2017 Husqvarna TX300 Review

2017 Husqvarna TX300 on www.Totalmotorcycle.com

The future 2-stroke…

Completely new for 2017, the TX 300 signifies the constant development and secure future of the historic 300cc 2-stroke in the Husqvarna off-road line-up. With a newly designed chassis based on the new generation 2016 FC and TC models, the TX 300 is a purpose-built closed course racing 2-stroke with off-road specific features. A larger fuel tank, an 18-inch rear wheel and a side-stand increase the ability and usability of the TX for its intended purpose. Additionally, the lightweight 2-stroke engine is efficienct, centralizes mass and features very little vibration thanks to a counter balancer shaft. As a result the TX 300 now offers a refined and manageable closed course racing package.






2017 Husqvarna TX300 www.Totalmotorcycle.com Key Features

Husqvarna Motorcycles has today officially unveiled their complete line-up of all-new enduro models at the historic brand’s homeland in Huskvarna, Sweden.

Embodying Husqvarna’s pioneering spirit, each of the enduro machines has been redesigned from the ground up for 2017. Featuring the most advanced technology they set the benchmark in terms of handling, power, weight and aesthetics.







2017 Husqvarna TX300 www.Totalmotorcycle.com Features and Benefits

Electric and kick start

The TX 300 is fitted with an electric starter located below the engine. This position ensures that the unit is always protected. Additionally, the system is powered by a lightweight and powerful Li-Ion battery which is 2.2 pounds lighter than a conventional battery. A standard kick starter is fitted as standard as a back up.

Standard off-road equipment

A large 2.65 gallon fuel tank gives the TX 300 the extra range needed for longer loops. The 6-speed semi-close transmission is perfectly suited for tackling the toughest off-road courses. The rear wheel is an 18-inch unit with Dunlop AT 81 off-road tires front and rear. A side stand completes the off-road transformation of the TX 300.

Wheels

Black high-strength alloy rims by DID are coupled to CNC machined hubs using lightweight spokes and silver anodised aluminium nipples.

Pro Taper handlebar

The Pro Taper handlebar is second to none for function and style. Manufactured to exacting standards, the Pro Taper handlebar features class-leading fatigue resistance while adding minimal weight. The Pro Taper logos are chemically applied and are scratch and peel resistant. The large Husqvarna bar pad has optimal impact resistance, while the standard handguards offer maximum roost protection.

Brembo brakes

Class-leading Brembo calipers and controls with high quality GSK discs deliver superior stopping power instilling confidence in any condition. 260mm disc front and 220mm rear.

Magura hydraulic clutch

The reliable, high quality, German-made clutch system guarantees even wear, near maintenance-free operation and perfect modulation in every condition. Meaning that play is constantly compensated so that the pressure point and function of the clutch remain identical in cold or hot conditions, as well as over time.

Self cleaning footpeg mount

The Husqvarna frame features an innovative, self -cleaning footpeg mount which prevents the build-up of dirt collected through deep ruts or muddy terrain. As a result, the footpeg will spring back into its original position even in the toughest conditions. For riders who prefer a higher footpeg set-up, the MY17 enduro footpegs can be fitted raising the position by 6mm.

Chromoly steel frame

The hydro-formed, laser-cut and robot-welded frame expertly crafted by WP Performance Systems is specifically designed with calculated parameters of longitudinal and torsional flex which best benefit handling and suspension functionality. The frame is finished off with a premium white powder coating and standard frame protectors guaranteeing supreme protection and durability.

Composite carbon fibre subframe

The composite subframe is a design unique to Husqvarna showcasing pioneering technologies and innovation. This 3 piece component is made up of 30% carbon fiber making it remarkably light (3.1 lbs.) and also particularly strong. Specific care is taken to create a certain rigidity for optimal handling and rider ergonomics.

WP AER 48

The 48 mm split air fork features an insulated air spring and pressurized oil chamber for progressive and consistent damping. The new component is lightweight and easily adjustable via a single air pressure valve for pre-load (on the left leg) as well as easy access clickers adjusting damping with 30 clicks (on the right leg). Additionally, the air pump needed to adjust air pressure in the fork will be provided as standard.

WP rear shock

The WP DCC rear shock is designed to provide advanced damping characteristics while conforming to a compact and lightweight design. With a pressure balance inside the shock, damping is improved resulting in greater rider comfort and handling while the outer contour of the reservoir increases cooling. The component is also fully adjustable and matched to a linkage system with a specific geometry to deliver the best possible traction and progression with a rear wheel travel of 300 mm.

