EVERYTHING YOU NEED, NOTHING YOU DON’T.

2019 Harley-Davidson Iron 1200:

THE THRILL OF RIDING STRIPPED TO ITS BARE ESSENCE

The Iron 1200™ 1200cc Evolution® engine that gives loads of famous Sportster® torque. It’s got a throwback look that goes right to the roots of Sportster motorcycle, thanks to 70’s-inspired tank graphics. It also features a low-slung Café solo seat, mid-mount controls, and mini ape hanger handlebars for an aggressive, two-fists-in-the-wind riding position.

The Iron 1200 recipe starts with power. A 1202cc Evolution® 1200 V-Twin engine delivers 36 percent more torque (73.0 ft. lbs. vs. 53.8 ft. lb.) than the 883 Evolution engine that powers the Iron 883, the original urban brawler in the Sportster family. The Iron 1200 brings more punch to the street fight – more power to blast away from green lights and more mid-range to muscle through traffic. More power means more rowdy fun.

The satin-black Mini Ape handle bar is an essential element of the garage-built chopper look that adds instant attitude. This 1.0-inch diameter handlebar offers an 8.75-inch rise, 32-inch spread and 6.5-inch pull back, that opens the rider triangle with a fist-in-the-wind posture. The gloss black speed screen framing the headlamp is a West Coast styling influence that amplifies the attitude of the tall bars, is intended to offer some wind deflection at speed and provides a space for easy personalization. The fast-back Café Solo Seat flows to the rear fender and is shaped to help hold the rider in position when the torque of the Evolution 1200 kicks in.

A classic 3.3-gallon Sportster fuel tank features multi-colored striped graphics that wrap around the tank profile. The dark engine finish helps draw the eyes to the bright tank graphics. Fuel tank paint color options include Vivid Black, Twisted Cherry and Billiard White, always contrasting with the Vivid Black speed screen.

The entire powertrain has been styled with a popular color: black upper and lower rocker boxes, black exhaust and muffler shields, and black timer, primary and derby covers. Chrome pushrod tubes and tappet covers are the only brightwork and highlight the V-Twin engine shape. The Iron 1200 is finished with all-black 9-Spoke wheels (19-inch front and 16-inch rear diameter) and a solid black belt guard and rear sprocket.

The Harley-Davidson Smart Security System and anti-lock braking system (ABS) are factory-installed options for the Iron 1200 model.

2019 IRON 1200™

A modern take on what’s been putting big grins on the faces of Sportster® motorcycle riders for decades.

THROWBACK STYLING. THROW YOUR HEAD BACK POWER.

2019 Harley-Davidson Iron 1200 Totalmotorcycle.com Key Features

Engine

Air-cooled, Evolution®

Engine Torque

73 ft-lb

Weight, As Shipped

547 lb.

Seat Height, Laden

25.7 in.

2019 Harley-Davidson Iron 1200 Totalmotorcycle.com Features and Benefits

Evolution engine on a 2019 Iron 1200 motorcycle
1200cc Evolution® Engine

1200cc at your command to deliver tons of torque for an unforgettably fun ride.

blacked-out finish on a 2019 Iron 1200 motorcycle
Blacked-Out Finishes

Blacked-out finishes from its powertrain to its air cleaner cover to its exhaust. Equipped to take on the urban grid.

Art Gas tank on a 2019 Iron 1200 motorcycle
Throwback 70’s Custom Tank Art

Authentic bold 70’s-inspired tank graphic shows the bike’s retro roots.

Solo seat on a 2019 Iron 1200 motorcycle
Café Solo Seat

Sit “in” the bike while your hands and feet reach naturally to the controls. This seat pays homage to the heritage of the iconic Cafe Racer style.

Black handlebars on a 2019 Iron 1200 motorcycle
Black Mini-Ape Handlebars

Fists in the wind attitude with a conservative rise and bend for rider comfort.

Front aluminum wheel on a 2019 Iron 1200 motorcycle
9-Spoke Cast Aluminum Wheels

Nine-spoke wheels that are black as night from rim to rubber to complement the Dark Custom look.

