2018 Ducati SuperSport Review

2018 Ducati SuperSport

2018 Ducati SuperSport 2018 Ducati SuperSport 2018 Ducati SuperSport 2018 Ducati SuperSport

SPORT MAKE LIGHT.

2018 Ducati SuperSport REVIEW BY TOTAL MOTORCYCLE



Eye-catching, fun and versatile, the SuperSport is a sport-road bike that, wherever its ridden, channels the energy and excitement of sport riding. From weekend roads to everyday roads, from city streets to twisting country highways. With a comfortable riding position, a dry weight of just 184 kg and the impressive performance of the Testastretta 11° engine, every ride becomes an opportunity to indulge your sporting instinct. Wherever, whenever, the SuperSport makes every motorcyclist a real rider: whichever road you take, get ready to experience it as never before.

The Ducati SuperSport is the bike for those eager to ride sports-style on everyday roads. Fun and versatile with true Ducati sports styling and zest, the SuperSport makes riders feel like racers: every day.

The Ducati Design Center has come up with a dynamic, polished, visually compact, light machine with strong Panigale superbike overtones: a Ducati to the core. A lean and mean road machine, the SuperSport has an approachable feel thanks to easy handling, the confidence-inspiring Ducati Safety Pack (ABS Bosch + Ducati Traction Control), the awesome price-quality ratio of the equipment and the long maintenance intervals.

Agile on city streets, comfortable on the motorway and superlative on out-of-town twisties, the SuperSport is super-versatile. Relaxed rider and passenger positions, good airflow deflection from the height-adjustable Plexiglas screen and the mileage provided by the 16-litre fuel tank also make the Ducati SuperSport a cool companion on medium-distance rides.

The SuperSport range includes a SuperSport S version with fully adjustable Öhlins suspension, the Ducati Quick Shift up/down system and a rear seat cover: the latter are also available as accessories for the SuperSport.

Powering the SuperSport is a twin-cylinder 937 cm³ Testastretta 11° engine. This delivers 113 hp at 9,000 rpm and a full yet linear torque curve that peaks at 96.7 Nm at 6,500 rpm. Thanks to the three Riding Modes (Sport, Touring and Urban), the SuperSport’s temperament can be adapted to ensure maximum enjoyment whatever the riding conditions. Each Riding Mode can, of course, be customised, allowing the bike to be set up quickly to suit personal preferences and riding skills.

The SuperSport frame is the latest development of the famous Trellis design that exploits the engine as a load-bearing element. Compact, light and rigid, it plays a pivotal role in making the SuperSport swift at the drop-in, yet also an instinctual machine that can be ridden by everyone. Intelligent frame configuration has played a key role in keeping wet weight down to around 210 kg. Superb chassis geometry, above all the 1,478 mm wheelbase and 180/55 rear tyre, makes the SuperSport easy to handle on both city streets and mountain hairpins, maximising stability on bends and at speed.

As one would expect from Ducati, the SuperSport can be fitted with a full range of Ducati Performance accessories (some are included in the Sport, Touring and Urban packages) that let owners configure the bike to suit personal wants and needs.

Expert riders will appreciate the true sports personality of the SuperSport, its excellent road performance and an evident penchant for journeying and everyday use. Riders approaching the Ducati sports world for the first time will discover dazzling versatility, easy handling and, above all, the very essence of sports riding as Ducati sees it.





2018 Ducati SuperSport Totalmotorcycle.com Key Features

Ducati SuperSport

  • Colours o Ducati Red with Ducati Red frame and Matt Black wheels
  • Main equipment o 937 cm³ Testastretta 11° engine with 113 hp at 9,000 rpm and 96.7 Nm at 6,500 rpm

o Euro 4 emissions

o 2-1-2 exhaust system with lower pre-silencer and lateral silencer with stacked pipes

o Trellis frame with load-bearing engine

o Height-adjustable 2-position Plexiglas screen with 50 mm of travel

o 3-spoke wheels with Y-shaped spokes

o Pirelli Diablo Rosso III tyres, 120/70 ZR17 front and 180/55 ZR17 rear

o Fully adjustable 41 mm Marzocchi forks

o Sachs shock with adjustable spring pre-load and rebound damping

o Brembo front braking system with two 320 mm discs and M4.32 calipers

o Brembo PR18/19 front radial brake pump

o 3 Riding Modes (Sport, Touring, Urban)

o Ducati Safety Pack (ABS Bosch + Ducati Traction Control)

o Ready for Ducati Quick Shift (up/down)

o Headlight with LED Daytime Running Lights (DRL)

o Full-LCD instrumentation

o Under-seat waterproof USB port

o Ready to incorporate Ducati Multimedia System (DMS)





