2017 Suzuki GSX-R750 Review

2017 Suzuki GSX-R750 on www.Totalmotorcycle.com

The Foundation for Today’s Sportbikes…

Three decades ago Suzuki revolutionized sport bikes with the introduction of the GSX-R750. Ever since then, the GSX-R750 has remained true to its original concept and championship-winning heritage. On the road or on the track, the GSX-R750 delivers a breathtaking combination of outstanding engine performance, crisp handling, compact size and light weight. Its secret is an unequaled pairing of 750cc performance with the lightweight, compact chassis of a 600cc Supersport, complemented by technologically advanced suspension front and rear. Try a GSX-R750 and you’ll quickly realize this motorcycle defines performance riding from the center of the sportbike class.

In 1985, Suzuki unleashed the GSX-R750 to the world, which would become the foundation for today’s sportbikes. With unmatched engineering feats in light weight frames and power, it made its race track debut with a stunning victory at The Le Mans 24-hour World Endurance Championships!

Suzuki has remained true to the GSX-R’s original concept with continued evolution for the GSX-R750. The GSX-R750 remains the best choice for riders who appreciate a state-of-the-art 750cc engine combined with the compactness of a GSX-R600cc Supersport. When you ride a GSX-R750 you experience the breathtaking combination of outstanding race winning heritage, engine performance, crisp handling, compact size and light weight. It’s a winning combination that allows any rider to experience the exhilarating rush any time, any place, anywhere.

Experience a breathtaking combination of outstanding engine performance, nimble handling, compact size and light weight. Experience the GSX-R750 – the latest version of The Original GSX-R, the best choice for riders who appreciate a state-of-the-art 750cc engine combined with the compactness of a 600cc Supersport.

2017 Suzuki GSX-R750 www.Totalmotorcycle.com Key Features

Fuel-injected 750cc, 4-cylinder, engine powers a balanced sportbike experience.

Suzuki Drive Mode Selector (S-DMS) lets the rider modify the power delivery.

Twin-spar aluminum frame and SHOWA big piston fork delivers extraordinary handling.

Twin Brembo Monobloc, radially mounted, front brakes deliver robust stopping power.

Race-ready, iconic GSX-R styling delivers sharp looks and an aerodynamic shape.

2017 Suzuki GSX-R750 www.Totalmotorcycle.com Features and Benefits

Engine Features
A 750cc, four-cylinder engine with a race-proven oversquare bore/stroke ratio provides exceptionally potent, high-revving performance.

Engine utilizes forged pistons, shot-peened conrods, chrome-nitride-coated upper compression and oil control rings, and pentagonal ventilation holes for outstanding engine performance.

Lightweight titanium-alloy valves are controlled by single valve spring to reduce mechanical losses.

Class leading Suzuki Dual Throttle Valve (SDTV) fuel injection system includes fine-spray 8-hole injectors, providing improved fuel atomization contributing to more complete combustion in the cylinder.

Advanced, MotoGP-developed transistorized ignition control circuit helps maintain more precise ignition timing across the range of engine temperatures.

Lightweight, durable forged pistons are designed with the Finite Element Method (FEM) and fatigue analysis technology and optimized camshaft profiles was developed using proven MotoGP racing technology.

A 4-into-1 stainless-steel exhaust system features a titanium muffler, which carries a Suzuki Exhaust Tuning (SET) valve. The system maximizes torque and improves throttle response, especially in the low-to-mid RPM range.

Suzuki Drive Mode Selector (S-DMS) offers push-button selection of two racing-developed engine control maps to suit road conditions and personal preference.

Suzuki Composite Electrochemical Material (SCEM) plated cylinders integrated into the upper crankcase helps reduce friction, improve heat transfer, increase durability and provide better ring seal.

TRANSMISSION Features
A six-speed close-ratio transmission features vertically staggered shafts to reduce overall engine length.

Race-proven back-torque-limiting clutch contributes to smoother downshifting and corner entry.

CHASSIS Features
Race-developed, lightweight Showa Big Piston front-Fork (BPF) delivers superb feedback and consistent performance.

Lightweight and compact: twin-spar aluminum cradle frame made of five cast sections and cast swingarm.

An electronically controlled steering damper provides lighter steering at lower speeds and more damping force at racetrack and highway speeds.

Front brakes feature fully floating 310mm discs and radial-mounted, four-piston Brembo monoblock calipers.

A single Showa rear shock features externally adjustable rebound and compression damping, along with adjustable ride height.