FIXED SPEED SCREEN

The fixed black speed screen leaves no question as to the attitude of the motorcycle. Get behind it and hang on.

2019 Harley-Davidson Iron 1200 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9999 – $10349 USD
Canada MSRP Price: $11999 – 12399 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS

• Pricing⁶

  • Vivid Black $9,999
  • Color $10,349
  • ABS Option $795
  • Security System Option $395
  • California Emissions $100
  • Freight $360

  Engine

  • Engine ¹ Air-cooled, Evolution^®
  • Bore 3.5 in.
  • Stroke 3.8 in.
  • Displacement 1,202 cc (73.4 cu in)
  • Compression Ratio 10:01
  • Fuel System ³ Electronic Sequential Port Fuel Injection (ESPFI)
  • Exhaust Black, staggered exhaust and headers with black slash-cut mufflers

  Dimensions

  • Length 86 in.
  • Seat Height, Laden ⁷ 25.7 in.
  • Seat Height, Unladen 28.9 in.
  • Ground Clearance 5.5 in.
  • Rake (steering head) (deg) 30
  • Trail 4.6 in.
  • Wheelbase 59.6 in.
  • Tires, Front Specification 100/90B19 57H
  • Tires, Rear Specification 150/80B16 77H
  • Fuel Capacity 3.3 gal.
  • Oil Capacity (w/filter) 2.8 qt.
  • Weight, As Shipped 547 lb.
  • Weight, In Running Order 564 lb.

  Performance

  • Engine Torque Testing Method J1349
  • Engine Torque ² 73 ft-lb
  • Engine Torque (rpm) 3,500
  • Lean Angle, Right (deg.) 27
  • Lean Angle, Left (deg.) 28
  • Fuel Economy Testing Method Estimated City/Hwy
  • Fuel Economy ⁵ 48 mpg

  Drivetrain

  • Primary Drive Chain, 38/57 ratio
  • Gear Ratios (overall) 1st 9.315
  • Gear Ratios (overall) 2nd 6.653
  • Gear Ratios (overall) 3rd 4.948
  • Gear Ratios (overall) 4th 4.102
  • Gear Ratios (overall) 5th 3.517

  Chassis

  • Wheels, Front Type ⁹ Black, 9-spoke
  • Wheels, Rear Type Black, 9-spoke
  • Brakes, Caliper Type Dual-piston front, Dual-piston rear

  Electric

  • Lights (as per country regulation), Indicator Lamps ⁸ High beam, neutral, low oil pressure, turn signals, engine diagnostics, low fuel warning, low battery, security system (if equipped), ABS (if equipped)
  • Gauges Handlebar-mounted electronic speedometer with odometer, time-of-day clock, dual tripmeter, low fuel warning light, low oil pressure light, engine diagnostics readout, LED indicator lights

  • 1. Recommended 91 octane or higher fuel (R+M)/2.
  • 2. Values shown are nominal. Performance may vary by country and region.
  • 3. Standard and optional fuel systems may vary by country.
  • 4. See motorcycle owner’s manual for complete details.
  • 5. Estimated from fuel economy tests on a sample motorcycle from the corresponding family conducted by Harley-Davidson under ideal laboratory conditions. Not all motorcycle models undergo fuel economy testing. Fuel economy and mileage may vary among motorcycle models within a family. Your mileage may vary depending on your personal riding habits, weather conditions, trip length, vehicle condition and vehicle configuration and other conditions. Break-in mileage may vary.
  • 6. Prices listed are the Manufacturer’s Suggested Retail Prices for base models. Options such as color are available at additional cost. Prices exclude tax, title, licensing, registration fees, destination charges, added accessories, and additional dealer charges, if any, and are subject to change. Harley-Davidson reimburses dealers for performing manufacturer-specified pre-delivery inspection and setup tasks. Dealer prices may vary.
  • 7. Measurement reflects 180 lb. (81.7 kg) operator weight.
  • 8. North America security system includes immobilizer; outside North America the security system includes immobilizer and siren.
  • 9. Standard and optional wheels may vary by country and region.





2019 Harley-Davidson Iron 1200 – Totalmotorcycle.com Canada Specifications/Technical Details

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
