up/nose-down design, distinctive split face and the characteristic gills. The “R” shows much less of its sharp-edged, muscular skin. Some people call it naked – we just call it focused on the essentials.

Versatile: the riding modes.

The S 1000 R can be reigned in and unleashed at the press of a button as standard. The “Rain” mode provides a gentle throttle response, with ABS and ASC adapted to wet road surfaces. Meanwhile “Road” optimizes throttle response, ABS and ASC for dry asphalt. The Pro modes are available as an optional extra for those chasing the threshold range: “Dynamic” and “Dynamic Pro” get the “R” into shape for the limits.

Full control: Race ABS and ASC as standard.

Power is nothing without control. The S 1000 R is fitted with Race ABS and ASC (automatic stability control) as standard. This duo ensures excellent acceleration and deceleration figures at threshold level. They can be activated and deactivated during travel, making for uninterrupted riding fun.

No compromises: the individualization options.

The “Standard” package adds Ride Modes Pro (Rain, Road + Dynamic, Dynamic Pro), gear shift assist, DTC (dynamic traction control) and cruise control. The “Premium” package includes all equipment in the “Standard” package plus DDC (dynamic damping control semi-active suspension), heated grips and engine spoiler. There will also be an extensive range of HP parts for the S 1000 R aimed at ambitious riders.

Engine

The S 1000 R is powered by the legendary high-performance 4-cylinder in-line engine from the S 1000 RR. But it has been optimised for use in the roadster.

• 10 Nm more than the S 1000 RR

• Extremely linear power delivery across the entire engine speed range

• Maximum of 112 Nm torque at 9,250 rpm

• Peak output of 160 bhp/118 kW at 11,000 rpm
Suspension: Race ABS and ASC.

The S 1000 R is fitted with Race ABS and ASC (automatic stability control) as standard. This sets the benchmark in terms of dynamic performance and safety in the bike’s segment.

• Part integral Race ABS as standard for optimum deceleration.

• Clear feedback in the hand lever to detect threshold range

• Can be deactivated while riding

• Ultra-light system, virtually maintenance-free

• ASC ensures optimum acceleration on all road surfaces

• Both systems are perfectly interconnected and their regulation response is very simple to adapt via the standard riding modes Road/Rain
Suspension: DDC and DTC

The S 1000 R features a highly active electronic suspension which is able to adapt to riding conditions within milliseconds, thereby enabling agility and dynamic performance.

• DTC is an assistance system with banking sensor which supports maximum possible throttle response and prevents rear wheel spin when there is reduced friction on the road surface. Maximum traction and agility as well as an additional safety bonus

• DDC: Dynamic Damping Control directly from the BMW HP4. Here the suspension adapts electronically within milliseconds to the surface and situation on the road.

• Characteristics and damping properties change from “pleasant” to “tight” depending on the riding modes selected, riding situation and road surface. The suspension supports the rider without the latter having to make any mechanical adjustments to the damper compression and rebound stage
Suspension: Riding modes

The riding modes available for the S 1000 R perfectly interconnect the individual systems of throttle response, ABS control response, traction control (ASC or DTC) and suspension (DDC or load state) for a dynamic but safe ride on varying road surfaces and in different weather conditions.

As standard:

• Rain mode for a gentle throttle response and sensitive ASC/ABS control response on wet road surfaces

• Road mode for optimum throttle response and optimum ASC/ABS control response for excellent acceleration and deceleration on dry roads

• The riding modes are simple to select by pressing a button and confirmed by closing the throttle and are shown on the display screen

Pro riding modes available with optional DTC or Sports package:

• Dynamic mode for optimum throttle response on dry roads with reduced lift detection function in the front and rear wheel when braking. DTC (Dynamic Traction Control) enables more dynamic acceleration in banking position

• Dynamic Pro mode is designed for very ambitious sports riders and can only be activated by means of a coded plug. DTC enables optimum acceleration with sports tyres on a dry surface. The ABS allows brake drifts using the footbrake but without having to dispense with ABS functions at the front wheel. The front and rear wheel lift detection function is deactivated.
Suspension: Steering damper

The suspension of the S 1000 R is fitted as standard with a mechanical steering damper which ensures optimum stability even on varying surfaces and at high speeds.
Options

