2016 Zero FX Review

2016 Zero FX on www.Totalmotorcycle.com

Do Anything. Ride Anywhere….

You’ve never experienced power and freedom like this. All those things you wished you could get away with… they just became possible. It is said, “Absolute power corrupts absolutely.” Just in case you find this to be true, hit the eco-switch…or don’t.

Delivering a nearly instantaneous 70 ft-lbs of torque and weighing less than 300 lbs, the Zero FX takes any type of riding to bold new levels. Stealthily ride at any hour of the day or night, on a motorcycle that distills riding into its most basic and adrenaline-pumping elements.


Tempting you to ride on any terrain that crosses your path, the Zero FX chassis hails from Zero Motorcycles’ championship-winning off-road heritage and features the most advanced Z-Force® technology yet.

Equipped with a maintenance-free powertrain, belt drive and fully modular power pack system, no riding time is wasted and each mile ridden only costs around a penny in electricity.

Thrilling acceleration with 70 ft-lbs. torque




2016 Zero FX www.Totalmotorcycle.com Key Features

New for 2016

Longer Rides. More Fun.

Owning a Zero FX is like having your own personal amusement park ride. For 2016, the ride got even longer and more fun.

New cell chemistry within the patented modular and removable Z-Force® power pack allows 14% more energy to be stored in the same amount of space and operate more efficiently, resulting in a system that boasts the highest energy density in the electric vehicle industry.

Ergonomics have also been improved—especially off-road—with new taller rise handlebars for increased leverage and an optimized rear brake pedal that provides better modulation.


Game Changing Z-Force® Power Pack

A fully modular system

The Zero FX features a fully modular power pack system. With slots for two power packs, you can operate the Zero FX with either one or both slots filled. The modules can be charged either on the motorcycle or elsewhere using optional accessories, giving you the ability to charge without a street-level outlet.

The Zero FX can be purchased with either one module (ZF3.3) or two modules (ZF6.5).

· Fully modular Z-Force® quick-swap technology allows you to swap power packs in seconds. You can also upgrade your motorcycle’s max capacity from 3.3 kWh to 6.5 kWh. · Note: Adding a second power pack may require an update of the vehicle’s registration documents. Please check with your local vehicle approval authority for details.

· State-of-the-art power pack configuration and cell chemistry · Cells last 2,500 full charge-discharge cycles before hitting 80% capacity, yielding as much as 185,000 miles on the original power pack

· Isolated power systems and 12 volt system for running accessories
· Modules can be fully removed from the motorcycle and transported to charge anywhere (this requires the purchase of a stand-alone Quick Charger and the Power Pack Module Charging Adapter)
· Module locking system for increased security and peace of mind
· Scalable off-board charging options available to reduce recharge times (see specs for details)







2016 Zero FX www.Totalmotorcycle.com Features and Benefits

Revolutionary Z-Force® Motor

Thrilling acceleration with 70 ft-lbs torque

The motor in the Zero FX is configured to produce incredible torque and sits inside the lightest motorcycle in the lineup. The result is thrilling acceleration. Zero Motorcycles designed the Z-Force® motor from the ground up to be compact, efficient and powerful. Completely air-cooled, the motor is designed to provide a fantastic riding experience minus the need for any regular maintenance. When slowing down, the motor generates electricity that is channeled back into the power pack to help extend ride times.

· Designed from the ground up by Zero Motorcycles to be the world’s most efficient, powerful, compact, brushless and sealed air-cooled motor
· Produces 44 hp and 70 ft-lbs of torque (Zero FX ZF6.5)
· Requires no routine maintenance
· Operates with such high efficiency that it does not require any complex cooling system
· Instant torque and broad power band for impressive acceleration
· Quad-level regenerative system recharges the power pack when decelerating · Re-gen level is increased during brake application vs. “neutral” deceleration
· Both braking and “neutral” re-gen levels are set higher in Eco vs. Sport mode
· “Custom” mode performance profile can be set using the Zero Motorcycles App




Zero FX Electric Motorcycle Motor

Zero FX Electric Motorcycle Charging System
Charge Anywhere

Plug in at any standard outlet

The Zero FX charging system is integrated into the motorcycle and can be plugged in at any standard outlet. No additional equipment is required for standard charging. This allows you to conveniently charge in your garage, at the office or when you stop at one of your favorite places while enjoying a day out.

