2017 Victory Magnum X-1 Review

2017 Victory Magnum X-1 on www.Totalmotorcycle.com

LIMITED EDITION MODEL DESIGNED FOR SERIOUS MUSIC AND MOTORCYCLE FANS…

The 2017 Magnum® X-1 takes the stage powered by a 200-watt 10-speaker surround sound audio system. Loaded with custom features such as contrast-cut billet wheels – featuring a 21-inch front – a new custom paint scheme and LED lighting, this may be the only motorcycle on the market that attracts both custom motorcycle fans and concert groupies.

Sound is no barrier.

2017 Victory Magnum X-1 www.Totalmotorcycle.com
Key Features

Climb on and plug into 10 speakers blasting 200 watts powered by a 106 cubic
in V-Twin.

• Pearl White with Platinum Overlay & Electric Red Pinstripes
• 10-Speaker, 200-Watt Sound System
• 21-Inch Contrast-cut Billet Front Wheel
• LED Headlight

2017 Victory Magnum X-1 www.Totalmotorcycle.com
Features and Benefits

High Performance Audio

A ride on the Magnum® X-1 is measured in decibels. This bike boasts 10-Speakers
cranking out 200 Watts of booming audio.

21” BLACK BILLET WHEELS

These 21-inch Black Billet wheels play big and loud. They are machined from
a single block of aluminum, making them stronger, lighter, and more aggressive.

Led Headlights

Magnum® X-1 enjoys the LED limelight. This chrome LED headlight is 74%
brighter than halogen bulbs.

Paint

White-pearl paint with hand-applied electric-red pinstripes — Victory’s
boldest paint scheme ever — accented by blacked-out trim makes a perfect
encore.

2017 Victory Magnum X-1 – www.Totalmotorcycle.com
USA Specifications/Technical Details
US MSRP Price: Available in Pearl White with Platinum overlay and Electric
Red pinstriping ($24,499).

Specifications

Curb Weight 822 lbs / 373 kg
Displacement 106 ci / 1,731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Battery 12 volts / 18 amp hours
Charging System 48 amps max output
Compression Ratio 9.4:1
Cooling Air / oil
Drive/Driven Clutch Wet, multi-plate
Exhaust Split dual exhaust with crossover
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Transmission/Final Drive Carbon Fiber Reinforced Belt
Transmission/Primary Drive Gear drive with torque compensator
Transmission Type 6-speed overdrive constant mesh
Bore x Stroke (mm) 101 x 108 mm
Engine Type 4-stroke 50° V-Twin

Suspension

Front Suspension Inverted cartridge telescopic fork, 43 mm diameter, 5.1
in / 130 mm travel
Rear Suspension Single, mono-tube gas, cast aluminum with constant rate linkage,
4.4 in / 113 mm travel, air adjustable

Brakes

Brake System Type Conventional w/ ABS
Front Brakes Dual 300mm floating rotor with 4-piston calipers
Rear Brakes 300mm floating rotor with 2-piston caliper

Tires / Wheels

Front Tires 120/70R 21 Dunlop Elite 3
Front Wheel Billet 21 x 3.5″
Rear Tires 180/60R 16 Dunlop Elite 3
Rear Wheel Billet 16 x 5.0″

DIMENSIONS

Fuel Capacity (Litres) 5.8 gal / 22 ltr
GVWR 1,310 lbs / 594 kg
Ground Clearance 5.3 in / 135 mm
Rake/Trail 29° / 5.6 in / 142 mm
Seat Height 25.7 in / 654 mm
Wheelbase 65.7 in / 1670 mm
Overall Length (in./mm.) 104.6 in / 2,657 mm

Features

Color Swatch Pearl White w/Platinum Overlay & Electric Red Pinstripe

Colors (Base) Pearl White w/Platinum Overlay & Electric Red Pinstripe

2017 Victory Magnum X-1 – www.Totalmotorcycle.com
Canadian Specifications/Technical Details
Canada MSRP Price: $28,999 CDN

Dry Weight 822 lbs / 373 kg
Displacement 106 ci / 1,731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Transmission Type 6-speed overdrive constant mesh
Transmission/Primary Drive Gear drive with torque compensator
Transmission/Final Drive Carbon Fiber Reinforced Belt
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Exhaust Split dual exhaust with crossover
Drive/Driven Clutch Wet, multi-plate
Cooling Air / oil
Compression Ratio 9.4:1
Charging System 48 amps max output
Battery 12 volts / 18 amp hours
Bore x Stroke (mm) 101 x 108 mm
Engine Type 4-stroke 50° V-Twin

Suspension

Rear Suspension Single, mono-tube gas, cast aluminum with constant rate linkage,
4.4 in / 113 mm travel, air adjustable
Front Suspension Inverted cartridge telescopic fork, 43 mm diameter, 5.1 in
/ 130 mm travel

Brakes

Rear Brakes 300mm floating rotor with 2-piston caliper
Front Brakes Dual 300mm floating rotor with 4-piston calipers
Brake System Type Conventional w/ ABS

Tires / Wheels

Rear Wheel Billet 16 x 5.0″
Rear Tires 180/60R 16 Dunlop Elite 3
Front Wheel Billet 21 x 3.5″
Front Tires 120/70R 21 Dunlop Elite 3

DIMENSIONS

Wheelbase 65.7 in / 1670 mm
Seat Height 25.7 in / 654 mm
Rake/Trail 29° / 5.6 in / 142 mm
Ground Clearance 5.3 in / 135 mm
GCWR 1,310 lbs / 594 kg
Fuel Capacity (Litres) 5.8 gal / 22 ltr
Overall Length (in./mm.) 104.6 in / 2,657 mm

Features

Colors (Base) Pearl White w/Platinum Overlay & Electric Red Pinstripe

Color / Graphics Pearl White w/Platinum Overlay & Electric Red Pinstripe

2017 Victory Magnum X-1 – www.Totalmotorcycle.com
European Specifications/Technical Details
Europe/UK MSRP Price: £TBA GBP (On The Road inc 20% Vat)

TBA
