2019 Kawasaki Z1000R ABS Guide

2019 Kawasaki Z1000R ABS

2019 Kawasaki Z1000R ABS 2019 Kawasaki Z1000R ABS 2019 Kawasaki Z1000R ABS 2019 Kawasaki Z1000R ABS

CALL OF THE WILD.

2019 Kawasaki Z1000R ABS:

The Z1000 was conceived in complete design freedom for a completely unique experience. Each part of the Z1000 was meticulously designed with a dual role in mind: individual functionality and realization of a condensed mass-forward image for a truly unique riding experience.

Sculpted bodywork brings the aggressive and unique sugomi inspired Z design to the next level, stripping off all unnecessary flourishes to boldly highlight brutal functionality.

Enhancing the riding impact, the new engine and chassis settings deliver a stiffer, more direct ride transforming the Z1000 into the market’s most
radical Supernaked.





2019 Kawasaki Z1000R ABS Totalmotorcycle.com Key Features

Metallic Spark Black / Pearl Storm Grey / Emerald Blazing Green







2019 Kawasaki Z1000R ABS Totalmotorcycle.com Features and Benefits

Idealised Riding Position
An idealised riding position sees the front lowered and the rear raised, creating a more aggressive posture. The more aggressive position matches the bike’s more direct throttle response and handling, putting riders in a position to fully capitalise on the Z1000’s sportier street riding potential.

Separate Function Fork – Big Piston (SFF-BP)
The more direct handling of the new Z1000 can be largely attributed to its new suspension. The new SFF-BP achieves both comfort and sport potential ideal for street riding. potential ideal for street riding. Combining the concepts of Showa SFF and BPF, the new fork features springs on both sides, with preload adjustability in the left tube and damping duties in the right tube.

Aluminium fat bar
Ideally suited to the Supernaked character, the wide-set fat bar facilitates rider control.The wide aluminium fat bar features a brushed finish and a black alumite1 coating.



Larger-volume fuel tank
New fuel tank design increases fuel capacity to 17 litres, offering a greater touring range.



Downdraft throttle bodies
In addition to contributing to performance, downdraft throttle bodies contribute to overall mass centralisation. Revised intake funnel length contributes to a stronger mid-range response.



Instrumentation
The Z1000’s compact instrument cluster is mounted directly to the handlebar, which added to design freedom and helped realise the compact headlamp cowl. Its low position creates an unobstructed view of the road ahead. The futuristic design of the LED tachometer and LCD screen reflects the sport potential of the new Z.



Pre-chamber and short silencers
Using an under-engine pre-chamber enables smaller-volume silencers, contributing to both mass centralisation and a more concentrated styling. New silencer end-cap design adds to sporty looks.



Embossed seat material
Seat is embossed with “Z” mark further distinguishing the bike from the standard model.



Mass Centralisation
The exhaust system (with large pre-chamber and short silencers), Horizontal Back-link rear suspension and the use of downdraft throttle bodies are the greatest contributors to mass centralisation. The Horizontal Back-link rear suspension arrangement frees up space taken up by the Uni-Trak suspension lower linkage, enabling a larger pre-chamber, which in turn allows the use of shorter mufflers and contributes to mass centralisation. The lightweight aluminium rear frame also contributes. The result is light, sharp handling.



Öhlins Rear Suspension
Complementing the enhanced braking performance of the Brembo brakes, high-quality Öhlins rear suspension offers both increased ride comfort and the pride in ownership that comes from the knowledge that your machine is equipped with top-shelf components.



Intoxicating Intake Howl
Designed specifically so that acceleration could be enjoyed aurally as well as physically, the carefully crafted auditory note of the intake is a key component of the street riding exhilaration offered by the Z1000.



Cool Air system
With the airbox nestled between the frame beams, intake air can be affected by engine heat. The Cool Air system routes cool air to the airbox from ducts at the front of the side fairings, minimising performance loss due to heated intake air. This should not be confused with Ram Air, where force-fed air becomes pressurised in the airbox.



Brembo Brake Components
To bring the already formidable braking performance of the Z1000 to the next level, high-spec brake components like those found on the Ninja H2R were implemented. The Brembo components featured are the best available for a massproduction model. The highprecision operation delivers brake force linearly, contributing to superb controllability.