For the SuperSport, Ducati Performance has come up with a series of individually available packages and accessories to bring out the bike’s full versatility and customise it to suit individual taste. Both SuperSport versions can be enhanced with the Sport, Touring and Urban packages, which can also be mounted together.

The Sport pack includes:

o Carbon front mudguard

o Carbon fuel tank cover

o Articulated racing lever kit

o Billet aluminium covers for front and rear brake fluid reservoirs



The Touring pack (available starting from mid-2017) includes:

o Pair of semi-rigid side panniers

o Larger touring screen

o Heated grips



The Urban pack includes:

o Tank bag

o Rubber-lined rider and passenger footpegs



Individually available accessories not in the packages include:

o Ducati Performance type-approved exhaust by Akrapovic

o Titanium racing exhaust with twin under-seat pipes, Ducati Performance by Akrapovic

o Öhlins adjustable steering damper

o Brake lever hand guard

o Billet aluminium rear view mirror plugs

o Seat range: high (+ 20 mm), low (-20 mm) and sport

o Ducati Quick Shift up/down (for SuperSport version only)

o Rear seat cover (for SuperSport version only)

o Rear LED indicators

o Bluetooth module for Ducati Multimedia System (DMS)

o Range of carbon and billet aluminium components.









2018 Ducati SuperSport Totalmotorcycle.com Features and Benefits

Design

The Ducati Design Center has come up with a dynamic, polished, visually compact, light machine that is Ducati to the core.

A front-on look shows it has a distinct ‘family feel’ with the Panigale superbike. In addition to the highly distinctive LED Daytime Running Lights (DRL), the headlight’s low and high beam parabolas are positioned in the shadows of the assembly, almost hiding them from direct frontal view: just like those mounted on the top Ducati sports models.

Low-set, streamlined and assertive, the SuperSport nose fairing flows naturally into the steel fuel tank structure, carrying the colour scheme all the way into the well-designed cockpit that houses the LCD instrument panel. A sports-style Plexiglas screen with two different height settings ensures aerodynamically efficient airflow protection.

Seen side-on, the lines, proportions and volumes are typical of Ducati sports bikes, with the streamlined tail and sculpted tank playing a pivotal role. The latter is coupled to both the main and nose fairings by beefy buttresses that enclose the Trellis frame. Cut to reveal exhaust manifold and engine, the lower fairing is designed to be easy on the eye, a must on a Ducati SuperSport.

Ducati’s scrupulous attention to technical components is also seen in the compact, sports-style stacked dual-pipe side muffler. Shaping and low-slung design bring out the dynamism of the tail, leaving the rear wheel Y-spokes in clear view and providing plenty of room for side panniers (available as accessories).

The single seat, the rider and passenger areas of which are outlined by contrasting stitching and just a hint of a rider “backrest”, is comfortable for daily use yet also highly suited to sports riding. Seen from above, the tank and nose fairing form, together with seat shaping, that unmistakeable silhouette shared by the sportiest Ducati motorcycles.

Ergonomics

Utmost attention to the ergonomic triangle, aerodynamic protection and the rider’s freedom of movement has resulted in comfort, versatility and jaw-dropping sports handling. The rider zone of the one-piece seat is just 810 mm off the ground, allowing feet to be placed firmly on the ground. Handlebar height does not place undue strain on the wrists and foot peg positioning prevents knees becoming tired while maximising control. The height-adjustable Plexiglas screen can be set to two different positions over 50 mm of travel, ensuring adequate airflow protection even at motorway speeds; enhanced protection can be had by fitting the larger Plexiglas touring screen, available as an accessory. Comfortably separated rider and passenger footpegs and a snugly compact lateral silencer ensure maximum freedom of movement.

The benefits of the riding position are evident during both everyday and medium-length journeys and also ensure fun-packed sports riding.