The extensive range of options gives the rider the opportunity to optimise the motorbike according to personal preferences. Two packages are available for this purpose:

• “Sport” package For dynamic, sporty-oriented rider; includes the Pro riding modes (Dynamic, Dynamic Pro), DTC, shift assistant for even faster acceleration and cruise control

• Also: Extensive range of HP parts for the S 1000 R











2014 BMW S1000R – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $13,150 USD


Engine

Type
Water/oil-cooled 4-cylinder 4-stroke in-line engine, four valves per cylinder, two overhead camshafts

Bore x stroke
80 mm x 49.7 mm

Capacity
999 ccm

Rated output
160 hp (118 kW) at 11,000 rpm

Max. torque
83 lb/ft (112 Nm) at 9,250 rpm

Compression ratio
12.0 : 1

Mixture control / engine management
Electronic injection

Emission control
2 closed-loop 3-way catalytic converters, EU-3 norm with interference pipe and acoustic valves


Performance / fuel consumption

Maximum speed
over 125 mph

Fuel consumption per 100 km at constant 90 km/h
44 mpg at a constant 56 mph (5.4 l)

Fuel consumption per 100 km at constant 120 km/h

Fuel type
Premium Unleaded


Electrical system

Alternator
350 W

Battery
12 V / 9 Ah, maintenance-free


Power transmission

Clutch
Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled

Gearbox
Constant-mesh 6-speed gearbox, straight-toothed

Drive
Chain 17/45


Chassis / brakes

Frame
Aluminum composite bridge frame, partially self-supporting engine

Front wheel location / suspension
Upside-down telescopic fork Ø 46 mm, compression and rebound stage adjustable

Rear wheel location / suspension
Aluminum 2-sided swing arm, rebound damping adjustable

Suspension travel front / rear
4.7 in / 4.7 in (120 mm / 120 mm)

Wheelbase
56.7 in (1,439 mm)

Castor
3.9 in (98.5 mm)

Steering head angle
65.4°

Wheels
Cast aluminum wheels

Rim, front
3.50 x 17″

Rim, rear
6.00 x 17″

Tyres, front
120/70 ZR 17

Tyres, rear
190/55 ZR 17

Brake, front
Dual floating disc brakes, diameter 320 mm, thickness 5 mm, radial 4-piston fixed calipers

Brake, rear
Single disc brake, single piston floating caliper, diameter 220 mm, 5 mm thick

ABS
STANDARD Race ABS (part integral, can be switched off)


Dimensions / weights

Length
81.0 in (2,057 mm)

Width (incl. mirrors)
33.3 in (845 mm)

Height (excl. mirrors)
48.3 in (1,228 mm)

Seat height, unladen weight
32.0 in (814 mm)

Inner leg curve, unladen weight
71.1 (1,805 mm)

Unladen weight, road ready, fully fuelled 1)
456 lbs (207 kg)

Dry weight

Permitted total weight
897 lbs (407 kg)

Payload (with standard equipment)
441 lbs (200 kg)

Usable tank volume
4.6 gallons

Reserve
Approx. 1 gal








2014 BMW S1000R – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $14,700 CDN


Engine

Type
Water/oil-cooled 4-cylinder 4-stroke in-line engine, four valves per cylinder, two overhead camshafts

Bore x stroke
80 mm x 49.7 mm

Capacity
999 ccm

Rated output
118 kW (160 hp) at 11,000 rpm

Max. torque
112 Nm at 9,250 rpm

Compression ratio
12.0 : 1

Mixture control / engine management
Electronic injection

Emission control
2 closed-loop 3-way catalytic converters, EU-3 norm with interference pipe and acoustic valves


Performance / fuel consumption

Maximum speed
over 200 km/h

Fuel consumption per 100 km at constant 90 km/h
5.4 l

Fuel consumption per 100 km at constant 120 km/h
5.6 l

Fuel type
Super (premium) unleaded, octane number 95 – 98 (RON) (knock control; rated output at 98 RON)


Electrical system

Alternator
350 W

Battery
12 V / 9 Ah, maintenance-free


Power transmission

Clutch
Multiplate clutch in oil bath, anti-hopping clutch, mechanically controlled