The Zero FX power pack modules can be removed from the motorcycle and charged separately using optional accessories. This makes it possible to charge the modules anywhere and thereby eliminates the necessity of a street-level outlet. Charging times can be reduced by up to ~75% by using a scalable off-board charging system.*

*Requires optional accessories. Please see your Zero Motorcycles dealer.

Zero FX Electric Motorcycle Frame



Frame and Bodywork

Light Aircraft Grade Aluminum

At the core of the Zero FX lies the ultimate dirt bike frame that Zero engineered from the ground up and hand-crafted using aircraft grade aluminum. The resulting combination of lower weight and higher strength means more responsiveness. In the corners and off the line, this translates into greater acceleration. For added durability, each frame is shot-peened and anodized.

· Rigid, robust and lightweight frame
· Hydroformed top tube for increased strength and reduced weight
· Large cylindrical swingarm cross tube for increased stiffness and suspension response
· Entire frame is shot-peened and anodized for resistance to corrosion and abrasion
· Robust headtube and head bearings for increased torsional rigidity and improved control
· The headlight, dash, key switch and bodywork are refined to provide elegant instrumentation and a sleeker front end aesthetic




Zero FX Electric Motorcycle Front Fork

Showa Suspension

The Magic Ride

Zero worked in close collaboration with Showa to develop suspension systems that provide excellent small bump compliance, predictable control of bigger impacts and exceptionally smooth action under all conditions. Torsional rigidity of the front end improves handling, and a hollow front axle reduces unsprung weight. Suspension settings are completely customizable to meet the demands of a wide variety of riders.

· Exceptionally smooth action for improved comfort and control
· Fully adjustable settings to meet the demands of a wide variety of riders
· Hollow front axle reduces unsprung weight
· Durable and highly protective fork guards
· Developed in close collaboration with Showa



Zero FX Electric Motorcycle brakes

Bosch Anti-lock Brake System (ABS)

Powerful. Precise. Control.

The Zero FX features an advanced Bosch anti-lock brake system (ABS) that improves control in a wide array of conditions and ensures the best braking performance.

· Advanced Bosch ABS is standard
· ABS can be switched on or off depending on rider preference
· Incredibly smooth actuation for improved control under extreme braking
· Refined hydraulic ratios improve braking power and modulation




Zero FX Electric Motorcycle Wheels
Wheels and Tires

Paved Road. Dirt Road. No Road.

Pirelli tires are standard on the Zero FX, providing improved traction in a wide variety of conditions, excellent durability and road feel. The Zero FX alloy wheels are designed to reduce unsprung weight while not compromising on strength.

· Dynamic Pirelli Scorpion MT-90 tires offer high performance from daily urban use to weekend off-road adventure.
· Wider 21 x 1.85 front and 18 x 2.5 rear wheels for increased strength and greater aftermarket tire options




Zero FX Electric Motorcycle Drivetrain

Direct Drive Gearing

Instant torque with a twist

Featuring a clutchless direct drive, the Zero FX is geared for rapid acceleration and maximum efficiency. Without ever needing to shift, the Zero FX provides controlled and powerful acceleration at any speed between 0-85 mph. The carbon fiber belt achieves minimal frictional losses for increased overall range and is integral to making the powertrain maintenance-free.

· Sophisticatedly simple “just ride” direct-drive system means no clutch, no shifting and no need to carry a heavy and complex transmission
· Maintenance-free and virtually silent belt drive system
· Clutchless single speed that simplifies operation
· Geared for rapid acceleration and maximum efficiency
· Adjustable rear axle to modify belt tension



Dash and Controls

Impressive information. Elegantly Displayed.

The dash is designed by Zero to quickly and accurately provide useful data on such information as state of charge, power output and your selected riding profile. You can toggle through three riding profiles using the ergonomic right-hand switch gear to better meet the needs of your ride: Sport, Eco, Custom. The dash screen features a cool blue backlit LCD display and integrates seamlessly into the front of the motorcycle. Want more information about the motorcycle while riding or at home· Try the Zero Motorcycles App.