The passenger section of the seat is well separated from the footpegs and features comfy padding. Long-distance comfort levels can be given a further boost by choosing a seat with extra padding from the broad accessory range; the latter also offers external passenger grab rails that give a more ergonomic grip compared to the standard under-seat ones.

Engine

The SuperSport is powered by a specially adapted version of the already renowned and appreciated 937 cm3 twin-cylinder Ducati Testastretta 11°. Euro 4-rated, it has four valves per cylinder, a secondary air system, liquid cooling, a 12.6:1 compression ratio and bore and stroke measurements of 94 and 67.5 mm respectively. Engine output amounts to a huge 113 hp at 9,000 rpm and a maximum torque of 96.7 Nm at 6,500 rpm.

On the SuperSport, the Testastretta 11° engine features crankcase and cylinder heads that have been redesigned to make the power unit a fully stressed part of the frame; further modifications include re-routing of the water through the heads and a specifically designed alternator cover to allow installation of the gear sensor. Large 53 mm throttle bodies – smoothly controlled by the full Ride-by-Wire system – allow the engine to gulp in the air-fuel mix. Moreover, this engine also features unprecedented control and injection systems.

Featuring ducts with an external diameter of 54 mm, the exhaust system has a 2-1-2 layout in which a lower pre-silencer is connected to a lateral silencer with two extremely compact stacked pipes.

Maintenance is as worry-free as it gets: the twin-cylinder engine has a service interval of 15,000 km (9,000 miles) or 12 months, with valve play inspection every 30,000 km (18,000 miles).

Engine power is transmitted via a 6-speed gearbox with a gear sensor specifically designed to enable the SuperSport range to be equipped with the cutting-edge Ducati Quick Shift (DQS) up/down unit, offered as standard on the SuperSport S series and available as an accessory for the SuperSport.

Featuring low-effort wire control, the clutch is of the oil-bath slipper type. The slipper function cuts in when the rear wheel exerts back-torque, reducing pressure on the discs to ensure vehicle stability during the aggressive downshifting that is typical of competitive riding.

Power and torque curves

With a torque curve that creates pulling power right across the rev range, the twin-cylinder Ducati Testastretta 11° engine offers a secure response to every twist of the throttle: a must on a bike mainly intended for road use.

At 3,000 rpm, some 80% of maximum torque is already at the rider’s fingertips: higher revs are met with a decisive, linear increase in torque, peaking at 96.7 Nm at 6,500 rpm. Beyond that threshold the torque curve slopes down gradually yet still remains above 90% with the revs at 9,000 rpm; the maximum power of 113 hp is delivered at around the same point, at 9,000 rpm.

On the road, the Testastretta 11° guarantees plenty of power throughout the rev range, meaning whip-like acceleration out of the corners, fewer gear changes and unparalleled riding enjoyment. Even on the road, riders can make full use of the bike’s 113 hp as the engine gives the reassuring sensation of total vehicle control.

Engine control and injection systems have been tweaked to make the most of the twin-cylinder’s innate characteristics, taking into account the likely usage of the SuperSport. Electronic throttle control ensures precise transmission of the rider’s wrist action to the engine; there follows a smooth, always-certain response that perfectly matches the SuperSport’s immense versatility.

Frame

The SuperSport makes excellent use of Trellis frame design developments that exploit the engine as a fully stressed element. Both cylinder heads are connected to the main steel frame: the seat sub-frame – again made of steel – is, instead, connected to only the vertical cylinder head. This configuration gives a highly compact, light frame of high torsional rigidity, just perfect for bringing out the SuperSport’s superb dynamic performance. Moreover, this frame-plus-engine load-bearing configuration helps keep wet weight down to around 210 kg.

Combined with a steering geometry that features a 24° rake and 91 mm trail, the 1,478 mm wheelbase gives the SuperSport lightness, excellent handling and superlative drop-in performance, maximising stability on corners and at speed. Those characteristics are also made evident – right from the first ride on the SuperSport – by the choice of rear tyre: the 180/55, in fact, does an impressive job of combining great handling with an optimised contact patch. Frame performance is also brought out by the 48° lean angle, ensuring limitless on-road fun.

Another source of SuperSport flair comes from the smartly designed forged aluminium handlebars, mounted on the top yoke, that leave the fork adjusters in view.

