2015 KTM 50 SX Mini

Back to 2015 KTM Motorcycle Model Review Page

Click photos to enlarge. Our big, clean bike pics make great desktop wallpaper.

2015 KTM 50 SX Mini
2015 KTM 50 SX Mini

2015 KTM 50 SX Mini
2015 KTM 50 SX Mini



2015 KTM 50 SX Mini Review

2015 KTM 50 SX Mini on www.Totalmotorcycle.com

The Perfect Launchpad into the MX World…

A real KTM for young crossers from the age of about 4 to 10 and a height of up to approx. 1.30 m. A real motorcycle with high quality components that’s child’s play to control and whose engine excels with linear power development and a beginner-friendly automatic clutch.


2015 KTM 50 SX Mini www.Totalmotorcycle.com Key Features

Top ergonomics



Top quality.



Made-to-measure performance



Control that’s child’s play






2015 KTM 50 SX Mini www.Totalmotorcycle.com Features and Benefits


OPTIONAL RESTRICTOR KIT

For absolute beginners, the engine power can be restricted to a moderate 5.5 hp with a kit from the PowerParts range.



RADIATOR

Just like the big KTM bikes, the 50 SX Mini is also equipped with water cooling that even cools the crankcase. Generously dimensioned radiators ensure excellent heat dissipation and therefore high reliability, even under extreme loads.



CLUTCH

The centrifugally controlled, multi-disc automatic clutch developed by KTM delivers easily controllable acceleration and makes riding this bike the easiest thing in the world. It can be adjusted in no time at all, without special tools, to the specific requirements of both track and rider.



ENGINE

The modern, extremely compact, 2-stroke engine sets the benchmark in its class with its very controllable power. Thanks to the 3-shaft concept, the crankshaft is close to the bike’s centre of gravity. This not only benefits the handling; it also provides a flow-optimised inflow angle at the intake membrane – a prerequisite for maximum performance.


SUSPENSION/DAMPING

Both the rear shock absorber and the 35 mm upside-down fork are high-quality products from WP Suspension and guarantee ultimate damping and responsiveness.



WP CHASSIS

A high quality, upside-down telescopic fork from WP Suspension, featuring 35 mm diameter outer tubes and 100 mm suspension travel, ensures outstanding ride stability. A WP shock absorber connected directly to the swingarm also supplies 171 mm of suspension travel at the rear wheel.



ADJUSTABLE AUTOMATIC TRANSMISSION

The centrifugally controlled, multi-disc automatic clutch developed by KTM delivers easily controllable acceleration and makes riding the 50 SX Mini the easiest thing in the world. Furthermore, it can still be quickly and easily adjusted to the specific requirements of both track and rider using the “KTM clicker system” – in a matter of seconds and with no special tools required.


GRAPHICS

The graphic design derived from that of the full-size SX bikes makes the little KTM even cooler. Its frame has a hardwearing plastic coating in anthracite metallic.



HANDLEBAR

The ergonomic Renthal handlebar made from a high-quality aluminium alloy ensures the highest levels of stability and safety. A Renthal crash pad around the centre brace protects the rider from hard knocks.


BRAKES

Both at the front and rear, state-of-the-art hydraulic disc brakes from FORMULA ensure best possible retardation. The exclusive, self-cleaning Wave brake discs stand for the ultimate in race technology and outstanding safety.



WATER COOLING

The liquid-cooling system of the KTM 50 SX Mini, with two large radiators and additional cooling for the crankcase, prevents the engine overheating, even under the most extreme loads. The smallest KTM is even unfazed by coming to blows with the ground.



WHEELS

Just like the big factory bikes, the 50 SX Mini is equipped with ultra-light, black anodised aluminium rims that easily withstand even the biggest of jumps. The 50 SX is now equipped with the very latest generation tyre from MAXXIS, featuring a profile that guarantees optimum grip on every surface.









2015 KTM 50 SX Mini – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See dealer for pricing in USD

ENGINE
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake
Displacement 49.0 cm³
Bore 39.5 mm
Stroke 40 mm
Starting aid Kickstarter
Transmission Rigid 1-stage reduction gear
Engine lubrication Separate lubrication
Primary gear ratio 33:61 straight cut spur gear
Final drive 10:42
Cooling system Liquid cooling system
Clutch Multidisc automatic clutch on the main shaft / centrifugal force
Ignition system SELETTRA 2p D36
CHASSIS
Frame Central tube frame of chrome molybdenum steel tubing, powder-coated
Forks WP Suspension USD 35
Shock absorber WP Suspension 3614 BAEM
Suspension travel Front 100 mm
Suspension travel Rear 171 mm
Brake system Front Disc brake with four-pot brake caliper
Brake system Rear Disc brake with two-pot brake caliper
Brake discs – diameter Front 160 mm
Brake discs – diameter Rear 160 mm
Chain 1/2 x 3/16″
Steering head angle 67.4°
Wheel base 914±10 mm
Ground clearance (unloaded) 184 mm
Seat height (unloaded) 558 mm
Total fuel tank capacity approx. 2.3 l
Unleaded premium fuel (95 RON)
Weight without fuel approx. 39.0 kg








2015 KTM 50 SX Mini – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See dealer for pricing in CDN

ENGINE
Design 1-cylinder 2-stroke engine, water-cooled, with reed intake
Displacement 49.0 cm³
Bore 39.5 mm
Stroke 40 mm
Starting aid Kickstarter
Transmission Rigid 1-stage reduction gear
Engine lubrication Separate lubrication
Primary gear ratio 33:61 straight cut spur gear
Final drive 10:42
Cooling system Liquid cooling system
Clutch Multidisc automatic clutch on the main shaft / centrifugal force
Ignition system SELETTRA 2p D36
CHASSIS
Frame Central tube frame of chrome molybdenum steel tubing, powder-coated
Forks WP Suspension USD 35
Shock absorber WP Suspension 3614 BAEM
Suspension travel Front 100 mm
Suspension travel Rear 171 mm
Brake system Front Disc brake with four-pot brake caliper
Brake system Rear Disc brake with two-pot brake caliper
Brake discs – diameter Front 160 mm
Brake discs – diameter Rear 160 mm
Chain 1/2 x 3/16″
Steering head angle 67.4°
Wheel base 914±10 mm
Ground clearance (unloaded) 184 mm
Seat height (unloaded) 558 mm
Total fuel tank capacity approx. 2.3 l
Unleaded premium fuel (95 RON)
Weight without fuel approx. 39.0 kg








2015 KTM 50 SX Mini – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £NA GBP (On The Road inc 20% Vat)

Not Available

* Manufacturer’s suggested retail price (MSRP), the actual sale prices can vary.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
