2019 Suzuki DR-Z400S Guide

2019 Suzuki DR-Z400S

2019 Suzuki DR-Z400S 2019 Suzuki DR-Z400S

STAND OUT AND BREAK NEW GROUND.

2019 Suzuki DR-Z400S:

The 2019 DR-Z400S is the latest version of the motorcycle that’s the foundation of the modern DualSport movement. Starting with the DR350S and then again with the DR-Z400S, Suzuki made fun, reliable, and capable motorcycles available to anyone who’s ready to take a ride down their favorite off-road trail or ribbon of asphalt.

Riders will be impressed with the amount of torque coming from the 398cc, liquid-cooled power plant, as well as the crisp handling from the adjustable suspension. This ultra-reliable bike is completely street legal, with an electric start and easy-to-read instrument cluster. The solid white bodywork with contrasting blue and black graphics make the bike stand out on the road, on the trail, or even when parked.

Whether you’re on the highway or on a twisty forest path, the Suzuki DR-Z400S can’t be beat.

The DR-Z400S is ideal for taking a ride down your favorite off-road trail. You’ll be impressed with the amount of torque coming from the 398cc liquid-cooled powerplant as well as the crisp handling from the adjustable suspension. This bike is completely street legal with an electric start and easy-to-read instrument cluster. Whether you’re on the highway or in a tight twisty forest trail, the Suzuki DR-Z400S can’t be beat.

Like the off road DR-Z400E it is based on, the DR-Z400S breaks new ground in off road/dual-sport riding by offering the broad, tractable power and torque of an advanced and a compact, light and agile chassis. Fully street-legal, the nimble handling and excellent 4-stroke engine for tackling runs also make the DR-Z400S a downright pleasure to ride on highway and city adventures.









2019 Suzuki DR-Z400S Totalmotorcycle.com Key Features

A pouch on the rear fender carries the tool kit and owner’s manual.

Special design mirrors rotate to avoid damage in case of impact.

Genuine Suzuki Accessories include a low-profile seat, cargo rack, handguard set, and more.

12-month limited warranty. Longer coverage periods with other benefits are available through Suzuki Extended Protection (SEP).









2019 Suzuki DR-Z400S Totalmotorcycle.com Features and Benefits

A compact design, 398cc, DOHC, liquid-cooled, dry-sump engine produces strong low-rpm power. Its compact, four-valve cylinder head features large 36mm intake valves and 29mm exhaust valves to help produce broad, tractable power and torque that’s ready for any terrain.

Suzuki Composite Electrochemical Materials (SCEM) cylinder is durable and lightweight and provides superior heat transfer.

Digitally-mapped DC-CDI system monitors throttle position/engine rpm and adjusts ignition timing to maintain efficient combustion.

Forged aluminum piston is 10 percent lighter than a cast piston and receives additional oil-cooling through a crankcase oil jet.

A refined Mikuni 36mm carburetor, with new deceleration enricher circuit, is fed by a six-liter airbox to provide smooth throttle response when accelerating or engine braking.

The left side body cover has quick-release fasteners for easy access to the air filter.

The addition of a PAIR (air supply) system to the exhaust helps the motorcycle achieve emissions compliance without affecting performance.

Magnesium-alloy clutch, magneto, and head covers contribute to the bike’s low weight.

Thermostatically-controlled cooling fan mounted to the left radiator helps maintain consistent operating temperature.



Transmission Features

Compact, five-speed transmission utilizes a cable-operated clutch with a separate magnesium outer cover for simplified clutch maintenance.

Low-maintenance, long-life sealed O-ring type drive chain produces minimal sounds when riding.



Chassis Features

A narrow frame combines thin chrome-moly steel tubes for exceptional torsional rigidity with minimal weight. The backbone tube, front down tube, and steering head gussets form the dry-sump engine oil tank. A bolt-on aluminum sub-frame helps reduce weight and simplify maintenance.

Long travel (11.3-inch), 49mm cartridge-style fork has protective rubber boots plus adjustable compression/rebound damping and adjustable spring preload for smooth performance on all types of on- and off-road terrain.