Featuring die cast aluminium supports, the footpegs are patterned to maximise grip. They can, however, be replaced with rubber-lined pegs more suitable for urban riding. Rider footpegs come complete with aluminium heel guards. Passenger pegs are directly connected to the rear sub-frame and can easily be removed to give the bike a racier look.

Underneath the seat there is, in addition to the tool kit, a convenient waterproof USB phone charger port.

Suspension

Like all true Ducati sports bikes, the SuperSport features adjustable suspension and a single-sided die cast swingarm that is light yet extremely rigid, giving the bike a decidedly technical, professional look.

Up front we have 43 mm Marzocchi forks with fully adjustable damping and pre-load. The rear features a Sachs monoshock – attached to the vertical cylinder at one end and the swingarm at the other – which allows for adjustment of spring pre-load and rebound damping.

The SuperSport S mounts a refined multi-adjustable Öhlins suspension set; up front the 48 mm TiN coated forks maximise smoothness while the rear has a fully adjustable Öhlins monoshock with integrated gas cartridge.

Tyres and wheels

The SuperSport features alloy wheels, with three aggressive-looking Y-shaped spokes, measuring 3.50 x 17 at the front and 5.50 x 17 at the rear. The wheels mount the Pirelli Diablo Rosso III tyres, 120/70 ZR 17 at the front and 180/55 ZR 17 at the rear. The Pirelli Diablo Rosso III – the direct successor of the Diablo Rosso II – gives even better sports handling and grip, raising road tyre performance to unprecedented levels. The Diablo Rosso III offers profiles, latest-generation materials, innovative construction, compounds and a tread pattern that stems directly from the Diablo Supercorsa, ensuring maximum yet long-lasting performance in terms of safety, consistent response and grip (also in the wet).

Braking system

The SuperSport braking system is, in terms of technical content and visual impact, very similar to those seen on the highest-performing sports models. At the front, radial monobloc Brembo M4-32 calipers – powered by a Brembo PR18/1 radial pump with separate reservoir and adjustable lever – squeeze two 320 mm discs. At the rear the SuperSport has a 245 mm disc gripped by a 2-piston Brembo caliper. The Brembo system offers powerful braking with excellent linearity between the applied force and actual braking. This translates into ready responsiveness, giving first-rate ‘fingertip feel’. The braking system is controlled by the Bosch 9MP ABS system with 3 mappings.

Ducati Quick Shifter (DQS) up/down

Ducati Quick Shift (DQS) up/down is a race-derived electronic system that lets riders up-change and down-change without using the clutch and without having to close the throttle to move up a gear. It consists of a two-way microswitch built into the linkage of the gear change lever; when actuated, it sends a signal to the ECU. The system works differently for upshifts and downshifts, integrating adjustment of spark advance and injection during upshifts with an auto-blipper function during downshifts. Extent and duration of system operation are designed to ensure seamless gear meshing under all riding conditions; during downshifts the system works in concert with the slipper clutch. Because upshifts can be made under full acceleration without using the clutch, precious fractions of a second that would otherwise be wasted in closing the throttle are gained: moreover, stability is improved as power delivery is absent for less time. Clutchless downshifting allows smooth gear engagement, letting riders focus their attention on braking and corner entry. This system not only enhances the thrill of sports riding: it also lends a welcome hand in city traffic or on winding roads requiring frequent gear changes. Ducati Quick Shift (DQS) up/down is fitted as standard on the SuperSport S and is available as an accessory for the SuperSport.

Ducati Safety Pack (DSP)

The SuperSport features a Ducati Safety Pack (DSP) that includes Bosch 9MP ABS and Ducati Traction Control (DTC). Together, they intensify dynamic performance, optimise control and ensure safety levels that are among the highest on the market.

