2019 Harley-Davidson Fat Bob 114 Guide

2019 Harley-Davidson Fat Bob 114

2019 Harley-Davidson Fat Bob 114 2019 Harley-Davidson Fat Bob 114 2019 Harley-Davidson Fat Bob 114 2019 Harley-Davidson Fat Bob 114

MASSIVE TORQUE.

2019 Harley-Davidson Fat Bob 114:

From the modern, aggressive look of its 2-1-2 upswept exhaust and asphalt-devouring fat tires to the massive torque of the Milwaukee-Eight® 114 engine to the ride of the Softail® frame, to inverted front forks and easily adjustable rear suspension, the Fat Bob® 114 is built to shake up the status quo. This is for the rider that wants to break new ground at a high rate of speed.

2019 FAT BOB 114®

The Fat Bob® motorcycle features aggressive, unapologetic styling, mind-blowing performance and handling, premium finishes, and the massive torque of the Milwaukee-Eight® 114 engine.

BREAK NEW GROUND AT A HIGH RATE OF SPEED





2019 Harley-Davidson Fat Bob 114 Totalmotorcycle.com Key Features

SOFTAIL®

One look at the FXDR™ 114 is all it takes to see how far the Softail® family has come. It’s the latest in a new revolution of custom motorcycles we launched last year. With every Softail, you get a lighter frame, responsive new suspension, and the power of the Milwaukee-Eight® v-twin engine. In keeping with the custom tradition, each model has its own attitude and style. Ranging from the blacked-out nostalgia of the Heritage Classic to the futuristic edge of the Fat Bob® and FXDR 114 models. Find the one that fits your style. You’re in for one hell of a ride.

The FXDR™ 114 model combines the power of the Milwaukee-Eight® 114 engine with the latest Softail® frame and a cast aluminum swing arm rear suspension, breaking all-new ground for 2019.



Engine

  • Engine 1 Milwaukee-Eight® 114
  • Bore 4.016 in.
  • Stroke 4.5 in.
  • Displacement 1,868 cc (114 cu in)
  • Compression Ratio 10.5:1
  • Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-1-into-2 dual side; catalyst in header

Weight, As Shipped

653 lb.

Seat Height, Laden

27.7 in.





2019 Harley-Davidson Fat Bob 114 Totalmotorcycle.com Features and Benefits

Front tire on a 2019 Fat Bob Motorcycle
Inverted Forks

Inverted front forks deliver precise handling.

Break system on a 2019 Fat Bob Motorcycle
Dual Disc Front Brakes

The Milwaukee-Eight® engine is not short on power. And these high-performance dual disc brakes help you keep that power in check when you need to.

Exhaust on a 2019 Fat Bob Motorcycle
2-1-2 Exhaust

Big performance-inspired, upswept exhaust with a custom contrast finish.

Cast wheels on a 2019 Fat Bob Motorcycle
Cast Wheels with Fat Tires

Bold aluminum wheels with fat, aggressive tires that give you asphalt-eating traction.

Milwaukee-Eight Big Twin Engine on a 2019 Fat Bob Motorcycle
Milwaukee-Eight® Big Twin 114 Engine

A powerful, smooth-running engine with crisp throttle response and a pure, soul-satisfying rumble. Available in 107 and 114 engine displacements.

Headlight on a 2019 Fat Bob Motorcycle
LED Lighting

A bold headlight design that gives you great visibility at night and during the day makes sure all eyes are focused on you.

RACE-STYLE FORK TECHNOLOGY

Inverted race-style front fork design, with single-cartridge technology that improves response to steering input and braking and handling performance.