· High contrast and blue backlit LCD screen features data that allows you to better understand your state of charge, see your current riding profile and view other useful riding information
· Ergonomic right-hand switch assembly with integrated switch to toggle on the fly between Sport, Eco and Custom riding modes
· Custom riding mode setting allows you to set your own performance profile (custom mode performance profile must be configured within the Zero Motorcycles App)
· Projector beam headlights and integrated fly screen provide a refined and contemporary front profile




Zero FX Electric Motorcycle Dashboard

Zero FX Electric Motorcycle App

Zero Motorcycles App

Get your Motorcycle Dialed

Using the Zero Motorcycles App you can see detailed information about your motorcycle such as the time until charged, average watts per mile, total charge cycles and much more. When parked, the app allows you to set the custom riding mode’s performance profile by adjusting the parameters for top speed, maximum torque and maximum regenerative braking. While riding, your phone transforms into a customized dash that provides detailed real-time motorcycle information. Synced using Bluetooth, the app works on iPhone and Android mobile devices.







2016 Zero FX – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $8,495 ZERO FX zf3.3; $10,990 ZERO FX zf6.5 USD

range ZERO FX zf3.3
City 41 miles (66 km)
Highway, 55 mph (89 km/h) 25 miles (40 km)
 » Combined 31 miles (50 km)
Highway, 70 mph (113 km/h) 17 miles (27 km)
 » Combined 24 miles (39 km)
Motor
Max torque 70 ft-lb (95 Nm)
Max power 27 hp (20 kW) @ 3,700 rpm
Top speed (max) 85 mph (137 km/h)
Top speed (sustained) 70 mph (113 km/h)
Acceleration, 0-60 mph (0-100 km/h) 4.3 seconds
Type Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, permanent magnet, brushless motor
Controller High efficiency, 420 amp, 3-phase brushless controller with regenerative deceleration
Power system
Est. pack life to 80% (city) 92,000 miles (148,000 km)
Power pack Z-Force® Li-Ion intelligent modular
Max capacity 3.3 kWh
Nominal capacity 2.9 kWh
Charger type 650 W, integrated
Charge time (standard) 4.7 hours (100% charged) / 4.2 hours (95% charged)
 » With one accessory charger 2.1 hours (100% charged) / 1.6 hours (95% charged)
 » With max accessory chargers 1.5 hours (100% charged) / 1.0 hour (95% charged)
Input Standard 110 V or 220 V
Drivetrain
Transmission Clutchless direct drive
Final drive 132T / 25T, Poly Chain® GT® Carbon™ belt
Chassis / Suspension / Brakes
Front suspension Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel 8.60 in (218 mm)
Rear suspension travel 8.94 in (227 mm)
Front brakes Bosch Gen 9 ABS, J-Juan dual piston floating caliper, 240 x 4.5 mm disc
Rear brakes Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Front tire Pirelli Scorpion MT 90 A/T 90/90-21
Rear tire Pirelli Scorpion MT 90 A/T 120/80-18
Front wheel 1.85 x 21
Rear wheel 2.50 x 18
Dimensions
Wheelbase 56.6 in (1,438 mm)
Seat height 34.7 in (881 mm)
Rake 25.4°
Trail 4.1 in (104 mm)
Weight
Frame 20 lb (9.1 kg)
Curb weight 247 lb (112 kg)
Carrying capacity 383 lb (174 kg)
Economy
Equivalent fuel economy (city) 485 MPGe (0.48 l/100 km)
Equivalent fuel economy (highway) 205 MPGe (1.15 l/100 km)
Typical cost to recharge $0.37
Pricing
MSRP $8,495
(Does not include local shipping, applicable taxes, PDI, or road registration fees.)
Warranty
Standard motorcycle warranty* 2 years
Power pack warranty* 5 years/50,000 miles