Bosch ABS System

The SuperSport mounts a Brembo braking system controlled by the 9MP Bosch ABS multi-calibration system with internal pressure sensor. Bosch 9MP ABS prevents wheel lock and rear wheel lift-up, shortening braking distances and enhancing stability. Three-level adjustment allows users to switch from one level to another by selecting the desired Riding Mode: this ensures settings are optimal whatever the riding conditions. Level 1 is recommended for high-grip surfaces. In this configuration the Bosch ABS provides track-type performance, acting on the front wheel only and disengaging the rear wheel anti-lift function; level 1 is not the default setting in any Riding Mode but riders can associate it with the Riding Mode of their choice by entering the specific menu. At level 2 the Bosch ABS also acts on the rear wheel and the anti-lift function is engaged. Maximum braking and rear wheel lift control is obtained by setting the system to level 3. The Bosch ABS system can be switched off in any Riding Mode and will stay off until the next Key-On. Factory settings can be restored with ease via the “default” option.

Ducati Traction Control (DTC)

The DTC detects and subsequently controls any wheelspin, enhancing both bike performance and active safety. DTC has eight profiles or “levels of sensitivity”. Each is programmed with a different wheelspin tolerance that corresponds to progressive levels of riding skill and/or grip conditions (classified from one to eight). Level 1 reduces system intervention to a minimum, while level 8 maximises sensitivity. The SuperSport has an optimised DTC software version. This ensures a fluid response by intervening on spark advance only, reducing torque until full rear end grip is re-established. While Ducati sets DTC levels for each of the three Riding Modes, they can be individually personalised and saved to satisfy riders’ specific needs. The DTC function can be switched off in any Riding Mode and will then stay off until the next Key-On. Factory settings can be restored with ease via the “default” option.

Ducati Riding Modes

Ducati Riding Modes let riders choose between different engine parameter and electronic control settings to adapt the bike to individual riding styles and different road conditions. The SuperSport has three Riding Modes – Sport, Touring and Urban – each of which acts on the electronic Ride-by-Wire system (to modify power and delivery), on Bosch ABS and DTC levels and on DQS up/down activation. Riding Mode can be changed on the move simply by pressing the relative key. Personalisation of factory-set Riding Mode parameters, however, can only be done with the bike at standstill for safety reasons. Factory settings can easily be restored at any time via the “default” option.

Sport

Sport Riding Mode lets riders unleash the SuperSport’s full potential. The engine delivers 113 hp with direct Ride-by-Wire throttle twist response, DTC has a low setting (level 3), Bosch ABS is at level 2 and rear wheel lift-up prevention is set to medium. DQS is on.

Touring

Touring Riding Mode ensures an exceptional balance between performance and comfort. The engine delivers full power (113 hp), the Ride-by-Wire system responds progressively to throttle twist, DTC is set to medium (level 4) and Bosch ABS to level 3 to ensure maximum braking control and stability. DQS is on.

Urban

Urban Riding Mode has been designed for surfaces which afford little grip. Power is limited to 75 hp, the Ride-by-Wire system responds progressively to throttle twist, DTC intervenes more assertively (level 6) while Bosch ABS is kept at its level 3 setting. DQS is off.

LCD Instrumentation

Lights on the upper section of the compact SuperSport instrument panel show neutral, high beam and DRL info; further warning lights highlight ABS status, DTC status, DTC intervention, engine error (MIL), rev limit, oil pressure and fuel reserve situations. The lower section, which shows all the other data, includes an LCD display dominated by a semicircular rpm graphic that frames the speedometer.

Further on-display information includes: total distance ridden, trip1 and trip2, engine coolant temperature, ambient temperature, clock and DQS on/off status (where applicable). And the info just keeps on coming: fuel level, distance remaining, real-time fuel consumption, average fuel consumption, average speed and trip duration. Selected Riding Mode and corresponding ABS and DTC levels are shown at all times.

The LCD instrument panel is also ready to display info related to the Ducati Multimedia System (DMS); the latter lets riders connect their smartphones via the Bluetooth module (available as an accessory) and control some of its functions via the switchgears. The panel displays music player controls and earphone connection, incoming call and received message icons.

Headlights and indicators

The SuperSport headlight is the result of in-depth design work aimed at reinforcing the styling ties with the Panigale superbike and making the motorcycle immediately recognisable on the road. The front headlight features LED Day Time Running Lights (DRL), to ensure riders stay seen during the day, and eye-catching design to reinforce the ‘family feel’ with the Panigale. High and low beam headlight parabolas are artfully concealed in the shadows of the DRL assembly. Tail lights, plate lights and the front indicators embedded in the rear-view mirrors are all of the LED type, while the bulb-lit rear indicators can be replaced with LED versions available as accessories.