2019 Harley-Davidson Fat Bob 114 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $18849 – $19249
USD
Canada MSRP Price: $23599 – $24949 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

Pricing6

  • Vivid Black $18,849
  • Color $19,249
  • Two-Tone Custom Color $19,999
  • ABS Option Standard
  • Security System Option Standard
  • California Emissions $200
  • Freight $390

Engine

  • Engine 1 Milwaukee-Eight® 114
  • Bore 4.016 in.
  • Stroke 4.5 in.
  • Displacement 1,868 cc (114 cu in)
  • Compression Ratio 10.5:1
  • Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-1-into-2 dual side; catalyst in header

Dimensions

  • Length 92.1 in.
  • Seat Height, Laden 7 27.7 in.
  • Seat Height, Unladen 28 in.
  • Ground Clearance 4.7 in.
  • Rake (steering head) (deg) 28
  • Trail 5.2 in.
  • Wheelbase 63.6 in.
  • Tires, Front Specification 150/80-16,71H,BW
  • Tires, Rear Specification 180/70B16,77H,BW
  • Fuel Capacity 3.6 gal.
  • Oil Capacity (w/filter) 5 qt.
  • Weight, As Shipped 653 lb.
  • Weight, In Running Order 676 lb.

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque 2 118 ft-lb
  • Engine Torque (rpm) 3,500
  • Lean Angle, Right (deg.) 31
  • Lean Angle, Left (deg.) 32
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy 5 47 mpg

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type 9 Denim black, Structure cast aluminum with laser etched graphics
  • Wheels, Rear Type Denim black, Structure cast aluminum with laser etched graphics
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps 8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS, security, low battery voltage, low fuel
  • Gauges 4-inch analog tachometer with digital speedometer, gear, odometer, fuel level, clock, trip and range indication
2019 Harley-Davidson Fat Bob 114 – Totalmotorcycle.com Canada Specifications/Technical Details

Pricing6

  • Vivid Black $ 23,599
  • Colour $ 24,049
  • Two Tone Custom Color $ 24,949
  • ABS Option Standard
  • Security System Option Standard

Engine

  • Engine 1 Milwaukee-Eight™ 114
  • Bore 102 mm
  • Stroke 114 mm
  • Displacement 1,868 cc
  • Compression Ratio 10.5:1
  • Fuel System 3 Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust 2-into-1-into-2 dual side; catalyst in header

Dimensions

  • Length 2,340 mm
  • Seat Height, Unladen 710 mm
  • Ground Clearance 120 mm
  • Rake (steering head) (deg) 28
  • Trail 132 mm
  • Wheelbase 1,615 mm
  • Tires, Front Specification 150/80-16,71H,BW
  • Tires, Rear Specification 180/70B16,77H,BW
  • Fuel Capacity 13.6 l
  • Oil Capacity (w/filter) 4.7 l
  • Weight, As Shipped 296 kg
  • Weight, In Running Order 306 kg

Performance

  • Engine Torque Testing Method J1349
  • Engine Torque 2 160 Nm
  • Engine Torque (rpm) 3,500
  • Lean Angle, Right (deg.) 31
  • Lean Angle, Left (deg.) 32
  • Fuel Economy: Estimated City/Hwy 5 5 l/100 km

Drivetrain

  • Primary Drive Chain, 34/46 ratio
  • Gear Ratios (overall) 1st 9.311
  • Gear Ratios (overall) 2nd 6.454
  • Gear Ratios (overall) 3rd 4.793
  • Gear Ratios (overall) 4th 3.882
  • Gear Ratios (overall) 5th 3.307
  • Gear Ratios (overall) 6th 2.79

Chassis

  • Wheels, Front Type 9 Denim black, Structure cast aluminum with laser etched graphics
  • Wheels, Rear Type Denim black, Structure cast aluminum with laser etched graphics
  • Brakes, Caliper Type 4-piston fixed front and 2-piston floating rear

Electric

  • Lights (as per country regulation), Indicator Lamps 8 High beam, turn signals, neutral, low oil pressure, engine diagnostics, ABS, security, low battery voltage, low fuel
  • Gauges 4-inch analog tachometer with digital speedometer, gear, odometer, fuel level, clock, trip and range indication



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