Rear shock absorber features 11.6 inches of travel, compression damping/preload adjustments, and connects to a lightweight aluminum swingarm through a progressive linkage system.

Spoke-style 21-inch front and 18-inch rear wheels with aluminum rims are fitted with Dunlop D208 dual-purpose tires. The wheels are sized perfectly to accept popular dual sport tires.

Sure stopping power is supplied by a 250mm front disc with a dual-piston caliper and a 220mm rear disc brake with a single-piston caliper.



Electrical Features

Electric start system provides convenient operation and features a lightweight starter motor and a compact, 6.5-amp, maintenance-free battery.

Compact digital instrument cluster includes speedometer, odometer, and twin-trip meters with addition/subtraction capability, clock, timer, and stopwatch functions.

On-road legal lighting includes bright 60/55-watt H4 halogen headlight, compact tail/stoplight, lightweight, rubber-mounted turn signals and horn.







2019 Suzuki DR-Z400S – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $6749 USD
Canada MSRP Price: $7249 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU
Engine
Engine 398cc, 4-stroke, liquid-cooled, single cylinder, DOHC
Bore x Stroke 90.0 mm x 62.6 mm (3.54 in x 2.44 in)
Compression Ratio 11.3:1
Fuel System Mikuni BSR36, single carburetor
Starter Electric
Lubrication Semi-dry sump
Drive Train
Clutch Wet multi-plate
Transmission 5-speed constant mesh
Final Drive Chain, RK520KZ0, 112 links
Chassis
Suspension Front Telescopic, coil spring, oil damped, adjustable damping force
Suspension Rear Link type, coil spring, oil damped, adjustable spring preload and damping force
Brakes Front Disc brake, single floating rotor
Brakes Rear Disc brake, single rotor
Tires Front 80/100-21 M/C 51P, tube type
Tires Rear 120/90-18 M/C 65P, tube type
Fuel Tank Capacity 10.0 L (2.6 US gal.), 9.5 L (2.5 US gal.) CA model
Color Solid Special White No. 2
Electrical
Ignition Electronic ignition (CDI)
Spark Plug NGK CR8E or DENSO U24ESR-N
Headlight 12V 60/55W (H4)
Tail Light 12V 21/5W
Dimensions
Overall Length 2310 mm (90.9 in.)
Overall Width 875 mm (34.4 in.)
Overall Height 1230 mm (48.4 in.)
Wheelbase 1485 mm (58.5 in.)
Ground Clearance 300 mm (11.8 in.)
Seat Height 935 mm (36.8 in.)
Curb Weight 144 kg (317 lb.)
Warranty
Warranty 12-month unlimited mileage limited warranty.*
Extensions *Longer coverage periods with other benefits available through Suzuki Extended Protection (SEP).





2019 Suzuki DR-Z400S – Totalmotorcycle.com Canada Specifications/Technical Details

Engine
Type 4-stroke, liquid-cooled, single cylinder, DOHC
Displacement 398cc
Bore x Stroke 90.0mm x 62.6mm (3.5in x2.5in)
Compression Ratio 11.3 : 1
Transmission 5-speed constant mesh
Chassis
Overall Length 2310 mm (90.9 in)
Overall Width 875 mm (34.4 in)
Overall Height 1230 mm (48.4 in)
Wheelbase 1485 mm (58.5 in)
Ground Clearance 300 mm (11.8 in)
Seat Height 935 mm (36.8 in)
Curb Mass 144 kg (317 lbs)
Suspension Front Telescopic, coil Spring, oil damped
Suspension Rear Link type, coil spring, oil damped
Brakes Front Disc
Brakes Rear Disc
Tires Front 80/100-21 M/C 51P, tube type
Tires Rear 120/90-18 M/C 65P, tube type
Ignition Type Electronic ignition (CDI)
Fuel Tank 10.0L (2.6 US gal)
Warranty
Standard Warranty 12 Month unlimited mileage limited warranty









2019 Suzuki DR-Z400S – Totalmotorcycle.com European Specifications/Technical Details









2019 Suzuki DR-Z400S – Totalmotorcycle.com Australian Specifications/Technical Details







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