2018 Ducati SuperSport – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $12,995 USD



Ducati SuperSport Ducati SuperSport S
Engine Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled
Displacement 937 cm³ 937 cm³
Bore X stroke 94 x 67.5 mm (3.7 x 2.66 in) 94 x 67.5 mm (3.7 x 2.66 in)
Compression ratio 12.6± 0.5 :1 12.6± 0.5 :1
Power 83.1 kW (113 hp) @ 9,000 rpm 83.1 kW (113 hp) @ 9,000 rpm
Torque 96.7 Nm (71.3 lb-ft) @ 6,500 rpm 96.7 Nm (71.3 lb-ft) @ 6,500 rpm
Fuel injection Continental electronic fuel injection system, 53 mm Mikuni throttle bodies with full Ride-by-Wire Continental electronic fuel injection system, 53 mm Mikuni throttle bodies with full Ride-by-Wire
Exhaust Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers
Gearbox 6 speed 6 speed
Primary drive Straight cut gears; Ratio 1.84:1 Straight cut gears; Ratio 1.84:1
Ratio 1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24 1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24
Final drive Chain; Front sprocket 15; Rear sprocket 43 Chain; Front sprocket 15; Rear sprocket 43
Clutch Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run
Frame Tubular steel Trellis frame attached to the chylinders head Tubular steel Trellis frame attached to the chylinders head
Front suspension Fully adjustable 43mm (1.7 in) usd Marzocchi forks Fully adjustable 48mm (1.9 in) usd Ohlins forks
Front wheel Y shaped, 3-spoke in light alloy 3.50″ x 17″ Y shaped, 3-spoke in light alloy 3.50″ x 17″
Front tyre Pirelli Diablo Rosso III 120/70 ZR17 Pirelli Diablo Rosso III 120/70 ZR17
Rear Suspension Progressive linkage with adjustable Sachs monoshock. Aluminium single-sided swingarm Progressive linkage with fully adjustable Ohlins monoshock. Aluminium single-sided swingarm
Rear Wheel Y shaped, 3-spoke in light alloy 5.50″ x 17″ Y shaped, 3-spoke in light alloy 5.50″ x 17″
Rear tyre Pirelli Diablo Rosso III 180/55 ZR17 Pirelli Diablo Rosso III 180/55 ZR17
Wheel travel (front/rear) 130/144 mm (5.12/5.67 in) 130/144 mm (5.12/5.67 in)
Front brake 2 x 320 mm (12.6 in) semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-piston, radial pump with ABS as standard 2 x 320 mm (12.6 in) semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-piston, radial pump with ABS as standard
Rear brake 245 mm (9.6 in) disc, 2-piston caliper, ABS as standard 245 mm (9.6 in) disc, 2-piston caliper, ABS as standard
Instrumentation LCD display LCD display
Dry weight 184 kg (406 lb) 184 kg (406 lb)
Kerb weight 210 kg (463 lb) 210 kg (463 lb)
Seat height 810 mm (31.9 in) 810 mm (31.9 in)
Wheelbase 1478 mm (58.2 in) 1478 mm (58.2 in)
Rake 24° 24°
Front wheel trail 91 mm (3.6 in) 91 mm (3.6 in)
Fuel tank capacity 16 l (4.2 US gal) 16 l (4.2 US gal)
Number of seats 2 2
Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC), RbW. Ready for anti-theft system Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC), RbW, DQS, seat cover. Ready for anti-theft system
Warranty (months) 24 months unlimited mileage 24 months unlimited mileage
Maintenance (km/months) 15,000 km (9,000 mi) or 12 months 15,000 km (9,000 mi) or 12 months
Valve clearance adjustment 30,000 km (18,000 mi) 30,000 km (18,000 mi)
Euro 4 Euro 4
The power values indicated above are measured using a chassis dynamometer. Homologated power data, as quoted in the Bike Registration Document, are measured using an engine dynamometer according to the homologation regulation. The two power values may differ because of the different measurement equipments.