range ZERO FX zf6.5
City 82 miles (132 km)
Highway, 55 mph (89 km/h) 50 miles (80 km)
 » Combined 62 miles (100 km)
Highway, 70 mph (113 km/h) 35 miles (56 km)
 » Combined 49 miles (79 km)
Motor
Max torque 70 ft-lb (95 Nm)
Max power 44 hp (33 kW) @ 3,700 rpm
Top speed (max) 85 mph (137 km/h)
Top speed (sustained) 70 mph (113 km/h)
Acceleration, 0-60 mph (0-100 km/h) 4.0 seconds
Type Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, permanent magnet, brushless motor
Controller High efficiency, 420 amp, 3-phase brushless controller with regenerative deceleration
Power system
Est. pack life to 80% (city) 185,000 miles (298,000 km)
Power pack Z-Force® Li-Ion intelligent modular
Max capacity 6.5 kWh
Nominal capacity 5.7 kWh
Charger type 650 W, integrated
Charge time (standard) 8.9 hours (100% charged) / 8.4 hours (95% charged)
 » With one accessory charger 3.8 hours (100% charged) / 3.3 hours (95% charged)
 » With max accessory chargers 1.7 hours (100% charged) / 1.2 hours (95% charged)
Input Standard 110 V or 220 V
Drivetrain
Transmission Clutchless direct drive
Final drive 132T / 25T, Poly Chain® GT® Carbon™ belt
Chassis / Suspension / Brakes
Front suspension Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel 8.60 in (218 mm)
Rear suspension travel 8.94 in (227 mm)
Front brakes Bosch Gen 9 ABS, J-Juan dual piston floating caliper, 240 x 4.5 mm disc
Rear brakes Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Front tire Pirelli Scorpion MT 90 A/T 90/90-21
Rear tire Pirelli Scorpion MT 90 A/T 120/80-18
Front wheel 1.85 x 21
Rear wheel 2.50 x 18
Dimensions
Wheelbase 56.6 in (1,438 mm)
Seat height 34.7 in (881 mm)
Rake 25.4°
Trail 4.1 in (104 mm)
Weight
Frame 20 lb (9.1 kg)
Curb weight 289 lb (131 kg)
Carrying capacity 341 lb (155 kg)
Economy
Equivalent fuel economy (city) 485 MPGe (0.48 l/100 km)
Equivalent fuel economy (highway) 205 MPGe (1.15 l/100 km)
Typical cost to recharge $0.73
Pricing
MSRP $10,990
(Does not include local shipping, applicable taxes, PDI, or road registration fees.)
Warranty
Standard motorcycle warranty* 2 years
Power pack warranty* 5 years/50,000 miles








2016 Zero FX – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $11,044 ZERO FX zf3.3; $14,287 ZERO FX zf6.5 CDN

range ZERO FX zf3.3
City 41 miles (66 km)
Highway, 55 mph (89 km/h) 25 miles (40 km)
 » Combined 31 miles (50 km)
Highway, 70 mph (113 km/h) 17 miles (27 km)
 » Combined 24 miles (39 km)
Motor
Max torque 70 ft-lb (95 Nm)
Max power 27 hp (20 kW) @ 3,700 rpm
Top speed (max) 85 mph (137 km/h)
Top speed (sustained) 70 mph (113 km/h)
Acceleration, 0-60 mph (0-100 km/h) 4.3 seconds
Type Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, permanent magnet, brushless motor
Controller High efficiency, 420 amp, 3-phase brushless controller with regenerative deceleration
Power system
Est. pack life to 80% (city) 92,000 miles (148,000 km)
Power pack Z-Force® Li-Ion intelligent modular
Max capacity 3.3 kWh
Nominal capacity 2.9 kWh
Charger type 650 W, integrated
Charge time (standard) 4.7 hours (100% charged) / 4.2 hours (95% charged)
 » With one accessory charger 2.1 hours (100% charged) / 1.6 hours (95% charged)
 » With max accessory chargers 1.5 hours (100% charged) / 1.0 hour (95% charged)
Input Standard 110 V or 220 V
Drivetrain
Transmission Clutchless direct drive
Final drive 132T / 25T, Poly Chain® GT® Carbon™ belt
Chassis / Suspension / Brakes
Front suspension Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel 8.60 in (218 mm)
Rear suspension travel 8.94 in (227 mm)
Front brakes Bosch Gen 9 ABS, J-Juan dual piston floating caliper, 240 x 4.5 mm disc
Rear brakes Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Front tire Pirelli Scorpion MT 90 A/T 90/90-21
Rear tire Pirelli Scorpion MT 90 A/T 120/80-18
Front wheel 1.85 x 21
Rear wheel 2.50 x 18
Dimensions
Wheelbase 56.6 in (1,438 mm)
Seat height 34.7 in (881 mm)
Rake 25.4°
Trail 4.1 in (104 mm)
Weight
Frame 20 lb (9.1 kg)
Curb weight 247 lb (112 kg)
Carrying capacity 383 lb (174 kg)
Economy
Equivalent fuel economy (city) 485 MPGe (0.48 l/100 km)
Equivalent fuel economy (highway) 205 MPGe (1.15 l/100 km)
Typical cost to recharge $0.37
Pricing
MSRP $11,044 CAD
(Does not include local shipping, PDI or road registration fees.)
Warranty
Standard motorcycle warranty* 2 years
Power pack warranty* 5 years/80,000 km

