2018 Kawasaki KLX140G Review

2018 Kawasaki KLX140G
2018 Kawasaki KLX140G

2018 Kawasaki KLX140G

2018 Kawasaki KLX140G

2018 Kawasaki KLX140G

2018 Kawasaki KLX140G



The KLX®140G motorcycle is over 30 pounds lighter than all other competitors*, offering confidence-inspiring performance in an easy-to-ride package. This off-road motorcycle features full-size wheels, comfortable ergonomics and light, nimble handling that is appreciated by riders of all skill levels. This combination allows riders to focus on fun, while the dependability and low-maintenance of the KLX140G make it the ultimate companion on the trail.​​​​​

The KLX140G offers a comfortable fit and a reliable, confidence-inspiring ride with larger wheels that’s ideal for off-road adventures. Light overall weight and roomy ergonomics make learning easier, allowing riders to focus on fun, while the dependability and low-maintenance of the KLX140G make it the ultimate companion on the trail.



2018 Kawasaki KLX140G Totalmotorcycle.com Key Features


 The Kawasaki KLX® family of off-road motorcycles are widely popular for their low maintenance, easy-to-ride character, and incredible capabilities while on trails. The five models consist of two engine configurations and are built to suit a variety of riders.

The same team that developed the championship winning Kawasaki KX™ family has engineered the KLX models, injecting the model range with a performance racing heritage and unmatched durability, ensuring all-day enjoyment with family and friends.





2018 Kawasaki KLX140G Totalmotorcycle.com Features and Benefits


The KLX®140 motorcycle is available in three model variations, and is designed to provide a natural terrain experience with memories to last a lifetime. The powerful 144cc, 4-stroke, air-cooled, single-cylinder engine features an electric starter and keyless ignition. Its broad and smooth high-revving 144cc engine utilizes a manual clutch and 5-speed transmission to offer an efficient and user-friendly feel. The clutch features a spring damper resulting in a progressive, 2-stage engagement that facilitates half-clutch use when riding at extremely low rpm or idling speeds.

The chassis consists of a rigid box section steel perimeter frame that is shared on each of the models for excellent handling characteristics, as well as a lightweight aluminum swingarm. Up front you’ll find 33mm telescopic front forks, which offer 7.1” of travel on the KLX140 and KLX®140L models, and 7.5” on the KLX®140G. On the KLX140, the single rear shock has fully adjustable preload and is held up by a Uni-Trak® rear linkage, while the KLX140L and KLX140G also feature 22-way rebound and 14-way compression damping adjustment. Additional travel can be found on the rear of the KLX140G (7.9” compared to 7.1” on the KLX140 and KLX140L).

Showing the KX™ heritage, a large 220mm petal-shaped front rotor with a twin-piston caliper and a 186mm petal-shape rear rotor provide plenty of stopping power. The KX influence continues with the wheels, which have strong die-cast hubs and lightweight aluminum rims. The KLX140 uses a 17” front and 14” rear wheel, while the mid-sized KLX140L motorcycle is equipped with a 19” front and 16” rear wheels to accommodate taller riders, providing extra ground clearance on the KLX140L. The KLX140G comes equipped with full-size off-road wheels and tires, using a 21” front and 18” rear.

With three different models to choose from, riders can easily select the bike that best suits their stature, starting with the KLX140’s 30.7” seat height and slightly larger KLX140L (31.5”). The  KLX140G motorcycle is the perfect fit for taller riders who want to experience the KLX lineup, thanks to its 33.9” seat height and spacious ergonomics.




2018 Kawasaki KLX140G – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $3699 USD



4-stroke, 1-cylinder, SOHC, air-cooled





Bore x Stroke

58.0 x 54.4mm


Compression ratio



Fuel System

Keihin PB20



Digital DC-CDI



5-speed, return shift


Final Drive




Front Suspension / Wheel Travel

33mm telescopic fork/7.5 in


Rear Suspension / Wheel Travel

Uni-Trak® linkage system and single shock with piggyback reservoir, fully adjustable preload and 22-way rebound damping/7.9 in


Front Tire



Rear Tire



Front Brakes



Rear Brakes




Frame Type

Tube, semi-double cradle



27°/4.6 in


Overall Length

78.9 in


Overall Width

31.1 in


Overall Height

44.7 in


Ground Clearance

12.4 in


Seat Height

33.9 in


Curb Weight

218.2 lb**


Fuel Capacity

1.5 gal



52.4 in


Color Choices

Lime Green



6 Months


Kawasaki Protection Plus™ (optional)

12, 24, or 36 months




2018 Kawasaki KLX140G – Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $4299 CDN


Type4-stroke, Single
Bore and stroke58.0 x 54.4 mm
Compression ratio9.5:1
Valve systemSOHC, 2 valves, screw type adjusters
Fuel systemKeihin PB20 carburetor
IgnitionDigital DC-CDI
LubricationForced lubrication (wet sump)


Front: typeSingle 220 mm petal disc
Front: calipersDual-piston caliper
Rear: typeSingle 190 mm petal disc
Rear: calipersSingle-piston caliper


Overall length2,005 mm
Overall width790 mm (31.1 in.)
Overall height1,135 mm
Wheelbase1,330 mm
Ground clearance315 mm
Seat height860 mm
Curb mass**99 kg
Fuel capacity5.8 litres (1.3 gal.)


Final driveChain
Primary reduction ratio2.880 (72/25)
Gear ratio: 1st2.667 (40/15)
Gear ratio: 2nd1.895 (36/19)
Gear ratio: 3rd1.474 (28/19)
Gear ratio: 4th1.182 (26/22)
Gear ratio: 5th1.000 (24/24)
Final reduction ratio4.385 (57/13)
ClutchWet multi-disc, manual, cable operation


TypeBox section perimeter, high-tensile steel
Wheel travel: front190 mm
Tire: front2.75-21 45M
Wheel travel: rear200 mm
Tire: rear4.10-18 59M
Caster (rake)27°
Trail116 mm


Suspension, front33 mm telescopic fork
Suspension, rearUni-Trak linkage system and single shock with piggyback reservoir, fully adjustable preload and rebound damping


Warranty6 months warranty




2018 Kawasaki KLX140G – Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)




Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