2018 Ducati SuperSport – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $14,495 CDN



Ducati SuperSport Ducati SuperSport S
Engine Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled
Displacement 937 cm³ 937 cm³
Bore X stroke 94 x 67.5 mm (3.7 x 2.66 in) 94 x 67.5 mm (3.7 x 2.66 in)
Compression ratio 12.6± 0.5 :1 12.6± 0.5 :1
Power 83.1 kW (113 hp) @ 9,000 rpm 83.1 kW (113 hp) @ 9,000 rpm
Torque 96.7 Nm (71.3 lb-ft) @ 6,500 rpm 96.7 Nm (71.3 lb-ft) @ 6,500 rpm
Fuel injection Continental electronic fuel injection system, 53 mm Mikuni throttle bodies with full Ride-by-Wire Continental electronic fuel injection system, 53 mm Mikuni throttle bodies with full Ride-by-Wire
Exhaust Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers
Gearbox 6 speed 6 speed
Primary drive Straight cut gears; Ratio 1.84:1 Straight cut gears; Ratio 1.84:1
Ratio 1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24 1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24
Final drive Chain; Front sprocket 15; Rear sprocket 43 Chain; Front sprocket 15; Rear sprocket 43
Clutch Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run
Frame Tubular steel Trellis frame attached to the chylinders head Tubular steel Trellis frame attached to the chylinders head
Front suspension Fully adjustable 43mm (1.7 in) usd Marzocchi forks Fully adjustable 48mm (1.9 in) usd Ohlins forks
Front wheel Y shaped, 3-spoke in light alloy 3.50″ x 17″ Y shaped, 3-spoke in light alloy 3.50″ x 17″
Front tyre Pirelli Diablo Rosso III 120/70 ZR17 Pirelli Diablo Rosso III 120/70 ZR17
Rear Suspension Progressive linkage with adjustable Sachs monoshock. Aluminium single-sided swingarm Progressive linkage with fully adjustable Ohlins monoshock. Aluminium single-sided swingarm
Rear Wheel Y shaped, 3-spoke in light alloy 5.50″ x 17″ Y shaped, 3-spoke in light alloy 5.50″ x 17″
Rear tyre Pirelli Diablo Rosso III 180/55 ZR17 Pirelli Diablo Rosso III 180/55 ZR17
Wheel travel (front/rear) 130/144 mm (5.12/5.67 in) 130/144 mm (5.12/5.67 in)
Front brake 2 x 320 mm (12.6 in) semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-piston, radial pump with ABS as standard 2 x 320 mm (12.6 in) semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-piston, radial pump with ABS as standard
Rear brake 245 mm (9.6 in) disc, 2-piston caliper, ABS as standard 245 mm (9.6 in) disc, 2-piston caliper, ABS as standard
Instrumentation LCD display LCD display
Dry weight 184 kg (406 lb) 184 kg (406 lb)
Kerb weight 210 kg (463 lb) 210 kg (463 lb)
Seat height 810 mm (31.9 in) 810 mm (31.9 in)
Wheelbase 1478 mm (58.2 in) 1478 mm (58.2 in)
Rake 24° 24°
Front wheel trail 91 mm (3.6 in) 91 mm (3.6 in)
Fuel tank capacity 16 l (4.2 US gal) 16 l (4.2 US gal)
Number of seats 2 2
Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC), RbW. Ready for anti-theft system Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC), RbW, DQS, seat cover. Ready for anti-theft system
Warranty (months) 24 months unlimited mileage 24 months unlimited mileage
Maintenance (km/months) 15,000 km (9,000 mi) or 12 months 15,000 km (9,000 mi) or 12 months
Valve clearance adjustment 30,000 km (18,000 mi) 30,000 km (18,000 mi)
Euro 4 Euro 4
The power values indicated above are measured using a chassis dynamometer. Homologated power data, as quoted in the Bike Registration Document, are measured using an engine dynamometer according to the homologation regulation. The two power values may differ because of the different measurement equipments.