Engine

The 300cc 2-stroke engine has for long been the best combination of unsurpassed power and lightweight construction. The simplicity and low maintenance cost of the 2-stroke motor has made it a favorite amongst riders for generations. The TX 300 features an advanced construction with shaft arrangements aimed at centralizing oscillating mass. A counter balancer shaft reduces vibration while a twin-valve controlled power valve ensures optimal performance.

Transmission

A 6-speed semi-close ratio gearbox compliments the off-road usage of the TX 300. An innovative shift lever reduces dirt build up guaranteeing easy operation in even the toughest conditions.

Crankcases

The TX 300 engine is designed with mass centralization as a key theme. As a result the lightweight, die-cast engine cases are developed to accommodate the specific location of shaft arrangements. Additionally the counter balancer shaft is integrated in a very compact manner having little affect on the compact design.

Carburettor

The TX 300 features a 38mm flat slide Mikuni TMX carburettor. This carburettor provides a smooth and controllable power delivery with optimal performance over the entire RPM range. Additionally, the carburettor has minimal sensitivity to changes in temperature and altitude which reduces the need for setting changes in different conditions.




2017 Husqvarna TX300 – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: See dealer for Pricing in USD

Engine
Design 1-cylinder, 2-stroke engine
Displacement 293.2 cm³
Bore 72 mm
Stroke 72 mm
Starter Kick and electric starter
Transmission 6-speed
Primary drive 26:73
Secondary gear ratio 13:50
Clutch Wet, multi-disc clutch, Magura hydraulics
EMS Kokusan

Chassis
Frame design 25CrMo4 steel central-tube frame
Front suspension WP-USD, AER 48, Ø 48 mm
Rear suspension WP shock absorber with linkage
Suspension travel (front) 310 mm
Suspension travel (rear) 300 mm
Front brake Brembo twin-piston floating calliper, brake disc
Rear brake Brembo single-piston floating calliper, brake disc
Front brake disc diameter 260 mm
Rear brake disc diameter 220 mm
Chain 5/8 x 1/4″
Steering head angle 63.9 °
Wheelbase 1485 ± 10 mm
Ground clearance 370 mm
Seat height 960 mm
Tank capacity (approx.) 10 l
Weight without fuel 98.4 kg








2017 Husqvarna TX300 – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: See dealer for pricing in CDN

Engine
Design 1-cylinder, 2-stroke engine
Displacement 293.2 cm³
Bore 72 mm
Stroke 72 mm
Starter Kick and electric starter
Transmission 6-speed
Primary drive 26:73
Secondary gear ratio 13:50
Clutch Wet, multi-disc clutch, Magura hydraulics
EMS Kokusan

Chassis
Frame design 25CrMo4 steel central-tube frame
Front suspension WP-USD, AER 48, Ø 48 mm
Rear suspension WP shock absorber with linkage
Suspension travel (front) 310 mm
Suspension travel (rear) 300 mm
Front brake Brembo twin-piston floating calliper, brake disc
Rear brake Brembo single-piston floating calliper, brake disc
Front brake disc diameter 260 mm
Rear brake disc diameter 220 mm
Chain 5/8 x 1/4″
Steering head angle 63.9 °
Wheelbase 1485 ± 10 mm
Ground clearance 370 mm
Seat height 960 mm
Tank capacity (approx.) 10 l
Weight without fuel 98.4 kg






2017 Husqvarna TX300 – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)

Engine
Design 1-cylinder, 2-stroke engine
Displacement 293.2 cm³
Bore 72 mm
Stroke 72 mm
Starter Kick and electric starter
Transmission 6-speed
Primary drive 26:73
Secondary gear ratio 13:50
Clutch Wet, multi-disc clutch, Magura hydraulics
EMS Kokusan

Chassis
Frame design 25CrMo4 steel central-tube frame
Front suspension WP-USD, AER 48, Ø 48 mm
Rear suspension WP shock absorber with linkage
Suspension travel (front) 310 mm
Suspension travel (rear) 300 mm
Front brake Brembo twin-piston floating calliper, brake disc
Rear brake Brembo single-piston floating calliper, brake disc
Front brake disc diameter 260 mm
Rear brake disc diameter 220 mm
Chain 5/8 x 1/4″
Steering head angle 63.9 °
Wheelbase 1485 ± 10 mm
Ground clearance 370 mm
Seat height 960 mm
Tank capacity (approx.) 10 l
Weight without fuel 98.4 kg