Additional Features
3-way adjustable footpegs, adjustable shift lever, and short fuel tank help compose a comfortable riding position.

Compact, lightweight instrument cluster with a built-in lap timer/stopwatch and programmable engine rpm indicators.

Analog tachometer. LCD readouts include speedometer, odometer, dual trip meter, reserve trip meter, clock, coolant temperature/oil pressure indicator, S-DMS and gear position indicators.

2017 Suzuki GSX-R750 – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $12299 USD

Engine
Engine 750cc, 4-stroke, liquid-cooled, DOHC
Bore x Stroke 70.0 mm x 48.7 mm (2.756 in x 1.917 in)
Compression Ratio 12.5 : 1
Fuel System Suzuki Fuel Injection
Starter Electric
Lubrication Wet sump
Drive Train
Transmission 6-speed constant mesh
Final Drive Chain, RK525ROZ5Y, 116 links
Chassis
Suspension Front Inverted Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Brembo, Disc, Twin
Brakes Rear Disc
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 180/55ZR17M/C (73W), tubeless
Fuel Tank Capacity 17.0 L (4.5 US gallons), 16.0 L (4.2 US gallons) CA model
Color Metallic Triton Blue, Glass Sparkle Black / Marble Daytona Yellow, Pearl Glacier White
Electrical
Ignition Electronic ignition (Transistorized)
Dimensions and Curb Weight
Overall Length 2030 mm (79.9 in)
Overall Width 710 mm (28.0 in)
Wheelbase 1390 mm (54.7 in)
Ground Clearance 130 mm ( 5.1 in)
Seat Height 810 mm (31.9 in)
Curb Weight 190 kg (419 lbs)
Warranty
Warranty
12 month unlimited mileage limited warranty.


Warranty
Warranty 12 month unlimited mileage limited warranty.
Tentative Specs *Tentative European model specs shown, US model specs may differ

2017 Suzuki GSX-R750 – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $ See Dealer for pricing in CDN

Engine FEATURES
Type 4-stroke, 4-cylinder, liquid-cooled, DOHC
Displacement 750cc
Bore x Stroke 70.0 mm x 48.7 mm
Compression Ratio 12.5 : 1
Fuel System Electronic Fuel Injection
Starter Electric
Lubrication Wet sump
Ignition Electronic ignition (Transistorized)
DRIVETRAIN FEATURES
Transmission 6-speed, constant mesh
Final Drive RK525ROZ5Y, 116 links, Chain
CHASSIS FEATURES
Suspension Front Inverted Telescopic, coil spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Brembo, Disc, Twin
Brakes Rear Disc
Tires Front 120/70ZR17M/C (58W), tubeless
Tires Rear 180/55ZR17M/C (73W), tubeless
Fuel Tank Capacity 17.0 L (4.5 US gal )
DIMENSIONs
Overall Length 2030 mm (79.9 in)
Overall Width 710 mm (28.0 in)
Overall Height 1135 mm (44.7 in)
Wheelbase 1390 mm (54.7 in)
Ground Clearance 130 mm ( 5.1 in)
Seat Height 810 mm (31.9 in)
Curb Weight 190 kg (419 lbs )
Warranty
Standard Warranty 12 Month unlimited mileage limited warranty

2017 Suzuki GSX-R750 – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £9999 GBP (On The Road inc 20% Vat)

Dimensions and Weights

Overall length: 2030mm (79.9in)
Overall width: 710mm (28in)
Overall height: 1135mm (44.7in)
Wheelbase: 1390mm (54.7in)
Seat height: 810mm (31.9in)
Kerb Mass: 190.0kg (418.9lbs)
Fuel capacity: 17.0litres (3.7 UK gallons)
Ground clearance: 130mm (5.1in)

Engine Specifications

Engine capacity: 750cc
Engine: 4-stroke, 4-cylinder, liquid-cooled, DOHC
Bore: 70.0mm x 48.7mm
Compression ratio: 12.5 : 1
Lubrication: Wet sump
Fuel system: Fuel Injection
Transmission: 6-speed constant mesh
Drive: chain
MPG: 53.95*
Power: 110.30kW @ 13200rpm (149.97ps)†
Torque: 86.30N.m @ 11200rpm (64.00lb.ft)†

Chassis Specification

Front suspension: Inverted telescopic, coil spring, oil damped
Rear suspension: Link type, coil spring, oil damped
Front brakes: Disc, twin
Rear brakes: Disc
Front tyres: 120/70ZR17M/C (58W) tubeless
Rear tyres: 180/55ZR17M/C (73W) tubeless

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
