2017 Harley-Davidson Wide Glide Review

2017 Harley-Davidson Wide Glide on www.Totalmotorcycle.com

Modern day performance anchored in a style that’s never backed down from authority…

Are you ready to light the fuse?

From the raked out wide fork straddling the 21-inch laced wheel to the Tommy Gun exhaust the Wide Glide® brings old school chopper design to a new generation. The look is carried all the way through the flames on the tank to the minimalist black wire sissy bar. Twist the throttle of the powerful High Output 103. The chopper tradition runs strong.

Long and lean up front. Fat and low in the back. Authentic and tough all over. The Wide Glide® motorcycle is oldschool custom chopper but with all the comforts of today’s modern rides. It’s an affordable entry into the Big Twin experience with attitude to spare.

DYNA®Built with the rawest styling of all of the Harley Big Twin motorcycles, Dyna models are an affordable platform from which to build the ultimate personalised motorcycle.

Family features:

High Output Twin Cam 103 engine (except Wide Glide models)
6-speed Cruise Drive transmission
ABS available on all models

2017 Harley-Davidson Wide Glide www.Totalmotorcycle.com Key Features

NEW IN 2017

Battery tender harness

MODEL UNIQUE FEATURES

Style
• Black powder-coated engine with chrome covers
• Chrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
• Black Steel Laced wheels, 21-inch front, 17-inch rear
• Old-school styling with available Flame paint scheme
• Narrow Street Bob® style fuel tank tilted up .75-inches in the front
• Wide, large diameter forks
• 21-inch diameter narrow front wheel
• Black, swept-back sissy bar
• Chrome rocker and derby covers
• Black battery cover, mirrors, fender strut covers, headlight bucket, and risers
• Chrome trim on battery cover with embossed Wide Glide® name
• Chopped rear fender
• Combination stop/turn/tail lights (U.S. configuration)
• Side-mounted license plate (U.S. configuration)

Fit
• Internally-wired 1.25-inch drag bars with 4-inch risers
• Forward-mounted foot controls; standard passenger footpegs
• Low-slung, split two-up seat (solo rider with separate passenger pillion)
• Low, 25.5-inch seat height
• Low, swept-back sissy bar

Function
• Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/ gear display, fuel gauge with low-fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
• Start, engine cutoff, left/right turn signals, horn, hi/low beam with flash-to-pass hand controls
• Self-canceling turn signal controls with integrated hazard warning
• Barrel key, tank console-mounted ignition; fork lock common with ignition key

Performance
• Rubber-mounted, Air-cooled, 1690 cc High Output Twin Cam 103™ engine
• 6-Speed Cruise Drive® transmission
• Electronic Sequential Port Fuel Injection (ESPFI) with heated O2 sensors
• Anti-lock Braking System (ABS)1 standard

AVAILABLE OPTIONS
• Smart Security System2 with proximity-based, hands-free security fob (factory installed option)
• Engine Idle Temperature Management Strategy (EITMS) (dealer-activated option)





2017 Harley-Davidson Wide Glide www.Totalmotorcycle.com Features and Benefits

Authentic Styling

The motorcycles in the Dyna® family trace their roots to the original Harley-Davidson® factory customs. Notice the powerful front ends, chromed steel details and tricked-out wheels. There isn’t an ounce of doubt that you’re looking at a rolling sculpture. But there’s something bigger at work here than a mere visual statement. These are motorcycles sprung from a long riding tradition, with a strong emphasis on the riding. Post-war bobbers. Rebellious 70s choppers. Motorcycles where the theme was riding hard and the only rule was nonconformity. The profile is long and low, built to show off plenty of muscle. The 45° V-Twin engine is the jewel at the center of the design. There is no denying the powerful message sent by such a machine. It says get in the saddle, fire up Big Twin engine, treat your ears to the most satisfying exhaust note in all of motorized transportation, then go wherever the road out of town takes you.

Check It Out

Iconic Engine

Iconic Engine

There is something about the steady pulse of power from an air-cooled Twin Cam 103™ engine that works its way into a rider and won’t let go. Once you’ve experienced it you understand. Nothing else in the world of motorized transportation could be as satisfying. There are perfectly rational explanations for this. The lightweight piston design and refined delivery of power. The strong driveline and bulletproof internal parts. The way engine and 6-Speed Cruise Drive® transmission work flawlessly together to carry you down the highway at a relaxed, easy-riding rpm. But rational explanations never go far enough. What you feel when the power of this engine pulls you down the road toward the vanishing point is the legacy of the Flathead, Knucklehead, Panhead, Shovelhead, Evolution®, Twin Cam 88® and Twin Cam 96™ engines that came before. It’s something no ordinary engine can deliver.