2018 Ducati SuperSport – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £11,795 GBP (On The Road inc 20% Vat)



Ducati SuperSport Ducati SuperSport S
Engine Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled Testastretta 11°, L-Twin cylinder, 4 valve per cylinder, Desmodromic, liquid cooled
Displacement 937 cm³ 937 cm³
Bore X stroke 94 x 67.5 mm (3.7 x 2.66 in) 94 x 67.5 mm (3.7 x 2.66 in)
Compression ratio 12.6± 0.5 :1 12.6± 0.5 :1
Power 83.1 kW (113 hp) @ 9,000 rpm 83.1 kW (113 hp) @ 9,000 rpm
Torque 96.7 Nm (71.3 lb-ft) @ 6,500 rpm 96.7 Nm (71.3 lb-ft) @ 6,500 rpm
Fuel injection Continental electronic fuel injection system, 53 mm Mikuni throttle bodies with full Ride-by-Wire Continental electronic fuel injection system, 53 mm Mikuni throttle bodies with full Ride-by-Wire
Exhaust Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers Lightweight 2-1-2 system with catalytic converter and two lambda probes. Twin aluminium mufflers
Gearbox 6 speed 6 speed
Primary drive Straight cut gears; Ratio 1.84:1 Straight cut gears; Ratio 1.84:1
Ratio 1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24 1=37/15 2=30/17 3=28/20 4=26/22 5=24/23 6=23/24
Final drive Chain; Front sprocket 15; Rear sprocket 43 Chain; Front sprocket 15; Rear sprocket 43
Clutch Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run Wet multiplate clutch mechanically operated, self-servo action on drive, slipper action on over-run
Frame Tubular steel Trellis frame attached to the chylinders head Tubular steel Trellis frame attached to the chylinders head
Front suspension Fully adjustable 43mm (1.7 in) usd Marzocchi forks Fully adjustable 48mm (1.9 in) usd Ohlins forks
Front wheel Y shaped, 3-spoke in light alloy 3.50″ x 17″ Y shaped, 3-spoke in light alloy 3.50″ x 17″
Front tyre Pirelli Diablo Rosso III 120/70 ZR17 Pirelli Diablo Rosso III 120/70 ZR17
Rear Suspension Progressive linkage with adjustable Sachs monoshock. Aluminium single-sided swingarm Progressive linkage with fully adjustable Ohlins monoshock. Aluminium single-sided swingarm
Rear Wheel Y shaped, 3-spoke in light alloy 5.50″ x 17″ Y shaped, 3-spoke in light alloy 5.50″ x 17″
Rear tyre Pirelli Diablo Rosso III 180/55 ZR17 Pirelli Diablo Rosso III 180/55 ZR17
Wheel travel (front/rear) 130/144 mm (5.12/5.67 in) 130/144 mm (5.12/5.67 in)
Front brake 2 x 320 mm (12.6 in) semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-piston, radial pump with ABS as standard 2 x 320 mm (12.6 in) semi-floating discs, radially mounted Monobloc Brembo M4-32 callipers, 4-piston, radial pump with ABS as standard
Rear brake 245 mm (9.6 in) disc, 2-piston caliper, ABS as standard 245 mm (9.6 in) disc, 2-piston caliper, ABS as standard
Instrumentation LCD display LCD display
Dry weight 184 kg (406 lb) 184 kg (406 lb)
Kerb weight 210 kg (463 lb) 210 kg (463 lb)
Seat height 810 mm (31.9 in) 810 mm (31.9 in)
Wheelbase 1478 mm (58.2 in) 1478 mm (58.2 in)
Rake 24° 24°
Front wheel trail 91 mm (3.6 in) 91 mm (3.6 in)
Fuel tank capacity 16 l (4.2 US gal) 16 l (4.2 US gal)
Number of seats 2 2
Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC), RbW. Ready for anti-theft system Riding Modes, Power Modes, Ducati Safety Pack (ABS + DTC), RbW, DQS, seat cover. Ready for anti-theft system
Warranty (months) 24 months unlimited mileage 24 months unlimited mileage
Maintenance (km/months) 15,000 km (9,000 mi) or 12 months 15,000 km (9,000 mi) or 12 months
Valve clearance adjustment 30,000 km (18,000 mi) 30,000 km (18,000 mi)
Euro 4 Euro 4
The power values indicated above are measured using a chassis dynamometer. Homologated power data, as quoted in the Bike Registration Document, are measured using an engine dynamometer according to the homologation regulation. The two power values may differ because of the different measurement equipments.







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).

About Michael Le Pard 872 Articles

“Mr. Totalmotorcycle”. Owner and Founder of Total Motorcycle. Supporting Motorcyclists and Motorcycling for 18 great years.

Be the first to comment

Leave a Reply
