2017 Hyosung GD250R Review

2017 Hyosung GD250R

2017 Hyosung GD250R

2017 Hyosung GD250R

2017 Hyosung GD250R

2017 Hyosung GD250R

2017 Hyosung GD250R Review

2017 Hyosung GD250R on www.Totalmotorcycle.com

The new Hyosung GD250R – innovative e-mobility on two wheels…

Coming soon from Korea is an all new 250cc platform, the GD250 series, which will feature a naked and sport version. The GD250 is a lightweight, nimble street bike allowing all riders (beginners and experienced) to experience the true essence of sport riding

2017 Hyosung GD250R www.Totalmotorcycle.com Key Features

Character

– True sports
– EZ-suit system

Key factors of design

– The essence of sports motorcycle
– Changeable position to suit various lifestyles

2017 Hyosung GD250R www.Totalmotorcycle.com Features and Benefits

EZ-suit system. (Switchable riding position to suit various lifestyles.)

Super sports position
– Focus on sports riding.
– Excellent controllability.

Street sports position
– Focus on daily street riding.
– Excellent accessibility.

Layout (Mass centralization – to the center of gravity of vehicle)

– Engine is located near in the steering head.
– Fuel tank is located near in the COG.
– Muffler is located below the swingarm pivot.
– Electric equipment unit is located near in the steering head.

Frame

– X-5’s steel tubular trellis frame is designed to connect directly between the steering head and
pivot. Its compact size reduces weight while enhancing the rigidity of the frame.

– X-5 is equipped with a long 553mm swingarm coupled with the short 1340mm wheelbase.
These features combine to provide a dynamic steering characteristic and constant movement of the
suspension.

Muffler

– Silencer located below the swingarm pivot which improves mass centralization.
Centralized muffler having optimized center of gravity gives X-5 more active handling.

Fuel tank

– Fuel tank located near in the COG. which improves weight centralization.
– Fuel tank is tilted toward swingarm pivot, the fuel always gathers around the center of gravity.
This feature provides natural steering character by reducing the amount of front / rear weight transfer.
– Fuel tank is made from plastic for weight reduction.

Brake

– F : Ø 300mm single disc, opposed 4 piston caliper.
– R : Ø 230mm single disc, opposed 2 piston caliper.

Suspension

– F : Ø 37mm upside down telescopic fork (120mm travel)
– R : Dual side Aluminum Swing arm with Gas charged Hydraulic shock absorber
(Nonstep Preload adjustable)
– The monocross shock absorber is laterally mounted because this solution frees up space to the
centrally located fuel tank, allowing perfectly symmetrical weight distribution.
The lateral shock absorber is pivoted directly on the swingarm.

Electric equipment unit box

– Electric equipment unit box is located at the top of the cylinder head. It contains battery, ECU,
relay, fuse, regulator, sensor, etc.
– This unit construction improves maintainability while reducing weight by shortening the harness
and reducing the number of brackets.

2017 Hyosung GD250R – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $4099 USD

Chassis Type Liquid cooled DOHC 4-valve Single cylinder
Displacement 249cc
Bore x Stroke 73 x 59.6
Compression Ratio 12 : 1
Max Power 28.4 HP
Fuel System Fuel injection
Lubrication Wet sump
Clutch Wet, Multiplate
Gear Constant mesh, Close ratio 6-speed (1down 5up)
Final Drive Chain
Frame Type Steel tubular trellis perimeter main frame & Steel tubular assembly sub frame
Overall Length 76.25 in
Overall Height 43.30 in
Overall Width 27.55 in
Wheel Base 52.99 in
Ground Clearance 5.31 in

Engine Seat Height 31.1 in
Caster 23.5 º
Trail 93.6mm
Brake F: 300ø Petal shaped spoke mounted single disc, 4 opposed pistons caliper, Stainless mesh hose
Brake R: 230ø Petal shaped single disc, 2 opposed pistons caliper, Stainless mesh hose
Suspension F: 37ø Upside down Telescopic
Suspension R: Dual side Aluminum Swing arm with Gas charged Hydraulic shock absorber (Nonstep Preload adjustable)

Transmission Tire F: 110/70 R17 54S / R: 150/60 R17 66S
Fuel Tank Capacity 2.9 gal
Curb Weight 352 lbs

Warranty year 2 Year Limited – 1st year parts & labor; 2nd year parts only.

2017 Hyosung GD250R – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ CDN

Chassis Type Liquid cooled DOHC 4-valve Single cylinder
Displacement 249cc
Bore x Stroke 73 x 59.6
Compression Ratio 12 : 1
Max Power 28.4 HP
Fuel System Fuel injection
Lubrication Wet sump
Clutch Wet, Multiplate
Gear Constant mesh, Close ratio 6-speed (1down 5up)
Final Drive Chain
Frame Type Steel tubular trellis perimeter main frame & Steel tubular assembly sub frame
Overall Length 76.25 in
Overall Height 43.30 in
Overall Width 27.55 in
Wheel Base 52.99 in
Ground Clearance 5.31 in

Engine Seat Height 31.1 in
Caster 23.5 º
Trail 93.6mm
Brake F: 300ø Petal shaped spoke mounted single disc, 4 opposed pistons caliper, Stainless mesh hose
Brake R: 230ø Petal shaped single disc, 2 opposed pistons caliper, Stainless mesh hose
Suspension F: 37ø Upside down Telescopic
Suspension R: Dual side Aluminum Swing arm with Gas charged Hydraulic shock absorber (Nonstep Preload adjustable)

Transmission Tire F: 110/70 R17 54S / R: 150/60 R17 66S
Fuel Tank Capacity 2.9 gal
Curb Weight 352 lbs

Warranty year 2 Year Limited – 1st year parts & labor; 2nd year parts only.

2017 Hyosung GD250R – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)

ENGINE

Type Liquid cooled DOHC 4-valve Single cylinder
Displacement 249cc
Bore x Stroke 73 x 59.6
Compression Ratio 12 : 1
Max Power 21.2 kW (28.4 HP) @ 8500 RPM
Max Torque 26.1 Nm (2.56 kgf.m) @ 7000 RPM
Fuel System Fuel injection
Lubrication Wet sump

TRANSMISSION

Clutch Wet, Multiplate
Gear Constant mesh, Close ratio 6-speed (1down 5up)
Final Drive Chain

CHASSIS

Frame Type Steel tubular trellis perimeter main frame & Steel tubular assembly sub frame
Overall Length 1937mm
Overall Height 1100mm
Overall Width 700mm
Wheel Base 1346mm
Ground Clearance 135mm
Seat Height 810mm
Caster 23.5 °
Trail 93.6mm
Brake F: 300Ø Petal shaped spoke mounted single disc, 4 opposed pistons caliper, Stainless mesh hose
R: 230Ø Petal shaped single disc, 2 opposed pistons caliper, Stainless mesh hose
Suspension F: 37Ø Upside down Telescopic
R: Dual side Aluminum Swing arm with Gas charged Hydraulic shock absorber (Nonstep Preload adjustable)
Tyre F: 110/70 R17 54S / R: 150/60 R17 66S
Fuel Tank Capacity 11L
Curb Weight 155kg

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