range ZERO FX zf6.5
City 82 miles (132 km)
Highway, 55 mph (89 km/h) 50 miles (80 km)
 » Combined 62 miles (100 km)
Highway, 70 mph (113 km/h) 35 miles (56 km)
 » Combined 49 miles (79 km)
Motor
Max torque 70 ft-lb (95 Nm)
Max power 44 hp (33 kW) @ 3,700 rpm
Top speed (max) 85 mph (137 km/h)
Top speed (sustained) 70 mph (113 km/h)
Acceleration, 0-60 mph (0-100 km/h) 4.0 seconds
Type Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, permanent magnet, brushless motor
Controller High efficiency, 420 amp, 3-phase brushless controller with regenerative deceleration
Power system
Est. pack life to 80% (city) 185,000 miles (298,000 km)
Power pack Z-Force® Li-Ion intelligent modular
Max capacity 6.5 kWh
Nominal capacity 5.7 kWh
Charger type 650 W, integrated
Charge time (standard) 8.9 hours (100% charged) / 8.4 hours (95% charged)
 » With one accessory charger 3.8 hours (100% charged) / 3.3 hours (95% charged)
 » With max accessory chargers 1.7 hours (100% charged) / 1.2 hours (95% charged)
Input Standard 110 V or 220 V
Drivetrain
Transmission Clutchless direct drive
Final drive 132T / 25T, Poly Chain® GT® Carbon™ belt
Chassis / Suspension / Brakes
Front suspension Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel 8.60 in (218 mm)
Rear suspension travel 8.94 in (227 mm)
Front brakes Bosch Gen 9 ABS, J-Juan dual piston floating caliper, 240 x 4.5 mm disc
Rear brakes Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4.5 mm disc
Front tire Pirelli Scorpion MT 90 A/T 90/90-21
Rear tire Pirelli Scorpion MT 90 A/T 120/80-18
Front wheel 1.85 x 21
Rear wheel 2.50 x 18
Dimensions
Wheelbase 56.6 in (1,438 mm)
Seat height 34.7 in (881 mm)
Rake 25.4°
Trail 4.1 in (104 mm)
Weight
Frame 20 lb (9.1 kg)
Curb weight 289 lb (131 kg)
Carrying capacity 341 lb (155 kg)
Economy
Equivalent fuel economy (city) 485 MPGe (0.48 l/100 km)
Equivalent fuel economy (highway) 205 MPGe (1.15 l/100 km)
Typical cost to recharge $0.73
Pricing
MSRP $14,287 CAD
(Does not include local shipping, PDI or road registration fees.)
Warranty
Standard motorcycle warranty* 2 years
Power pack warranty* 5 years/80,000 km







2016 Zero FX – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ See Dealer GBP/EUR (On The Road inc 20% Vat)

range ZERO FX zf3.3
City 66 km
Highway, 89 km/h 40 km
 » Combined 50 km
Highway, 113 km/h 27 km
 » Combined 39 km
Motor
Max torque 95 Nm
Max power 27 hp (20 kW) @ 3.700 rpm
Licensing Requirement A2 Licence
Top speed (max) 137 km/h
Top speed (sustained) 113 km/h
Acceleration, 0-100 km/h 4,3 seconds
Type Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, permanent magnet, brushless motor
Controller High efficiency, 420 amp, 3-phase brushless controller with regenerative deceleration
Power system
Est. pack life to 80% (city) 148.000 km
Power pack Z-Force® Li-Ion intelligent modular
Max capacity 3,3 kWh
Nominal capacity 2,9 kWh
Charger type 650 W, integrated
Charge time (standard) 4,7 hours (100% charged) / 4,2 hours (95% charged)
 » With one accessory charger 2,1 hours (100% charged) / 1,6 hours (95% charged)
 » With max accessory chargers 1,5 hours (100% charged) / 1,0 hour (95% charged)
Input Standard 110 V or 220 V
Drivetrain
Transmission Clutchless direct drive
Final drive 132T / 25T, Poly Chain® GT® Carbon™ belt
Chassis / Suspension / Brakes
Front suspension Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel 218 mm
Rear suspension travel 227 mm
Front brakes Bosch Gen 9 ABS, J-Juan dual piston floating caliper, 240 x 4,5 mm disc
Rear brakes Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4,5 mm disc
Front tire Pirelli Scorpion MT 90 A/T 90/90-21
Rear tire Pirelli Scorpion MT 90 A/T 120/80-18
Front wheel 1,85 x 21
Rear wheel 2,50 x 18
Dimensions
Wheelbase 1.438 mm
Seat height 881 mm
Rake 25,4°
Trail 104 mm
Weight
Frame 9,1 kg
Curb weight 112 kg
Carrying capacity 174 kg
Economy
Equivalent fuel economy (city) 0,48 l/100 km
Equivalent fuel economy (highway) 1,15 l/100 km
Typical cost to recharge 0,67 €
Warranty
Standard motorcycle warranty* 2 years
Power pack warranty* 5 years/80.000 km