Handling

If there’s anything the unruly bunch of riders that gravitate to a Dyna motorcycle have in common, it’s that they’re not easily satisfied. So we built every bike in the family to bridge the gap between knockout looks and uncompromising open road function. The exceptional stiffness of the chassis makes for sure-footed handling. The brakes and suspension components are top end, and the custom-style wheels roll on premium rubber designed for both durability and grip performance. A Dyna motorcycle is rolling proof that you don’t need a bike that looks like it belongs in a B-grade science fiction movie to burn through a wicked set of curves.

Comfort

Journey back far enough in the factory custom history of the Dyna family and you get to the machine that started the whole thing off: a Harley-Davidson touring bike. Seriously, and that’s your first clue to the rider comfort that waits for you in the saddle of today’s Dyna motorcycle. That early touring machine featured a new kind of isolation mounting system for the engine. Which led to a series of innovative frame designs. And that brings us to the current Dyna frame and its two-point engine isolation mounting system. It makes sure the power of 103 cubic inches of Twin Cam 103™ engine gets to the pavement. But the vibrations don’t get to the rider. You’ll find the same dogged approach to rider comfort throughout every inch of every bike in the family. Handlebars designed to fight the fatigue of a long day in the wind. Foot pegs and controls that hit your boots exactly where they ought to. The look is hard as nails. That doesn’t mean the ride has to be.






2017 Harley-Davidson Wide Glide – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $15999 to $16749 USD

PRICING 6
Vivid Black $15,999
Two-Tone Option $16,749
ABS Option Standard
Security Option $395
California Emissions $200
Freight $390
DIMENSIONS
Length 96.3 in.
Seat Height, Laden 7 25.5 in.
Seat Height, Unladen 7 26.8 in.
Ground Clearance 3.9 in.
Rake (steering head) (deg) 34
Trail 5.2 in.
Wheelbase 67.5 in.
Tires, Front Specification 80/90-21 54H
Tires, Rear Specification 180/60B17 75V
Fuel Capacity 4.7 gal.
Oil Capacity (w/filter) 3 qt.
Weight, As Shipped 650 lb.
Weight, In Running Order 683 lb.
ENGINE
Engine 1 Air-cooled, High Output Twin Cam 103™
Bore 3.875 in.
Stroke 4.374 in.
Displacement 103.1 cu in
Compression Ratio 9.6:1
Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Gear Ratios (overall) 1st 9.311
Gear Ratios (overall) 2nd 6.454
Gear Ratios (overall) 3rd 4.793
Gear Ratios (overall) 4th 3.882
Gear Ratios (overall) 5th 3.307
Gear Ratios (overall) 6th 2.79
CHASSIS
Exhaust Chrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
Wheels, Front Type 9 Black Steel Laced
Wheels, Rear Type Black Steel Laced
Brakes, Caliper Type 4-piston front and 2-piston torque-free floating rear
PERFORMANCE
Engine Torque Testing Method J1349
Engine Torque 2 99.5 ft-lb
Engine Torque (rpm) 3,750
Lean Angle, Right (deg.) 28.4
Lean Angle, Left (deg.) 31.9
Fuel Economy: Combined City/Hwy 5 42 mpg
ELECTRIC
Lights (as per country regulation), Indicator Lamps 8 High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system (optional), 6-speed, low fuel warnings
Gauges Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
1. Recommended 91 octane or higher fuel (R+M)/2.
2. Values shown are nominal. Performance may vary by country and region.
3. Standard and optional fuel systems may vary by country.
4. See motorcycle owner’s manual for complete details.
5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
6. Prices listed are the Manufacturer’s Suggested Retail Prices. Options such as color are available at additional cost. Prices exclude dealer setup, taxes, title and licensing and are subject to change. Dealer prices may vary.
7. Measurement reflects 180 lb. (81.7 kg) operator weight.
8. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
9. Standard and optional wheels may vary by country and region.