Aluminium twin-tube frame
The highly rigid aluminium frame features a high degree of mass centralisation, creating a balance between sharp turning and firm handling. Lightweight and highly rigid, the frame uses the engine as a stressed member. The frame offers a firm, planted feeling, good stability and light, nimble turning. The frame is a 5-piece cast aluminium construction, consisting of steering stem, left and right main frames, and two cross pieces. The two main frame components have open C-shaped cross sections and were die-cast to ensure a smooth surface finish.

LED headlamp
The thin, compact headlamp cowl was positioned as low as possible, extending the line that starts from the top of the tank. This is first time for Kawasaki to use the reflector-less LED headlamp design. Using LED lamps allows the design to be thin, the shape contributing to the more intense glare of the new Z1000’s face, and the reflector-less design further enhances its predatory appearance. There are four long-life, low-energy LED bulbs: two low-beam (centre), two high-beam (outside). All four bulbs light up when the high-beams are on. A separate LED position lamp is located on the meter cover

Die-cast Mirrors
New mirrors have a sharper design that contributes to the aggressive image. Die-cast mirror stays contribute to a less plastic, higher quality feel of the cockpit.

LED taillight
New LED taillight design adds a futuristic touch to the bike’s rear

Sugomi Design
The Japanese word sugomi describes the intense aura or energy given off by a person or object of greatness and felt by the viewer. Someone, or something, possessing sugomi inspires awe, leaves an indelible impression, is daunting in stature or ability, and commands respect. In the new Z1000, sugomi is evident both in its fiercely intense design and the exhilarating performance it delivers, radiating as a palpable energy. Idealised dimensions (lower front, raised rear) and all-new tight-fitting bodywork capture the essence of a predator crouched and ready to pounce. The lean, muscular styling hints at the Z1000’s more direct, sporty street riding performance

Lightweight wheels
Supersport-style wheels are approximately 1.5 kg lighter, reducing unsprung weight and contributing to lighter handling.

1,043 cm3 liquid-cooled, 4-stroke In-line Four
Powerful engine pulls strongly from all rpm and does not let up before the redline. Adding to rider exhilaration, the engine delivers superb response, a strong mid-range hit and an intoxicating intake howl. More direct response thanks to new engine settings and shorter gearing adds to the Z1000’s sporty street riding potential.









2019 Kawasaki Z1000R ABS – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ USD
Canada MSRP Price: $14499 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU

NA











2019 Kawasaki Z1000R ABS – Totalmotorcycle.com Canada Specifications/Technical Details

Engine

Displacement1,043cc
Type4-stroke, In-Line Four
Bore and stroke77.0 x 56.0 mm
CoolingLiquid
Compression ratio11.8:1
Valve systemDOHC, 16 valves (4 valves per cylinder)
Fuel systemDigital fuel injection with four 38 mm Keihin with oval sub-throttles
IgnitionDigital
LubricationForced lubrication (wet sump)

Brakes

Front: typeDual semi-floating 310 mm Brembo discs
Front: calipersDual radial-mount, Brembo M50 monobloc, opposed 4-piston
Rear: typeSingle 250 mm petal disc
Rear: calipersSingle-piston caliper

Dimensions

Overall length2,045 mm
Overall width790mm
Overall height1,055 mm (41.5 in)
Wheelbase1,435 mm (56.5 in.)
Ground clearance125 mm (4.9 in.)
Seat height815 mm (32.1 in.)
Curb mass**220kg
Fuel capacity17 litres

Drivetrain

Transmission6-speed, return
Final driveSealed Chain
Primary reduction ratio1.627 (83/51)
Gear ratio: 1st2.600 (39/15)
Gear ratio: 2nd1.950 (39/20)
Gear ratio: 3rd1.600 (24/15)
Gear ratio: 4th1.389 (25/18)
Gear ratio: 5th1.238 (26/21)
Gear ratio: 6th1.107 (31/28)
Final reduction ratio2.867 (43/15)
ClutchWet multi-disc, manual