range ZERO FX zf6.5
City 132 km
Highway, 89 km/h 80 km
 » Combined 100 km
Highway, 113 km/h 56 km
 » Combined 79 km
Motor
Max torque 95 Nm
Max power 44 hp (33 kW) @ 3.700 rpm
Licensing Requirement A2 Licence
Top speed (max) 137 km/h
Top speed (sustained) 113 km/h
Acceleration, 0-100 km/h 4,0 seconds
Type Z-Force® 75-5 passively air-cooled, high efficiency, radial flux, permanent magnet, brushless motor
Controller High efficiency, 420 amp, 3-phase brushless controller with regenerative deceleration
Power system
Est. pack life to 80% (city) 298.000 km
Power pack Z-Force® Li-Ion intelligent modular
Max capacity 6,5 kWh
Nominal capacity 5,7 kWh
Charger type 650 W, integrated
Charge time (standard) 8,9 hours (100% charged) / 8,4 hours (95% charged)
 » With one accessory charger 3,8 hours (100% charged) / 3,3 hours (95% charged)
 » With max accessory chargers 1,7 hours (100% charged) / 1,2 hours (95% charged)
Input Standard 110 V or 220 V
Drivetrain
Transmission Clutchless direct drive
Final drive 132T / 25T, Poly Chain® GT® Carbon™ belt
Chassis / Suspension / Brakes
Front suspension Showa 41 mm inverted cartridge forks, with adjustable spring preload, compression and rebound damping
Rear suspension Showa 40 mm piston, piggy-back reservoir shock with adjustable spring preload, compression and rebound damping
Front suspension travel 218 mm
Rear suspension travel 227 mm
Front brakes Bosch Gen 9 ABS, J-Juan dual piston floating caliper, 240 x 4,5 mm disc
Rear brakes Bosch Gen 9 ABS, J-Juan single piston floating caliper, 240 x 4,5 mm disc
Front tire Pirelli Scorpion MT 90 A/T 90/90-21
Rear tire Pirelli Scorpion MT 90 A/T 120/80-18
Front wheel 1,85 x 21
Rear wheel 2,50 x 18
Dimensions
Wheelbase 1.438 mm
Seat height 881 mm
Rake 25,4°
Trail 104 mm
Weight
Frame 9,1 kg
Curb weight 131 kg
Carrying capacity 155 kg
Economy
Equivalent fuel economy (city) 0,48 l/100 km
Equivalent fuel economy (highway) 1,15 l/100 km
Typical cost to recharge 1,34 €
Warranty
Standard motorcycle warranty* 2 years
Power pack warranty* 5 years/80.000 km






*Starting at MSRP is the manufactured suggested price and excludes delivery, setup, tax, title, license, and additional fees and expenses. Bikes may be shown with optional accessories. Final sale price determined by an authorized dealer. Specifications and MSRP are subject to change.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).

About Michael Le Pard 10138 Articles
"Mr. Totalmotorcycle". Owner and Founder of Total Motorcycle, the World’s Largest Motorcycle Site with over 425 million readers since 1999. Total Motorcycle is my pride and joy and being able to reach 425 million people has been incredible and I could not have done it without the support of my visitors, readers and members...thank you so much! We are all making a difference to millions of riders worldwide.

Be the first to comment

Leave a Reply