Gearbox
Constant-mesh 6-speed gearbox, straight-toothed

Drive
Chain 17/45


Chassis / brakes

Frame
Aluminium composite bridge frame, partially self-supporting engine

Front wheel location / suspension
Upside-down telescopic fork Ø 46 mm, compression and rebound stage adjustable

Rear wheel location / suspension
Aluminium 2-sided swing arm, rebound damping adjustable

Suspension travel front / rear
120 mm / 120 mm

Wheelbase
1,439 mm

Castor
98.5 mm

Steering head angle
65.4°

Wheels
Cast aluminium wheels

Rim, front
3.50 x 17″

Rim, rear
6.00 x 17″

Tyres, front
120/70 ZR 17

Tyres, rear
190/55 ZR 17

Brake, front
Twin disc brake, floating brake calipers, radial 4-piston fixed caliper, diameter 320 mm, 5 mm thick

Brake, rear
Single disc brake, single piston floating caliper, diameter 220 mm, 5 mm thick

ABS
BMW Motorrad Race ABS (part-integral), disengageable


Dimensions / weights

Length
2,057 mm

Width (incl. mirrors)
845 mm

Height (excl. mirrors)
1,228 mm

Seat height, unladen weight
814 mm

Inner leg curve, unladen weight
1,805 mm

Unladen weight, road ready, fully fuelled 1)
207 kg

Dry weight

Permitted total weight
407 kg

Payload (with standard equipment)
200 kg

Usable tank volume
17.5 l

Reserve
ca. 4 l









2014 BMW S1000R – Totalmotorcycle.com European/UK Specifications/Technical Details
UK/European MSRP Price: £9,990.00 GBP (On The Road).

Engine
Type Liquid cooled in-line, DOHC 4 cylinder 16 valve engine
Bore x stroke 80 mm x 49.7 mm
Capacity 999 cc
Rated output 163 bhp at 11,000 rpm
Max. torque 112 Nm at 9,250 rpm
Compression ratio 12.0 :1
Mixture control / engine management Digital Engine Management
Emission control Emission standard EU3
Performance / fuel consumption
Maximum speed Over 125 mph
Fuel consumption per 100 km at constant 90 km/h 5.4 litres
Fuel consumption per 100 km at constant 120 km/h 5.6 litres
Fuel type Unleaded octane 98 RON, min octane 95 RON
Electrical System
Alternator 350 W Alternator
Battery 12 V / 9 Ah, maintenance free
Power transmission
Clutch Wet Clutch
Gearbox 6 speed transmission
Drive Chain Drive
Chassis / brakes
Frame Aluminium composite frame, partially self supporting engine
Front wheel location / suspension Upside down telescopic fork ? 46 mm
Rear wheel location / suspension Aluminium dual swing arm, adjustable rear suspension
Suspension travel front / rear 120 mm / 120 mm
Wheelbase 1439 mm
Castor 98.5 mm
Steering head angle 65.4°
Wheels Cast Aluminium
Rim, Front 3.50 x 17″ / 120/70 ZR 17
Rim, rear 6.00 x 17″ / 190/55 ZR 17
Tyre, front 3.50 x 17″ / 120/70 ZR 17
Tyre, rear 6.00 x 17″ / 190/55 ZR 17
Brake, front Twin floating disc, ? 320 mm, 4 piston fixed callipers
Brake, rear Single disc, ? 220 mm, single piston floating calliper
ABS Race ABS, disengageable
Dimensions / weights
Length 2,057 mm
Width (incl. mirrors) 845 mm
Height (excl. mirrors)
Seat height, unladen weight 814 mm
Inner leg curve, unladen weight 1,805 mm
Unladen weight, road ready, fully fueled 207 kg
Dry weight
Permitted total weight 407 kg
Payload (with standard equipment) 200 kg
Usable tank volume 17.5 litres
Reserve approx 4 litres

Specifications, features and prices to change by manufacturer without notice. All information correct as of posted date.
Technical data relate to the unladen weight (DIN)
1) According to Directive 93/93/EEC with all fluids, fuelled to at least 90% of usable fuel tank
2) Unladen weight without fluids



About Michael Le Pard 1307 Articles
"Mr. Totalmotorcycle". Owner and Founder of Total Motorcycle. Supporting Motorcyclists and Motorcycling for 18 great years.

Be the first to comment

Leave a Reply