Frame

TypeAluminium twin-tube
Wheel travel: front120 mm (4.7 in.)
Tire: front120/70-ZR17
Wheel travel: rear131 mm
Tire: rear190/50-ZR17
Caster (rake)24.5°
Trail101 mm
Steering angle (left/right)29° / 29°

Performance

Maximum Power105 kW {143 PS} @ 10,000 rpm
Maximum Torque111 N.m {11.3 kgf.m} @ 7,300 rpm

Suspension

Suspension, front41 mm inverted fork with stepless compression and rebound damping and spring preload adjustability
Suspension, rearHorizontal Back-link, gas-charged, with stepless rebound damping and spring preload adjustability

Details

Warranty12 months warranty





* The Manufacturer’s Suggested Retail Price does not include freight, pre-delivery inspection or applicable taxes. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice. The amount indicated as “Your price” may include an optional instant Mega Cash credit that is deducted from the manufacturer’s suggested retail price before taxes. This promotion is time limited and certain conditions will apply. See your dealer for complete details. Offer not available on financed purchases and cannot be combined with any other special offers. The final price is at the discretion of the dealer. Prices and Specifications are subject to change without prior notice.

** Includes all necessary materials and fluids to operate correctly, full tank of fuel (more than 90% of capacity) and tool kit (if supplied)

‡ Power / Torque figures measured at the crankshaft.

The specifications mentioned here apply to and have been achieved by production models under standard operating conditions. We intend only to give a fair description of the vehicle and its performance capabilities but these specifications may not apply to every machine supplied for sale. Kawasaki Heavy Industries, Ltd. reserves the right to alter specifications without prior notice. Equipment illustrated and specifications may vary to meet individual markets. Available colours may vary by market.







2019 Kawasaki Z1000R ABS – Totalmotorcycle.com European Specifications/Technical Details

Engine

Engine type

Liquid-cooled, 4-stroke In-Line Four

Displacement

1,043 cm³

Bore x stroke

77 x 56 mm

Compression ratio

11.8:1

Valve system

DOHC, 16 valves

Fuel system

Fuel injection: Ø38 mm x 4 (Keihin) with oval sub-throttles

Ignition

Digital

Starting System

Electric

Lubrication

Forced lubrication, wet sump

Performance & Transmission

Maximum power

104.5 kW {142 PS} / 10,000 rpm

Fuel consumption

5.8 l/100 km

CO2 emission

151 g/km

Maximum torque

111 N•m {11.3 kgf•m} / 7,300 rpm

Transmission

6-speed

Final drive

Sealed chain

Primary Reduction Ratio

1.627 (83/51)

Gear Ratios 1st

2.600 (39/15)

Gear Ratios 2nd

1.950 (39/20)

Gear Ratios 3rd

1.600 (24/15)

Gear Ratios 4th

1.389 (25/18)

Gear Ratios 5th

1.238 (26/21)

Gear Ratios 6th

1.107 (31/28)

Final reduction ratio

2.867 (43/15)

Clutch

Wet multi-disc, manual

Brakes & Suspension

Brakes, front

Dual semi-floating 310 mm Brembo discs. Caliper: Dual radial-mount, Brembo M50 monobloc, opposed 4-piston.

Brakes, rear

Single 250 mm disc. Caliper: Single-piston

Suspension, front

41 mm inverted fork with top-out springs, stepless compression and rebound damping and spring preload adjustability

Suspension, rear

Horizontal Back-link, Öhlins S46DR1S gas-charged shock with rebound damping and remote preload adjustability.

Frame & Dimensions

Frame type

Twin-tube, aluminium

Trail

101 mm

Wheel travel front

120 mm

Wheel travel rear

131 mm

Tyre, front

120/70ZR17M/C (58W)

Tyre, rear

190/50ZR17M/C (73W)

Steering angle, left / right

29o / 29o

L x W x H

2,045 x 790 x 1,055 mm

Wheelbase

1,435 mm

Ground clearance

125 mm

Fuel capacity

17 litres

Seat height

815 mm

Curb mass

221 kg









2019 Kawasaki Z1000R ABS – Totalmotorcycle.com Australian Specifications/Technical Details

TBA









Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