2017 Harley-Davidson Wide Glide – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $18699 to 19549 CDN

PRICING
Vivid Black $ 18,699
Two-Tone Option $ 19,549
ABS Option Standard
Security Option $ 455
Freight $ 250
ENGINE
Engine 1 Air-cooled, High Output Twin Cam 103™
Bore 98.4 mm
Stroke 111.1 mm
Displacement 1,690 cc
Compression Ratio 9.6:1
Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Gear Ratios (overall) 1st 9.311
Gear Ratios (overall) 2nd 6.454
Gear Ratios (overall) 3rd 4.793
Gear Ratios (overall) 4th 3.882
Gear Ratios (overall) 5th 3.307
Gear Ratios (overall) 6th 2.79
CHASSIS
Exhaust Chrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
Wheels, Front Type Black, Laced Steel
Wheels, Rear Type 8 Black, Laced Steel
Brakes, Caliper Type 4-piston front and 2-piston torque-free floating rear
PERFORMANCE
Engine Torque Testing Method J1349
Engine Torque 2 135 Nm
Engine Torque (rpm) 3,750
Lean Angle, Right (deg.) 28.4
Lean Angle, Left (deg.) 31.9
Fuel Economy: Combined City/Hwy 5 5.6 l/100 km
ELECTRIC
Lights (as per country regulation), Indicator Lamps 7 High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system(optional), 6-speed, low fuel warnings
Gauges Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
1. Recommended 91 octane or higher fuel (R+M)/2.
2. Values shown are nominal. Performance may vary by country and region.
3. Standard and optional fuel systems may vary by country.
4. See motorcycle owner’s manual for complete details.
5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
6. Measurement reflects 180 lb. (81.7 kg) operator weight.
7. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
8. Standard and optional wheels may vary by country and region.






2017 Harley-Davidson Wide Glide – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £13695 to £14445 GBP (On The Road inc 20% Vat)

PRICING 5
Vivid Black £ 13,695
Two-Tone Option £ 14,445
DIMENSIONS
Length 2,445 mm
Seat Height, Unladen 680 mm
Ground Clearance 100 mm
Rake (steering head) (deg) 34
Trail 132 mm
Wheelbase 1,715 mm
Tyres, Front Specification 80/90-21 54H
Tyres, Rear Specification 180/60B17 75V
Fuel Capacity 17.8 l
Oil Capacity (w/filter) 2.8 l
Weight, As Shipped 295 kg
Weight, In Running Order 307 kg
ENGINE
Engine Air-cooled, Twin Cam 103™
Bore 98.4 mm
Stroke 111.1 mm
Displacement 1,690 cc
Compression Ratio 9.7:1
Fuel System Electronic Sequential Port Fuel Injection (ESPFI)
DRIVETRAIN
Primary Drive Chain, 34/46 ratio
Gear Ratios (overall) 1st 9.311
Gear Ratios (overall) 2nd 6.454
Gear Ratios (overall) 3rd 4.793
Gear Ratios (overall) 4th 3.882
Gear Ratios (overall) 5th 3.307
Gear Ratios (overall) 6th 2.79
CHASSIS
Exhaust Chrome, “Tommy Gun” 2-1-2 collector exhaust with dual mufflers
Wheels, Front Type Black, Laced Steel
Wheels, Rear Type Black, Laced Steel
Brakes, Caliper Type 4-piston front and 2-piston torque-free floating rear
PERFORMANCE
Engine Torque Testing Method EC 134/2014
Engine Torque 130 Nm
Engine Torque (rpm) 3,500
Lean Angle, Right (deg.) 28.4
Lean Angle, Left (deg.) 31.9
Fuel Economy: Combined City/Hwy 5.6 l/100 km
ELECTRIC
Lights (as per country regulation), Indicator Lamps High beam, directional light bar, neutral, low oil pressure, engine diagnostics, turn signals, security system, 6-speed, low fuel warnings, ABS
Gauges Tank-mounted electronic speedometer with odometer, time-of-day clock on odometer, dual tripmeter, RPM/Gear display, fuel gauge with low fuel warning light and countdown feature, low oil pressure indicator light, engine diagnostics readout, LED indicator lights, 6-speed indicator light
1. Availability of colours may vary from dealer to dealer and is subject to change without further notice.
2. Recommended 95 octane or higher fuel (R+M)/2.
3. Values shown are nominal. Performance may vary by country and region.
4. See motorcycle owner’s manual for complete details.
5. Prices shown are suggested retail prices only. Please contact your nearest dealer for further details.
6. Measurement reflects 81.7 kg operator weight.
7. Security system includes immobiliser and siren.
8. Standard and optional wheels may vary by country and region.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
